Asoni CAM417-PoE User manual

Network Camera
CAM417 / CAM417-PoE
User’s Manual
Date: 7/02/2010
Firmware Version: V3.2.70

1
Content
Content ........................................................................................................................................1
1. Preface .................................................................................................................................2
2. Product Specifications...........................................................................................................2
3. Product Installation ...............................................................................................................4
A. Hardware Installation.........................................................................................................4
B. Monitor Setting..................................................................................................................7
C. IP Assignment ...................................................................................................................8
4. Live Video...........................................................................................................................10
5. Configuration ......................................................................................................................15
A. System............................................................................................................................15
B. Video/Audio Setting.........................................................................................................22
C. Network Setting...............................................................................................................29
D. Event Handling................................................................................................................35
6. Network Configuration ........................................................................................................46
A. Intranet Only....................................................................................................................46
B. Internet Only....................................................................................................................48
C. Intranet + Internet............................................................................................................51
7. Factory Default ...................................................................................................................54

2
1. Preface
This camera is a professional CCD network camera which builds in web server. User
views real-time video via IE browser. It supports MPEG-4 & M-JPEG video compression
which provides smooth and high quality video. The recorded video file can be can be
playback remotely using Microsoft Media Player.
The PoE model built-in support for Power over Ethernet allows the camera to receive both
data and power over a single Ethernet cable.
This camera is an easy-to-use IP camera which is designed for security application.
2. Product Specifications
MPEG-4 / MJPEG compression formats. Supports resolution up to 30/25 fps @ Full
D1 (720x480 / 720x576)
MPEG-4 / MJPEG dual streaming.
Self-Contained HTTP Web Server providing Internet capability for remote access
Built-in PoE splitter, support for Power over Ethernet (PoE model)
2-way audio
Online firmware upgrade
Recorded files compatible with Microsoft Windows Media Player
Hardware
CPU / RAM / ROM ARM 9, 32 bit RISC / 64MB RAM / 8MB ROM
Image Sensor 1/3" Sony CCD
Lens Fixed Lens, Focal length 6 mm, F1.6
Illumination 0.05 lux
Lens Changeable Yes, CS Mount
Support DC IRIS Yes
Video Out 1 Analog video out (BNC connector)
Audio In Built-in microphone
Audio Out 1 Line out (RCA connector)
Digital I/O 2 In / 2 Out
Power Supply Normal model: DC 12V, 1A
PoE model (built-in PoE Splitter):

3
Use PoE: PoE Injector (IEEE 802.3af)
Or, use Power Adaptor: DC 12V, 1A
Power Consumption Max. 5 Watt
Dimensions W69 x H60 x D151 mm
Network
Ethernet 10/ 100 Base-T
Network Protocol HTTP, TCP/IP, RTP/RTSP, 3GPP, NTP, SMTP, FTP, PPPoE, DHCP, DDNS, UPnP
System
Video Resolution NTSC: 720x480, 704x480, 352x240, 176x120
PAL: 720x576, 704x576, 352x288, 176x144
Compression Format MPEG-4, MJPEG
Frame Rate Up to 30 FPS
Dual Streaming Yes
3GPP Yes, Live view with 3G mobile phone
Video Bitrate Adjustment CBR, VBR
Video Adjustment Brightness, Contrast, Saturation, Hue, AES, BLC, AGC
Image Snapshot Yes
Motion Detection Yes, 3 different areas
Event Trigger Motion Detection, Digital In
Triggered Action Send Email, Send to FTP, Digital Out
Pre/ Post Alarm Yes, configurable
Security Password protection
Firmware Upgrade HTTP mode, can be upgraded remotely
Connection Up to 10 clients simultaneously
Audio Yes, 2-way
Web browsing requirement
OS Windows 2000, XP, Vista, Windows 7
Web Browser Microsoft IE V7.0 or above, Mozilla Firefox V5.0 or above, Opera V10 or
above, Safari V4.0.5 or above, Google Chrome V5.0 or above
Suggested Hardware Intel-C 2.0G, RAM: 512MB
Graphic card: 64MB onboard RAM
* Specifications are subject to change without notice

4
3. Product Installation
A. Hardware Installation
Cable Connections
Network Connector: The RJ-45 connector allows connect the Ethernet cable.

Power Jack:
To connect the included power adapter.
Audio Out: The RCA connector allows connect to an amplified speaker,
you can hear the voice of the remote site from the speaker.
Video Out: The BNC connector allows connect to the analog display to
output analog video for locally monitoring.
Digital I/O: Digital In and Digital Out.
Video Level: To adjust the video level.
1. Connect the cable of Digital I/O, Video output, and Audio output if you want to use
these functionalities.
2. Connect Ethernet cable for network connection.
3. Connect power adapter to turn on the camera.







5
4. If the camera is PoE model, the power adapter is not necessary. The camera will get
the power from the Ethernet cable. Please follow the below figure for the connection.
5. Set up the network configurations according to the network environment. For further
explanation, please refer to Network Configuration chapter.
I/O Connections
12V
GND

Digital Input 1

Digital Input 2
Digital Output 1
Digital Output 2
D-

D+
I/O connector – used in application, for e.g., motion detection, event triggering, alarm
notifications. It provides the interface to:
2 sets of Digital Input (Digital In + GND) – The digital inputs for connecting devices
that can toggle between an open and closed circuit, such as PIRs, door/window
contacts, glass break detectors, etc. When a signal is received the status changes
and the input becomes active.
2 sets of Digital Output (Digital Out + GND) – The output to Relay Box or Relay
Board, and switch on the alarm device such as LEDs, Sirens, etc.
PoE Switch or PoE Injector
Ethernet Cable
Data only
Ethernet Cable
Mixed data and power
PoE Network Camera
To Network

6
Digital Input (Alarm Input)
GND (Ground): Initial status is LOW.
Digital In:Max. 50mA, 12VDC.
Digital Output (Alarm Output)
Door/Window
Contacts
Relay Board
or
Relay Box
Digital IN 1
Digital IN 2
Digital OUT 2
Digital OUT 1

7
B. Monitor Setting
1. Right-Click on the desktop. Select “Properties”
2. Change color quality to “Highest (32bit)”.

8
C. IP Assignment
Always consult your network administrator before assigning an IP address to your
camera in order to avoid using a previously assigned IP address.
MACAddress: Each network camera has a unique Ethernet address (MAC address)
shown on the sticker of the camera.
One final note, although the IP Search is able to find and configure any network
camera on the LAN except those that are behind a router, it is a good idea to set the
host PC to the same subnet. In order to connect to the Web-based user interface of
the network camera, the host PC must be in the same subnet. For more information
about subnets, please consult your network administrator.
There are 3 kinds of IP configuration:
Fixed IP (Public IP or Virtual IP)
DHCP (Dynamic IP)
Dial-up (PPPoE)
IP Search is a utility that provides an easier, more efficient way to configure the IP
address and network settings of the network camera in Local Network (LAN). It even
provides a convenient way to set the network settings for multiple devices simultaneously.
Moreover, IP Search can save the network settings for all devices as a backup and
restore them when necessary.
The software can be installed from the attached software CD.
1. Once IP Search has been successfully installed on the computer, double click the
“IP Search” icon on the desktop.

 





9
2. IP Search searches all the network devices which connect to the intranet and lists
on the window. Click [Search] button to search again.
3. From the list, select the device with the MACAddress that corresponds to the
device that is to be configured.
4. Click and select one of the network devices, the network configuration of this device
will show on the bottom, filling in the IPAddress, Subnet Mask, Gateway and the
others.
5. Click [Set] button to complete the configuration settings and save into the device.
6. Wait for 1 minute to let the device update the settings, and then click [Search]
button again to re-search the network devices.
7. Click and select the network device listed on the window and click [Open Web]
button. It will open an IE browser and connect to this device directly.
8. You can assign a name to identify the device. Type the name in “Device Name” field,
click [Save] and then click [Search] button, the name will be displayed in the list.
