Anova F2022 User manual

Assembly Instructions
Component parts:
Hardware Needed:
Assembly:
1
Contact Us:
800.231.1327
[email protected]om
This assembly is a two-person operation.
1. Inspect the shipping container contents for damaged or missing components.
2. Lay all parts on a soft work surface or on the shipping packaging to prevent damage to nish.
NOTE: Before assembly, it is recommended that a light oil or petroleum jelly be applied to screw threads.
Tools Needed:
• Ratchet with 1/2” Socket
• 1/2” Open-end or Box-end Wrench
• Rubber Mallet
F2022 - 8’ ADA Rectangular Expanded Steel Table, Fusion Adv,
Portable Frame
ADA Table
(4) Table Supports
(1) Table Top (1) Long Seat Platform
(2) Short Seat Platforms (4) Cross Braces
(32) 5/16"-18 x 1 1/4"
Hex Head Bolts
(32) 5/16-18
Nylock Nuts
(64) 5/16 Flat
Washers (8) Rubber Feet

3.
4.
6. 6.
Assembly Instructions
ADA Table
2
3. Locate the table support and two rubber feet and
place them as shown.
4. Insert the two rubber feet into the bottom of the
table support. Use a rubber mallet if necessary.
5. Repeat steps 3 and 4 with the remaining table
supports and rubber feet.
6. Mount a table support to the table top by inserting
two hex head bolts and two at washers through
the mounting holes of the table support and table
top. Place a washer and nylock nut on each bolt
and tighten nger tight.
Repeat this step to attach the remaining table
supports.

7.
7.
7a.
8.
8.
Assembly Instructions
ADA Table
3
7. Mount a cross brace to a table support by inserting
one hex head bolt and at washer through the
mounting holes. Place a washer and nylock nut on
the end of the bolt and tighten nger tight.
Repeat this step to mount the remaining cross
braces on the other table supports
a. Align the two cross braces with the
mounting hole on the table top. Insert one
hex head bolt and at washer through the
mounting holes. Place a washer and nylock
nut on the end of the bolt and tighten nger
tight.
8. Mount the long seat platform to a table support by
inserting two hex head bolts and two at washers
through the mounting holes. Place a washer and
nylock nut on the end of each bolt and tighten
nger tight.
Repeat this step to mount the long seat platform
to the three remaining table supports.

9.
9.
Table Top
Long Bench Seat
Table Supports Cross Brace
Short Bench Seat
Assembly Instructions
ADA Table
4
• Furniture must not be used other than for its intended purpose and should be inspected regularly for loose, missing, or
broken hardware, and general instability
• Furniture that is damaged or appears to be unstable must be removed from service and repaired or replaced
• Repairs must be made using only factory authorized parts and methods.
WARNING
• Do not drag the assembled unit across any surface.
• This product requires only periodic cleaning with a sponge and a solution of mild detergent and water to remove surface
dirt. Do not clean with a solvent or petroleum based products.
CARE AND
MAINTENANCE
Note: Please contact Customer Care at 1-866-797-1761 when ordering replacement parts.
12/12/2022 Copyright 2022 Anova ® Manufactured in the U.S.
9. Mount a short seat platform to the table supports
by inserting two hex head bolts and two washers
through the mounting holes. Place a washer and
nylock nut on the end of each bolt and tighten
nger tight.
Repeat this step to mount the short seat platform
to the other table supports.
10. Turn the table upright and move it to desired
location.
