Anova PLK60T User manual

anovafurnishings.com
888.535.5005 tel
TOOLS NEEDED:
• 5/32" Allen Wrench
Assembly Instructions
Plank
PLK60T - Plank Chair with Armrests, Thermory
PLK60R - Plank Chair with Armrests, Recycled Plastic
COMPONENT PARTS:
ASSEMBLY HARDWARE: All hardware is stainless steel.
(1) Right Armrest
Subassembly
(10) 1.25" Stainless
Steel Button Head
Hex Drive Bolt
(1) Le Armrest
Subassembly
(1) Backrest
Subassembly
(1) Seat Frame
Subassembly
ASSEMBLY:
Inspect the shipping container contents for damage and to
determine that all components and hardware are present.
1.
2. Lay all parts on a so work surface or on the shipping
packaging to prevent damage to nish.
3. Locate the Right Armrest Subassembly and place it with
the outside facing down, as shown:
NOTE: Before assembling the nuts to the bolts, it is
recommended that a light oil or petroleum jelly be applied
to the screw threads.
1
Right Armrest Subassembly

2
4. Gather the Seat Frame Subassembly and three 1.25"
Stainless Steel Button Head Hex Drive Bolts. Align the
three holes of the Seat with the Armrest's and secure them
together with the three bolts.
6. Stand the lower portion of the chair on its feet and
locate the Backrest Subassembly. Place the Backrest
Subassembly into position, aligning the holes in the
armrests and seat frame with those in the backrest.
7. Secure the Backrest Subassembly to the rest of the chair
using four 1.25" Stainless Steel Button Head Hex Drive
Bolts.
5. Repeat step 4 with the Le Armrest Assembly.
Right Armrest Subassembly
Backrest Subassembly
Seat Frame Subassembly

1/5/2021 Copyright 2021 ANOVA® Manufactured in the U.S. 3
Note: Please contact Customer Care at 1-866-797-1761 when ordering replacement parts.
Right Armrest Subassembly
Le Armrest Subassembly
Backrest Subassembly
Seat Frame Subassembly
Replacement Parts
