ABL eMH3 Quick guide

R 20210617
ABL SURSUM
Bayerische Elektrozubehör GmbH & Co. KG
Albert-Büttner-Straße 11
D-91207 Lauf / Pegnitz
Tel. [phone]
Fax [phone]
[email protected]
www.ablmobility.de
CONFIGURATION WITH
NEW CONFIGURATION SOFTWARE
GROUP CONFIGURATION eMH3 TWIN
Follow preconditions
Press [Continue] button
Switch on last extender charging station
Wait 15 seconds
Press [Automatic Configuration] button
Extender charging station is displayed in delivery state (3/4)
Switch on next extender charging station
Wait 15 seconds
Press [Automatic Configuration] button
Extender charging station is displayed in delivery state (3/4)
Switch on controller charging station (only RCCBs!)
1
2
3
4
5
6
8
9
10
11
7
12
13
Extender charging station is shifted to the next available
address values (15/16)
Extender charging station is shifted to the next available address
values (13/14)
1 - 2

R 20210617
ABL SURSUM
Bayerische Elektrozubehör GmbH & Co. KG
Albert-Büttner-Straße 11
D-91207 Lauf / Pegnitz
Tel. [phone]
Fax [phone]
[email protected]
www.ablmobility.de
Press [Automatic Configuration] button
Press [Continue] button
Charging stations are shifted one by one to the front
Address configuration is completed, additional settings possible
14
17
18
19
20
15
16 Controller charging station is displayed in delivery state (1/2),
RFID address value stays empty
Controller charging station is shifted to the next available
address values (11/12)
CONFIGURATION WITH
NEW CONFIGURATION SOFTWARE
GROUP CONFIGURATION eMH3 TWIN
Wait 15 seconds
2 - 2
