BEGA 22 203 Manual

Installation and Technical Information
BEGA
In the interest of product improvement, BEGA reserves the right to make technical changes without notice.
Replacement Parts
Accessories
Please refer to the appropriate
accessory installation sheet for
further instruction when applicable.
Recessed wall with louvers 22 203
Tools Required:
3mm hex key
Phillips medium screwdriver
Protection Class: IP65
Weight: 0.5 lb.
Dimensions
A: 3 1/8 “
B: 3 1/8 ”
C: 4 “
Relamping/Maintenance
Undo faceplate screws and remove casting. Carefully
remove lens with attached gasket. Remove dirt and
debris from casting and lens using only solvent-free
cleansers. Replace faceplate and tighten screws
evenly, making sure the gasket is seated properly.
Lamp: 2.1W LED, 24V DC
22 203
06/2018
Page 1 of 2
Description
Lens
Lens gasket
LED board
Part No
140425
830839.1
74020
Remote 25W LED driver and box 19 580
Remote 50W LED driver and box 19 591
Notice to Installer for 22 203:
1. BEGA luminaires may be damaged if connected to conduit systems
containing water - Article 300-5G of National Electric Code requires that
“Conduits or raceways through which moisture may contact energized live
parts shall be sealed or plugged at either or both ends”.
2. Luminaire is Non-IC rated. Insulation must be at least 3” from luminaire.
3. Suitable for installation in hollow wall construction or poured concrete construction.
4. Back housing provided with (2) 7/8” holes (horizontal entry) for 1/2” trade size
conduit.
5. Back housing must be installed so that the front face is ush or slightly in front of
nished wall.
6. Suitable for through wiring: max. of (4) No. 12 AWG conductors (plus ground) rated
for 90°C.
7. Suitable for wall applications only. (No ceiling and in-grade applications).
NOTE: Requires a 24V DC class 2 electronic power supply to operate intended
LED wattage. (not included), DO NOT CONNECT TO LINE VOLTAGE.
BB2002LED - back housing installation in hollow (stud) wall construction:
1. Install the (2) slotted mounting brackets provided as shown in Figure #1, using the
(2) #6-32 wing nuts provided in the installation kit.
2. Adjust the brackets (by loosening the #6-32 wing nuts) so that the face of the back
box will be ush or slightly in front of pnished wall surface after installation.
3. Secure the mounting brackets to wood or metal horizontal blocking as shown in
Figure #2.
4. Connect conduit to back housing and pull wires for electrical connections to be
made later.
BB2002LED - back housing installation in poured concrete construction:
1. Attach (2) #8-32 threaded rods into the pressed nuts located in the bottom of the
xture back box (Fig #3).
2. Attach the xture back box to the concrete form using the wing nuts and washers
provided in the installation kit (Fig #4).
3. Connect conduit to back housing and pull wires for electrical connections to
be made later. Pour concrete. IMPORTANT NOTE: DO NOT PUMP OR DROP
CONCRETE DIRECTLY ON TOP OF THE BACK HOUSING.
4. After concrete is poured, remove the #8-32 wing nuts from the threaded rod before
removing the form.
22 203 - inner housing wiring and installation:
1. Undo faceplate screws and carefully remove casting and lens.
2. Connect the corresponding positive and negative wires from the inner housing to
the remote driver.
3. Place a small bead of silicone between edge of housing and wall to provide a seal.
4. Install inner housing into back housing, and tighten the (2) M3 screws until secure.
5. Install faceplate casting and lens. Make sure that gasket and lens are seated
properly.
6. Tighten the (2) M4 athead screws evenly to secure.
BEGA 1000 Bega Way, Carpinteria, CA 93013 [phone] Fax [phone] www.bega-us.com © Copyright BEGA-US 2018

Installation and Technical Information
BEGA
In the interest of product improvement, BEGA reserves the right to make technical changes without notice.
Recessed wall with louvers 22 203
22 203
Page 2 of 2
Product Safety Warnings:
THIS PRODUCT MUST BE INSTALLED IN ACCORDANCE WITH THE APPLICABLE INSTALLATION CODE BY A PERSON
FAMILIAR WITH THE CONSTRUCTION AND OPERATION OF THE PRODUCT AND THE HAZARDS INVOLVED.
SUITABLE FOR WET LOCATIONS.
MIN 90° SUPPLY CONDUCTORS.
CE PRODUIT DOIT ÊTRE INSTALLÉ SELON LE CODE D’INSTALLATION PERTINENT, PAR UNE PERSONNE QUI CONNAÎT
BIEN LE PRODUIT ET SON FONCTIONNEMENT AINSI QUE LES RISQUES INHÉRENTS.
CONVIENT AUX EMPLACEMENTS MOUILLÉS.
LES FILS D’ALIMENTATION 90°C MIN.
