BEGA 84457 Manual

Installation and Technical Information
BEGA
Due to the dynamic nature of lighting products and the associated technologies, luminaire data on this sheet is subject to change at the discretion of BEGA North America. For the most current technical data, please refer to bega-us.com
BEGA 1000 Bega Way, Carpinteria, CA 93013 [phone] © copyright BEGA 2021
Figure 2: Faceplate Detail
Figure 1: Mounting
Overview:
LED Watts: 28.2W
System Watts: 34.0W
Controllability: 0-10V dimmable down to 1%
Weight: 17.2 lbs.
Protection Class: IP68
Tools Required:
• 5mm hex head screwdriver
• 3mm hex head screwdriver
Figure 3: Optical Assembly Adjustment (Generic Image)
Notice to Installer:
1. See page 2 for specic product safety warnings.
2. A foundation must accommodate the luminaire’s max pressure load of 11,000 lbs.
(5,000 kg.). The pressure load transfers to the foundation provided by the customer
through the housing.
3. The installation housing must be set in concrete for drive over applications.
4. Aggressive chemicals can compromise the luminaire from the surface and avoid
excessive de-icing agents near the luminaire.
5. The luminaire is sealed from the factory; it should only be opened if maintenance is
required on the internal electrical components.
6. Do not use power tools to open and close xture, use hand tools only. Failure to do
so can result in incorrect sealing of xture and void warranty.
7. Do not install luminaire housing in heat-insulating material.
8. At least 6’’ of drainage must be provided in the foundation to allow surface water to
drain from the recessed housing.
9. A customer-provided waterproof wiring box is required to connect the luminaire to
the supply power.
10. Luminaire supplied with 7.5 ft. whip exiting the xture.
Installation: Luminaire Back housing
1. Position back housing on the stable foundation; anchor using hardware (by others).
[Figure 1]
2. The nished surface must be level with or below the upper edge of the recessed
housing to guarantee a proper seal of the luminaire faceplate. [Figure 1] [Figure 2]
Installation: Luminaire
1. Connect luminaire incoming supply wiring at wiring box:
MAIN VOLTAGE SUPPLY WIRE TO BLACK WIRE;
NEUTRAL COMMON SUPPLY WIRE TO WHITE WIRE;
GREEN GROUND WIRE TO GREEN WIRE;
Dimming (0-10V):
DIMMING CONTROL WIRE (+) TO (+) DIM CONTROL WIRE;
DIMMING CONTROL WIRE (-) TO (-) DIM CONTROL WIRE;
2. Insert the luminaire housing into the outer housing, turn it clockwise min. 10° and
align as needed or until stops.
Installation: Optical Assembly Adjustment
1. Remove luminaire faceplate and glass.
2. Loosen (2) 3mm hex head adjustment screws; adjust optical assembly by applying
pressure in the area circled in [Figure 3], tighten adjustment screws when complete.
3. Reinstall the glass ensuring the gasket is positioned properly then install the face-
plate over the glass.
4. Tighten the screws on luminaire faceplate to secure it in the installation housing
(Torque = 6.5Nm./4.8 ft-lb). Tighten the faceplate in a star pattern to seal correctly.
In-grade luminaire - Adjustable 84 457
Dimensions
A: 9 1/2’’
B: 10 7/8’’
C: 9 1/4”
Maintenance:
Clean regularly with solvent-free cleaner
removing dirt and debris. Do not use high
pressure cleaners.
Replacement Parts
See label inside of xture for LED replacement
part number.
Consult factory for all other replacement
components.
Accessories
Please refer to the appropriate accessory installation
sheet for further instruction when applicable.
Updated: 10/20/21
84 457 1 of 2
BEGA Gantenbrink-Leuchten KG · Postfach 31 60 · 58689 Menden · [e-mail] · www.bega.com
3 / 6
A
BEGA Gantenbrink-Leuchten KG · Postfach 31 60 · 58689 Menden · [e-mail] · www.bega.com
3 / 6
A
Waterproof wiring box
(by others)
Flush with Back housing
Drainage area
A
C
B
Mounting hardware
(by others)

Installation and Technical Information
BEGA
Due to the dynamic nature of lighting products and the associated technologies, luminaire data on this sheet is subject to change at the discretion of BEGA North America. For the most current technical data, please refer to bega-us.com
BEGA 1000 Bega Way, Carpinteria, CA 93013 [phone] © copyright BEGA 2021
Product Safety Warnings:
THIS PRODUCT MUST BE INSTALLED IN ACCORDANCE WITH THE APPLICABLE INSTALLATION CODE BY A PERSON
FAMILIAR WITH THE CONSTRUCTION AND OPERATION OF THE PRODUCT AND THE HAZARDS INVOLVED.
SUITABLE FOR WET LOCATIONS.
MIN 90°C SUPPLY CONDUCTORS.
CE PRODUIT DOIT ÊTRE INSTALLÉ SELON LE CODE D’INSTALLATION PERTINENT, PAR UNE PERSONNE QUI CONNAÎT
BIEN LE PRODUIT ET SON FONCTIONNEMENT AINSI QUE LES RISQUES INHÉRENTS.
CONVIENT AUX EMPLACEMENTS MOUILLÉS.
LES FILS D’ALIMENTATION 90°C MIN.
Updated: 10/20/21
2 of 2
84 457
In-grade luminaire - Adjustable 84 457
