TOOLS NEEDED:
• Ratchet with 1/2" socket
• 1/2" Open-end or box-end wrench
• Phillips screwdriver
• Rubber mallet
Assembly Instructions
Streetside Café Tables
D1147 - 46" Round Perforated Steel Table
F1147 - 46" Round Expanded Steel Table
TABLE COMPONENTS:
ASSEMBLY HARDWARE: All hardware is stainless steel.
(1) Table Top (4) Table Top Supports
Round Perforated Steel Table Round Expanded Steel Table
(1) Cross Brace
(8) 5/16" - 18 x 1 1/4"
Hex Head Bolts
(4) 5/16 - 18 x 2 1/2"
Phillips Head Screws
(8) Plugs(12) 5/16" - 18
Nylock Nuts
(24) 5/16" Flat
Washers
Assembly:
Inspect the shipping container contents for damage and to determine that all components and hardware are present.1.
2. Lay all parts on a so work surface or on the shipping packaging to prevent damage to nish.
NOTE: Before assembling the nuts to the bolts, it is
recommended that a light oil or petroleum jelly be applied to
the screw threads.
1
The assembly is a two-person operation.
Locate the table top and place it upside down on the work
surface as shown.
Position one of the supports next to the mounting ange of
the table top. Align the mounting holes in the support with the
mounting holes of the ange.
Place a at washer on one of the 1 1/4" hex head bolts and insert
the bolt through one of the mounting holes in the table top
mounting ange and the table top support. Place a at washer
and nylock nut on the end of the bolt and tighten it nger tight.
Repeat this process on the other side of the table top support.
Leave the hardware nger tight so adjustments can be made
during assembly.
3.
4.
5.
5/16" Flat Washer
5/16" Flat Washer
5/16" -18 Nylock Nut
Table Top Support
5/16"-18 x 1 1/4"
Hex Head Bolt
Table Top
Repeat Steps 4 and 5 for the remaining three table top supports.6.

2
Locate the rubber feet and insert one in each of the two outside
holes on the bottom of each of the table top supports.
Use the rubber mallet to set the feet if necessary.
Locate the cross brace and position it in the center of the table top supports so that the mounting holes in the brace line up
with the mounting holes in the supports.
Place a at washer on one of the 2 1/2" Phillips head screws and insert the screw through one of the table top mounting holes
and through the matching hole in the cross brace.
Place a at washer on the screw and then tighten it nger tight with a nylock nut.
Repeat this process for the three remaining cross brace mounting holes.
7.
8.
Install Rubber Feet in
the two outside holes
Cross Brace
Table Top Support
5/16" Flat Washer
5/16" Flat Washer
5/16" -18 Nylock Nut
5/16 - 18 x 2 1/2"
Phillips Head Screw
Turn the table right side up.
Level the table top while tightening all of the hardware.
Move the table to the location where it will be used.
Aer two weeks, retighten all of the hardware.
9.
10.
11.
12.

01/30/2018 Copyright 2018 ANOVA® Made in USA. 3
Note: Please contact Customer Care at 1-866-797-1761 when ordering replacement parts.
Table Top
Cross Brace
Table Top Supports
Assembly and Replacement Parts
