Barska AX11644 User manual

User Manual for Biometric
Fingerprint Lock Safe
Registering a Fingerprint
1. Press and release the initialization button on the inside of the
safe door
2. Immediately place finger on scanner, you will hear two beeps
and one long beep. Remove fingerprint from scanner
3. Registration of fingerprint is now complete
4. To add a fingerprint repeat steps 1 through 3
Note
Three short beeps will be heard if fingerprint was NOT
registered successfully. Repeat steps 1-3
For Accurate and Consistent Fingerprint Scanning
- Use scanner in low light conditions
- Use the thumb finger
- Place and hold finger firmly on the scanner
- Each user should register 2-3 different fingerprints
Parts of the Safe
Initial Numeric Pin Code
1. Press and hold number "1" key until green indicator light is on
2. Input pin code and press the confirmation key. You will hear
one beep
Note: For initial setup factory default code is “1234”
3. Enter the new pin code (four to eight digits) and press
confirmation key
4. Re-enter the new code and press the confirmation key. You
will hear one beep indicating that the new code is saved
5. Registration of pin code is now complete
Note
If you hear 3 short beeps this indicates that the pin was not
registered successfully, repeat steps 1-4
Safe only retains one pin number
Opening the Door with Pin code
1. Enter pin code and press the confirmation key
2. One beep and the scanner flashes green indicates that you
have entered the correct pin
3. Turn the knob clockwise and open the safe
Note
Three short beep indicates incorrect pin code, repeat
steps 1-3
Opening the Door with Fingerprint
1. Press the confirmation key until the scanner illuminates red
2. Place finger on scanner until red illumination ceases
3. The green indicator light will flash and you will hear one beep,
indicating a successful scan
4. Turn the knob clockwise and open the safe
Note
Three short beeps indicate an unsuccessful fingerprint scan,
repeat steps 1-3
Closing and Locking Door
Close the door and turn the knob counter clockwise
Note
Be sure the door is closed completely
Set Up
Remove special access keys from the inside of safe before set
up and keep them in a safe place
Factory settings have no stored fingerprints
Factory default pin code is "1234"
For security purposes, change the factory default code as soon
as possible
Closing and Locking Door
Close the door and turn the knob counter clockwise
Note
Be sure the door is closed completely
Batteries
1. To replace batteries open safe door and remove
battery cover
2. Only use four AA alkaline batteries and be sure to note the
polarity of the battery
LOW BATTERY INDICATOR
If the red indicator light is flashing or is consistently on, this
indicates that the batteries are low. Open safe by using the
supplied emergency key
1
2
3
4
1
2
3
4
Parts of the Safe
1. Removable Shelf
2. Initialization
3. Bolts
4. Battery Compartment
Parts of the Control Panel
1. Key Pad
2. Knob
3. Fingerprint Scanner
4. Confirmation Key
Changing the Pin Code
1. Press and hold number "1" key until green indicator light
is on
2. Enter the old pin code and press the confirmation key
3. When a beep is heard enter the new pin code
(four to eight digits) and press the confirmation key
4. Enter new pin code and press the confirmation key again.
If a long beep is heard, the adjustment was successful.
Note
If you hear 3 short beeps this indicates that pin was not
succesful, repeat steps 1-4
Safe only retains one pin number
See reverse side for more information

Care and Maintenance
- If necessary use a damp cloth to clean the safe. DO NOT use
chemicals or cleaning agents
- Keep liquids away from the control panel. Spills on the control
panel will cause damage and possibly electric shock
- Properly secure the safe to prevent it from falling and causing
damage or injury
- For security purposes, change the factory default code as
soon as possible
- DO NOT over stuff the contents of the safe or you can
damage the motor mechanism or the contents
- DO NOT disassemble the product. For all repairs and
maintenance, contact authorized service centers or distributor
- DO NOT place emergency keys inside of safe
Biometric Safe Warranty
1. BARSKA warrants the Biometric Safe against original defects
in material and/or workmanship under normal use for a period
of twelve (12) months from the date product is received
by purchaser.
2. This Warranty is limited to original purchaser and is
not transferable.
3. This Warranty applies only to products purchased in the
United States.
4. BARSKA will examine and test returned product and repair or
replace defective part(s) or units with new part(s) or a new
unit if necessary within the warranty period. Purchaser is
required to remit $50.00 to BARSKA for return shipping and
handling at time product is returned.
5. If repair is required after warranty period expiration,
purchaser will be charged for replacement parts and return
shipping.
6. Purchaser must contact BARSKA at 1.909.445.8168 to
request a Returned Merchandise Authorization (RMA)
number. The RMA number must appear on the outside of the
shipping package. Product must be packed carefully and
sturdily in its original packaging to prevent damage in transit
and returned freight pre-paid to:
BARSKA
Repair Department
1721 Wright Avenue
La Verne, CA 91750
What is NOT covered by this Warranty?
1. Damage caused by improper installation or maintenance.
2. Damage from misuse, abuse, accident (such as dropping),
fire, flood, or acts of nature.
3. Damage from service or repairs other than those performed
by BARSKA.
4. Labor, cost and shipping charges for the removal and
replacement of defective parts beyond the initial
twelve-month warranty period.
5. All transportation and shipping charges.
6. Removing or altering the seal on the rear of the front part of
the safe under any circumstances will automatically void
the warranty.
© 2011 BARSKA®
1721 Wright Ave| La Verne, CA 91750 | USA
(t) 888.666.6769 | (f) 909.445.8169 | www.barska.com
6/11
BC196
Opening the Safe with Key
1. In emergency situations where number pad and/or fingerprint
module is disabled, use emergency key to open the safe
2. Use supplied hex tool to remove the badge bolts on the
safe door
3. Place key in the emergency lock and turn counterclockwise
4 Turn the knob clockwise to open safe door
Note
DO NOT place emergency keys inside of safe
Mounting
The safe may be mounted to a wall or through the floor. When
mounting to a wall, be sure of the load bearing so as to hold the
weight of the safe and the contents. Failure to do so could result
in the safe falling and damaging property and or people.
Suggested 12mm socket wrench tool and drill bits
Mounting Through The Bottom Of The Safe
1. Check the floor for what type it is (wood, tile and or concrete)
2. Get the appropriate anchors for the type of floor you have
3. Check location on the floor for concealed wires or pipes
4. Mark the floor to drill your anchor
5. Drill the appropriate size hole for the anchors you have
6. Mount the safe and make sure it is securely mounted
DO NOT mount safe without anchoring to the wall behind the
safe!
Mounting Through The Back Of The Safe
1. Check the wall or cabinet for structural soundness
2. For safety, have someone help you to hold the safe during
mounting
3. Check location for concealed wires or pipes
4. Mark the surface to drill holes for the anchors you will
be using
5. Drill the appropriate size holes for the anchors you are using
6. While having someone hold the unit, anchor the safe to
the wall
7. Test the strength of the mounted safe so it will not fall off the
wall or cabinet
DO NOT mount safe without anchoring to the wall behind the
safe!
User Manual for Biometric
Fingerprint Lock Safe
To Delete All Fingerprints and Pin Code
1. Open safe door by either of the three methods; fingerprint,
pin code or emergency key
2. Press and hold down the initialization key
3. The finger scanner flashes green twelve times and a beep is
heard to indicate all fingerprints and pin code is deleted
4. Once the flashing ceases release the initialization button
5. The safe is now in its original factory setting
Note
Any fingerprint can open safe door
Factory defalut pin code is “1234”
