ACME LED?7TC User manual

15-
Innovation, Quality, Performance
LED PANEL
LED-7TC
UserManual
Please read the instructions carefully before use

1-
TABLE OF CONTENTS
1. Safety Instructions
2. Technical Specifications
3. Installation
4. How to set the unit
5. How to control the fixture
6. DMX512 Configuration
7. DMX512 Connections
8. Troubleshooting
9. Fixture Cleaning
14-
9. Fixture Cleaning
The cleaning of internal must be carried out periodically to optimize light output. Cleaning
frequency depends on the environment in which the fixture operates: damp, smoky or
particularly dirty surrounding can cause greater accumulation of dirt on the fixture’s optics.
yClean with soft cloth using normal glass cleaning fluid.
yAlways dry the parts carefully.
yClean the external optics at least every 20 days. Clean the internal optics at least every
30/60 days.
EC Declaration of Conformity
We declare that our products (lighting equipments) comply with the following
specification and bears CE mark in accordance with the provision of the
Electromagnetic Compatibility (EMC) Directive 89/336/EEC.
EN55103-1:199601-2; EN55103-2:1996;
EN61000-3-2:2000+A2:2005;
EN61000-3-3:1995+A1:2001+A2:2005.
&
Harmonized Standard
EN 60598-1: 2004
IEC 60598-1:2003+ corrigendum 2004
Part 1:General requirements and test
Following the provisions of the low voltage directive 73/23/EEC and
93/68/EEC

13-
8. Troubleshooting
Following are a few common problems that may occur during operation. Here are some
suggestions for easy troubleshooting:
A. The fixture does not work, no light
1. Check the connection of power and main fuse.
2. Measure the mains voltage on the main connector.
B. Not responding to DMX controller
1. DMX LED should be on. If not, check DMX connectors, cables to see if link properly.
2. If the DMX LED is on and no response to the channel, check the address settings and
DMX polarity.
3. If you have intermittent DMX signal problems, check the pins on connectors or on PCB
of the fixture or the previous one.
4. Try to use another DMX controller.
5. Check if the DMX cables run near or run alongside to high voltage cables that may
cause damage or interference to DMX interface circuit.
C. Some fixtures don’t respond to the easy controller
1. You may have a break in the DMX cabling. Check the LED for the response of the
master/ slave mode signal.
2. Wrong DMX address in the fixture. Set the proper address.
D. No response to the sound
1. Make sure the fixture does not receive DMX signal.
2. Check microphone to see if it is good by tapping the microphone.
E. One of the channels is not working well
1. The stepper motor might be damaged or the cable connected to the PCB is broken.
2. The motor’s drive IC on the PCB might be out of condition.
2-
1. Safety Introductions
WARNING
yPlease keep this User Manual for future consultation. If you sell the fixture to another
user, be sure that they also receive this instruction booklet.
yUnpack and check carefully there is no transportation damage before using the fixture.
yBefore operating, ensure that the voltage and frequency of power supply match the
power requirements of the fixture.
yIt’s important to ground the yellow/green conductor to earth in order to avoid electric
shock.
yDisconnect main power before servicing and maintenance.
yUse safety chain when fixes this fixture. Don’t handle the fixture by taking its head only,
but always by taking its base.
yMaximum ambient temperature is Ta : 40℃. Don’t operate it where the temperature is
higher than this.
yIn the event of serious operating problem, stop using the fixture immediately. Never try
to repair the fixture by yourself. Repairs carried out by unskilled people can lead to
damage or malfunction. Please contact the nearest authorized technical assistance
center. Always use the same type spare parts.
yDo not connect the device to any dimmer pack.
yDo not touch any wire during operation and there might be a hazard of electric shock.
yTo prevent or reduce the risk of electrical shock or fire, do not expose the fixture to rain
or moisture.
yThe housing must be replaced if they are visibly damaged.
yDo not look directly at the LED light beam while the fixture is on.
Warning
Please read the instructions carefully which includes important
information about the installation, operation and maintenance.
If using a 230Vac 50Hz power supply, do not connect in series more than
20 units, use another mains supply for the next 20 units.
If using a 120Vac 60Hz power supply, do not connect in series more than
10 units, use another mains supply for next 10 units.

3-
yTo prevent or reduce the risk of electrical shock or fire, do not expose the unit to rain or
moisture.
yDo not open the unit within five minutes after switching off.
yThe housing, the lenses, or the ultraviolet filter must be replaced if they are visibly
damaged.
Caution
There are no user serviceable parts inside the fixture. Do not open the housing or attempt
any repairs yourself. In the unlikely situation, your unit may require service, please contact
your nearest dealer.
2. Technical Specifications
•DMX channel: 4 channel modes
•LED: 7 x 3W RGB(Tri-color) LED
•Power supply
Input Voltage: AC 100V-240V~50/60Hz
•Power consumption: 28.5W
•Fuse: T 6.3A
•Dimension: 212 x 80 x 212 mm
•Weight: 2.5kgs
3. Installation
The unit should be mounted via its screw holes on the bracket. Always ensure that the unit is
firmly fixed to avoid vibration and slipping while operating. Always ensure that the structure
to which you are attaching the unit is secure and is able to support a weight of 10 times of
the unit’s weight. Also always use a safety cable that can hold 12 times of the weight of the
unit when installing the fixture.
The equipment must be fixed by professionals. And it must be fixed at a place where is out
of the touch of people and has no one pass by or under it.
12-
7. DMX512 Connections
The DMX512 is widely used in intelligent lighting control, with a maximum of 512 channels.
1. If you using a controller with 5 pins DMX output, you need to use a 5 to 3 pin
adapter-cable.
2. Connect the fixture together in a “daisy chain” by XLR plug cable from the output
of the fixture to the input of the next fixture. The cable cannot be branched or
split to a “Y” cable. Inadequate or damaged cables, soldered joints or corroded
connectors can easily distort the signal and shut down the system
3. The DMX output and input connectors are pass-through to maintain the DMX
circuit when one of the units’ power is disconnected.
4. At last fixture, the DMX cable has to be terminated with a terminator to reduce
signal errors. Solder a 120-ohm 1/4W resistor between pin 2(DMX-) and pin
3(DMX+) into a 3-pin XLR-plug and plug it in the DMX-output of the last fixture.
5. Each lighting fixture needs to have an address set to receive the data sent by
the controller. The address number is between 0-511 (usually 0 & 1 are equal to
1).
6. 3 pin XLR connectors are more popular than 5 pin XLR.
3 pin XLR: Pin1: GND, Pin2: Negative signal (-), Pin3: Positive signal (+)
5 pin XLR: Pin1: GND, Pin2: Negative signal (-), Pin3: Positive signal (+)
Pin4/5:NotUsed.

11-
Blackout To blackout all the fixture
Function Strobe
1. Synchronous strobe
in white color
2. The same color chase
3. Different color strobe
Select Color
Color 1-16 or
manual setting
color
Select show
Show 1-12
Select Chase
Chase 1-16 or fade
Mode Sound 1
(LED OFF) Manual (LED ON) Sound 2 (LED slow blinking) Auto (LED fast blinking)
6. DMX512 Configuration
4-
4. How To Set The Unit
4.1 Control Panel
○
1Display: To show the various menus and the selected functions
LED:
○
2DMX On DMX input present
○ 3 MASTER On Master Mode
○ 4 SLAVE On Slave Mode
○ 5 SOUND Flashing Sound activation
Button: ○
6 MENU To select the programming functions
○
7DOWN To go backward in the selected functions
○
8UP To go forward in the selected functions
○
9ENTER To confirm the selected functions
○
10Microphone: Receive music for the sound active.
○
11 Only for remote control: By connect to the CA-8 or CA-9 RTX to control the unit for
Stand by, Function and Mode function.
○
12DMX output: For DMX512 link, use 3/5-pin XLR plug cable to link the next unit.
○
13DMX input: For DMX512 link, use 3/5-pin XLR plug cable to input DMX signal.
○
14Mains input: Connect to supply mains power.
○
15Mains output: Connect to supply mains power for the next unit.

5-
4.2 Main Function
To select any of the given functions, press the MENU button up to the required one is shown
on the display. Select the function by ENTER button and the display will blink. Use DOWN
and UP button to change the mode. Once the required mode has been selected, press the
ENTER button to setup or it will automatically return to the main functions without any
change after idling 8 seconds. To go back to the functions without any change press the
MENU button. The main functions are shown below:
10-
Software version
Press the MENU button up to when the is blinking on the display. Pressing ENTER
button and the display will show the version of software of the unit. To go back to the
functions press the MENU button again.
5. How to control the fixture
There are three ways to control the fixture
A. Universal DMX controller
B. Master/Slave operation
C. Easy controller (by CA-8)
A. Universal DMX controller
The fixture can be set the DMX address remotely by universal DMX controller. First, you
need to programming two scenes into a chase, and then link the fixtures to the universal
DMX controller. When you run the chase, all the fixtures of the chain will be set the series
DMX address automatically. The fixture uses four channels. Please refer to the following
diagram to set the address for the first four units.
B. Master/Slave operation
The fixture will allow you to link 16 fixtures together and operate without a controller. In
Master/Slave mode, the first fixture will control the others to give an automatic, sound
activated, synchronized light show. This function is good when you want an instant show.
The first fixture it’s DMX input cable will have nothing connect it, and the other fixtures will
be set in slave mode automatically. Their DMX input cables connect the last fixture DMX
output cable (daisy chain). Any fixture can act as a Master or as a Slave
C. Easy Controller (by CA-8)
The easy remote control is used only in master/slave mode. There is a
terminator for connect the easy controller inside the fixture. By connecting the
cable into DMX IN waterproof cable entry gland to the CA-8 terminator of the
first fixture, you will find that the remote control on the first fixture will control all
the other fixtures for Stand by, Function and Mode functions.

9-
Led Display
Press the MENU button up to when the is shown on the display. Pressing ENTER
button and the display will blink. Use DOWN and UP button to select the (Led on)
or (Led off) mode. Once the mode has been selected, press the ENTER button to
setup or automatically return to the main functions without any change after 8 seconds. To
go back to the functions without any change press the MENU button again.
Display Inversion
It is good for you to install the unit on the floor or under ceiling. Press the MENU button up to
when the is shown on the display. Pressing ENTER button and the display will blink.
Use DOWN and UP button to select the (display inversion) or (display
normal). Once select, press the ENTER button to setup or automatically return to the main
functions without any change after 8 seconds. To go back to the functions without any
change press the MENU button again.
Fixture Temperature
Press the MENU button up to when the is blinking on the display. Pressing ENTER
button and the display will show the temperature of the unit. To go back to the functions press
the MENU button again.
White balance
Press the MENU button up to when the is shown on the display. Pressing ENTER
button and the display will blink. Use DOWN and UP button to select the (red) or
(green) or (blue), press ENTER button to confirm, then use DOWN and
UP button to adjust the value (125-255) and press ENTER button to store, automatically
return to the main functions without any change after 8 seconds. To go back to the functions
without any change press the MENU button again.
Fixture Hours
Press the MENU button up to when the is blinking on the display. Pressing ENTER
button and the display will show the number of working hours of the unit. To go back to the
functions press the MENU button again.
6-

7-
DMX 512 Address Setting
Press the MENU button up to when the is shown on the display. Press ENTER
button and the display will blink. Use DOWN and UP button to change the DMX512 address.
Once selected, press the ENTER button to store or automatically return to the main
functions without any changes after 8 seconds. To go back to the functions without any
change press the MENU button again.
Channel mode
Press the MENU button up to when the is shown on the display. Pressing the
ENTER button and the display will blink. Use the DOWN and UP button to select the
(channel 1) or (channel 2) or (channel 3) or (channel 4)
mode. Once the mode has been selected, press the ENTER button to setup or automatically
return to the main functions without any change after 8 seconds. To go back to the functions
without any change press the MENU button again.
ShowMode
Press the MENU button up to when the is shown on the display. Pressing ENTER
button and the display will blink. Use DOWN and UP button to select the (auto
show) or (show 1) or (show 2) or … (show 12). Once the show
has been selected, press the ENTER button to confirm, if you select (show 1) or
(show 2) or … (show 12), you can press DOWN and UP button to select
(slowest) or …(fastest), press ENTER button to store or automatically
return to the main functions without any change after 8 seconds. To go back to the functions
without any change press the MENU button again.
Chase Mode
Press the MENU button up to when the is shown on the display. Pressing ENTER
button and the display will blink. Use DOWN and UP button to select the (chase 1)
or … or (chase 16) or (fade). Once the chase has been selected, press
the ENTER button to confirm, then press DOWN and UP button to select (slowest)
or …(fastest), press ENTER button to store or automatically return to the main
functions without any change after 8 seconds. To go back to the functions without any
change press the MENU button again.
8-
Slave Mode
Press the MENU button up to when the is shown on the display. Pressing ENTER
button and the display will blink. Use DOWN and UP button to select the (Mater) or
(normal) or … or (16 light show) mode. Once the mode has been selected,
press the ENTER button to setup or automatically return to the main functions without any
change after 8 seconds. To go back to the functions without any change press the MENU
button again.
Sound control
Press the MENU button up to when the is shown on the display. Pressing ENTER
button and the display will blink. Use DOWN and UP button to select the (sound
control on) or (sound control off). Once the mode has been selected, press the
ENTER button to setup or automatically return to the main functions without any change
after 8 seconds. To go back to the functions without any change press the MENU button
again.
Blackout Mode
Press the MENU button up to when the is shown on the display. Pressing ENTER
button and the display will blink. Use DOWN and UP button to select the (no
blackout) or (yes blackout) mode. Once the mode has been selected, press the
ENTER button to setup or automatically return to the main functions without any change
after 8 seconds. To go back to the functions without any change press the MENU button
again.
Color Mode
Press the MENU button up to when the is shown on the display. Pressing ENTER
button and the display will blink. Use DOWN and UP button to select the (color 1)
or … or (show 16) or (manual setting). Once select, press the ENTER
button to confirm, if you select (manual setting), you can press DOWN and UP
button to select (red) or (green) or (blue), press ENTER button to
confirm, then use DOWN and UP button to adjust the value (0-255) and press ENTER
button to store, automatically return to the main functions without any change after 8
seconds. To go back to the functions without any change press the MENU button again.
