Arris Ruckus T310n User manual

Unleashed T310n Access
Point
Quick Setup Guide
This Quick Setup Guide provides step-by-step instructions on
how to field-install the Ruckus Unleashed T310n access point
(AP). For detailed information on planning the installation,
performing a site survey, and operating the T310n, refer to the
Ruckus Wireless Outdoor Access Point User Guide , available
at https://support.ruckuswireless.com.
WARNING! Only trained and qualified personnel should be
allowed to install, replace, or service this equipment.
WARNING! Installation of this equipment must comply with
local and national electrical codes.
CAUTION! Make sure that you form a 80mm - 130mm
(3”-5”) drip loop in any cable that is attached to the AP or
the building. This will prevent water from running along the
cable and entering the AP or the building where the cable
terminates.
CAUTION! Be sure that grounding is available and that it
meets local and national electrical codes. For additional
lightning protection, use lightning rods and lightning
arrestors.
CAUTION! Make sure that proper lightning surge protection
precautions are taken according to local electrical code.
WARNING! Ruckus Wireless strongly recommends that you
wear eye protection before mounting the T310n.
This Guide in Other Languages
•请从以下网站获得该指南的简体中文版 https://
support.ruckuswireless.com.
• Vous trouverez la version française de ce guide à l'adresse
suivante https://support.ruckuswireless.com.
•このガイドの日本語版は https://
support.ruckuswireless.com でご覧ください。
•이가이드의 한국어 버전은 웹사이트 (https://
support.ruckuswireless.com) 에서 확인하시기 바랍니다.
• Veja a versão em português (Brasil) deste guia em https://
support.ruckuswireless.com.
• Puede ver la versión en español (América Latina) de esta
guía en https://support.ruckuswireless.com.
Before You Begin
Before deploying Ruckus Wireless products, please check for
the latest software and the release documentation.
• Release Notes and other user documentation are available
at http://support.ruckuswireless.com/documents.
• Software upgrades are available at http://
support.ruckuswireless.com/software.
• Open source information is available at http://
opensource.ruckuswireless.com.
• Software license and limited warranty information are
available at http://support.ruckuswireless.com/warranty.
Before deploying your Ruckus Wireless Access Point, verify
that all items listed in Package Contents are included in the
package. If any item is damaged or missing, notify your
authorized Ruckus Wireless sales representative. Also,
make sure that you have the required hardware and tools.
Required Hardware and Tools
Prepare the following before starting this procedure:
• No. 2 Phillips screwdriver
• Small flat-blade screwdriver
• Torque wrench or torque screwdriver with sockets
• Long-nose pliers
• Electrical wire stripping and terminal crimping pliers
• Pipe or pole --OR-- a sturdy flat surface
• Electric drill with drill bits and customer-supplied wall
anchors, flat washers, and hex nuts for flat-surface mount
Package Contents
A complete T310n field installation package includes all of the
items listed below (see Figure below for illustrations):
• T310n Access Point (A)
• M25 data cable gland (B)
• Ground wire with lug (C)
• Pole/Wall Mount Bracket Kit (D)
• Four steel pipe clamps
• Service Level Agreement/Limited Warranty Statement
• Declaration of Conformity
• Regulatory Statement
• Ruckus Wireless AP Getting Started Guide
• DC Power Supply Installation Guide
• This Quick Setup Guide
FIGURE 1 T310n Package Contents
T310n Sector Antenna Coverage
The T310n 30-Degree Narrow Sector AP is best deployed
where internal-antenna narrow beamwidths can provide
exceptional coverage to a narrow sector, or can support
extended reach in a point-to-point deployment. See the
following illustrations for typical internal-antenna coverage
patterns and high-density narrow-sector coverage pattern.
FIGURE 2 Typical AP narrow sector or point-to-point coverage
Copyright ©2018 ARRIS Enterprises LLC. All rights reserved. Page 1 of 4
Published March 2018, Part Number 800-71728-001 Rev A

FIGURE 3 Typical AP high-density narrow-sector coverage
Unleashed Network Configuration
Setup Using the Unleashed Mobile App
To perform setup using the Unleashed Mobile App, download
the iOS or Android app from the app store.
1. As soon as the Unleashed AP is powered on and
connected to the local network, it boots up and begins
broadcasting a temporary unencrypted WLAN named
“Configure.Me-[xxxxxx]” from both radios.
2. Using your client’s Wi-Fi connection settings, select and
associate to the “Configure.Me-[xxxxxx]” WLAN.
3. Launch the app, and follow the on-screen instructions to
configure your Unleashed network(s).
FIGURE 4 Unleashed Mobile App for iOS and Android
FIGURE 5 Configuring Unleashed from the Mobile App
Setup Using a Web Browser
1. As soon as the Unleashed AP is powered on and
connected to the local network, it boots up and begins
broadcasting a temporary unencrypted WLAN named
“Configure.Me-[xxxxxx]” from both radios.
2. Using your client’s Wi-Fi connection settings, select and
associate to the “Configure.Me-[xxxxxx]” WLAN.
3. Launch a web browser and enter the following into the
browser’s URL bar: unleashed.ruckuswireless.com , and
press Enter.
4. You will be redirected to the Setup Wizard. Complete the
steps in the Setup Wizard and click Finish.
FIGURE 6 Complete the Setup Wizard to set up your Unleashed network
5. Once the Setup Wizard is finished, a “Configuring system
settings and rebooting” progress screen appears. Wait
until the process is complete.
6. Connect to the WLAN that you configured in the Setup
Wizard, and click OK to reconnect. You will be redirected
to the Unleashed login screen.
7. Enter your Admin Name and Password to login.
FIGURE 7 The Login page
8. Upon successful login you will be presented with the
Unleashed Dashboard, which displays an overview of your
Ruckus Unleashed network.
Mounting Instructions
Connecting And Sealing the RJ-45 Cables
Connect and seal the RJ-45 cable(s) using the M25 data
cable glands shown in the Figure below.
WARNING! Do not use any PoE injector not tested and
approved by Ruckus Wireless to power the T310n Access
Point.
FIGURE 8 T310n LEDs and Ports
1. Feed the end of the cable through the sealing nut, rubber
O-ring, clamping ring assembly and cable gland base as
shown.
NOTE: Do not seat the clamping ring and rubber O-ring
into the gland body until the gland body has been
torqued to spec.
Copyright ©2018 ARRIS Enterprises LLC. All rights reserved. Page 2 of 4
Published March 2018, Part Number 800-71728-001 Rev A

FIGURE 9 RJ-45 cable and cable gland assembly
2. Use a wide flat-blade screwdriver to remove the required
(PoE IN) blanking cap from the AP.
3. Connect the cable to the Ethernet port on the AP.
4. Tighten the cable gland base into the AP chassis to 7 N.m
or 62 in-lbs.
5. Wrap the clamping ring assembly around the rubber O-
ring. Make sure that the clamping ring assembly fully
encloses the rubber O-ring.
6. Seat the clamping ring assembly and rubber O-ring in the
cable gland base.
7. Hand-tighten the sealing nut.
Attaching the U-Joint Bracket to the Mounting
Bracket
1. Position the U-joint bracket on the mounting bracket.
NOTE: Mount the U-joint bracket in any direction on the
mounting bracket, preferably to allow AP azimuth
adjustments. Then the AP bracket allows AP elevation
adjustments.
FIGURE 10 U-joint bracket attached horizontally to the mounting
bracket
2. Use four 1/4-28 bolt and washer sets (A) to mount the U-
joint bracket (B) to the mounting bracket (C). Tighten the
bolts to 9.5 N.m (7 ft-lbs).
3. Continue with Attaching the Mounting Bracket to a Flat
Surface or Attaching the Mounting Bracket to a Pole .
Attaching the Mounting Bracket to a Flat Surface
1. Place the mounting bracket at the location on the flat
surface where you want to mount the AP. Use the holes
on the mounting bracket as a template to mark the
locations of the mounting holes.
FIGURE 11 Mounting bracket flat surface holes
2. Remove the mounting bracket from the flat surface.
3. Drill holes required for the mounting hardware.
NOTE: The hardware required for mounting to a wall
are not included in the mounting kit.
4. Attach the mounting bracket to the flat surface using the
mounting hardware.
5. Using the mounting hardware instructions, tighten the
hardware to secure the mounting bracket.
6. Continue with Mounting the Linkage Bracket to the U-
Joint Bracket .
Attaching the Mounting Bracket to a Pole
1. Insert the open end of one steel clamp into the upper two
slots on the mounting bracket.
2. Take the other steel clamp and insert it into the lower two
slots on the mounting bracket.
NOTE: The clamps can be daisy-chained together to
accommodate larger poles.
3. Use the clamps to attach the mounting bracket to the
pole. Tighten the clamps to 3 N.m or 27 in-lbs, or per
manufacturer’s specifications.
FIGURE 12 Attaching the mounting bracket to a vertical pole
4. Continue with Mounting the Linkage Bracket to the U-
Joint Bracket .
Mounting the Linkage Bracket to the U-Joint
Bracket
1. The linkage bracket attaches to the U-joint bracket using
an M8 bolt and washer set. The linkage bracket is
symmetrical, and either end can be attached to the U-joint
bracket.
NOTE: Make sure that linkage bracket is installed with
its serrated external-tooth lock washer on the inside of
the U-joint bracket flanges. This ensures that the
azimuth adjustment does not change.
2. Loosely assemble the linkage bracket (A), the U-joint
bracket (C), one serrated external-tooth lock washer (B),
and one M8 bolt and washer set (D).
FIGURE 13 Attaching the linkage bracket to the U-joint bracket
3. Set the azimuth required by the AP.
4. Tighten the M8 bolt to 13.6 N-m (10 ft-lbs).
5. Continue with Attaching the AP Bracket to the Linkage
Bracket .
Copyright ©2018 ARRIS Enterprises LLC. All rights reserved. Page 3 of 4
Published March 2018, Part Number 800-71728-001 Rev A

Attaching the AP Bracket to the Linkage Bracket
Attach the AP bracket to the linkage bracket using the
included bolt, lock washer, flat washer, serrated external-tooth
washer and nut shown in the illustration below.
The linkage bracket is symmetrical, and either end can be
attached to the AP bracket.
Loosely assemble the AP bracket to the linkage bracket
using the M8 bolt, washer and nut set.
FIGURE 14 Attach the linkage bracket to the AP bracket
NOTE: Make sure that the linkage bracket is installed
with its serrated external-tooth lock washer on the
inside of the AP bracket flanges. This ensures that the
elevation adjustment does not change.
Attaching the AP Bracket to the Access Point
1. Place the AP bracket onto the back side of the AP so that
the four larger screw holes on the bracket align with the
four screw holes on the AP.
FIGURE 15 Attaching the AP bracket to the AP
2. Use four 0.5-inch x 0.250-28 hex bolts with split lock and
flat washer sets to mount the AP bracket to the AP.
Tighten the bolts to 2.5-3.0 N.m or 22-27 in-lbs.
CAUTION! Make sure that the screws are no longer
than 0.5 inch. If a screw is longer than 0.5 inch, it can
damage the AP chassis.
NOTE: This kit may include extra screws, nuts and
washers. You may use the extras where required.
3. Continue with Set the Elevation and Tighten Elevation
Bolt .
Set the Elevation and Tighten the Elevation Bolt
1. Set the elevation required by the AP.
2. Tighten the M8 bolt to 13.6 N-m (10 ft-lbs).
3. Continue with Powering the AP with DC .
Powering the AP with DC
1. Install the DC power supply as described in the DC Power
Supply Installation Guide .
2. Connect the power cord to a DC power source.
3. Verify that the PWR LED is a steady green.
Installing a USB Dongle
To install a USB dongle (such as an IoT radio device such as
BLE, 802.15.4, Z-wave or similar), remove the two 3mm hex
screws, remove the cap, and insert the dongle into the USB
port.
Once installed, replace the cap and the hex screws, and
torque the screws to 7 in-lbs (0.79 N.m).
NOTE: If required, a larger USB dongle cap can be
purchased separately. The maximum dimensions of the
USB dongle that can be inserted (with the large USB
dongle cap, part # 902-0127-000) are 6 cm x 2 cm x 1.1
cm. Max Power: 450mW (SiLabs EM3578 max current
draw at +20 dBm is 80mA over a 3.3V rail).
FIGURE 16 Installing a USB dongle
Ruckus, Ruckus Wireless, the Ruckus logo, and the Big Dog design are
trademarks of Ruckus Wireless, Inc., a wholly owned subsidiary of ARRIS
International plc. ARRIS is a trademark of ARRIS Enterprises LLC. All other
trademarks are the property of their respective owners.
Copyright ©2018 ARRIS Enterprises LLC. All rights reserved. Page 4 of 4
Published March 2018, Part Number 800-71728-001 Rev A
