(5/16" - 18 x 10")
Bollard - round LED with wide spread distribution 84 061
Tools Required:
1/2” nut driver
3mm hex key
4mm hex key
5mm hex key
Protection Class: IP65
Weight: 16.1 lbs.
Dimensions
A: 6-1/2”
B: 39-3/8”
Relamping/Maintenance
Loosen (2) hex screws and remove bollard top.
Unscrew driver assembly screws and remove driver
assembly. Clean luminaire and lens using only
solvent-free cleansers. Replace driver assembly and
top, making sure gasket is seated properly. Tighten
screws evenly.
Lamp: 19.4W LED
84 061
5/1/2018
Page 1 of 2
Description
Lens
Driver (120V-277V)
LED (3000K)
LED (4000K)
Part No
Consult Factory
75983-02
LED-0389/830
LED-0389/840
Anchorage 79 817
Notice to Installer for 84 061:
1. See page 2 for specic product safety warnings.
2. Fixture may be damaged if connected to conduit systems that contain water - Article 300-
5G of the National Electric Code requires that “Conduits or raceways through which moisture
may contact energized live parts shall be sealed or plugged at either or both ends.”
3. 79 817 anchorage kit (included) must be installed in concrete pad/foundation.
4. It is recommended that when installing in planting areas the bollard base be slightly elevated to
avoid prolonged submerging during heavy rains.
5. Wet location listing does not imply suitability for exposure to standing water for long periods of time.
6. LED driver and LED module included in luminaire housing.
79 817 anchorage installation for 84 061:
1. Provide means to bring supply wiring to the bollard in accordance with local code. The template has a
2-3/8” conduit hole for conduit entry.
2. Assemble anchorage kit. Unscrew the (3) hex bolts from the female couplers. Remove each hex
bolt and washer. Align each anchor bolt with the hole in the template. Attach each anchor bolt to the
template by replacing the washer and hex bolt and tightening.
3. Determine the nished grade for the application. Use leveling hardware to adjust template to
desired nished height after pouring.
4. Install anchorage kit using either method:
A. Attach template to forming or cross bracing using the (2) nail holes provided in the
template. Level template properly. Pour concrete.
B. Insert anchorage assembly into poured concrete. Concrete must be vibrated to
ensure proper anchorage setting. Level template properly.
84 061 - installation:
1. Remove (3) hex bolts and washers, once anchorage is set.
2. Remove template, making sure that there is a smooth, at surface to mount the base.
3. Loosen the 5mm set screw at the base of the xture. Turn the base plate and remove from
bollard.
4. Align base plate holes with anchorage holes.
5. Bolt the base plate to the anchorage kit using the (3) hex bolts and washers.
6. Make supply wiring connections to wire leads from driver inside the xture
MAIN VOLTAGE SUPPLY WIRE TO BLACK DRIVER WIRE;
NEUTRAL (COMMON) SUPPLY WIRE TO WHITE DRIVER WIRE;
GREEN GROUND WIRE TO GREEN DRIVER WIRE.
Dimming (if applicable):
DIMMING CONTROL WIRE (+) TO POSITIVE DRIVER DIM CONTROL WIRE
DIMMING CONTROL WIRE (-) TO NEGATIVE DRIVER DIM CONTROL WIRE
7. Place the bollard over the base plate so that the (3) notches in the base plate align with the top.
Lock xture into place by turning bollard 1/4” turn.
8. Secure the bollard by tightening the 5mm set screw at the base.

Installation and Technical Information
BEGA
In the interest of product improvement, BEGA reserves the right to make technical changes without notice.
BEGA 1000 Bega Way, Carpinteria, CA 93013 [phone] Fax [phone] www.bega-us.com © Copyright BEGA-US 2018
Bollard - round LED with wide spread distribution 84 061
84 061
5/1/2018
Page 2 of 2
Product Safety Warnings:
THIS PRODUCT MUST BE INSTALLED IN ACCORDANCE WITH THE APPLICABLE INSTALLATION CODE BY A PERSON
FAMILIAR WITH THE CONSTRUCTION AND OPERATION OF THE PRODUCT AND THE HAZARDS INVOLVED.
SUITABLE FOR WET LOCATIONS.
MIN 60°C SUPPLY CONDUCTORS.
CE PRODUIT DOIT ÊTRE INSTALLÉ SELON LE CODE D’INSTALLATION PERTINENT, PAR UNE PERSONNE QUI CONNAÎT
BIEN LE PRODUIT ET SON FONCTIONNEMENT AINSI QUE LES RISQUES INHÉRENTS.
CONVIENT AUX EMPLACEMENTS MOUILLÉS.
LES FILS D’ALIMENTATION 60°C MIN.
