Installation and Technical InformationBEGA
Due to the dynamic nature of lighting products and the associated technologies, luminaire data on this sheet is subject to change at the discretion of BEGA North America. For the most current technical data, please refer to bega-us.com
BEGA 1000 Bega Way, Carpinteria, CA 93013 (805)684-0533 © copyright BEGA 2019
Figure 1:
Figure 2:
Figure 3:
Overview:
System Watts: 2.4W
LED Watts: 2.1W
Controllability: non dimmable
Weight: 0.5 lbs.
Protection Class: IP65
Tools Required:
• 3mm hex key
• 2.5mm hex key
Recessed wall luminaire - Unshielded 22 202
Notice to Installer:
1. BEGA luminaires may be damaged if connected to conduit systems containing
water - Article 300-5G of National Electric Code requires that “Conduits or
raceways through which moisture may contact energized live parts shall be sealed
or plugged at either or both ends.”
2. Luminaire is Non-IC rated. (Insulation must be at least 3” from luminaire)
3. Suitable for through wiring: max. of (4) No. 12 AWG conductors (plus ground) rated
for 90°C.
4. Suitable for installation in hollow wall construction or poured concrete construction.
5. Back housing provided with (2) 7/8” holes (horizontal entry) for 1/2” trade size
conduit.
6. Back housing must be installed so that the front face is ush or slightly in front of
nished wall.
7. Wall applications only. (No ceiling and in-grade applications).
8. Requires a remote 24V DC class 2 electronic power supply. (Not provided).
Backbox Installation: Hollow (stud) wall
1. Install the (2) slotted mounting brackets [Figure 1], using the (2) #6-32 wing nuts in
the installation kit. (Provided)
2. Adjust the brackets (by loosening the #6-32 wing nuts) so that the face of the
backbox mounts ush or slightly in front of nished wall surface.
3. Secure the mounting brackets to wood or metal horizontal blocking, as shown in
[Figure 2].
4. Connect conduit to back housing and pull wires for wiring connections to be made
later.
Backbox Installation: Poured concrete
1. Attach (2) #8-32 threaded rods inside backbox. [Figure 3]
2. Attach the backbox to the concrete form using the (2) wingnuts in the installation kit
(Provided) [Figure 4].
3. Connect conduit to back housing and pull wires for wiring connections.
4. Pour concrete.
NOTE: DO NOT POUR CONCRETE DIRECTLY ON TOP OF THE BACK
HOUSING.
5. After concrete is set remove the wing nuts from threaded rod, remove form.
Inner Housing Installation: Luminaire Installation
1. Undo (2) faceplate screws using 3mm hex key and carefully remove casting and
lens from luminaire.
2. Connect the luminaire to 24V DC supply wiring in backbox.
3. Install inner housing into backbox, using a 2.5mm hex key tighten the (2) screws
until housing is secure.
4. Place a small bead of silicone between the edge of backbox and wall to provide a
seal.
5. Re-install faceplate. Make sure that gasket and lens are seated properly.
6. Tighten the (2) faceplate screws evenly to secure.
Dimensions
A: 3 1/8''
B: 3 1/8''
C: 3 7/8''
Due to the dynamic nature of lighting products and the associated technologies, luminaire data on this sheet is subject to change at the discretion of BEGA North America. For the most current technical data, please refer to bega-us.com
BEGA 1000 Bega Way, Carpinteria, CA 93013 (805)684-0533 © copyright BEGA 2019
Maintenance:
Clean regularly with solvent-free cleaner
removing dirt and debris. Do not use high
pressure cleaners.
Replacement Parts
See label inside of xture for LED replacement
part number.
Consult factory for all other replacement
components.
Accessories
Please refer to the appropriate accessory installation
sheet for further instruction when applicable.
Remote 25W LED driver and box 19 580
Remote 50W LED driver and box 19 591
Updated: 10/04/19
22 202 1 of 2
