AMGO BP-10 Manual

TWO-POST LIFT
Model: BP-10

1
CONTENTS
Product Features and Specifications .........................................................1
Installation Requirement ........................................................................3
Steps of Installation ………………………………………………………..…………....................4
Exploded View .....................................................................................17
Test Run .............................................................................................20
Operation Instruction ...........................................................................21
Maintenance .......................................................................................22
Trouble Shooting .................................................................................23
Parts List ……….....................................................................................24

1
I. PRODUCT FEATURES AND SPECIFICATIONS
FLOORPLATE CHAIN-DRIVED MODEL FEATURES
MODEL BP-10 (See Fig.1)
· Compact design small footprint.
· Dual hydraulic chain-drive cylinders, designed and made on ANSI standard, utilizing oil
seal in cylinder.
· Self-lubricating UHMW Polyethylene sliders and bronze bush.
· Single-point safety release, and dual safety design.
· Super-symmetric arms design, make lifts easily find the lift point of the car.
· Stackable adapters 1.5”, 2.5”, 5” as standard.
MODEL BP-10 SPECIFICATIONS
Model Style Lifting
Capacity
Lifting
Time
Lifting
Height
Overall
Height
Overall
Width
Width
Between
Columns
Minimum
Pad
Height
Gross
Weight Motor
BP-10 Floor-plate
Chain-drive
62S
1638lbs
3.0
HP
10,000 lbs
77 1/4”-
86 1/4” 112” 139 1/4” 112 1/4” 4 1/2” -
13
1/2”
Fig.1

2
Arm Swings View
Fig. 2
100 错
误！未

3
II. INSTALLATION REQUIREMENT
A. TOOLS REQUIRED
Rotary Hammer Drill (3/4”)
Hammer
Level Bar
English Spanner (12")
Ratchet Spanner With Socket (28#)
Wrench set
Carpenter’s Chalk
Screw Sets
Tape Measure(295”)
Pliers
Socket Head Wrench ( 6#)
Lock Wrench
(10#, 13#, 14#, 15#, 17#, 19#, 24# ,27#)
Fig. 3

4
B. SPECIFICATIONS OF CONCRETE (See Fig. 4)
Specifications of concrete must be adhered to the specification as following.
Failure to do so may result in lift and/or vehicle falling.
1. Concrete must be thickness 4in minimum and without reinforcing steel bars，and
must be dried completely before the installation.
2. Concrete must be in good condition and must be of test strength 3,000psi
minimum.
3. Floors must be level and no cracks.
C. POWER SUPPLY
The electrical source must be 3HP minimum. The source cable size must be
0.003875sq.in and in good condition of contacting with floor.
III. STEPS OF INSTALLATION
A. Location of Installation
Check and insure the installation location (concrete, layout, space size etc.) is
suitable for lift installation.
B. Use a carpenter’s chalk line to establish installation layout of baseplate (See Fig. 5).
Concrete intensity must be 3,000psi
Fig. 4
Chalk a line
71
4in

5
C. Check the parts before assembly
1．Packaged lift and hydraulic power unit (See Fig. 6)
2. Move the lift aside with a fork lift or hoist, and open the outer packing carefully, take
off the parts from upper and inside the column, take out the parts box，check the
parts according to the shipment parts list (See Fig. 7).
3. Loose the screws of the upper package stand, take off the upper column and remove
the package stand.
4. Move aside the parts and check the parts according to the shipment parts list (See
Fig. 8, 9).
Fig. 6
Shipment Parts list
Serial
Nameplate
Floor cover
Fig. 7
Parts box
Fig. 8
Parts in the shipment parts list
Fig. 9
Parts in the parts box (83)
83

6
5. Open the parts bag and check the parts according to parts box list (See Fig. 10).
D. Lay down two columns on the installation site parallelly, position the power-side
column according to the actual installation site. Usually, it is suggested to install
Power side column on the front-right side from which vehicles are driven to the lift.
Then install the top plate (See Fig. 11).
Fig. 10
Offside column
Power-side column
Car in direction
Fig. 11
Assemble top-plate using
1/2*1-3/16 hex bolt with nut
and washer.

7
E. Connecting cables (See Fig. 12)
1．Put down columns and then push the carriages higher than chain pulley。
2．Push the carriages to the bottom of the columns (See Fig. 13).
Fig. 12
b:Push the carriages higher than chain
pulley, cable pass through the top of the
carriages and pass through the hole of
the bottom steel plate of carriages
c: Pull out cable
a: Let the cable rope into
the carriage.
Fig. 13

8
F. Position columns and install safety device (See Fig. 14).
Check the columns plumbness with level bar, and adjusting with the shims if the
columns are not vertical.
G. Install anchor bolts
. Prepare the anchor bolts (See Fig.15)
2. Using the prescribed rotary hammer drill, and drill all the anchor holes and install the
anchor bolts. Then tighten the anchor bolts (See Fig. 16).
Note: Torque of Anchors is 492N.Ft .Minimum embedment of Anchors is 错误！未找到引用
源。.
Fig. 15
Fig. 14
Washer
Lock washer
Nut
Fig. 16
Drilling
Tighten
Check the columns
plumbness with level
bar on front and side
column

9
H. Lift the carriages up by hand and make them be locked at the same level
(See Fig.17).
Fig. 17
Bolting

10
I. Install cables (See Fig.18)
Fig. 18
Let th
e cable cross over the hole
which on the top plate of the
carriages, and to
be screwed the
nuts at the end of the cable.

11
J. Connecting oil hose (See Fig. 19)
Fig. 19
77
78
77A
77
77
75
75A
76
77

12
K. Install power unit and oil hose (See Fig. 20)
Tighten all the hydraulic fittings, and fix the oil hose by retainer.
Fig. 20
Use 19#Wrench to tighten
the nut after installing the
fitting of power unit
5
81
78
82
Fix the oil hose by
Retainer

13
L. Install safety cable
Install safety cable from offside safety lock to power-side safety lock (See Fig. 21).
Fig. 21
View A
View B
Connecting
direction of
safety cable

14
M. Install floor cover (See Fig. 22).
N. Install lifting arms and adjust the arm locks
1. Install the lifting arms (See Fig. 23)
2. Lowing the carriages down to the lowest position, then use the 8# wrench to loosen
the nut of arm lock (See Fig. 24)
Fig. 22
Fig. 24
Fig. 23
Use the 8# wrench
to loosen the
Socket bolt
Snap Ring
Floor cover
Use the 17# wrench to loosen the lock nut

15
3. Adjust the arm lock as arrow direction (See Fig. 25).
4. Adjust moon gear and arm lock to make it to be meshed, then tighten the nut of
arm lock (See Fig. 26).
O. Install Electrical System
Connect the power source on the data plate of power unit.
Note: 1. For the safety of operators, the power wiring must contact the floor well.
2. Pay attention to the direction of rotations when using three phase motors.
AMGO single phase motor (See Fig. 27).
1. Connecting the two power supply lines (active wire Land neutral wire N) to
terminals of AC contactor marked L1, L2 respectively.
2. Connecting the two motor wires to terminals of AC contactor marked T1, T2.
3. Connecting A2 to L2 of AC contactor.
4. Control button (4#) connect with terminals of AC contactor marked A1;control
button (3#) connect with terminals of AC contactor marked L1.
Locking the nut
Adjust the
moon gear
Locking the nuts after the moon gear
and arm lock engaged well
Fig. 25
Fig. 26
Moon gear
Single phase

16
AMGO 3 phase motor.
1、Circuit diagram(See Fig. 28).
2. Connection step (See Fig. 29)
a. The source wires L1, L2, L3 connected with terminals of AC contactor marked
L1, L2, L3 respectively.
b. Terminals of AC contactor marked L1 connected with terminals 4# of control
button;Terminals A1 of AC contactor connected with terminals 3# of control
button.
Fig. 27
Three phase
Fig. 28
L3
L2
L1
A1
4#
3#
Fig. 29

17
IV. EXPLODED VIEW
Model BP-10
Fig. 30
Car in
direction

18
Cylinder
AMGO MANUAL POWER UNIT
220V/50HZ/1 Phase
380V/50HZ/3 phase
Fig. 31
