Assa Abloy Yale Conexis L1 User manual

smart
Living
The smarter way to protect your home•
Sync Module

2

3
Thank you for purchasing the
Yale Sync module. The process
of pairing your lock to the Sync
Alarm System is broken down
into the following 3 steps:
Inserting the Module
Put the Alarm into learning
Mode
Put the Lock into learning
Mode
On each of these steps please
follow the instructions for your
smart door lock.

4
Contents
1. Inserting the module
Conexis L1 5
Keyless Connected 7
Keyfree Connected 8
Inserting the Module 8
2. Put the Alarm into learning
mode 9
3. Put Lock into learning
mode
Conexis L1 10
Keyless Connected &
Keyfree Connected 11
Help & Support 12

5
Conexis®L1
1. Inserting the module
Remove the batteries
(21)
Press “R”
3 times
“Connecting to a home automation system is a two way process and may require the
compatible home automation system to be configured to look for a new device, please
consult the manual that came with the system for more information.
Pairing with a third party gateway.
3
1
2
1
3
2
Insert
Connection
Module

6
Insert the radio module
(21)
Press “R”
3 times
“Connecting to a home automation system is a two way process and may require the
compatible home automation system to be configured to look for a new device, please
consult the manual that came with the system for more information.
Pairing with a third party gateway.
3
1
2
1
3
2
Insert
Connection
Module
Re-insert the batteries
(21)
Press “R”
3 times
“Connecting to a home automation system is a two way process and may require the
compatible home automation system to be configured to look for a new device, please
consult the manual that came with the system for more information.
Pairing with a third party gateway.
3
1
2
1
3
2
Insert
Connection
Module

RR
Insert the module
Remove the batteries
Keyless Connected
RR
Re-insert batteries
Re-insert the batteries
7

Keyfree Connected
Inserting the Module

Remove the batteries

Insert the module


Re-insert batteries
Keyfree Connected
Inserting the Module

Remove the batteries

Insert the module


Re-insert batteries
Keyfree Connected
Re-Insert batteries
Insert the module
Remove the batteries
Keyfree Connected
Inserting the Module

Remove the batteries

Insert the module


Re-insert batteries
8

2. Put the Alarm into learning
mode
(This step is the same for all Smart
Door Locks)
On the Yale Home App, go to the
app menu (top left corner)
Select add device.
Follow the instructions on the app.
When learning mode is activated
on the alarm, please follow the
instructions for your lock in section 3
of this manual.
9

3. Put lock into Learning Mode
Conexis L1
Make sure the sync Alarm is in
leaning mode.
Press the R button on the lock 3
times quickly (within 1.5 seconds)
You will hear a fanfare sound from
the lock and the alarm panel will
beep twice.
Follow the on screen instructions
to complete the process.
10

11
Keyless Connected & Keyfree
Connected
Make sure Sync alarm is in learning
mode.
Enter the Master code on the lock,
followed by #
Press the 4 button, followed by #
Press the 1 button followed by #
You will hear a fanfare sound from
the lock and the alarm panel will
beep twice.
Follow the on screen instructions to
complete the process.

The smarter way to protect your home•
smart
Living
Help & Support
For Help & Support please visit
www.yale.co.uk/help
Hereby, ASSA ABLOY Ltd, School
Street, WV13 3PW declares that the
Sync Module is in compliance with
Directive 2014/53/EU. The full text
of the EU declaration of conformity
is available at the following
internet address: www.yale.co.uk/
declaration-of-conformity
