Beurer BGL60 User manual

BGL60
mg/dL
BLOOD PRESSURE AND
BLOOD SUGAR
2IN1 MEASURING DEVICE
Step by step
Beurer GmbH • Söflinger Str. 218 • D-89077 Ulm • Germany
Phone: [phone] • E-mail: [e-mail] • www.beurer-medical.de 0344
IVD
GB
instructions for use

2 Beurer BGL60 mg/dL
Contents
1About Your Beurer Blood Sugar Measuring Device ................................................4
1.1 Delivery scope, replacement parts and accessories .....................................................5
1.2 Functions of the unit .....................................................................................................7
1.3 Signs and symbols .......................................................................................................8
2Safety information and warnings ............................................................................ 10
3Description of the unit and accessories ................................................................. 16
3.1 Blood pressure/blood sugar measuring device ........................................................... 16
3.2 Lancing device and needle lancets............................................................................. 16
3.3 Test strips................................................................................................................... 19
4Using the unit for the first time and basic settings................................................ 22
4.1 Operating the unit with a mains power adapter........................................................... 22
4.2 Inserting and replacing the batteries ........................................................................... 22
4.3 Basic settings ............................................................................................................. 23
5Measuring your blood pressure .............................................................................. 25
5.1 Putting on the inflatable cuff........................................................................................ 25
5.2 Assuming the proper posture...................................................................................... 26
5.3 Measuring your blood sugar .......................................................................................27
5.4 Evaluating a blood pressure measured value ............................................................. 28
6Measuring your blood sugar.................................................................................... 29
6.1 Acquiring blood samples............................................................................................. 29
6.2 Measuring the blood sugar value................................................................................ 34
6.3 Evaluating a blood sugar measured value .................................................................. 35
6.4 Function check with control solution ........................................................................... 38

Beurer BGL60 mg/dL 3
7The Measured Value Memory.................................................................................. 42
7.1 Displaying individual values ....................................................................................... 42
7.2 Displaying average blood sugar levels ....................................................................... 43
7.3 Deleting the measured value memory........................................................................ 44
7.4 Transferring measured values to a computer ............................................................. 45
8Storage and maintenance of the unit...................................................................... 47
9Troubleshooting....................................................................................................... 48
10 Technical specifications.......................................................................................... 52
11 Guarantee and Customer Service........................................................................... 55

4 Beurer BGL60 mg/dL
1 About Your Beurer Blood Sugar Measuring Device
Dear valued customer,
Thank you for choosing one of our products. Our name stands for high-quality,
thoroughly tested products for applications in the areas of heat, weight, blood
pressure, body temperature, pulse, gentle therapy, massage and air.
Please read these instructions for use carefully and keep them for later use, be
sure to make them accessible to other users and observe the information they
contain.
With kind regards
Your Beurer team
About Your Beurer Blood Sugar Measuring Device
The upper arm blood pressure / blood sugar measuring device is designed for
non-invasive measuring and monitoring of arterial blood pressure levels of adults
as well as measuring blood sugar.
You can use it to measure your blood pressure quickly and easily, determine your
blood sugar content, save the measured values and display the history and aver-
age of the measured values. You are warned in the event of arrythmia. The
measured values are classified according to WHO guidelines and evaluated
graphically.

Beurer BGL60 mg/dL 5
1.1 Delivery scope, replacement parts and accessories
Inspect your set for external damage to the carton packaging and for complete-
ness of the content.
Item Designation
A 1 inflatable cuff
B 1 blood pressure/blood sugar measuring device
C 10 test strips
D 1 lancing device with AST cap for taking blood samples from alternative
sites
E 10 sterile needle lancets
F 1 practical carry case
G 4 alkaline batteries 1.5 V AA (provided in the case)
These instructions for use, additional information material

6 Beurer BGL60 mg/dL
•If the box has sustained extensive damage or if any contents are missing,
please return the system to the retailer.
•The blood pressure/blood sugar measuring device, test strips and control so-
lution (available to purchase separately) are all designed to be used together.
Therefore use only the test strips and control solution intended for this meas-
uring device.
Note
•Only use the manufacturer's original accessories.
Purchasing supplies
Test strips, control solution and lancets are also available for purchase without a
prescription.
Item REF
50 test strips REF 464.00
MEDIUM control solution REF 457.02
100 needle lancets REF 457.01
Mains power adapter for the BGL60 REF 071.17
Large inflatable arm cuff REF 162.628
Beurer GL32, GL34, BGL60 PC kit
(connection cable, driver and test software)
REF 462.10

Beurer BGL60 mg/dL 7
1.2 Functions of the unit
This unit combines two functions in one unit. It is designed for measuring blood
pressure and pulse on the upper arm of adults as well as for measuring the blood
sugar content. It is suitable for self-testing.
Using this measuring device, you can quickly and easily:
•Measure your blood pressure/pulse and blood sugar.
•Display and save your measured values.
•display your average blood sugar measurements from the last 7, 14, 21, 28,
60 and 90 days.
•Set the time and date.
•Set the blood pressure level unit (mmHg or KPa).
The measuring device also features the following control functions:
•A warning in the event of unsuitable temperatures.
•Battery change reminder when battery power is low.
Warning
•This unit is only to be used for regular monitoring and not for the
diagnosis of diabetes.
•Discuss your insulin dose with your doctor.

8 Beurer BGL60 mg/dL
1.3 Signs and symbols
The symbols on the packaging and the nameplate of the measuring device and
accessories have the following meaning:
In-vitro diagnostics Type BF applied part
Serial number Manufacturer
Temperature range +4°C
to +40°C
Refer to instructions for
use
Not for reuse/For single
use only
PCT: Certification for pro-
ducts exported to the
Russian Federation and
CIS countries
Expiry date
Grüner Punkt: German
recycling system
Maximum shelf life after
opening in months
Contents sufficient for
<n> tests
Lot number Order number
Sterilised by radiation
(lancets)
Caution, refer to accom-
panying documents
Biohazard, risk of infec-
tion

Beurer BGL60 mg/dL 9
For an upper arm circumference of 24 cm to
35 cm.
Unit of measure for blood sugar value
The following symbols in these instructions mean
Warning Warning instruction indicating a risk of injury
or damage to health.
Important Safety note indicating possible damage to the
unit/accessories.
Note Important information to be noted.
mg/dL

10 Beurer BGL60 mg/dL
2 Safety information and warnings
Risk of infection
All components of the measuring device and accessories may come
into contact with human blood, and are therefore a possible source of
infection.
Warning
•This measuring device must display the blood sugar content in mg/dL. The
measuring unit mg/dL appears next to each blood sugar level reading. Be
sure to contact customer service if your measuring device does not display
mg/dL.
•You risk damaging your health if you perform a blood sugar measurement
using an unfamiliar unit of measure, since values may be interpreted incor-
rectly and cause the wrong corrective measures to be taken.
•This measuring device must only be used by one person. There is a risk of
infection if the same unit is used by more than one person.
•The lancing device is suitable for self-testing. Never share the lancing device or
needle lancet with other people (risk of infection!).
•Use a new sterile needle lancet for each blood test (for one-time use only).
General notes
Warning
•Do not use the unit near strong electromagnetic fields, wireless systems or
mobile telephones.
•Use only the inflatable cuff provided or original replacement cuffs. Otherwise
the unit may give false measured values.
•When the unit is switched off, do not press the on/off button unless the inflat-
able cuff is attached.

Beurer BGL60 mg/dL 11
Measuring blood pressure
Warning
•Restricted blood flow in an arm due to chronic or acute vascular diseases (in-
cluding vasoconstrictions) reduces measurement accuracy.
•Values that you measure yourself are useful for information purposes only –
they are not intended to replace consultation with your doctor. Discuss your
measured values with your physician, but by no means base any personal
medical decisions on them (e.g. medications and their doses).
•Erroneous measurements can arise from diseases of the cardiovascular circu-
lation system, just as from very low blood pressure, blood flow and cardiac ar-
rythmias as well as from other pre-existing conditions.
Measuring blood sugar
Warning
•The measured values you determine are useful for information purposes only
– they are not intended to replace consultation with your doctor. Discuss your
measured values with your doctor regularly. Do not change any aspects of
your treatment unless instructed by your doctor.
•Water deficiency or a large loss of fluid, for example by sweating, can lead to
false measurement results.
•A very high or very low haematocrit value (proportion of red blood cells) can
lead to incorrect measurements. With a very high haematocrit value (over
60%), the displayed blood sugar value may be too low. If you have a very low
haematocrit value (below 20%), the blood sugar value may be too high. If you
do not know your haematocrit value, ask your doctor.
•Do not use the test strips to take blood sugar measurements of newborn infants.
•Metabolites such as uric acid, ascorbic acid, acetaminophen (paracetamol),
dopa, methyldopa, L-dopa and tolbutamide do not influence the results if they
are present within the physiological value range.

12 Beurer BGL60 mg/dL
•Lipemia effects: Increased blood triglycerides up to 2000 mg/dL hardly affect
the results. Above this level, however, the blood sugar test may be affected.
•Only use fresh capillary whole blood. Do not use serum or plasma.
•Use capillary blood obtained without squeezing the puncture site. Squeezing
causes interstitial fluid to dilute the blood and leads to a false measurement
result.
•Do not use the test strips at elevations over 3275 m
Note
•The Beurer BGL60 monitoring system is suitable for measuring capillary
whole blood.
Storage and maintenance
Warning
•Store the measuring device and accessories out of the reach of young chil-
dren. Small parts, such as needle lancets, batteries or test strips, can be life-
threatening if swallowed. If parts are swallowed, seek medical advice immedi-
ately.
•The test strip container contains a desiccant that may cause skin or eye irrita-
tions if inhaled or swallowed. Keep the container out of reach of young chil-
dren.

Beurer BGL60 mg/dL 13
The Beurer BGL 60 monitoring system is made from precision and electronic
components. The accuracy of the measured values and service life of the unit
depend on careful use:
•Protect the unit from shock, moisture, dirt, large temperature fluctuations and
direct sunlight.
•Do not let the unit fall.
Batteries/Saving measured values
Warning
•Make sure batteries are not accessible to children. Children can put batteries
in their mouth and swallow them. This can cause severe harm to their health.
In this case, consult a physician immediately!
•Normal batteries must not be recharged, heated or thrown into an open flame
(danger of explosion!).
Important
•Do not disassemble or short-circuit the batteries.
•Always replace all batteries at the same time and use batteries of the same
type. Do not use any rechargeable batteries.
•Leaking batteries may damage the unit. If you do not intend to use the unit for
a prolonged period, remove the batteries from the battery compartment.
Caution!
•Leaking or damaged batteries can cause burns if they come into contact with
your skin. In this case, wear suitable safety gloves.

14 Beurer BGL60 mg/dL
Note
•The stored measured values are retained when you replace the batteries.
The date and time are also retained when you replace the batteries and
when the batteries are empty.
•Alkaline batteries should be used wherever possible.
Repairs
Note
•Never open the unit. Opening the unit invalidates the guarantee.
•Do not perform any repairs on the unit yourself, otherwise correct functioning
of the unit can no longer be guaranteed.
•If repairs are required, please contact customer service.
Disposal
Warning
•When disposing of the materials of the measuring device, be sure to observe
the generally applicable safety precautions for handling blood. Carefully dis-
pose of all blood samples and materials with which you have come into con-
tact, in order to prevent injury and infection of others.
•After use, dispose of the test strips and lancets in a sharp-proof container.

Beurer BGL60 mg/dL 15
Note
In the interest of protecting the environment, the unit must not be thrown
out with the household waste at the end of its service life. Please
dispose of the unit in accordance with EU directive 2002/96/EC –
WEEE (Waste Electrical and Electronic Equipment). For any
queries, please contact the municipal authority responsible for
disposal.
Standard and rechargeable batteries should not be disposed of along with hou-
sehold waste. As a consumer, you are legally obliged to return used batteries
for proper disposal. You can hand in your used batteries at public collection
points in your district or sales outlets where batteries of this type are sold.
The following symbols are found on batteries that contain harmful substances:
Pb = battery contains lead
Cd = battery contains cadmium
Hg = battery contains mercury

16 Beurer BGL60 mg/dL
3 Description of the unit and accessories
3.1 Blood pressure/blood sugar measuring device
Item Designation
1 Cuff tube
2 Cuff plug
3 Upper arm inflatable cuff
4 Connector for mains power adap-
ter (rear side)
5 Display
6 Computer port
7 M - memory button
8 ON/OFF button (do not press the
button unless the inflatable cuff is
attached).
9 T/ SET: Set button
10 S: Set button
11 Port for cuff plug
12 Test strip slot
3.2 Lancing device and needle lancets
Item Designation
1 Cap
2 Protective disk for the lancet
3 Sterile needle lancet
4 Lancet holder
5 Release button
1
234
56
6 Tensioning device

Beurer BGL60 mg/dL 17
Display symbols for blood pressure/sugar
1
2
3
6
7
4
5
8
9
10
11
12
13
14
15
16
SYS
DIA
mg/dL
mmol/L
mmHg
kPa
1 Blood drop symbol 9 Systolic blood pressure (SYS)
2 Code symbol - not functional 10 Blood sugar unit mg/dL
3 SYS value display / blood sugar 11 Blood sugar unit mmol/L
4 Test strip symbol – not functional
5 WHO classification display 12 Blood pressure unit mmHg
6 Symbol for heartbeats per min 1/min 13 Blood pressure unit KPa
Cardiac arrythmia symbol 14 Diastolic blood pressure (DIA)
7 Pulse value display, 15 Memory symbol
Average blood sugar 16 DIA value display
8 Confirmation symbol

18 Beurer BGL60 mg/dL
Other display symbols
17
19
18
20
Date
Time
CTL
DAY AVG
17 Display of date or time
Date: Day – month
19 CTL for control solution
measurement
18
Time: Hours – minutes
Battery change symbol
20 DAY AVG for average value
7, 14, 21, 28, 60, 90 days
Note
The measuring device is supplied with the following basic settings:
•Blood pressure level unit: mmHg
•Blood sugar unit: mg/dL

Beurer BGL60 mg/dL 19
3.3 Test strips
Front view Rear view
1 Slit for blood collection
2 Hold here
3 Contacts
You will know which side is the rear
from the "X" symbol.
Insert the test strip into the unit so that the contacts are visible in the slit. En-
sure that the front side of the test strip is facing you.
Note
Read the following information about handling and storing your test strips care-
fully. The test strips are guaranteed to yield accurate measurement results only
if you observe all instructions.
Warning
•Each test strip is to be used only once and only for one patient!
1
2
3

20 Beurer BGL60 mg/dL
Handling test strips
Note
•Before using the first test strip, ensure that the seal on the container is un-
broken. If the seal is damaged, do not use the test strips.
•Once you have removed the test strip, tightly close the container again im-
mediately.
•Do not use test strips if the expiry date has passed. The use of expired test
strips can lead to inaccurate measurements. The expiry date is located on
the container next to the hourglass symbol .
•The test strips can be kept for three months once the container is open.
•Make a note of when this time will run out (date of opening + 3 months )
on the label. The shelf life decreases if the expiry date is reached before the
end of the 3 months (see the date next to the hourglass symbol ).
•Do not use the test strips if either of these dates has expired ( / ).
•Any part of the test strip may be handled with dry, clean hands.
•Use the test strips immediately upon removal from the container.
•Do not bend, cut, or otherwise modify the test strip.
•Do not use test strips that have come into contact with liquids for the blood
sugar measurement.
