Belden HIRSCHMANN SPIDER II 16TX EEC User manual

Installation SPIDER II 16TX
Release 02 12/2014
Technical Support
https://hirschmann-support.belden.eu.com
User Manual
Installation
Industrial Ethernet Rail Switch
SPIDER II 16TX EEC, SPIDER II 16TX/2DS-S EEC
SPIDER II 16TX EEC SPIDER II 16TX/2DS-S EEC

The naming of copyrighted trademarks in this manual, even when not specially indicated, should
not be taken to mean that these names may be considered as free in the sense of the trademark
and tradename protection law and hence that they may be freely used by anyone.
© 2014 Hirschmann Automation and Control GmbH
Manuals and software are protected by copyright. All rights reserved. The copying, reproduction,
translation, conversion into any electronic medium or machine scannable form is not permitted,
either in whole or in part. An exception is the preparation of a backup copy of the software for
your own use. For devices with embedded software, the end-user license agreement on the
enclosed CD/DVD applies.
The performance features described here are binding only if they have been expressly agreed
when the contract was made. This document was produced by Hirschmann Automation and
Control GmbH according to the best of the company's knowledge. Hirschmann reserves the right
to change the contents of this document without prior notice. Hirschmann can give no guarantee
in respect of the correctness or accuracy of the information in this document.
Hirschmann can accept no responsibility for damages, resulting from the use of the network
components or the associated operating software. In addition, we refer to the conditions of use
specified in the license contract.
You can get the latest version of this manual on the Internet at the Hirschmann product site
(www.hirschmann.com).
Hirschmann Automation and Control GmbH
Stuttgarter Str. 45-51
72654 Neckartenzlingen
Germany
Tel.: [phone]
InstallationSPIDER II 16TX

Installation SPIDER II 16TX
Release 02 12/2014 3
Contents
Safety instructions 5
About this Manual 10
Legend 10
1 Description 11
1.1 General device description 11
1.2 Description of the device variants 11
1.3 Ethernet ports 12
1.3.1 10/100 Mbit/s twisted pair port 12
1.3.2 100/1000 Mbit/s F/O port (optional) 13
1.4 Display elements 14
2 Installation 15
2.1 Checking the package contents 15
2.2 Installing and grounding the device 15
2.2.1 Installing the device onto the DIN rail 15
2.2.2 Grounding the device 16
2.3 Wiring the terminal block for the supply voltage and the
grounding 17
2.4 Operating the device 18
2.5 Connecting data cables 18
2.6 Installing an SFP transceiver (optional) 19
2.7 Removing the SFP transceivers 19
3 Maintenance and service 20
4 Disassembly 21
4.1 Removing the device from the DIN rail 21
5 Technical data 22
A Further Support 29

4Installation SPIDER II 16TX
Release 02 12/2014

Installation SPIDER II 16TX
Release 02 12/2014 5
Safety instructions
General safety instructions
You operate this device with electricity. Improper usage of the device
entails the risk of physical injury or significant property damage. The
proper and safe operation of this device depends on proper handling
during transportation, proper storage and installation, and careful opera-
tion and maintenance procedures.
Before connecting any cable, read this document, and the safety
instructions and warnings.
Operate the device with undamaged components exclusively.
The device is free of any service components. In case of a damaged
or malfunctioning the device, turn off the supply voltage and return the
device to Hirschmann for inspection.
Qualification requirements for personnel
Only allow qualified personnel to work on the device.
Qualified personnel have the following characteristics:
Qualified personnel are properly trained. Training as well as practical
knowledge and experience make up their qualifications. This is the
prerequisite for grounding and labeling circuits, devices, and systems
in accordance with current standards in safety technology.
Qualified personnel are aware of the dangers that exist in their work.
Qualified personnel are familiar with appropriate measures against
these hazards in order to reduce the risk for themselves and others.
Qualified personnel receive training on a regular basis.
Intended usage
Use the product only for the application cases described in the
Hirschmann product information, including this manual.
Operate the product only according to the technical specifications.
See “Technical data” on page 22.
Connect to the product only components suitable for the requirements
of the specific application case.
National and international safety regulations
Verify that the electrical installation meets local or nationally applicable
safety regulations.

6Installation SPIDER II 16TX
Release 02 12/2014
Supply voltage
The supply voltage is electrically isolated from the housing.
Ground the device before connecting any other cables.
Connect only a supply voltage that corresponds to the type plate of
your device.
Every time you connect the electrical conductors, make sure that the
following requirements are met:
The voltage supply conforms to overvoltage category I.
The power supply has an easily accessible disconnecting device
(e.g., a switch or a plug). This disconnecting device is clearly iden-
tified. So in the case of an emergency, it is clear which discon-
necting device belongs to which power supply cable.
The electrical wires are voltage-free.
Relevant for North America:
The power supply is Class 2 compliant.
The supply voltage inputs are designed for operation with safety
extra-low voltage. Connect only SELV circuits with voltage restric-
tions in line with IEC/EN 60950-1 to the supply voltage connec-
tions.
A fuse suitable for DC voltage is located in the plus conductor of the
power supply.
Regarding the properties of this fuse: See “General technical data”
on page 22.
The wire diameter of the power supply cable is at least 1 mm²
(North America: AWG16) on the supply voltage input.
The power supply cables used are permitted for the temperature
range required by the application case.
Relevant for North America: For use in Class 2 circuits
Use copper wire/conductors of class 1 60/75 °C or 75 °C or 90 °C
exclusively.
Installation site requirements
Verify that there is at least 4 in (10 cm) of space above and below the
device.
Verify that there is at least 0.8 in (2 cm) of space on the right and left
sides of the device.
Only install the device in “operating sites with restricted access” based
on EN 60950-1.

Installation SPIDER II 16TX
Release 02 12/2014 7
Housing
Only technicians authorized by the manufacturer are permitted to open
the housing.
Never insert pointed objects (narrow screwdrivers, wires, etc.) into the
device or into the connection terminals for electric conductors. Do not
touch the connection terminals.
Verify that the electrical installation meets locally or nationally appli-
cable safety regulations.
Keep the ventilation slits free to ensure good air circulation.
Install the device in the vertical position.
At ambient temperatures > 140 °F (60 °C):
The surfaces of the device housing may become hot. Avoid touching
the device while it is operating.
LED or laser components
Relevant for SPIDER II 16TX/2DS-S EEC:
LED or LASER components according to IEC 60825-1 (2007):
CLASS 1 LASER PRODUCT
CLASS 1 LED PRODUCT
Only use SFP transceiver which are limited to the laser class 1.
CE marking
The labeled devices comply with the regulations contained in the following
European directive(s):
2011/65/EU (RoHS)
Directive of the European Parliament and of the Council on the restriction
of the use of certain hazardous substances in electrical and electronic
equipment.
2004/108/EC (EMC)
Directive of the European Parliament and the council for standardizing the
regulations of member states with regard to electromagnetic compati-
bility.
In accordance with the above-named EU directive(s), the EU conformity
declaration will be at the disposal of the relevant authorities at the
following address:
Hirschmann Automation and Control GmbH
Stuttgarter Str. 45-51
72654 Neckartenzlingen
Germany
Tel.: [phone]

8Installation SPIDER II 16TX
Release 02 12/2014
The device can be used in the industrial sector.
Interference immunity: EN 61000-6-2
Emitted interference: EN 55022
Warning! This is a class A device. This device can cause interference in
living areas, and in this case the operator may be required to take appro-
priate measures.
Note: The assembly guidelines provided in these instructions must be
strictly adhered to in order to observe the EMC threshold values.
Relevant for Use in Hazardous Locations Class I Div. 2
Groups A, B ,C and D (according to the Standards
ANSI/ISA12.12.01-2013 / CSA C22.2 No.213-M1987)
These devices are open-type devices that are to be installed in an enclo-
sure with tool removable cover/door that is suitable for the environment..
This equipment is suitable for use in Class I, Division 2, Groups A, B, C,
and D or non-hazardous locations only.
WARNING - EXPLOSION HAZARD – Do not connect or disconnect
equipment unless power has been removed or the area is known to be
non-hazardous.
WARNING - EXPLOSION HAZARD – Substitution of any components
may impair suitability for Class I, Division 2.
Relevant for use in Ex Zone 2 according to ATEX 95
(European directive 94/9/EC)
Any unauthorized modifications to or use of this equipment outside its
specified mechanical, electrical, or other operating limits may cause
personal injury and/or property damage, including damage to the equip-
ment.
Any such unauthorized modifications: (1) constitute “misuse” and/or
“negligence” within the meaning of the product warranty, thereby
excluding warranty coverage for any resulting damage; and (2) invalidate
product certifications or listings.
Conditions of Safe Use
Equipment intended for use in potentially explosive atmosphere directive
94/9/EC.
Compliance with the essential health and safety requirements has been
assured by compliance with the following standards: EN 60079-0:2012,
EN 60079-15:2010.
This product should be installed by personnel trained in installation of
equipment in Hazardous Locations and meet the representative National
Electrical Code of the according country.
Installation only in Zone 2 for gas group IIC.

Installation SPIDER II 16TX
Release 02 12/2014 9
Subject devices are to be installed in an ATEX Certified IP54 (as defined
in EN 60079-0 and EN 60079-15) enclosure and accessible only by the
use of a tool.
Subject devices are for use in an area of not more than pollution degree
2 in accordance with IEC 60664-1.
Provision shall be made to prevent the rated voltage being exceeded by
the transient disturbances of more than 140 % of the peak rated voltage.
When end users are providing Optical SFP Communications modules,
these must be limited to Laser Class I only.
FCC note:
This device complies with part 15 of the FCC rules. Operation is subject
to the following two conditions: (1) this device may not cause harmful
interference; (2) this device must accept any interference received,
including interference that may cause undesired operation.
Appropriate testing has established that this device fulfills the require-
ments of a class A digital device in line with part 15 of the FCC regula-
tions.
These requirements are designed to provide sufficient protection against
interference when the device is being used in a business environment.
The device creates and uses high frequencies and can also radiate these
frequencies. If it is not installed and used in accordance with this oper-
ating manual, it can cause radio transmission interference. The use of this
device in a residential area can also cause interference, and in this case
the user is obliged to cover the costs of removing the interference.
Recycling note
After usage, this device must be disposed of properly as electronic waste,
in accordance with the current disposal regulations of your county, state,
and country.

10 Installation SPIDER II 16TX
Release 02 12/2014
About this Manual
The “Installation User Manual” document contains a device description,
safety instructions, a display description and other information that you
require to install the device before starting with the configuration of the
device.
Legend
The symbols used in this manual have the following meanings:
Listing
Work step
Subheading

Installation SPIDER II 16TX
Release 02 12/2014 11
1 Description
1.1 General device description
The SPIDER II 16TX devices are designed for the special requirements of
industrial automation. They meet the relevant industry standards, provide
very high operational reliability, even under extreme conditions, and also
long-term reliability and flexibility.
The devices allow you to set up switched industrial Ethernet networks that
conform to the IEEE 802.3 standard.
The device is mounted by latching in place on a DIN rail.
The devices work without a fan.
You have the option of choosing various media to connect to the terminal
devices and other network components:
twisted pair cable
multimode F/O
singlemode F/O
The Hirschmann network components help you ensure continuous commu-
nication across all levels of the company.
1.2 Description of the device variants
The devices differ with regard to the number of interfaces and the media type
for connecting segments.
The table below shows the number and type of ports for each device variant.
The abbreviations F/O (fiber optic) and TP (twisted pair) indicate the media
type. The abbreviations SFP and RJ45 indicate the socket type.
Variant RJ45 socket for
10/100 Mbit/s twisted pair
connections
SFP slot for 100/1000 Mbit/s
F/O connection
SPIDER II 16TX EEC 16 –
SPIDER II 16TX/2DS-S EEC 16 2
Table 1: Number and type of ports

12 Installation SPIDER II 16TX
Release 02 12/2014
1.3 Ethernet ports
1.3.1 10/100 Mbit/s twisted pair port
This port is an RJ45 socket.
The 10/100 Mbit/s twisted pair port offers you the ability to connect network
components according to the IEEE 802.3 10BASE-T/100BASE-TX standard.
This port supports:
Autonegotiation
Autopolarity
Autocrossing
100 Mbit/s half-duplex mode, 100 Mbit/s full duplex mode
10 Mbit/s half-duplex mode, 10 Mbit/s full duplex mode
The green and yellow LEDs at the individual twisted pair ports provide port-
related information.
1 5 pin, pluggable terminal block for redundant power supply
2 LED display elements
3 RJ45 socket for 10/100 Mbit/s twisted pair connections
4 SFP slot for 100/1000 Mbit/s F/O connection
Table 2: Overview: interfaces, display elements, and terminal block for the supply
voltage
SPIDER II 16TX EEC SPIDER II 16TX/2DS-S EEC
1
2
3
4

Installation SPIDER II 16TX
Release 02 12/2014 13
1.3.2 100/1000 Mbit/s F/O port (optional)
This port is an SFP slot.
The 100/1000 Mbit/s F/O port offers you the ability to connect network
components according to the IEEE 802.3 100BASE-FX/1000BASE-
SX/1000BASE-LX standard.
When a Fast Ethernet transceiver is used, this port supports:
100 Mbit/s half-duplex mode, 100 Mbit/s full duplex mode
Default setting: Full duplex
When a Gigabit Ethernet transceiver is used, this port supports:
Full duplex mode
Autonegotiation
Delivery state: Autonegotiation active.
Note: Verify that you connect only optical ports with the same optical trans-
mission properties with each other.
LED Display Color Activity Meaning
100 Data rate Yellow Lights up 100 Mbit/s connection
None 10 Mbit/s connection
LS/DA Link status
data
Green Lights up Device detects a valid link
Flashing Device is transmitting and/or
receiving data
None Device detects an invalid or missing
link

14 Installation SPIDER II 16TX
Release 02 12/2014
1.4 Display elements
Figure 1: 1 – Relevant for SPIDER II 16TX/2DS-S EEC:
Information on F/O port status
2 – All devices:
Information on supply voltage
LED Activity Meaning
17 Lights up Device detects a valid link
Flashing Device is transmitting and/or receiving data
None Device detects an invalid or missing link
18 Lights up Device detects a valid link
Flashing Device is transmitting and/or receiving data
None Device detects an invalid or missing link
P1 Lights up Supply voltage 1 is on
None Supply voltage 1 is off
P2 Lights up Supply voltage 2 is on
None Supply voltage 2 is off
P1 P2
17 18
LS/DA
12

Installation SPIDER II 16TX
Release 02 12/2014 15
2Installation
The devices have been developed for practical application in a harsh indus-
trial environment.
On delivery, the device is ready for operation.
To configure a subdomain, follow these steps:
Checking the package contents
Installing and grounding the device
Wiring the terminal block for the supply voltage and the grounding
Operating the device
Connecting data cables
Installing an SFP transceiver (optional)
2.1 Checking the package contents
Check whether the package includes all items named in the section
“Scope of delivery” on page 26.
Check the individual parts for transport damage.
2.2 Installing and grounding the device
2.2.1 Installing the device onto the DIN rail
Verify that there is at least 4 in (10 cm) of space above and below the
device.
Verify that there is at least 0.8 in (2 cm) of space on the right and left sides
of the device.
CAUTION
TRANSIENT OR ELECTROSTATIC DISCHARGES
Do not open the housing.
Failure to follow these instructions can result in injury or equipment
damage.

16 Installation SPIDER II 16TX
Release 02 12/2014
To mount the device onto a horizontally mounted 35 mm DIN rail according
to DIN EN 60715, proceed as follows:
Slide the upper snap-in guide of the device into the DIN rail.
Press the media module downwards onto the clip-in bar.
Snap in the device.
2.2.2 Grounding the device
The device is grounded via a 5-pin terminal block.
Note: Ground the device before connecting any other cables.
Note: The shielding ground of the connectable twisted pair cables is
connected to the ground connection as a conductor.
Beware of possible short circuits when connecting a cable section with
conductive shielding braiding.
WARNING
ELECTRIC SHOCK
Ground the device before connecting any other cables.
Failure to follow these instructions can result in death, serious injury,
or equipment damage.

Installation SPIDER II 16TX
Release 02 12/2014 17
2.3 Wiring the terminal block for the supply
voltage and the grounding
Supply voltage
The supply voltage can be connected redundantly. Both inputs are uncou-
pled. There is no distributed load. With redundant supply, the power
supply unit with the higher output voltage supplies the device on its own.
Note: Relevant for North America:
The tightening torque of the terminal screws is max. 4.4 lb in. (0.5 Nm).
Pull the terminal block off the device.
Connect the ground connection.
Connect the power supply lines.
WARNING
ELECTRIC SHOCK
Never insert pointed objects (narrow screwdrivers, wires, etc.) into the
device or into the connection terminals for electric conductors. Do not touch
the connection terminals.
Start connecting the electrical wires only if all the above safety require-
ments are fulfilled.
See “Supply voltage” on page 6.
Failure to follow these instructions can result in death, serious injury,
or equipment damage.
Figure Pin assignment on the device Specification of the
supply voltage
1 Power supply connection 1, 24 V Rated voltage range DC
24 V
Voltage range DC incl.
maximum tolerances
18 V ... 32 V
2 Power supply connection 1, 0 V
3 Ground connection
4 Power supply connection 2, 0 V
5 Power supply connection 2, 24 V
Table 3: Pin assignment: 5-pin pluggable terminal block
1
2
3
4 5

18 Installation SPIDER II 16TX
Release 02 12/2014
2.4 Operating the device
By connecting the supply voltage via the terminal block, you start the opera-
tion of the device.
2.5 Connecting data cables
Note: In general, adhere to the following recommendations for data cable
connections in environments with high electrical interference levels:
Keep the length of the data cables as short as possible.
When using copper cables, verify that there is a sufficient gap between
the power supply cables and the data cables when laid over a long
distance. Ideally, install the cables in separate cable channels.
Use shielded cables.
Note: Verify that you connect only optical ports with the same optical trans-
mission properties with each other.
You can connect end devices and other segments to the device ports using
twisted pair cables or optical fibers (F/O).
CAUTION
ELECTRIC SHOCK
Connect only a supply voltage that corresponds to the type plate of your
device.
Failure to follow these instructions can result in injury or equipment
damage.

Installation SPIDER II 16TX
Release 02 12/2014 19
2.6 Installing an SFP transceiver (optional)
Remove the protective cap from the SFP transceiver.
Push the SFP transceiver with the lock closed into the socket until you
hear it latch in.
Note: For this device, only use suitable SFP modules from Hirschmann.
See “Accessories” on page 26.
2.7 Removing the SFP transceivers
Pull the SFP transceiver out of the socket by means of the opened lock.
Close the SFP transceiver with the protective cap.
1
2

20 Installation SPIDER II 16TX
Release 02 12/2014
3 Maintenance and service
When designing this device, Hirschmann largely avoided using high-wear
parts. The parts subject to wear and tear are dimensioned to last longer
than the lifetime of the product when it is operated normally. Operate this
device according to the specifications.
Depending on the degree of pollution in the operating environment, check
at regular intervals that the ventilation slots in the device are not
obstructed.
Note: You will find information about the complaints and returns procedures
on the Internet under
http://www.beldensolutions.com/en/Service/Repairs/index.phtml .
