Overview:
LED Watts: 195.0W
System Watts: 211.0W
Controllability: DMX and RDM compatible
Weight: 43.9 lbs.
Protection Class: IP67
Tools Required:
• 6mm hex head screwdriver
Figure 3:
191
2
"
1
2
"
3
8
"
7
8
"
31
8
"
77
8
"
131
8
"
203
4
"
10°
170°
85
8
"
- 84530
LARGE SCALE FLOOLIGHT -
RGBW WIDE BEAM
4/27/21
REV PART NO. SIZE
TYPE:
PROPRIETARY AND CONFIDENTIAL
THE INFORMATION CONTAINED IN THIS DRAWING IS THE SOLE PROPERTY
OF BEGA NORTH AMERICA, INC.
ANY REPRODUCTION IN PART OR AS A WHOLE WITHOUT THE WRITTEN
PERMISSION OF BEGA NORTH AMERICA, INC. IS PROHIBITED.
DATE: APPROVED:
P [phone] - www.bega-us.com
DESCRIPTION:
1000 BEGA Way, Carpinteria, California 93013
B
SHEET 1 OF 2 NOT TO SCALE
DATE DESCRIPTION CHANGED BY REV
THE INFORMATION CONTAINED IN THIS
SHEET 1 OF 1
BEGA
D
C
B
A
B
C
D
123
45
6
7
8
87 6
5432
1
F
E
F
DO NOT SCALE DRAWING
RGBW large floods wiring
E
UNLESS OTHERWISE SPECIFIED:
SCALE: 2:1 WEIGHT:
REV
DWG. NO.
C
SIZE
TITLE: A
PERMISSION OF BEGA U.S. IS PROHIBITED.
BEND
Carpinteria, CA. 93013
ANY REPRODUCTION IN PART
1000 BEGA Way
XX =
DRAWN
FINISH
MATERIAL PROPRIETARY AND CONFIDENTIAL
BEGA U.S.
OR AS A WHOLE WITHOUT THE WRITTE N
Phone: [phone]
FAX: [phone]
XXX =
DRAWING IS THE SOLE PROPERTY OF
TOLERANCES:
FRACTIONAL
ANGULAR: MACH
APPROVED: DATE:
ALL DIMENSIONS ARE IN INCHES
REVISIONS
REV. CHANGED BY DESCRIPTION DATE
"DMX SHIELD" ON BARE WIRE
"DMX -" ON BLUE WIRE
"DMX+" ON BLACK WIRE
DMX + (WHITE WIRE)
DMX - (BLUE WIRE)
DMX SHIELD (BLACK WIRE)
DMX SHIELD (BLACK WIRE)
DMX - (BLUE WIRE)
DMX + (WHITE WIRE)
WAGO CONNECTORS
WAGO CONNECTORS
WIRING FOR INCOMING DMX AND POWER INTO THE FIXTURE
DMX (+) (BLACK)
DMX (-) (BLUE)
DMX SHIELD
INCOMING 5 FT. OF DMX CABLE
INTO THE FIXTURE
DMX WIRES FROM DRIVER 1
DMX WIRES FROM DRIVER 2
POWER WIRES (US5010, US5016)
FROM DRIVER 1
INCOMING 5 FT. OF POWER CABLE
INTO THE FIXTURE
GROUND
NEUTRAL (WHITE)
LINE (BLACK)
POWER WIRES (US5010, US5016)
FROM DRIVER 2
"DMX SHIELD" ON BARE WIRE
"DMX -" ON BLUE WIRE
"DMX+" ON BLACK WIRE
WAGO CONNECTORS
LINE (BLACK)
INCOMING 5 FT. OF DMX CABLE
INTO THE FIXTURE
WAGO CONNECTORS
INCOMING 5 FT. OF POWER CABLE
INTO THE FIXTURE
Large-scale oodlight - RGBW wide beam 84 530
Dimensions
A: 19-1/2”
B: 20-3/4”
C: 8-5/8”
19
1
2
"
1
2
"
3
8
"
7
8
"
31
8
"
77
8
"
131
8
"
203
4
"
10°
170°
85
8
"
- 84530
LARGE SCALE FLOOLIGHT -
RGBW WIDE BEAM
4/27/21
REV PART NO. SIZE
TYPE:
PROPRIETARY AND CONFIDENTIAL
THE INFORMATION CONTAINED IN THIS DRAWING IS THE SOLE PROPERTY
OF BEGA NORTH AMERICA, INC.
ANY REPRODUCTION IN PART OR AS A WHOLE WITHOUT THE WRITTEN
PERMISSION OF BEGA NORTH AMERICA, INC. IS PROHIBITED.
DATE: APPROVED:
P [phone] - www.bega-us.com
DESCRIPTION:
1000 BEGA Way, Carpinteria, California 93013
B
SHEET 1 OF 2 NOT TO SCALE
DATE DESCRIPTION CHANGED BY REV
Maintenance:
Clean regularly with solvent-free cleaner
removing dirt and debris. Do not use high
pressure cleaners.
Replacement Parts
See label inside of xture for LED replacement
part number.
Consult factory for all other replacement
components.
Luminaire Accessories
Please refer to the appropriate accessory installation
sheet for further instruction when applicable.
180° glare shield 71 101
Mounting Accessories
Please refer to the appropriate accessory installation
sheet for further instruction when applicable.
Mounting bracket for pole top Ø 3” 79 435
Pole mount hub for pole top Ø 3” 79 555
Pole mount canopy for 5” OD pole 79 553
Pole mount arm for 5” OD pole 79 550
Wall mount canopy 79 554
Wall mount arm 79 551
Pole top for 2 oodlights 70 762
Pole top for 3 oodlights 70 763
Pole top for 4 oodlights 70 764
Cross beam for 3 oodlights 70 761
Cross beam for 6 oodlights 70 765
Updated: 04/27/21
84 530 1 of 2
B
A C
Notice to Installer:
1. See page 2 for specic product safety warnings.
2. Suitable for operation in ambient temperatures not to exceed 25°C.
3. Floodlight must be connected to a DMX compatible lighting control system, oodlight
will not operate otherwise.
4. Installer should be familiar with “Recommended Practice for DMX 512”.
5. A terminator must be used at the end of the run between data lines per the
“Recommended Practice for DMX 512”.
6. It is recommended to avoid running DMX cables in parallel with power cables and
dimming cables. Failure to do so could cause interference with DMX controls.
7. BEGA luminaires may be damaged if connected to conduit systems containing water
- Article 300-5g of the National Electric Code requires that “Conduits or raceways
through which moisture may contact energized live parts shall be sealed or plugged
at either or both ends”.
8. Floodlight is provided with mounting yoke that is compatible with various BEGA
mounting accessories, see specication sheet for details.
9. Floodlight is provided with 5ft of shielded 22 AWG, 2 conductor DMX cable, OD
.281”.
10. Floodlight is provided with 5ft of 18 AWG, 3 conductor SJTOW supply power cable,
OD .310”.
Luminaire 84530 installation:
1. Install the oodlight using the appropriate BEGA mounting accessory, or mount the
stainless steel yoke directly to a surface capable of providing suitable anchorage for
the weight of the xture, using hardware by others. Mounting holes provided with the
yoke, see Figure 1.
2. A seperate, wet location wiring box must be supplied (by others). A U.L. listed water
tight compression tting must be used to accept the cord from the xture. See notice
to installer steps 9 and 10 for cord information. Note that DMX and supply wiring
connections cannot be made in the same compartment and must be separated to
prevent interference with the DMX controls.
3. Make DMX cable connections per “Recommended Practice for DMX 512”:
“DMX SHIELD” : BARE WIRE
“DMX -” [NEGATIVE] : BLUE WIRE
“DMX +” [POSITIVE] : WHITE WIRE
4. Make suppy wiring and cable connections inside junction box:
MAIN VOLTAGE SUPPLY WIRE TO BLACK LUMINAIRE WIRE;
NEUTRAL (COMMON) SUPPLY WIRE TO WHITE LUMINAIRE WIRE
GREEN (GROUND) WIRE TO GREEN LUMINAIRE WIRE
5. Floodlight is vertically adjustable between -10° and +170°. To adjust oodlight aiming
angle, loosen (2) 6mm hex head screws on either side of the yoke where it attaches
to the oodlight. Aim the oodlight as desired and then tighten the (2) 6mm hex head
screws to lock into place.
