Aqualisa Bath User manual

Bath
Overflow filler
Aqualisa Products Limited
The Flyer’s Way
Westerham Kent TN16 1DE
Customer helpline: 01959 560010
Brochure Hotline: [phone]
Website: www.aqualisa.co.uk
Email: [email protected]
Republic of Ireland
Sales enquiries: 01-864-3363
Service enquiries: 01-844-3212
Part No: 524001 Issue 01 Apr09
Please note that calls may be recorded for training and quality purposes
The company reserves the right to alter, change or modify the product specifications without prior warning
® Registered Trademark Aqualisa Products Limited
Installation guide

Bath overflow filler
Carefully unscrew and
remove the overflow
filler outlet from the
body assembly and
set aside.
1
The bath overflow filler is suitable for baths
up to a maximum thickness of 24mm.
Carefully unscrew
and remove the
bath waste clicker
assembly from the
waste body and
set aside.
2
Offer the bath waste
into position
ensuring the rubber
washer is correctly
aligned between the
waste assembly and
the bath base.
3
Ensuring the rubber
washer is correctly
aligned, pass the bath
waste clicker through
the bath and secure
to the waste body
assembly.
4
Connect the bath waste to a suitable
waste pipe.
Offer the outlet body
assembly into
position at the rear
of the bath ensuring
the rubber washer is
correct aligned
between the outlet
body assembly and
bath wall.
6
Ensuring the rubber
washer is correctly
aligned, pass the
overflow filler outlet
through the bath
and secure to the
body assembly.
7
Remove the relevant
inlet blanking plug
and attach the
flexible hose to the
blended inlet
connection.
8
!
This product must be installed by a competent
person in accordance with the current
Water Supply Regulations.
If an alternative bath outlet or bath spout
with hand shower combination is used, due to
the restrictive characteristics of some of these
products, outlet flow rate may be affected.
Aqualisa Products Ltd cannot guarantee outlet
flow rate if an alternative outlets solution
is used. Please refer to the manufacturer’s
installation guide for full fitting instructions.
Aqualisa Products Ltd reserves the right to
revoke the guarantee if an overhead shower
kit system is fitted with a bath controller.
This installation instruction sheet supersedes any
other overflow filler instructions that may be
provided with this product.
!
!
!
Literature not shown
Components
Waste pipe extension kit
5
If required, for larger baths, a 900mm
waste pipe conversion kit is available from
Aqualisa Customer Service department,
part number 477502.
Unscrew the clamping
nut and remove the
waste pipe from the
waste assembly.
!
1
Remove the clamping nut and sealing
washer from the waste pipe and set aside.
2
Carefully pull the
waste pipe away from
the outlet assembly.
3
Reassemble the unit using the longer waste
pipe by reversing the above procedure.
4
Connect the flexible hose to the blended
supply pipe ensuring suitable non
restrictive double check valves are fitted in
line with current Water Supply Regulations
(not supplied).
9
Bath overflow filler user guide
1 Push the waste cover to
engage the plug fitting.
2 Push the waste cover again
to disengage the plug fitting.
Cleaning
The bath overflow filler system should be cleaned
using only a soft cloth and washing up liquid.
DO NOT USE ABRASIVE CLEANERS.
DO NOT USE ABRASIVE CLEANERS.
