Akuvox E18 User manual

1、Take out E18/A07 Door phone.
2、Remove the the back cover of the device.
Main Accessories :
LTE module x 1 M2 x 4 machine screw x 2
Step 1: Remove Back Cover
LTE Module Installation
E18/A07
1
SIM card extractor x 1
Unpacking
Before the installation, please check and ensure that the
following items are included in the shipped box:
LTE Module Installation

1、Take out SIM card extractor, and insert it into the card tray
hole properly to take out the card tray.
2、Put the SIM card on the card tray and push it back to the
card slot.
Step 2: Install SIM Card
2
LTE Module Installation
E18/A07

1、Take out TF card and insert it into its corresponding slot on
the device in the direction as indicated by the arrow.
Step 3: Install TF Card (Note: Skip this step, if you do not
need the TF card.)
1、Take out LTE module and the two M2 x 4 Machine screws.
Step 4: Install LTE Module
3
LTE Module Installation
E18/A07

2、Fit LTE module into the corresponding socket base with its
“U” slot end facing towards the base and the other end with
main terminal facing in opposite direction.
3、Lock the LTE module onto the back cover using two M2 x 4
Machine screws, and press the Coaxial cable terminal into the
socket marked with “MAIN” on the module.
MAIN
2. R29 LTE SIM Card Installation and Removal
4
LTE Module Installation
E18/A07

1、Lock the back cover back onto its corresponding position.
Step 5: Lock the Back cover
2.2 R29 LTE SIM Card Removal
5
LTE Module Installation
E18/A07
Coaxial cable terminal

2、Installation completed.
