Advanced Redundant Control
System (ARCS)
Direct Acting Platform
-141 Series
Safety Manual for Safety Integrated system

Page 2of 24 IM-IND-536661-Rev AA
No. 57, Kundrathur Main Rd., Gerugambakkam, Chennai -6000128, India www.asco.com
TABLE OF CONTENTS
1INTRODUCTION.........................................................................................................................3
1.1 TERMS AND ABBREVIATIONS................................................................................................3
1.2 ACRONYMS ........................................................................................................................3
1.3 PRODUCT SUPPORT............................................................................................................4
1.4 RELATED LITERATURE.........................................................................................................4
1.5 REFERENCE STANDARDS ....................................................................................................4
2ARCS DIRECT ACTING DESCRIPTION ........................................................................................4
2.1 REDUNDANT CONFIGURATIONS............................................................................................4
2.2 REDUNDANT FUNCTIONS.....................................................................................................4
3DESIGNING A SAFETY INSTRUMENTED FUNCTION USING AN ASCO ARCS.................................5
3.1 SAFETY FUNCTION..............................................................................................................5
3.2 ENVIRONMENTAL LIMITS ......................................................................................................5
3.3 APPLICATION LIMITS............................................................................................................5
3.4 DESIGN VERIFICATION ........................................................................................................5
3.5 SIL CAPABILITY..................................................................................................................5
3.5.1 SYSTEMATIC INTEGRITY ................................................................................................5
3.5.2 RANDOM INTEGRITY......................................................................................................6
3.5.3 SAFETY PARAMETERS...................................................................................................6
3.6 CONNECTION OF THE ARCS TO THE SIS LOGIC-SOLVER .......................................................6
3.7 GENERAL REQUIREMENTS...................................................................................................6
4INSTALLATION AND COMMISSIONING ..........................................................................................7
4.1 INSTALLATION.....................................................................................................................7
4.2 PHYSICAL LOCATION AND PLACEMENT .................................................................................7
4.3 ELECTRICAL CONNECTIONS.................................................................................................7
4.4 PNEUMATIC CONNECTIONS..................................................................................................7
5OPERATION AND MAINTENANCE ................................................................................................8
5.1 MODES OF OPERATION .......................................................................................................8
5.1.1 1OO2WITHOUT ONLINE MAINTENANCE &WITHOUT DIAGNOSTIC.......................................8
5.1.2 1OO2WITH COMMON BYPASS &WITHOUT DIAGNOSTIC ....................................................8
5.1.3 2OO2WITHOUT ONLINE MAINTENANCE &WITHOUT DIAGNOSTIC.....................................10
5.1.4 2OO2WITHOUT ONLINE MAINTENANCE &WITH DIAGNOSTIC...........................................11
5.1.5 2OO2WITH COMMON BYPASS AND WITH DIAGNOSTIC.....................................................12
5.1.6 2OO2WITH INDIVIDUAL ISOLATION AND WITH DIAGNOSTIC ..............................................13
5.1.7 2OO3WITHOUT ONLINE MAINTENANCE &WITHOUT DIAGNOSTIC.....................................14
5.1.8 2OO3WITHOUT ONLINE MAINTENANCE &WITH DIAGNOSTIC...........................................16
5.1.9 2OO3WITH INDIVIDUAL ISOLATION AND WITH DIAGNOSTIC ..............................................18
5.1.10 2OO3WITH COMMON BYPASS AND WITH DIAGNOSTIC.....................................................20
5.2 OPERATOR INTERFACE OPTIONS .......................................................................................22
5.3 ADT -OPTIONAL ..............................................................................................................23
5.3.1 STATE VERIFICATION TEST..........................................................................................23
5.4 REPAIR AND REPLACEMENT ...............................................................................................23
5.5 ASCO NOTIFICATION........................................................................................................23
6STATUS OF THE DOCUMENT.....................................................................................................23
6.1 RELEASES .......................................................................................................................23
APPENDIX A–SIS CHECKLIST......................................................................................................24
