The HD67517-B2 is a converter from Modbus slave to DMX and vice versa.
They allows the following characteristics:
Triple isolation between Modbus - ower Supply, Modbus - DMX, ower Supply - DMX.
Two-directional information between Modbus bus and DMX bus;
Mountable on 35mm Rail DIN;
Wide power supply input range: 8…24V AC or 12…35V DC;
Wide temperature range: -40°C / 85°C [-40°F / +185°F].
CONFIGUR TION:
You need Compositor SW67517 software on your C in order to perform the following:
Define the parameter of Modbus line;
Define the parameter of DMX line;
Update the device.

Industrial Electronic Devices
ADFweb.com S.r.l.
User Manual
DMX / Modbus Slave
Document code: MN67517_ENG Revision 1.000 age 7 of 24
POWER SUPPLY:
The devices can be powered at 8…24V AC and 12…35V DC. For more details see the two tables below.
V C
VDC
Vmin Vmax Vmin Vmax
8V 24V 12V 35V
Consumption at 24V DC:
Device Consumption [W/V ]
HD67517-B2 3.5
HD67517
-
B2
Caution: Not reverse the polarity power

Industrial Electronic Devices
ADFweb.com S.r.l.
User Manual
DMX / Modbus Slave
Document code: MN67517_ENG Revision 1.000 age 8 of 24
FUNCTION MODES:
The device has got two functions mode depending of the position of the ‘Dip1 of Dip-Switch A’:
The first, with ‘Dip1 of Dip-Switch A’ at “OFF” position, is used for the normal working of the device.
The second, with ‘Dip1 of Dip-Switch A’ at “ON” position, is used for upload the roject and/or Firmware.
For the operations to follow for the updating, see ‘U DATE DEVICE’ section.
According to the functioning mode, the LEDs will have specifics functions, see ‘LEDS’ section.

Industrial Electronic Devices
ADFweb.com S.r.l.
User Manual
DMX / Modbus Slave
Document code: MN67517_ENG Revision 1.000 age 9 of 24
LEDS:
The device has got five LEDs that are used to give information of the functioning status.
The various meanings of the LEDs are described in the table below.
LED Normal Mode Boot Mode
1: Device State (green) Blinks slowly (~1Hz) ON: Device powered
OFF: Device not powered
2: Modbus communication
(yellow) Blinks when a Modbus request is received Blinks quickly: Boot state
Blinks very slowly (~0.5Hz): update in progress
3: DMX communication
(yellow) Blinks when a DMX frame is received Blinks quickly: Boot state
Blinks very slowly (~0.5Hz): update in progress
4: Not used (yellow) OFF Blinks quickly: Boot state
Blinks very slowly (~0.5Hz): update in progress
5: Ethernet Link (green) ON: Ethernet cable connected
OFF: Ethernet cable disconnected
ON: Ethernet cable connected
OFF: Ethernet cable disconnected

Industrial Electronic Devices
ADFweb.com S.r.l.
User Manual
DMX / Modbus Slave
Document code: MN67517_ENG Revision 1.000 age 10 of 24
RS485 (MODBUS):
For terminate the RS485 line with a 120Ω resistor it is necessary to put ON dip 1, like in figure.
The maximum length of the cable should be 1200m (4000 feet).
Here some codes of cables:
Belden: p/n 8132 - 2x 28AWG stranded twisted pairs conductor + foil shield + braid shield;
Belden p/n 82842 - 2x 24AWG stranded twisted pairs conductor + foil shield + braid shield;
Tasker: p/n C521 - 1x 24AWG twisted pair conductor + foil shield + braid shield;
Tasker: p/n C522 - 2x 24AWG twisted pairs conductor + foil shield + braid shield.

Industrial Electronic Devices
ADFweb.com S.r.l.
User Manual
DMX / Modbus Slave
Document code: MN67517_ENG Revision 1.000 age 11 of 24
RS485 (DMX):
The maximum length of the cable should be 1200m (4000 feet).
Here some codes of cables:
Belden: p/n 8132 - 2x 28AWG stranded twisted pairs conductor + foil shield + braid shield;
Belden p/n 82842 - 2x 24AWG stranded twisted pairs conductor + foil shield + braid shield;
Tasker: p/n C521 - 1x 24AWG twisted pair conductor + foil shield + braid shield;
Tasker: p/n C522 - 2x 24AWG twisted pairs conductor + foil shield + braid shield.

Industrial Electronic Devices
ADFweb.com S.r.l.
User Manual
DMX / Modbus Slave
Document code: MN67517_ENG Revision 1.000 age 12 of 24
ETHERNET:
The Ethernet port is used for programming the device.
The Ethernet connection must be made using Connector2 of HD67517-B2 with at least a Category 5E cable. The maximum length of the
cable should not exceed 100m. The cable has to conform to the T568 norms relative to connections in cat.5 up to 100 Mbps. To connect the
device to an Hub/Switch is recommended the use of a straight cable, to connect the device to a C is recommended the use of a cross cable.

Industrial Electronic Devices
ADFweb.com S.r.l.
User Manual
DMX / Modbus Slave
Document code: MN67517_ENG Revision 1.000 age 13 of 24
USE OF COMPOSITOR SW67517:
To configure the Converter, use the available software that runs with Windows called SW67517. It is downloadable from the site
www.adfweb.com and its operation is described in this document (this manual is referenced to the last version of the software present on our
web site). The software works with MSWindows (X , Vista, Seven, 8, 10; 32/64bit).
When launching the SW67517, the window below appears (Fig. 2).
Note:
It is necessary to have installed .Net Framework 4.
Figure : Main window for SW67517

Industrial Electronic Devices
ADFweb.com S.r.l.
User Manual
DMX / Modbus Slave
Document code: MN67517_ENG Revision 1.000 age 14 of 24
NEW CONFIGUR TION / OPEN CONFIGUR TION:
The “New Configuration” button creates the folder which contains the entire device’s configuration.
A device’s configuration can also be imported or exported:
To clone the configurations of a rogrammable “DMX / Modbus slave - Converter” in
order to configure another device in the same manner, it is necessary to maintain the
folder and all its contents;
To clone a project in order to obtain a different version of the project, it is sufficient to
duplicate the project folder with another name and open the new folder with the
button “Open Configuration”.

Industrial Electronic Devices
ADFweb.com S.r.l.
User Manual
DMX / Modbus Slave
Document code: MN67517_ENG Revision 1.000 age 15 of 24
SOFTW RE OPTIONS:
By pressing the “Settings” ( ) button there is the possibility to change the language of the software and check the updatings for the
compositor.
In the section “Language” it is possible to change the language of the
software.
In the section “Connection Options”, it is possible to check if there are some
updatings of the software compositor in ADFweb.com website.
Checking the option “Check Software Update at Start of Program”, the
SW67517 check automatically if there are updatings when it is launched.

Industrial Electronic Devices
ADFweb.com S.r.l.
User Manual
DMX / Modbus Slave
Document code: MN67517_ENG Revision 1.000 age 16 of 24
In the section “Software Settings”, it is possible to enable/disable some
keyboard’s commands for an easier navigation inside the tables contained in
the different sections of the software.

Industrial Electronic Devices
ADFweb.com S.r.l.
User Manual
DMX / Modbus Slave
Document code: MN67517_ENG Revision 1.000 age 17 of 24
SET COMMUNIC TION:
This section define the main communication parameters of two buses, Modbus and DMX.
By ressing the “Set Communication” button from the main window for SW67517 (Fig. 2)
the window “Set Communication” appears (Fig. 3).
The means of the fields for “DMX” section are:
In the field “DMX” it is possible to define if the converter will act as DMX controller
(“OUT”) or as DMX device (“IN”);
In the field “Channel Number” the number of channels of the DMX side is defined
(up to 512 channels);
If the field “Enable End-Line Resistor” is checked, the termination resistor for
DMX line is inserted.
The means of the fields for “Modbus Slave” are:
In the field “Serial” the serial port to use is defined;
In the field “Baudrate” the baudrate for the serial line is defined;
In the field “Parity” the parity of the serial line is defined;
In the field “Stop Bits” the number of Stop Bits of the serial line is defined;
In the field “ID Device” the ID of Modbus side of the converter is defined;
If the field “Map one DMX Channel in one Register” is checked, each Modbus
register of the converter will contain the data for a single DMX channel (low byte).
Otherwise, each register will contain two DMX channels. The DMX channels are
mapped starting from Modbus register 0;
The means of the fields for “Ethernet” are:
In the field “IP DDRESS” the I address of the converter is defined;
In the field “SUBNET Mask” the SubNet Mask of the converter is defined;
In the field “G TEW Y” the default gateway of the network is defined. This feature
can be enabled or disabled pressing the Check Box field. This feature is used for going out of the net.
Figure 3: “Set Communication” window

Industrial Electronic Devices
ADFweb.com S.r.l.
User Manual
DMX / Modbus Slave
Document code: MN67517_ENG Revision 1.000 age 18 of 24
DMX DEF ULT V LUE:
By pressing the “DMX Default Value” button from the main window for SW67517 (Fig. 2) the “DMX Default Value” window appears (Fig. 4).
In this section it is possible to define the default value for each channel of the DMX array when the converter is turned ON.
Figure
4
:
“DMX Default Value” window

Industrial Electronic Devices
ADFweb.com S.r.l.
User Manual
DMX / Modbus Slave
Document code: MN67517_ENG Revision 1.000 age 19 of 24
UPD TE DEVICE:
By pressing the “Update Device” button, it is possible to load the created
Configuration into the device; and also the Firmware, if necessary. This by using the
Ethernet port.
If you don’t know the actual I address of the device you have to use this procedure:
Turn OFF the Device;
ut Dip1 of ‘Dip-Switch A’ in ON position;
Turn ON the device
Connect the Ethernet cable;
Insert the I “192.168.2.205”;
Select which operations you want to do;
ress the “Execute update firmware” button to start the upload;
When all the operations are “OK” turn OFF the Device;
ut Dip1 of ‘Dip-Switch A’ in OFF position;
Turn ON the device.
If you know the actual I address of the device, you have to use this procedure:
Turn ON the Device with the Ethernet cable inserted;
Insert the actual I of the Converter;
Select which operations you want to do;
ress the “Execute update firmware” button to start the upload;
When all the operations are “OK” the device automatically goes at Normal Mode.
At this point the configuration/firmware on the device is correctly updated.
Figure 5: “Update device” windows

Industrial Electronic Devices
ADFweb.com S.r.l.
User Manual
DMX / Modbus Slave
Document code: MN67517_ENG Revision 1.000 age 20 of 24
Note:
When you install a new version of the software, if it is the first time it is better you do the update of the Firmware in the HD67517
device.
Note:
When you receive the device, for the first time, you also have to update the Firmware in the HD67517 device.
Warning:
If Fig. 6 appears when you try to do the Update try these points before seeking
assistance:
Try to repeat the operations for the updating;
Try with another C;
Try to restart the C;
Check the LAN settings;
Check the Wi-Fi settings;
If you are using the program inside a Virtual Machine, try to use in the main
Operating System;
If you are using Windows Seven, Vista, 8 or 10 make sure that you have the
administrator privileges;
In case you have to program more than one device, using the "UD Update", you
have to cancel the AR table every time you connect a new device on Ethernet. For
do this you have to launch the "Command rompt" and write the command "arp -
d". ay attention that with Windows Vista, Seven, 8, 10 you have to launch the
"Command rompt" with Administrator Rights;
ay attention at Firewall lock.
In the case of HD67517 you have to use the software “SW67517”: www.adfweb.com\download\filefold\SW67517.zip.
Figure 6: “Protection” window
