Installation Instructions
Supervisor 4500
(SU4500)
Optical Turnstile with Bi-Directional Motorized Barriers

Supervisor 4500 Installation Instructions
Page 2 For assistance: [email protected] [phone] PUD4385R1-1
Contents. ......................................................................................................................................................................... 2
Safety Precautions. ......................................................................................................................................................... 3
Safety Icons..................................................................................................................................................................... 3
Installation Tools.............................................................................................................................................................. 4
Uncrating. ........................................................................................................................................................................ 4
Parts List.......................................................................................................................................................................... 5
Introduction...................................................................................................................................................................... 7
Before You Begin............................................................................................................................................................. 9
Slab Requirements. .................................................................................................................................................. 9
Space Requirements. ............................................................................................................................................... 9
Electrical Requirements. ......................................................................................................................................... 10
Conduit Requirements. ............................................................................................................................................11
Environmental Requirements...................................................................................................................................11
Communication Requirements................................................................................................................................ 12
Internal Card Reader Installation Requirements .................................................................................................... 12
User Training........................................................................................................................................................... 12
Pre-Installation Checklist. ....................................................................................................................................... 12
Pre-Installation Instructions. .......................................................................................................................................... 13
Cabinet Panel Removal. ......................................................................................................................................... 13
Installation Instructions.................................................................................................................................................. 14
Anchoring the Turnstile. .......................................................................................................................................... 14
Internal Card Reader Installation. ........................................................................................................................... 17
Wiring Instructions......................................................................................................................................................... 18
Low-Voltage - 24VDC Connection. ......................................................................................................................... 18
Crossover Cable Connection. ................................................................................................................................. 18
LED Light Connection from Secondary Cabinet............................................................................................................ 19
I/O Control Board. ................................................................................................................................................... 20
I/O Control Board Terminal Descriptions................................................................................................................. 21
Conguring Passage Modes. ........................................................................................................................................ 22
Ethernet Communication (Optional). ............................................................................................................................. 24
Barrier Installation.......................................................................................................................................................... 24
Post-Installation Functions Check. ................................................................................................................................ 26
Finish the Installation..................................................................................................................................................... 30
Cabinet Lid Installation............................................................................................................................................ 30
Cabinet Panel Installation. ...................................................................................................................................... 31
Base Cover Installation. .......................................................................................................................................... 31
Post-Installation Checklist. ............................................................................................................................................ 32
Troubleshooting............................................................................................................................................................. 33
Appendix A - External DC Power Supply Installation..................................................................................................... 34
Appendix B - Setting the Home Position. ...................................................................................................................... 40
Appendix C - 36" Single Lane - Plan, Elevation, & Footprint Drawing. ......................................................................... 41
Appendix D - Multi-Lane Conduit Requirements. .......................................................................................................... 42
Appendix E - Crossover Cable Connection Diagrams................................................................................................... 43
Appendix F - Single Lane Platform Dimensions - 28" & 36" Passages......................................................................... 44
Revision History............................................................................................................................................................. 45
Contents

Supervisor 4500 Installation Instructions
PUD4385R1-1 For assistance: [email protected] [phone] Page 3
The following symbols are used throughout the manual to highlight important information and
potential risks when installing, servicing or using the turnstiles covered in this manual.
This symbol is used in this manual to warn installers and operators of
potential harm. Please read these instructions very carefully.
This symbol is used in this manual to designate potential conditions that
may pose a risk to pedestrians, personnel, property and equipment. Please
read these instructions very carefully.
NOTE This symbol is used in this manual to designate useful information for the
installer and operator. Please read these instructions.
For questions, please contact Alvarado at [phone], Monday – Friday
7:00am to 4:00pm PST. Please read this manual completely before
installing or operating the purchased product.
Safety Icons
A minimum of two people
is required to complete
the installation of this
product.
The Supervisor 4500 may present a risk to persons and property if it is not installed and/or operated
correctly. This manual must be read in its entirety and all safety and operations information must be
followed. Note the following precautions:
• For indoor use only.
• Use only skilled individuals to install and service the turnstile.
• DO NOT operate the turnstile if it has been damaged in any manner. If damaged, have the unit repaired or adjusted by a
skilled service person before use.
• DO NOT modify or alter the turnstile.
• Have skilled individuals maintain the turnstile according to a proper maintenance schedule.
• In access control applications, train all personnel that will be using the turnstile in the proper method of operation. In
addition, properly train new users as they are added to the system.
• DO NOT use non-Alvarado parts to repair a damaged turnstile.
• Closely follow the handling instructions for moving or lifting the turnstile during installation.
• Power o󰀨 the turnstile before connecting or disconnecting any communication or power wiring to the turnstile.
• Pour utilisation à l'intérieur seulement.
• Utilisez uniquement des personnes qualiées pour installer et entretenir le tourniquet.
• NE PAS faire fonctionner le tourniquet s'il a été endommagé de quelque façon. S'il est endommagé, faire réparer ou
ajuster l'unité avant l'utilisation par un(e) préposé(e) à l'entretien qualié(e).
• NE PAS modier ou altérer le tourniquet.
• Le tourniquet doit être maintenu selon un calendrier d'entretien adéquat par des personnes qualiées.
• Dans les applications de contrôle d'accès, former tout le personnel qui utilisera le tourniquet selon la bonne méthode de
fonctionnement. De plus, bien former les nouveaux utilisateurs à leur intégration au système.
• NE PAS utiliser des pièces ne provenant pas du Alvarado pour réparer un tourniquet endommagé.
• Suivez strictement les instructions de manutention pour déplacer ou soulever le tourniquet lors de l'installation
• Éteignez le tourniquet avant de brancher ou de débrancher le câblage de communication ou le câblage d'electricité.
• This turnstile can be used by children aged 12 years and above, and persons with reduced physical, sensory or mental
capabilities or lack of experience and knowledge, if they have been given supervision or instruction concerning use of the
turnstile in a safe way and understand the hazards involved. Children shall not play with or around the turnstile.
• The turnstile shall be disconnected from its power source during service and when replacing parts. The turnstile shall be
disconnected from its power source before connecting or disconnecting any communication or other activation/feedback
control wires. If it is not possible that the technician can check from any point to which he has access that the main power
is removed, a disconnection with a locking system in the isolated position shall be provided.
Safety Precautions
CAUTION
WARNING
WARNING

Supervisor 4500 Installation Instructions
Page 4 For assistance: [email protected] [phone] PUD4385R1-1
Installation Tools
• Tape Measure
• Chalk Line
• Pencil
• Hammer Drill
• 5/8" Concrete Drill Bit
• Shop Vac
• Hammer
• 9/16" Wrench
• Torque Wrench (ft-lbs.)
• Torque Wrench (in-lbs)
• 9/16" Socket
• 5/32" Hex Key
• #2 Phillips Head Screwdriver
• Precision Flat Head Screwdriver
• Clear RTV Silicone
• Level
Uncrating
The SU4500 has been packed for shipping to prevent damage to the unit. Two or more installers are required
to unload the SU4500 at the installation site. Once the turnstile cabinets have been placed in the installation
location, carefully remove the protective packing material from the sides of the cabinets.

Supervisor 4500 Installation Instructions
PUD4385R1-1 For assistance: [email protected] [phone] Page 5
This product is shipped with all installation hardware and components. If installing a single lane, refer to the Single Lane Parts List
below. For additional lanes, refer to the Center Cabinet Parts List. Make sure that none of these parts are missing and/or damaged
before beginning installation. If parts are missing and/or damaged, please contact Alvarado.
Single Lane Parts List
Concrete Anchor Package:Hardware:
Cabling:
Software:
Parts List
• ⅜" x 2½" Hex Head Cap Screws (Qty 14)
• ⅜" Flat Washers (Qty 14)
• ⅜" x 2" Concrete Anchors (Qty 14)
• Barrier Clamp Bars (Qty 2)
• Barrier Clamp Bar Screws (Qty 8)
• Lid Screws (Qty 16)
• Binding Posts (Qty 8)
• Anchor Block Hex Screws (Qty 8)
• Base Cover Screws (Qty 8)
• Remote Power Supply with Enclosure
• Spade Connectors (Qty 12)
• 8' Crossover Cable (Qty 1)
• File Management USB (Qty 1)
Main Cabinet
(Qty 1) Secondary Cabinet
(Qty 1)
Barriers
(Qty 2)
Cabinet Lids
(Qty 2)
Main Cabinet Base Covers
(Qty 1)
Secondary Cabinet Base Covers
(Qty 1)
Front Anchor Block
(Qty 4)
Rear Anchor Block
(Qty 4)

Supervisor 4500 Installation Instructions
Page 6 For assistance: [email protected] [phone] PUD4385R1-1
Center Cabinets are used to create additional lanes for multi-lane congurations. Each additional lane includes the parts below.
Cabling:
• 8' Crossover Cable (Qty 1)
Center Cabinet Parts List (Per Center Cabinet)
Concrete Anchor Package:
Hardware:
Parts List (cont.)
• ⅜" x 2½" Hex Head Cap Screw (Qty 7)
• ⅜" Flat Washers (Qty 7)
• ⅜" x 2" Concrete Anchors (Qty 7)
• Removable Barrier Clamps (Qty 2)
• Barrier Clamp Mounting Screws (Qty 8)
• Lid Screws (Qty 8)
• Binding Posts (Qty 4)
• Base Cover Screws (Qty 4)
Center Cabinet
(Qty 1)
Barriers
(Qty 2)
Center Cabinet Lid
(Qty 1)
Center Cabinet
Base Covers
(Qty 1)
Front Anchor Block
(Qty 2)
Rear Anchor Block
(Qty 2)

Supervisor 4500 Installation Instructions
PUD4385R1-1 For assistance: [email protected] [phone] Page 7
Introduction
This manual covers the physical installation process for SU4500 Optical Turnstile. A separate SU4500 User Guide provides
operating instructions and additional information such as conguring turnstiles for bi-directional passage applications and
monitoring outputs. It is highly recommended that both this manual and the SU4500 User Guide be read in their entirety prior to
beginning installation.
There are three types of SU4500 cabinets used to create passage lanes: a Main cabinet, a Secondary cabinet, and a center
(expansion) cabinet. A single passage lane consists of a Main cabinet and a Secondary cabinet [Figure 1A]. The center cabinet is
used to create additional passage lanes with the addition of a single cabinet [Figure 1B].
Each cabinet has an unsecured and secured side. Alvarado follows what we call the “right-hand rule." User status lights and card
readers are always installed on the right-hand side as you enter the turnstile.
SU4500 Cabinets
The center portion of the Main cabinet contains the main
turnstile controller, I/O control board, motor and motor control
board, power supply, safety sensor receivers, one moving
barrier, and a power switch located at the base on the secured
side.
The top channel of the Main cabinet contains the operational
sensor receivers, a Free Pass sensor, a drive system, and a
user status display that communicates lane status to the user. A
card reader is normally installed during installation underneath
the lid below the user status display.
Center cabinets contain both Main and Secondary
components. Center cabinets are extension cabinets used
in multi-lane applications. An unlimited number of center
cabinets can be added.
The center portion of the center cabinet contains the main
turnstile controller, I/O control board, two motors and two
motor control boards, power supply, safety sensors for both
the Main and Secondary side of the center cabinet, two
moving barriers, and a power switch located at the base on
the secured side of the Main side.
The top channel of the center cabinet contains Main and
Secondary side operational sensors, a Free Pass sensor, two
drive systems, and two user status displays that communicate
lane status to the user. Two card readers are normally
installed during installation underneath the lid below the user
status display on both sides of the center cabinet top channel.
The center portion of the Secondary cabinet contains a motor
and motor control board, safety sensor transmitters, and one
moving barrier.
The top channel of the Secondary cabinet contains the
operational sensor transmitters, a drive system, and a user
status display that communicates lane status to the user. A card
reader is normally installed during installation underneath the lid
below the user status display.
Main Cabinet
Center Cabinet (Multi-Lane Conguration)
Secondary Cabinet
User
Status
Light
User
Status
Light
Power
Key
Switch
Unsecured Side
Secured Side
Entry
Direction
Exit
Direction
Secondary
Cabinet
Main
Cabinet
Exit
Direction
Unsecured Side
Secondary
Cabinet
Center
Cabinet Main
Cabinet
Secured Side
Power
Key
Switch
Power
Key
Switch
Exit
Direction
Entry
Direction
Entry
Direction
Main
Side Secondary Side
Fig. 1AFig. 1A Single Lane Conguration
Fig. 1BFig. 1B Multi-Lane Conguration

Supervisor 4500 Installation Instructions
Page 8 For assistance: [email protected] [phone] PUD4385R1-1
Passage Lane Width
36" Passage Lane28" Passage Lane
SU4500 barriers come in widths to create 28" or 36" passage lanes [Figure 3].
SU4500 barriers come in low (35") heights [Figure 2].
Barrier Height
Fig. 3Fig. 3 Passage Lane WidthsPassage Lane Widths
Access Control Integration
Single passage activation and the various other inputs and outputs available to / from the SU4500 are accessed through the I/O
control board located in the Main cabinet. The required system input is a voltage-free, momentary dry contact. Outputs are also
provided in this form. In rare cases, depending on the access control system, it may be desirable to utilize isolation relays to ensure
proper system signaling. Additional information on I/O interfacing is provided later in this manual.
For select projects, a TCP/IP interface is available. This interface allows a third party access system to communicate to / from
the SU4500 using a dened TCP/IP command structure. There is an additional charge for implementation and use of the TCP/IP
interface and implementation requires programming e󰀨orts on the part of the access system provider. Instructions pertaining to the
TCP/IP interface is outside the scope of this manual.
There are two types of interfaces to allow an access control system to operate with the SU4500:
Dry Contact
TCP/IP
Network Communication
SU4500 turnstiles are TCP/IP enabled. Running Ethernet cabling to the SU4500 provides a number of benets. (1) It allows
implementation of Alvarado’s TCP/IP control and monitoring software. (2) It allows easy implementation of SU4500 application
software updates and enhancements. If the SU4500s are networked, updates can be installed over the network. (3) Alvarado has
future plans to further develop the TCP/IP capabilities of the SU4500. The benets of this future development can only be realized
if the turnstiles are networked.
28
(711)
36
(914)
35"
(889)
Fig. 2Fig. 2 Low Height Barrier
6" (152)
Inch (mm)

Supervisor 4500 Installation Instructions
PUD4385R1-1 For assistance: [email protected] [phone] Page 9
Before You Begin
Use only skilled technicians for site preparation and installation of the turnstile using Alvarado’s instructions.
Refer to the footprint and plan drawings [Figure 4a, 4b, 4c] to determine the installation location and conduit requirements for a 28"
single lane. See Appendix C on pg.41 for 36" width dimensions.
For ease of installation and service, allow 2" of space between cabinets and walls or other surfaces.
The following slab requirements must be taken into consideration when selecting the installation location:
• A level solid concrete pad with a minimum thickness of 4" (102mm).
• Use full sweep electrical conduit underneath the oor.
• Three separate conduits for primary source power, external data, and the crossover cable must be used.
• Cabinets must be installed plumb with the oor while level and square to each other.
NOTE
Slab Requirements
Space Requirements
38 [965]
28 [711]
13
[330]
42.3 [1074]
6.0 [152]
41.0 [1041]
Plan View Elevation View
Fig. 4aFig. 4a Fig. 4bFig. 4b
Inch (mm)Inch (mm)

Supervisor 4500 Installation Instructions
Page 10 For assistance: [email protected] [phone] PUD4385R1-1
16.3 [414]
12.8 [325]
6.3 [159]
3.3 [83]
0
2.6 [66]
3.3 [83]
6.3 [159]
12.8 [325]
16.3 [414]
1.36 [34.5]
1.36 [34.5]
7X
Ø .61 [15.5]
ANCHORING
LOCATIONS
CONDUIT
OPENING
1.9 [49]
4X .03 [.8]
0
2X .7 [18]
0
Space Requirements (Cont.)
Power Supply 110-120 VAC, 60 Hz or 220/240 VAC, 50 Hz
Power Consumpion Peak: 65W Operating: 40W Idle: 20W
Operational Voltage Primary power is stepped down and rectied for low-voltage: 24 VDC, 12 VDC,
and 5 VDC operation
Fuse 2.5A (slo-blo) located in the Main cabinet
Drive Motor 24 VDC (brushless)
Surge Protection Alvarado suggests the use of surge protection on the high-voltage power line to
further protect electronics
Electrical Requirements
Footprint Drawing
This model requires the use of an External DC Power Supply. Refer to Appendix A for instructions of how to wire &
mount the external power supply housing.
Low-voltage wires must be pulled from the External DC Power Supply install location to each Main and Center
cabinets (if any).
Fig. 4cFig. 4c
Inch (mm)

Supervisor 4500 Installation Instructions
PUD4385R1-1 For assistance: [email protected] [phone] Page 11
Environmental Requirements
Conduit Requirements
• DO NOT install the product outdoors. This product is intended for indoor use only.
• DO NOT install the SU4500 where infrared lighting (strobe lights, ash photography, etc.) is in the direct path of the
optical sensors. Interference may a󰀨ect the performance of the turnstile.
The following are suggested operating temperature and humidity ranges for the SU4500:
Operation Non-Operation/Storage
Temperature Range 10-32°C / 50-90°F 0-40°C / 32-104°F
Humidity Range (Non-Condensing) 15% - 85% RH --
Fig. 5Fig. 5 SU4500 Conduit LinesSU4500 Conduit Lines
• Seal the oor area around the conduits running up
and into the cabinets. This will prevent condensation
and debris build-up coming from whatever may be
below the oor.
• Refer to Appendix A for instructions to wire the
External DC Power Supply.
NOTE
Operating the SU4500 outside the listed temperature and humidity ranges may negatively a󰀨ect turnstile
performance, and could potentially cause damage to the turnstile and void the warranty.
CAUTION
Symbology Description Conduit Size
Low-Voltage -
24VDC 1/2”
Access Control /
Ethernet 3/4”
Access
Control 3/4”
Crossover
Cable 1.5”
The opening for the conduit in the center of each cabinet
is 6.50” x 2.50” (165mm x 64mm). The three required
conduits MUST t in this area [Figure 5].
NOTE
For multi-lane conduit requirements, refer to
Appendix D.
NOTE
Secondary
Cabinet Main Cabinet

Supervisor 4500 Installation Instructions
Page 12 For assistance: [email protected] [phone] PUD4385R1-1
Communication Requirements
Internal Card Reader Installation Requirements
User Training
Pre-Installation Checklist
Signal Inputs and Outputs To / From Access Control System
Inputs - Signal inputs from outside systems are wired into the SU4500’s I/O control board. There are two types of input
signals, momentary dry contacts (MDC) and sustained dry contacts (SDC). All input signals must be normally open, voltage-
free, dry contacts, with the exception of the re alarm input, which can be congured (via jumper on the I/O control board) to
accept either a normally open or normally closed sustained contact. MDC’s must be at least 100ms in duration to register.
While the SU4500 can accept signals up to 2 seconds in duration, the suggested MDC input duration is 1 second or less to
support rapid throughput in high volume applications.
Outputs – Signal outputs are available from the SU4500’s I/O control board. Outputs are normally open, voltage-free,
momentary dry contacts. The output signal length is 500ms in duration.
Inability to Provide Specied Inputs - If the access system cannot provide the specied MDCs, isolation relays should be
used. NEVER connect signal lines containing voltage directly to the I/O control board.
Network Communication
A networked PC with Alvarado's TCP/IP control and monitoring software is required. Adhere to IEEE standards for network cabling
requirements.
It is the installer's responsibility to ensure the following steps are completed before beginning the installation.
Card readers or other physical access devices may be installed under the top channel lid on either or both right-hand sides of the
turnstile. Card readers / physical access devices are not supplied by Alvarado.
All personnel that will be involved with operating the SU4500 should be trained in the proper method of operation. Detailed
operation instructions are outside the scope of this manual, but can be found in the SU4500 User Guide (also included with the
product). If further training is desired, contact Alvarado for information regarding on-site training services.
1. All components and hardware to be installed have been unpacked, correctly identied, and moved to the installation location.
2. The turnstile conguration and layout has been conrmed with the site manager.
3. All applicable requirements in the Before You Begin section have been met.
The card reader maximum dimensions: 2.125" H x 4.5" W x 8" D (54mm x 114mm x 203mm)

Supervisor 4500 Installation Instructions
PUD4385R1-1 For assistance: [email protected] [phone] Page 13
Cabinet Panel Removal
It is assumed that the Pre-Installation Checklist steps are complete.
Pre-Installation Instructions
1. Using a Phillips screwdriver, remove the six (6) mounting
screws that secure the cabinet panel to the Main cabinet
[Figure 6]. Do not discard the cabinet panel screws as they
will be reused.
2. Once the screws are removed, gently slide the cabinet
panel out of position and set the panel o󰀨 to the side
[Figure 6].
3. Repeat steps 1 and 2 to remove the Secondary cabinet
panel.
Fig. 6Fig. 6 Removing ScrewsRemoving Screws
NOTE
NOTE
Barrier spindle not shown for ease of view.

Supervisor 4500 Installation Instructions
Page 14 For assistance: [email protected] [phone] PUD4385R1-1
Installation Instructions
Anchoring the Turnstile
1. Remove the turnstile cabinets from the wooden skids.
2. Using a Phillips screwdriver, remove the L-bracket attached to the bottom edge of the stationary panels. Discard the bracket.
3. Place the Main cabinet and the Secondary cabinet in the determined location [see dimensions - Figure 4].
4. All cabinets must be level and square to each other. This will ensure that the optical sensors are aligned, and that the barriers
will line up properly when installed. Use the following procedures to level the cabinets, and square each cabinet with respect to
the oor and other cabinets:
A. Measure the distance from the inside wall of one cabinet
top channel to the inside wall of the other cabinet top
channel, on both the entry and exit side of the lane for a
consistent measurement [Figure 7A].
B. Measure the diagonal distance from the end of one
cabinet to the end of the opposing cabinet, then
measure the opposing diagonal distance [Figure 7B]. If
these distances are equal, the cabinets are square.
C. Using a level, verify each cabinet is level [Figure 7C]. If
necessary, shim to bring the cabinets level.
Fig. 7AFig. 7A
Fig. 7CFig. 7C
Fig. 7BFig. 7B
NOTE The Lane 1 Main cabinet is always the right-most cabinet in relation to the unsecured side.

Supervisor 4500 Installation Instructions
PUD4385R1-1 For assistance: [email protected] [phone] Page 15
Fig. 8Fig. 8 Marking Anchor HolesMarking Anchor Holes
Fig. 9Fig. 9 Inserting AnchorsInserting Anchors
Anchoring the Turnstile (cont.)
8. Move the cabinets once anchor locations have been
marked.
9. Using a 5/8" concrete drill bit, drill the anchor holes 3"
in depth at the center of each marked location.
10. Using a Shop Vac, vacuum debris from each drilled
anchor hole.
11. Insert anchors into each drilled hole [Figure 9]. The
threaded end of the anchor must be inserted into the
hole rst. Use a hammer to tap the anchors into place,
if needed. Ensure that the anchors are ush with the
concrete oor.
NOTE
The anchor holes must be clean before installing the
anchor bolts. If the holes are not clear of debris, the
anchor bolts may not tighten correctly.
NOTE
The anchors are not torqued to specication yet, as
the turnstile may need shimming during the barrier
leveling procedure on Page 25. Torque anchors to
25 ft-lbs after the barrier leveling procedure on
pg.24 is completed.
Anchoring Holes
(7 total)
Concrete Anchor
5. Using a pencil, mark each mounting hole location
on the center black frame of the turnstile . There will
be a total of three (3) mounting holes per frame.
[Fig 8]
6. Using the included anchor template, t the curved
portion of the template against the curved portion
of the center black frame. Ensure the template is
ush with the frame - mark the location of the two (2)
anchor holes using a pencil.
7. Flip the anchor template 180 degrees and repeat
Step 6 for the remaining two (2) anchor holes.
NOTE
There are a total of 7 anchor holes per cabinet.
Caution
If drilling through terrazzo ooring, add the thickness
of the terrazzo tile to the hole depth. Use appropriate
length anchor bolts. Anchor
Locatons

Supervisor 4500 Installation Instructions
Page 16 For assistance: [email protected] [phone] PUD4385R1-1
12. Place the two (2) Rear Anchor Blocks onto the oor, aligning
the anchor holes. Repeat for Secondary cabinet.
13. Insert two (2) 3/8" x 2-1/2 Hex Head Cap Screws and at
washers into each of the Rear Anchor Blocks. [Fig. 10]
14. Using a torque wrench and a 9/16" socket, torque Rear Anchor
Blocks anchors to 25 ft-lbs.
15. Maneuver each cabinet over the anchor locations and align
the holes on the lower edge of the stationary panels with the
holes in the Rear Anchor Blocks.
16. If not already done, pull all wires (low-voltage power, access
control and crossover cable) through the conduit access hole
into the center frame of the cabinet.
17. Using RTV silicone, seal the gaps between the conduit and
conduit holes.
18. Insert three (3) 3/8" x 2-1/2" Hex Head Cap Screws and at
washers into the remaining holes in the black frame.
19. Using a torque wrench, provisionally snug the anchor bolts.
Do not fully tighten.
20. Using two (2) binding posts, insert the posts into the Rear
Anchor Blocks.
21. Press the Front Anchor Block into position and secure in
place using two (2) binding screws and two (2) #2 Phillips
screwdrivers. The Front Anchor Block should be located inside
the lane.
22. Using a 5/32" hex key, insert and secure two (2) hex bolts to
secure the Rear and Front Anchor Blocks together.
23. Ensure cabinets are square and level to each other. Shim as
needed to level cabinets.
24. Using a torque wrench and 9/16 socket, torque remaining
anchor bolts to 25 ft-lbs.
Anchoring the Turnstile (cont.)
Fig. 10Fig. 10 Securing Rear Anchor Blocks
The last Secondary cabinet to be installed will have a
bundle of RJ45 cable that must be routed along with
the crossover cable. See Page 19.
NOTE

Supervisor 4500 Installation Instructions
PUD4385R1-1 For assistance: [email protected] [phone] Page 17
Internal Card Reader Installation
Routing the Output CableRouting the Output Cable
Fig. 11aFig. 11a
1. Locate the card reader mounting bracket [Figure 11].
2. Install the card reader per manufacturer's instructions.
3. Route the output cable through the turnstile and connect to your access control system. [Figure 11a & 11b].
Output cable must be routed down through the access hole.
NOTE
Card readers used in conjunction with the sites' access control system are not included with the SU4500.
Most card readers do not require separate power inputs. In the event that your reader requires a separate power input – do not
draw power from the SU4500 power supply.
Access control boards used in conjunction with the SU4500 are to be installed at locations outside of the SU4500, such as a wiring
closet or other location.
NOTE
If the distance between the installed card reader and top channel lid exceeds the read range of the card reader, shims may be
used to elevate the card reader by a maximum of 3/8" (9.5mm).
Card reader mounting plate
Routing the Output CableRouting the Output Cable
Fig. 11bFig. 11b
Ensure wires do not obstruct the discrete optic sensors.
NOTE

Supervisor 4500 Installation Instructions
Page 18 For assistance: [email protected] [phone] PUD4385R1-1
Wiring Instructions
Low-Voltage - 24VDC Connection
Crossover Cable Connection
It is assumed the External DC Power Supply has been mounted and
wired for Primary Power. Low-Voltage conduit should be run to the
turnstiles according to the Conduit Requirements. Refer to Appendix A for
instructions
NOTE
Data/Communication
Cable (tucked in the
bottom of the cabinet)
Fig. 13Fig. 13
Crossover Cable
(packaged separately)
24VDC Power and
Ground Wire (tucked in
the bottom of the cabinet)
The included crossover cable carries communication signals and
low-voltage 24VDC between the Main and Secondary cabinets. The
default length of the crossover cable included with the SU4500 is 8'.
Optional crossover cable lengths of 13', 20' and 40' are available; as
well crossover cables for conduits smaller than 1.5".
1. Locate the low-voltage terminal block tucked in the bottom of the
base in the Main cabinet [Figure 13].
2. Insert the 24VDC positive wire (orange) and the negative wire
(black) into the terminal block, matching the colors with the other
side and tighten [Figure 13].
3. Connect the data connector from the crossover cable to the data
connector in the Main cabinet [Figure 13].
4. Repeat Steps 1 – 3 for the Secondary cabinet.
The crossover cable must connect from Main to Secondary.
Center cabinets have two crossover cable connectors tucked in
the base: one labeled Main and one labeled Secondary.
Refer to Appendix E for crossover cable connection diagrams.
NOTE
CAUTION
DO NOT MODIFY CROSSOVER CABLE.
Modifying the crossover cable will void the
product warranty.
Power Key
Switch
GND
24VDC
Power Terminal
Block
Fig. 12Fig. 12
1. Locate the pre-installed Power Terminal Block
(located next to the power key switch).
2. Attach each low-voltage wire to the power
terminal block with the corresponding color
exiting on the other side. [Fig. 12]
3. Using a Phillips head screwdriver, tighten each
terminal block connection.
4. Reattach the plastic cover over the Power
Terminal Block.

Supervisor 4500 Installation Instructions
PUD4385R1-1 For assistance: [email protected] [phone] Page 19
LED Light Connection from Secondary Cabinet
The Secondary cabinet will contain a bundle of RJ45 cable located at the bottom of the black frame of the cabinet.
This cable must be pulled along with the crossover cable and connect to the Main cabinet, if a single lane; or the
last Center cabinet, if a multi-lane set. [Figure 14 A&B]
Connect Secondary RJ45 to
Secondary on power board
located in Main cabinet.
Connect Secondary RJ45 to
Secondary on power board
located in last Center cabinet.
Single Lane:
Multi-Lane:
Fig. 14AFig. 14A Single Lane LED Connection Location
Fig. 14BFig. 14B Multi-Lane Set LED Connection Location

Supervisor 4500 Installation Instructions
Page 20 For assistance: [email protected] [phone] PUD4385R1-1
I/O Control Board
Fig. 15Fig. 15 Main CabinetMain Cabinet
Fig. 15AFig. 15A I/O Control BoardI/O Control Board )
LEGEND
ITEM NAME
J1 Input Terminals
J2 Output Terminals
JP1 RS485 Termination Resistor
JP2 RS485 Termination Resistor
JP3 Fire Alarm System Jumper
(N.O. - N.C.)
S1 Entry Side Open Test Button
S2 Entry Side Reject Test Button
S3 Previous Sensor Group
S4 Next Sensor Group
S5 Exit Side Open Test Button
S6 Exit Side Reject Test Button
Signal Inputs and Outputs
To / From Access Control System
Inputs
Signal inputs from outside systems
are wired into the SU4500’s I/O control
board. There are two types of input
signals, momentary dry contacts (MDC)
and sustained dry contacts (SDC). All
input signals must be normally open
(N.O.), voltage-free, dry contacts, with
the exception of the re alarm input,
which can be congured (via jumper
on the I/O control board) to accept
either a normally open or normally
closed (N.C.) sustained contact. MDC’s
must be at least 100ms in duration to
register. While the SU4500 can accept
signals up to 2 seconds in duration,
the suggested MDC input duration
is 1 second or less to support rapid
throughput in high volume applications.
Outputs
Signal outputs are available from the
SU4500’s I/O control board. Outputs
are normally open, voltage-free,
momentary dry contacts. The output
signal length is 500ms in duration.
Inability to Provide Specied Inputs
If the access system cannot provide the
specied MDCs, isolation relays should
be used. NEVER connect signal lines
containing voltage directly to the I/O
control board.
102109
