Anova MIX2930R User manual

1
(4) 1/4”-20 x 1/2"
Button Head Socket
Cap Screws
(24) 1/4”
Nylock Nuts
(28) 1/4”
Flat Washers
(4) Glides
ASSEMBLY INSTRUCTIONS
MIX2930R - Mixx Recycled Plastic 42” Bar Height Table
MIX2930T - Mixx Thermory® 42” Bar Height Table
anovafurnishings.com
888.535.5005 tel
TOOLS NEEDED:
•Ratchet with 7/16” socket
•5/32” Allen wrench
TABLE COMPONENTS:
ASSEMBLY HARDWARE: All hardware is stainless s teel.
ASSEMBLY:
(1) Table Top
(4) Tabl e Legs
1. Inspect the shipping container contents for damage and to determine that all components and hardware are present.
2. Assemble the table over the shipping packaging or padded work area to avoidscratching the product.
NOTE: Before assembling the nuts to the PEM® studs, it is recommended that a light oil or petroleum jelly be
applied to the screw threads.
The assembly is a two-person operation.
(1) Tabl e Stretcher
Shown in Thermory.
Shown in mahogany recycled plastic.

2
Glide
Table Leg
Packing cardboard or
other soft work surface
Rivet Nut
5. Insert one 1/4” flat washer per each PEM® stud. Then screw on a
1/4” Nylock nut and loosely hand-tighten all four legs.
Table Top
Nylock Nut
Flat
Wa s her
4. While leaving the pre-assembled tabletop upside down onthe
padded work area,slide each leg down the slots of each cornerof
the table top as shown.
Table Leg
NOTE: All four legs need to be loose in order to
align the stretcher to each threaded boss in
step 6.
3. Locate the hardware pack included with the product. Hand-screw
each glide into the rivet nut at the base of each leg.
PEM® Stud

3
7/17/2019 Copyright 2019 ANOVA®Manufactured in the U.S.
Threaded Boss
Stretcher
6. Slide the stretcher into place making sure it’s aligned with all four legs.
8. Use a 5/32” Allen wrench to tighten the four 1/4”-20 x 1/2” button head socket
cap screws.
10. Tighten all four legs. Then carefully standthe table upright.
9. Use a ratchet with a 7/16” socket to fully tighten each 1/4” Nylock nut. The
aprons are adjustable and should alignwith the legs.
11. After two weeks, retighten all the hardware.
7. Place one 1/4” flat washer onto one 1/4”-20 x 1/2” button head socket cap
screw. Then insert the screw into the threaded boss as shown.
1/4”-20 x 1/2” Button Head
Socket Cap Screw
Flat Washer
NOTE: Please contact Customer Care at 1-866-797-1761 to receive assistance in placing a replacement part order.
Apron
Apron
