ABB EMERGI-LITE Serenga Manual

RECESSED LUMINAIRES
—
agnereS
INSTRUCTION LEAFLET
EN
05
—
Contacts
Art. nr. 69458/30 Rev G 14.08.2018
We reserve the right to make technical changes or modify the contents of this document
without prior notice. With regard to purchase orders, the agreed particulars shall prevail.
ABB AG does not accept any responsibility whatsoever for potential errors or possible
lack of information in this document.
We reserve all rights in this document and in the subject matter and illustrations contained
therein. Any reproduction, disclosure to third parties or utilization of its contents – in whole
or in parts – is forbidden without prior written consent of ABB AG.
Copyright© 2017 ABB. All rights reserved.
Technical Specifications Recessed Surface Mounted
Power supply Self-Contained: 230-240V 50Hz Self-Contained: 230-240V 50Hz
Slave: 220-240V AC / 176-275V DC Slave: 220-240V AC / 176-275V DC
Autonomy 3 hours 3 hours
Commissioning time 60 hours 60 hours
Ambient temperature Self-Contained: +5°C ... +35°C Slave: 0°C ... +40°C Self-Contained: +5°C ... +35°C Slave: 0°C ... +40°C
Protection class II II
Degree of protection IP42/IP20 (below ceiling/above ceiling) IP54
Battery NiMH 4,8V - 2,0Ah (Self Contained) NiMH 4,8V - 2,0Ah (Self Contained)
Lightsource 2 LED’s (2 x 0, 85W = 1,9W) 2 LED’s (2 x 0, 85W = 1,9W)
Compliance
ENGLISH
Carefully read this instruction leaflet before installing or using the luminaire. This leaflet
provides important information about the correct installation, use, maintenance and dis-
posal of this product.
Please observe the following guidelines:
1. The luminaire should only be installed by qualified personnel and installation must be
in accordance with European installation requirements HD 60364 and additional
local regulations.
2. This product may not be modified in any way what so ever or used for a purpose or in an
environment other than for which it is designed. Failling to observe these guidelines
will invalidate the warranty and the CE-compliance of this product.
3. The luminaire is suitable for indoors use only.
4. Before installing the luminaire, the supply must be isolated.
5. The lightsource in this luminare is not replaceable; when the luminaire reaches end of
life the whole luminaire shall be replaced.
INSTALLING AND CONNECTING
The luminaire should be connected to the voltage equivalent to that indicated on the
type label. The surface mounted luminaire is fitted with a terminal block suitable
for loop-in-loop-out connection. For further information on the different connection
possibilities, see the instructions in this instruction leaflet.
SELF-TESTING
All self contained versions of this luminaire are equipped with an automatic self-testing
system that continuously monitors battery operation, the light source(s) and the electronics.
The amber LED’s will indicate when one of these components is not working properly.
To prevent all luminares to start the test sequence at the same time, an odd and even function
is available. All even luminares start the test sequence as normal; all odd luminares start
the test sequence 24 hours later. The luminaire can also be tested manually with the
test button. When pushing the button previous errors will be “reset” and the battery will
supply the LED’s. After 5 seconds an eventual error will be displayed. The test schedule
can be reset by pushing the test button for 10 seconds. For more detailed information on
the different testing schedule and meaning of the indications, see further in this
instruction leaflet.
LUMINAIRES POWERED FROM CENTRAL BATTERY SYSTEMS
These luminaires are not equipped with their own integrated testing function. They are
tested by means of the central battery system to which the luminaire is connected.
CT-NAVEO-LUMINARES
Central test luminaires (CT-Naveo / CIS) are supplied under a separate part code and are
fitted with a test system PCB (COM-Box).
SLAVE LUMINAIRES WITH LTC
Slave type luminares for Emex / Sentara central emergency power systems are supplied
under a separate part code and are fitted with an LTC PCB (COM-Box).
BATTERY
A fault will occur when test results for duration no longer meets the
requirements indicated for the luminaire. The batteries must then be replaced.
Please see the label on the batteries for the type required. Given the technical
life of the battery, it is recommended to replace them after 4 years. When the
battery is replaced and the mains supply restored, the amber LED indicating
a battery failure will disappear after a successful duration test. Used batteries
must be replaced or disposed of as household chemical waste.
PLEASE NOTE!
Constant voltage is required and the batteries must be sufficiently charged for emergency
lighting to function properly. Failure to observe this requirement can damage the
batteries, the lightsource or in worst-case scenario, the luminaires electronics.
INSPECTION AND MAINTENANCE
Emergi-lite strongly advises annual inspection of your emergency lighting installation.
®
ABB Emergi-Lite Ltd
Bruntclie Lane
Morley, Leeds
West Yorkshire LS27 9LL
United Kingdom
Sales [phone]
Technical [phone]
Email: [e-mail]
www.emergi-lite.co.uk
ABB United Arab Emirates
P.O. Box 11070
Dubai,
United Arab Emirates
Tel: [phone]
Fax: [phone]
E-mail: [email protected]
www.abb.com/lowvoltage
EN 60598-1, EN 60598-2.22, VDE 0711, IEC 62034, EN 62386-202 EN 60598-1, EN 60598-2.22, VDE 0711, IEC 62034, EN 62386-202
KM 655958
DALI LUMINAIRES
Self-Contained luminaires fitted with a DALI communication module are supplied
under a separate article number and have a configurable autotest (not equal to self test).
SURFACE MOUNTED LUMINAIRES

Only self-contained luminaires
COMMISSIONING
60h60h
SELFTEST SCHEDULE
After 60 hours the luminaire is fully commissioned
Connect mains
230 - 240V / 50Hz
Wait
100%0-30%
Functional test
Every 7 days - 1 minute.
Installation test / Inbetriebnahme / Test d’installation
Duration test after 36 hours, 3 hours.
1
2
Manual testing
Push test button < 1 sec. to set luminaire in test mode (5 sec. test).
Setup even or odd testing schedule
Push test button > 3 sec. to enter the setup mode for even or odd testing schedule.
If LED’s flash synchronously the luminare is set to even schedule.
If LED’s flash alternately the luminare is set to odd schedule. Toggle between
even and odd by pushing the test button.
Reset luminaire
Push test button > 10 sec. to reset test schedule.
Autonomy test
Every 26 weeks, 3 hours.
3
INSTALLATIONDIMENSIONS
b
l
i
n
k
EXPLANATIONS
Maintained Non-maintained Switched maintained
Emergencymode
In test
OK
Failure
b
l
i
n
k
b
l
i
n
k
54
SETUP Self Contained Slave Surface Mounted
SPECIAL APPLICATIONS
!
CB FE
5 lx
1
2
1
2
1
2
3
POWER
SUPPLY
Sheathing
Communication
Wiring area
max. Ø 13
max. Ø 10 (2X)
max. 3mm
Slave
Non-maintained Switched maintained Maintained
Self-contained Slave
4
5
Max. 3 Nm
Max. 10A Max. 10A Max. 10A Max. 10A
LTC
SWL USL
L N N L
D C B A
N 1L 2L N 1L 2L N 1L 2L N 1L 2L
120
120
Max. Ø 4mm
max. Ø 13 max. Ø 10
150
150
12652 35 6
38
216
150
35 6Ø100 95
95
58
78
RISK GROUP 2
CAUTION Possibly hazardous optical radiation
emitted from this product. Do not stare at operating lamp.
May be harmful to the eyes.
SR2.. G1
Corridor - Wall mounted
SR2.. LENS2
Object lighting
SR2.. BC1
Corridor high ceiling
SR2.. EF1
Open area high ceiling
< 25 cm <
8- 12m 4 - 8m 8- 12m 4 - 8m
2- 4m
2- 4m
Cover
Battery
Base +
Electronics
Cable Cover
Com-box
PCB (option)
Base
Cable entry cover
Battery
Com-box
(option)
Geartray +
Electronics
INSTALLATION
A
B
C
D
Battery
N
2L
1L
N
2L
1L
Max. 10 A Max. 10 AMax. 10 A
N
2L
1L
Connection Spot
Option COM - MD, DALI
D
Option Infra Red
L
CIS/BUS/MD
+ --
FLX
N
K
4
K
3
K
1
Non-maintained Maintained Switched maintained
1
Connection mains
3
4
min. 110 mm
Ø 68 mm
Ø 68 mm
Ø 68 mm Ø 70 mm
2
1
Orientation
push
insert
Option:
Ceiling adapter
5-30 mm
15-30 mm
5-15 mm
min. 45 mm
Ø 68 mm
3
A
B
C
D
DALI
DA DA
!
Do not connect Mains power to the A-B-C-D
terminals
2
Connection spot
Slave
Self Contained
Self- contained
CT-NAVEO/CIS
–+
D C B A
DALI
DA DA
D C B A
!
Do not connect Mains power to
the A-B-C-D terminals
