Akuvox X912 User manual

X912
Quick Guide
Unpacking
Rotary bracket x1
M4X10 crosshead screw x5
Before you begin using the device, please check the version you got and ensure that the following items are included in the
shipped box:

X912
Insert the four plastic wall
anchors into the drilled holes.
As figure shown, mark four screw holes on
the position that according to the cable place.
The horizontal distance of two holes should
be 50 mm, and the vertical distance of two
holes should be 180 mm. Then use a hand
drill with a diameter of 6 mm to drill the four
marked holes with a depth of 20 mm.
Installation

X912
Place the rotary bracket closely against
the wall while lining up its four holes
with their corresponding drilled holes.
And then fasten the rotary bracket on
the wall by tightening four ST4x20
crosshead screws to the plastic wall
anchors.
Fix wall-mounting bracket with five M4x10
crosshead screws on the rotary bracket.
Or
Or
Rotate right in 30 degrees
Rotate right 30 degrees
Rotate left in 30 degrees
Rotate left in 30 degrees

X912
Information contained in this document is believed to be accurate and reliable at the time of printing. This document is subject to change
without notice, any update to this document can be viewed on Akuvox’ s website: http://www.akuvox.com © Copyright 2022 Akuvox Ltd. All
rights reserved.
