ARM ARM966E-S Use and care manual

Copyright © 2000 ARM Limited. All rights reserved.
ARM DDI 0186A
ARM966E-S
(Rev 1)
Technical Reference Manual

ii Copyright © 2000 ARM Limited. All rights reserved. ARM DDI 0186A
ARM966E-S
Technical Reference Manual
Copyright © 2000 ARM Limited. All rights reserved.
Release Information
Proprietary Notice
Words and logos marked with ®or ™are registered trademarks or trademarks of ARM Limited in the EU and
other countries, except as otherwise stated below in this proprietary notice. Other brands and names
mentioned herein may be the trademarks of their respective owners.
Neither the whole nor any part of the information contained in, or the product described in, this document
may be adapted or reproduced in any material form except with the prior written permission of the copyright
holder.
The product described in this document is subject to continuous developments and improvements. All
particulars of the product and its use contained in this document are given by ARM in good faith. However,
all warranties implied or expressed, including but not limited to implied warranties of merchantability, or
fitness for purpose, are excluded.
This document is intended only to assist the reader in the use of the product. ARM Limited shall not be liable
for any loss or damage arising from the use of any information in this document, or any error or omission in
such information, or any incorrect use of the product.
Where the term ARM is used it means “ARM or any of its subsidiaries as appropriate”.
Confidentiality Status
This document is Non-Confidential. The right to use, copy and disclose this document may be subject to
license restrictions in accordance with the terms of the agreement entered into by ARM and the party that
ARM delivered this document to.
Product Status
The information in this document is final, that is for a developed product.
Web Address
http://www.arm.com
Change history
Date Issue Change
31st July 2000 A First Release

ARM DDI 0186A Copyright © 2000 ARM Limited. All rights reserved. iii
Contents
ARM966E-S Technical Reference Manual
Preface
About this document ..................................................................................... xii
Further reading ............................................................................................. xv
Feedback ..................................................................................................... xvi
Chapter 1 Introduction
1.1 About the ARM966E-S ................................................................................ 1-2
1.2 Microprocessor block diagram .................................................................... 1-3
Chapter 2 Programmer’s Model
2.1 About the programmer’s model ................................................................... 2-2
2.2 About the ARM9E-S programmer’s model .................................................. 2-3
2.3 ARM966E-S CP15 registers ....................................................................... 2-4
Chapter 3 Memory Map
3.1 About the ARM966E-S memory map .......................................................... 3-2
3.2 Tightly-coupled SRAM address space ........................................................ 3-3
3.3 Bufferable write address space ................................................................... 3-4
Chapter 4 Tightly-coupled SRAM
4.1 ARM966E-S SRAM requirements ............................................................... 4-2
4.2 SRAM stall cycles ....................................................................................... 4-3

Contents
iv Copyright © 2000 ARM Limited. All rights reserved. ARM DDI 0186A
4.3 Enabling the SRAM .................................................................................... 4-4
4.4 ARM966E-S SRAM wrapper ...................................................................... 4-7
Chapter 5 Direct Memory Access (DMA)
5.1 About the DMA interface ............................................................................ 5-2
5.2 Timing interface .......................................................................................... 5-5
5.3 DMAENABLE setup and hold cycles ........................................................ 5-11
5.4 Summary of signal behavior ..................................................................... 5-12
Chapter 6 Bus Interface Unit
6.1 About the BIU and write buffer ................................................................... 6-2
6.2 Write buffer operation ................................................................................. 6-3
6.3 AHB bus master interface ........................................................................... 6-7
6.4 AHB clocking ............................................................................................ 6-17
Chapter 7 Coprocessor Interface
7.1 About the coprocessor interface ................................................................. 7-2
7.2 LDC/STC .................................................................................................... 7-4
7.3 MCR/MRC .................................................................................................. 7-8
7.4 Interlocked MCR ......................................................................................... 7-9
7.5 CDP .......................................................................................................... 7-10
7.6 Privileged instructions ............................................................................... 7-11
7.7 Busy-waiting and interrupts ...................................................................... 7-12
Chapter 8 Debug Support
8.1 About the debug interface .......................................................................... 8-2
8.2 Debug systems ........................................................................................... 8-4
8.3 ARM966E-S scan chain 15 ........................................................................ 8-7
8.4 Debug interface signals .............................................................................. 8-9
8.5 ARM9E-S core clock domains .................................................................. 8-14
8.6 Determining the core and system state .................................................... 8-15
8.7 About the EmbeddedICE-RT .................................................................... 8-16
8.8 Disabling EmbeddedICE-RT .................................................................... 8-18
8.9 The debug communications channel ........................................................ 8-19
8.10 Monitor mode debug ................................................................................. 8-23
8.11 Debug additional reading .......................................................................... 8-25
Chapter 9 Embedded Trace Macrocell Interface
9.1 About the ETM interface ............................................................................. 9-2
9.2 Enabling the ETM interface ........................................................................ 9-3
9.3 ARM966E-S trace support features ............................................................ 9-4
Chapter 10 Test Support
10.1 About the ARM966E-S test methodology ................................................. 10-2
10.2 Scan insertion and ATPG ......................................................................... 10-3
10.3 BIST of tightly-coupled SRAM .................................................................. 10-4

Contents
ARM DDI 0186A Copyright © 2000 ARM Limited. All rights reserved. v
Chapter 11 Instruction cycle timings
11.1 Introduction to instruction cycle timings .................................................... 11-2
11.2 When stall cycles do not occur .................................................................. 11-3
11.3 Tightly-coupled SRAM cycles ................................................................... 11-4
11.4 AHB memory access cycles ...................................................................... 11-6
11.5 Interrupt latency calculation .................................................................... 11-10
Appendix A Signal Descriptions
A.1 Signal properties and requirements ............................................................ A-2
A.2 Clock interface signals ................................................................................ A-3
A.3 AHB signals ................................................................................................ A-4
A.4 Coprocessor interface signals ..................................................................... A-6
A.5 Debug signals ............................................................................................. A-8
A.6 Miscellaneous signals ............................................................................... A-11
A.7 ETM interface signals ............................................................................... A-12
A.8 INTEST wrapper signals ........................................................................... A-14
A.9 DMA Signals ............................................................................................. A-15
Appendix B AC Parameters
B.1 Timing diagrams ......................................................................................... B-2
B.2 AC timing parameter definitions ................................................................ B-12
Appendix C SRAM Stall Cycles
C.1 About SRAM stall cycles ............................................................................ C-2

Contents
vi Copyright © 2000 ARM Limited. All rights reserved. ARM DDI 0186A

ARM DDI 0186A Copyright © 2000 ARM Limited. All rights reserved. vii
List of Tables
ARM966E-S Technical Reference Manual
Change history .............................................................................................................. ii
Table 2-1 CP15 register map .................................................................................................... 2-4
Table 2-2 Register 0, ID code ................................................................................................... 2-5
Table 2-3 Register 1, Control register ....................................................................................... 2-5
Table 2-4 Register 13, Trace process identifier ........................................................................ 2-9
Table 2-5 Register 15, Test register map .................................................................................. 2-9
Table 2-6 Trace control register .............................................................................................. 2-10
Table 2-7 BIST control register ............................................................................................... 2-10
Table 2-8 BIST size encoding examples ................................................................................. 2-11
Table 4-1 I-SRAM stall cycles ................................................................................................... 4-3
Table 5-1 Simultaneous access behavior ................................................................................. 5-3
Table 5-2 DMAENABLE setup and hold cycles with respect to DMAnREQ ............................ 5-11
Table 5-3 DMA signal behavior ............................................................................................... 5-12
Table 7-1 Handshake encoding ................................................................................................ 7-6
Table 8-1 Scan chain 15 addressing mode bit order ................................................................. 8-7
Table 8-2 Mapping of scan chain 15 address field to CP15 registers ....................................... 8-7
Table 8-3 Coprocessor 14 register map .................................................................................. 8-19
Table 10-1 Instruction BIST address and general registers ...................................................... 10-5
Table 10-2 Data BIST address and general registers ............................................................... 10-6
Table 11-1 I-SRAM access ....................................................................................................... 11-4
Table 11-2 D-SRAM access ...................................................................................................... 11-5
Table 11-3 Key to tables ........................................................................................................... 11-7
Table 11-4 AHB read and unbuffered write transfer cycles ....................................................... 11-7

List of Tables
viii Copyright © 2000 ARM Limited. All rights reserved. ARM DDI 0186A
Table 11-5 AHB buffered writes cycles ..................................................................................... 11-9
Table 11-6 Interrupt latency cycle summary ........................................................................... 11-10
Table 11-7 Interrupt latency calculated examples .................................................................. 11-11
Table A-1 Clock interface signals .............................................................................................. A-3
Table A-2 AHB signals .............................................................................................................. A-4
Table A-3 Coprocessor interface signals .................................................................................. A-6
Table A-4 Debug signals ........................................................................................................... A-8
Table A-5 Miscellaneous signals ............................................................................................. A-11
Table A-6 ETM interface signals ............................................................................................. A-12
Table A-7 INTEST wrapper signals ......................................................................................... A-14
Table A-8 DMA signals ............................................................................................................ A-15
Table B-1 AC parameters ........................................................................................................ B-12

ARM DDI 0186A Copyright © 2000 ARM Limited. All rights reserved. ix
List of Figures
ARM966E-S Technical Reference Manual
Key to timing diagram conventions ............................................................................ xiv
Figure 1-1 ARM966E-S block diagram ....................................................................................... 1-3
Figure 3-1 ARM966E-S memory map ........................................................................................ 3-2
Figure 3-2 I-SRAM aliasing example .......................................................................................... 3-3
Figure 4-1 SRAM read cycle ...................................................................................................... 4-2
Figure 4-2 ARM966E-S SRAM hierarchy ................................................................................... 4-7
Figure 4-3 ONESEGX32 interface .............................................................................................. 4-8
Figure 4-4 FOURSEGX32 interface ........................................................................................... 4-9
Figure 4-5 FOURSEGX8 interface ........................................................................................... 4-11
Figure 5-1 Single-port RAM DMA interface ................................................................................ 5-3
Figure 5-2 Dual-port RAM DMA interface ................................................................................... 5-4
Figure 5-3 Single-port RAM DMA reads ..................................................................................... 5-5
Figure 5-4 Single-port RAM DMA writes .................................................................................... 5-7
Figure 5-5 Dual-port DMA reads ................................................................................................ 5-8
Figure 5-6 Dual-port RAM DMA writes ....................................................................................... 5-9
Figure 5-7 Mixed DMA read and write ...................................................................................... 5-10
Figure 6-1 Write buffer FIFO content example ........................................................................... 6-4
Figure 6-2 Sequential instruction fetches, after being granted the bus ...................................... 6-8
Figure 6-3 Sequential instruction fetches, no AHB data access required .................................. 6-9
Figure 6-4 Back-to-back LDR, no external instruction access .................................................... 6-9
Figure 6-5 Simultaneous instruction and data requests ........................................................... 6-10
Figure 6-6 Single STM, no instruction fetch ............................................................................. 6-11
Figure 6-7 Single LDM, no instruction access .......................................................................... 6-12

List of Figures
xCopyright © 2000 ARM Limited. All rights reserved. ARM DDI 0186A
Figure 6-8 Single STM, followed by sequential instruction fetch .............................................. 6-13
Figure 6-9 Single LDM followed by sequential instruction fetch ............................................... 6-14
Figure 6-10 Single STM, crossing a 1KB boundary ................................................................... 6-15
Figure 6-11 Single LDM, crossing a 1KB boundary ................................................................... 6-15
Figure 6-12 SWP instruction ...................................................................................................... 6-16
Figure 6-13 AHB 3:1 clocking example ...................................................................................... 6-17
Figure 6-14 ARM966E-S CLK to AHB HCLK sampling ............................................................. 6-19
Figure 7-1 LDC/STC cycle timing ............................................................................................... 7-4
Figure 7-2 MCR/MRC transfer timing with busy-wait ................................................................. 7-8
Figure 7-3 Interlocked MCR/MRC timing with busy-wait ............................................................ 7-9
Figure 7-4 Late cancelled CDP ................................................................................................ 7-10
Figure 7-5 Privileged instructions ............................................................................................. 7-11
Figure 7-6 Busy-waiting and interrupts .................................................................................... 7-12
Figure 8-1 Clock synchronization ............................................................................................... 8-3
Figure 8-2 Typical debug system ............................................................................................... 8-4
Figure 8-3 ARM9E-S block diagram .......................................................................................... 8-5
Figure 8-4 Breakpoint timing .................................................................................................... 8-10
Figure 8-5 Watchpoint entry with data processing instruction .................................................. 8-11
Figure 8-6 Watchpoint entry with branch ................................................................................. 8-12
Figure 8-7 The ARM9E-S, TAP controller and EmbeddedICE-RT .......................................... 8-16
Figure 8-8 Debug communications channel status register ..................................................... 8-20
Figure 8-9 Coprocessor 14 debug status register format ......................................................... 8-21
Figure 9-1 ARM966E-S ETM interface ...................................................................................... 9-2
Figure B-1 Clock, reset and AHB enable timing ......................................................................... B-2
Figure B-2 AHB bus request and grant related timing ................................................................ B-3
Figure B-3 AHB bus master timing ............................................................................................. B-4
Figure B-4 Coprocessor interface timing .................................................................................... B-5
Figure B-5 Debug interface timing .............................................................................................. B-6
Figure B-6 JTAG interface timing ............................................................................................... B-7
Figure B-7 DBGSDOUT to DBGTDO timing .............................................................................. B-8
Figure B-8 Exception and configuration timing ........................................................................... B-8
Figure B-9 INTEST wrapper timing ............................................................................................ B-9
Figure B-10 ETM interface timing ............................................................................................... B-10
Figure B-11 DMA interface timing .............................................................................................. B-11
Figure C-1 SRAM write cycle ...................................................................................................... C-2
Figure C-2 Read follows write ..................................................................................................... C-3
Figure C-3 Simultaneous instruction fetch, data read ................................................................. C-4
Figure C-4 Data read from I-SRAM ............................................................................................ C-5
Figure C-5 Data read followed by instruction fetch ..................................................................... C-6
Figure C-6 Simultaneous instruction fetch, data write ................................................................ C-7
Figure C-7 I-SRAM data write followed by instruction fetch ....................................................... C-8
Figure C-8 I-SRAM write followed by instruction fetch, data write .............................................. C-9
Figure C-9 I-SRAM write followed by instruction fetch, data read ............................................ C-10

ARM DDI 0186A Copyright © 2000 ARM Limited. All rights reserved. xi
Preface
This preface introduces the ARM966E-S and its reference documentation. It contains
the following sections:
•About this document on page xii
•Further reading on page xv
•Feedback on page xvi.

Preface
xii Copyright © 2000 ARM Limited. All rights reserved. ARM DDI 0186A
About this document
This document is a reference manual for the ARM966E-S.
Intended audience
This document has been written for experienced hardware and software engineers who
might or might not have any experience of ARM products.
Using this manual
This document is organized into the following chapters:
Chapter 1 Introduction
Read this chapter for an introduction to the ARM966E-S.
Chapter 2 Programmer’s Model
Read this chapter for a description of the programmer’s model including
a summary of the ARM966E-S coprocessor registers.
Chapter 3 Memory Map
Read this chapter for a description of the ARM966E-S fixed memory
map implementation.
Chapter 4 Tightly-coupled SRAM
Read this chapter for a description of the requirements and operation of
the tightly-coupled SRAM.
Chapter 5 Direct Memory Access (DMA))
Read this chapter for a description of the optional DMA interface in the
ARM966E-S.
Chapter 6 Bus Interface Unit
Read this chapter for a description of the operation of the Bus Interface
Unit and write buffer.
Chapter 7 Coprocessor Interface
Read this chapter for a description of the coprocessor interface and the
operation of common coprocessor instructions.
Chapter 8 Debug Support
Read this chapter for a description of the debug support for the
ARM966E-S and the EmbeddedICE-RT logic.

Preface
ARM DDI 0186A Copyright © 2000 ARM Limited. All rights reserved. xiii
Chapter 9 Embedded Trace Macrocell Interface
Read this chapter for a description of the ETM interface, including details
of how to enable the interface.
Chapter 10 Test Support
Read this chapter for a description of the test methodology used for the
ARM966E-S synthesized logic and tightly-coupled SRAM.
Appendix A Signal Descriptions
Read this appendix for a description of the ARM966E-S signals.
Appendix B AC Parameters
Read this appendix for a description of the timing parameters applicable
to the ARM966E-S.
Appendix C SRAM Stall Cycles
Read this appendix for a description of the tightly-coupled SRAM stall
cycle mechanism in the ARM966E-S.
Typographical
The typographical conventions are:
italic Highlights important notes, introduces special terminology,
denotes internal cross-references, and citations.
bold Highlights interface elements, such as menu names. Denotes
signal names. Also used for terms in descriptive lists, where
appropriate.
monospace Denotes text that you can enter at the keyboard, such as
commands, file and program names, and source code.
monospace Denotes a permitted abbreviation for a command or option. You
can enter the underlined text instead of the full command or option
name.
monospace italic Denotes arguments to monospace text where the argument is to be
replaced by a specific value.
monospace bold Denotes language keywords when used outside example code.

Preface
xiv Copyright © 2000 ARM Limited. All rights reserved. ARM DDI 0186A
< and > Angle brackets enclose replaceable terms for assembler syntax
where they appear in code or code fragments. They appear in
normal font in running text. For example:
•
MRC p15, 0 <Rd>, <CRn>, <CRm>, <Opcode_2>
• The Opcode_2 value selects which register is accessed.
Timing diagram conventions
This manual contains a number of timing diagrams. The following key explains the
components used in these diagrams. Any variations are clearly labeled when they occur.
Therefore, no additional meaning should be attached unless specifically stated.
Key to timing diagram conventions
Shaded bus and signal areas are undefined, so the bus or signal can assume any value
within the shaded area at that time. The actual level is unimportant and does not affect
normal operation.
Clock
Bus stable
HIGH to LOW
Transient
Bus to high impedance
Bus change
HIGH/LOW to HIGH
High impedance to stable bus
Valid (correct) sampling point

Preface
ARM DDI 0186A Copyright © 2000 ARM Limited. All rights reserved. xv
Further reading
This section lists publications by ARM Limited, and by third parties.
If you would like further information on ARM products, or if you have questions not
answered by this document, please contact
[email protected] or visit our web site at
http://www.arm.com .
ARM publications
ARM Architecture Reference Manual (ARM DDI 0100).
ARM9E-S Technical Reference Manual (ARM DDI 0165).
AMBA Specification Rev 2.0 (ARM IHI 0011).
AHB Example AMBA System Technical Reference Manual (ARM DDI 0170).
Other publications
IEEE Std. 1149.1- 1990, Standard Test Access Port and Boundary-Scan Architecture.

Preface
xvi Copyright © 2000 ARM Limited. All rights reserved. ARM DDI 0186A
Feedback
ARM Limited welcomes feedback both on the ARM966E-S, and on the documentation.
Feedback on the ARM966E-S
If you have any comments or suggestions about this product, please contact your
supplier giving:
• the product name
• a concise explanation of your comments
Feedback on the ARM966E-S
If you have any comments about this document, please send e-mail to
[email protected]
giving:
• the document title
• the document number
• the page number(s) to which your comments refer
• a concise explanation of your comments.
General suggestions for additions and improvements are also welcome.

ARM DDI 0186A Copyright © 2000 ARM Limited. All rights reserved. 1-1
Chapter 1
Introduction
This chapter introduces the ARM966E-S processor. It contains the following sections:
•About the ARM966E-S on page 1-2
•Microprocessor block diagram on page 1-3.

Introduction
1-2 Copyright © 2000 ARM Limited. All rights reserved. ARM DDI 0186A
1.1 About the ARM966E-S
The ARM966E-S is a synthesizable macrocell combining an ARM processor with
tightly-coupled SRAM memory. It is a member of the ARM9 Thumb family of
high-performance, 32-bit System-on-Chip (SoC) processor solutions and is targeted at
a wide range of embedded applications where high performance, low system cost, small
die size, and low power are all important.
The ARM966E-S processor macrocell provides a complete high-performance
processor subsystem, including an ARM9E-S RISC integer CPU, tightly-coupled
SRAM for each of the instruction and data CPU interfaces, write buffer and an AMBA
AHB bus interface. Providing this complete high-frequency subsystem frees the SoC
designer to concentrate on design issues unique to their system. The synthesizable
nature of the device eases integration into ASIC technologies.
The tightly-coupled SRAMs within the ARM966E-S macrocell allow high-speed
operation without incurring the performance and power penalties of accessing the
system bus, while having a lower area overhead than a cached memory system. The size
of both the instruction and data SRAM are implementor-configurable to allow tailoring
of the hardware to the embedded application. Additionally, You can configure the data
SRAM interface to allow Direct Memory Access (DMA) to this RAM.
The ARM9E-S core within the ARM966E-S macrocell executes both the 32-bit ARM
and 16-bit Thumb instruction sets, allowing trade off between high performance and
high code density. Additionally the ARM9E-S features:
• ARMv5T 32-bit instruction set with improved ARM/Thumb code interworking
and enhanced multiplier designed for improved DSP performance
• ARM debug architecture with additional support for real-time debug, which
allows critical exception handlers to execute while debugging the system.
The ARM966E-S includes support for external coprocessors allowing floating point or
other application-specific hardware acceleration to be added.
To minimize die size and power consumption the ARM966E-S does not provide virtual
to physical address mapping as this is not required by most embedded systems. A
simple fixed memory map is implemented for the close-coupled local RAM, ideally
suited to small, fast, real-time embedded control applications.
The ARM966E-S synthesizable implementation supports the use of a scan test
methodology for the standard cell logic and Built-In-Self-Test (BIST) for the
tightly-coupled SRAM.

Introduction
ARM DDI 0186A Copyright © 2000 ARM Limited. All rights reserved. 1-3
1.2 Microprocessor block diagram
The ARM966E-S block diagram is shown in Figure 1-1.
Figure 1-1 ARM966E-S block diagram
ARM9E-S
Instruction
SRAM
Data
SRAM System control
coprocessor
(CP15)
External
coprocessor
interface
AHB
Bus Interface Unit
and write buffer
System
controller
ETM
interface
IA DA
WDATA
RDATAINSTR
Addr Din Addr Din
Dout Dout
DMA
interface
AHB Peripherals
DMA Controller
ETM
Coprocessors

Introduction
1-4 Copyright © 2000 ARM Limited. All rights reserved. ARM DDI 0186A
