Non-contact Forehead Thermometer
Instruction manual ...................................2
ESPAÑOL
Termómetro clínico sin contacto
Manual de instrucciones.......................24
FRANÇAIS
Thermomètre frontal sans contact
Mode d’emploi........................................47
For Canada only/ Solo para Canadá/
Seulement pour le Canada :
Manufacturer/ Fabricante/ Fabricant :
Beurer GmbH, Söflinger Str. 218
89077 Ulm, Germany
Distributed by/ Distribuido por/ Distribué par :
Beurer North America LP
1 Oakwood Boulevard, Suite 255
Hollywood, FL 33020, USA
www.beurer.com
Questions or Comments? Call our US-based
customer service toll free at 1-800-536-0366.
¿Preguntas o comentarios? Llame a nuestro
servicio al cliente en Estados Unidos gratis al
teléfono 1-800-536-0366.
Questions ou commentaires? Appelez gratuitement
notre service clientèle situé aux États-Unis au
1-800-536-0366.

READ THIS MANUAL COMPLETELY AND
CAREFULLY BEFORE USING THIS PRODUCT
Keep this manual in a safe location for future reference
LEA TODO ESTE MANUAL CON ATENCIÓN ANTES DE USAR ESTE PRODUCTO
Conserve este manual en un lugar seguro para consultarlo en el futuro
LISEZ CE MODE D’EMPLOI COMPLÈTEMENT ET ATTENTIVEMENT
AVANT D’UTILISER CE PRODUIT
Conservez ce manuel en lieu sûr pour y faire référence ultérieurement

3
Content
Dear Valued Customer,
Thank you for choosing one of our products. Our name stands for high-quality, thoroughly
tested products for application in the areas of heating, weight management, blood pressure,
body temperature, pulse, gentle therapy, massage, and beauty.
Register your product today to receive further benefits:
• added protection for your purchase
• health and wellness tips
• new product information
• continual outstanding customer service and support.
Visit www.registerbeurer.com or contact customer service at 1-800-536-0366.
Please read these instructions for use carefully and keep them for later use.
Make them accessible to other users and observe the information they contain.
With kind regards,
Your Beurer Team
1. Important safety notes....................................... 4
2. Package Contents................................................ 8
3. Parts and Controls............................................... 9
4. Introduction ........................................................... 10
5. Initial Use................................................................ 12
6. Switching On and Setting The
Thermometer......................................................... 12
7. Forehead Measurement................................... 15
8. Measuring Object Temperature/Room
Temperature........................................................ 17
9. Troubleshooting Guide.................................. 18
10. Changing batteries.......................................... 18
11. Care, Maintenance and Disposal............. 19
12. Technical Specifications............................... 20
13. Warranty ............................................................... 21
ENGLISH

4
SAVE THESE INSTRUCTIONS FOR FUTURE REFERENCE
If the instruction manual is damaged or if you no longer have the instruction
manual in your possession, please contact Beurer customer service. Please see
warranty for service contact.
Indication for use
The non-contact forehead thermometer, model FT90, is an infrared thermometer intended for
the periodic measurement of human body temperature for persons of all ages. Additionally it
can measure the room and object temperature in seconds.
1. Important safety notes
Signs and symbols
Whenever used, the following signs identify safety and property damage messages and
designate a level of hazard or seriousness.
READ THIS ENTIRE MANUAL INCLUDING THE SAFETY SECTION AND ALL
INSTRUCTIONS AND WARNINGS COMPLETELY AND CAREFULLY BEFORE USING
THIS PRODUCT. FOLLOW ALL SAFETY INSTRUCTIONS AND WARNINGS TO AVOID
HAZARDOUS SITUATIONS AND TO MAKE CORRECT USE OF THIS PRODUCT.
WARNING WARNING indicates a hazardous situation which, if not avoided, could
result in death or serious injury.
CAUTION CAUTION indicates a hazardous situation which, if not avoided, may
result in minor or moderate injury.
NOTICE NOTICE addresses practices not related to personal injury, such as
product and/or property damage.
Type BF applied part

5
Follow instructions for use
Operating
Permissible operating temperature and humidity
Storage
Permissible storage temperature and humidity
Serial number
IP 22
IP class
Device protected against foreign objects ≥ 12.5 mm and against water
dripping at an angleDevice protected against foreign objects ≥ 12.5 mm
and against water dripping at an angle
WARNING:
• Prolonged high fever requires medical attention-especially in young children.
• The thermometer needs to be in the room in which the measurement is taken for
at least 30 minutes before use.
• The thermometer is only designed for the measuring point on the human body
stated in the instructions for use.
• The device is only intended for the purpose stated in these instructions for use.
• Children must not be allowed to use the device. Medical products are no toys.
• The device has been designed for practical use, but is not a substitute for a visit
to the doctor.
• Should you have any questions about using the device, please contact either
your retailer or Customer Services.

6
• Packaging materials are a deadly hazard for children and can cause suocation.
Remove all packaging materials immediately and keep them away from children
at all times.
• Swallowing batteries and/or battery fluid can be extremely dangerous. Keep the
battery out of the reach of children. Should a child, or any other person swallow a
battery and/or battery fluid, please call 911 immediately.
• Should battery fluid leak and come into contact with your eyes or skin,
immediately rinse with plenty of clean water. Please call 911 immediately.
CAUTION:
• Check before each use that the measuring sensor is intact. If it is damaged,
please contact your retailer or the service address.
• This unit is intended for home use only. It is not intended for professional use
in hospitals or other medical facilities. This unit does not support the standards
required for professional use.
• Do not disassemble this unit.
NOTICE:
• Portable and mobile HF communication systems may interfere with this device.
For more details, please contact our customer service at the address indicated or
see the enclosed information sheet.
• Do not subject the device to mechanical impacts.
• When not in use, store the thermometer in the provided storage case.
• Do not expose the device to liquids. The device is not waterproof. Avoid all direct
contact with water or other liquids.
• Do not expose the device to direct sunlight.
• Clean the measuring sensor before each use.
• Do not touch the measuring sensor with fingers.
• Do not use any aggressive solvents, cleaning agents, detergents or any other
strong chemicals to clean the device.

7
• Replace weak batteries before they discharge completely. When “ ” in the
display occurs please change the batteries.
• Due to anatomical differences in people, the (highest) temperature measured at
different positions on the forehead may vary. When in doubt, move the thermometer
over the entire forehead area during measurement.
• Do not use mobile telephones, microwaves, and other devices which generate
strong electrical or electromagnetic fields near the unit. This may result in incorrect
operation of the unit.
• Do not press the buttons with excessive force or with any pointed objects.
• Never attempt to repair the instrument or adjust it yourself. This may damage the unit
and impair the functions. If you need to have the unit repaired, please contact our
Customer Service. Please see warranty for service contact. Before submitting any
complaint, first check the batteries and replace them if necessary.
• Changes or modifications to the device will nullify the user warranty.
Battery Handling Safety Precautions
• Use only the size and type of battery specified.
• Be sure to follow the correct polarity when installing the battery. Reversed battery may
cause damage to the device.
• If the battery in the device is depleted or the device will not be used for a long period of
time, remove the battery to prevent damage or injury from possible battery leakage.
• Do not try to recharge a non-rechargeable battery; it can overheat and rupture (follow
battery manufacturer’s directions.)
• Do not dispose of battery in fire, battery may explode or leak.
• Clean the battery contacts and also those of the device contacts prior to battery
installation.
• Remove discharged battery from the product and dispose/recycle in compliance with all
applicable laws.
• Keep battery away from children and pets. Battery may be harmful if swallowed. Should a
child or pet swallow a battery, seek medical assistance immediately.

8
Notes on electromagnetic compatibility
• The device is suitable for use in all environments listed in these instructions for use,
including domestic environments.
• T he use of the device may be limited in the presence of electromagnetic disturbances.
This could result in issues such as error messages or the failure of the display/device.
• A void using this device directly next to other devices or stacked on top of other devices,
as this could lead to faulty operation. If, however, it is necessary to use the device in the
manner stated, this device as well as the other devices must be monitored to ensure they
are working properly.
• T he use of accessories other than those specified or provided by the manufacturer of this
device can lead to an increase in electromagnetic emissions or a decrease in the device’s
electromagnetic immunity; this can result in faulty operation.
• F ailure to comply with the above can impair the performance of the device.
2. Package Contents
• Non-contact forehead thermometer FT 90
• 2 x AAA (LR03) batteries
• Storage box
• Instruction manual

9
3. Parts and Controls
1Display
2MODE/MEM button
3On/O button
4LIGHT/SET button
5Start-measurement button
6Measuring sensor
7Battery compartment lock
8Battery compartment lid
Buttons Functions
Turns the device on and o.
Start
Starts the temperature
measurement.
MODE/MEM (short)
MODE/MEM (5 sec.)
Sets the measurement mode.
Displays stored measurements.
LIGHT/SET (short)
LIGHT/SET (long)
Manual switch on of the
illuminated display.
Sets the basic functions.
START
MODE
MEM
LIGHT
SET
1
3
2
4
5
6
7
8

10
3.1 Display Description
1Object temperature mode 1 2 3 4
5
6
7
8
9
10
11
12
13
14
2Room temperature mode
3Forehead temperature mode
4Acoustic signal symbol
5Year
6Memory function
7Date
8Battery level
9Temperature/memory space number display
10 Fahrenheit/Celsius measurement unit
11 Measurement result: “fever”
12 Measurement result: “no fever”
13 Illuminated display symbol
14 Year/date/time display
4. Introduction
The temperature measurement varies depending on the part of the body where the
measurement is taken. In a healthy person, the variance can be between 0.2°C and 1°C
(0.4°F and 1.8°F) in dierent parts of the body.
The result of FT90 is shown as oral temperature.

11
Normal temperature range with various thermometers
Measurements Thermometer used
Forehead temperature 35.8 °C to 37.6 °C
(96.4 °F to 99.7 °F) Forehead thermometer
Ear temperature 36.0 °C to 37.8 °C
(96.8 °F to 100.0 °F) Ear thermometer
Oral temperature 36.0 °C to 37.4 °C
(96.8 °F to 99.3 °F) Conventional thermometer
Rectal temperature 36.3 °C to 37.8 °C
(97.3 °F to 100.0 °F) Conventional thermometer
Note:
• Temperatures measured with dierent thermometers should never be compared with one
another.
• Tell your doctor what type of thermometer you used to take your temperature and on what
part of the body. Also bear this in mind while you are monitoring yourself.
Holding the thermometer for too long in the hand before taking a measurement can
cause the device to warm up. This means the measurement could be incorrect.
Influences On Body Temperature
• A person’s individual metabolism
• Age
Body temperature is higher in babies and toddlers than in adults. Greater temperature
fluctuations occur faster and more often in children. Normal body temperature decreases
with age.
• Clothing

12
• Outside temperature
• Time of day
Body temperature is lower in the morning and increases throughout the day towards
evening.
• Activities
Physical and, to a lesser extent, mental activities increase body temperature.
Note:
Taking the body temperature provides a current measurement of a person’s temperature.
If you are uncertain about interpreting the results or if the values are abnormal (e.g. fever),
please consult your doctor. This also applies in the case of slight temperature changes if
there are other symptoms of illness such as agitation, severe sweating, flushed skin, fast
pulse rate, tendency to collapse, etc.
5. Initial Use
If provided, pull out the battery insulating strip at the battery compartment or remove the
protective film from the battery and insert the battery with the correct polarity.
6. Switching On and Setting The Thermometer
The measuring sensor should be cleaned before and after each use, to eliminate dirt
and fingerprints and ensure accuracy of your readings.
Briefly press the On/O button .
After a brief self-test and two short beeps the thermometer is ready for forehead
measurement.
The device always starts up in forehead temperature mode .

13
6.1 Setting The Basic Functions
This menu allows you to set the following functions individually, one after another.
Time format
• With the thermometer switched on, press and hold the
LIGHT/SET button for 5 seconds.
The time format option flashes on the display (Fig. 1).
• Use the MODE/MEM button to set your preferred
time format and confirm with the LIGHT/SET button.
Fig. 1
Date
The year flashes in the display (Fig. 2).
• Use the MODE/MEM button to set the year and
confirm with the LIGHT/SET button.
Month/day flashes in the display (Fig. 3).
• Use the MODE/MEM button to set the month and day,
and confirm with the LIGHT/SET button.
In the 24h format, the date is displayed as day/
month. In the 12h format, it is displayed as month/
day.
Fig. 3
Fig. 2
Temperature
meas. unit Illuminated
display
Time format Date Time Acoustic
signal

14
Time
The time flashes in the display (Fig. 4).
• Use the MODE/MEM button to set the time and
confirm with the LIGHT/SET button.
In the 12h format, the time is displayed as AM/PM.
Fig. 4
Temperature meas. unit
The temperature measurement unit flashes in the display
(Fig. 5).
You can set the device to display the temperature in
degrees Fahrenheit (°F) or degrees Celsius (°C).
• To display the temperature in Celsius, select °C using
the MODE/MEM button and confirm with the LIGHT/
SET button.
• To display the temperature in Fahrenheit, select °F
using the MODE/MEM button and confirm with the
LIGHT/SET button.
Fig. 5
Acoustic signal
The acoustic signal symbol flashes in the display (Fig. 6).
You can activate/deactivate the acoustic signals (device
activation, measurement in progress, measurement
completion).
• To activate the acoustic signals, select using the
MODE/MEM button and confirm with the LIGHT/SET
button.
• To deactivate the acoustic signals, select using
the MODE/MEM button and confirm with the LIGHT/
SET button.
Fig. 6

15
Illuminated display
The light symbol flashes in the display (Fig. 7).
You can activate or deactivate the automatic illuminated
display (appears following forehead temperature
measurement).
• To activate the automatic illuminated display, select
using the MODE/MEM button and confirm with
the LIGHT/SET button.
• To deactivate the automatic illuminated display, select
using the MODE/MEM button and confirm with
the LIGHT/SET button.
Fig. 7
You can also activate the illuminated display manually by briefly pressing the LIGHT/
SET button.
The display lights up for 5 seconds.
The automatic and manual illuminated display cannot be used while measurement
is in progress.
7. Forehead Measurement
Briefly press the On/O button .
After a brief self-test and two short beeps the device is ready for forehead temperature
measurement. The device is in forehead temperature mode. This is indicated by the
symbol.
Note:
Remember that
• physical activity, increased perspiration on the forehead, taking vasoconstrictive
medication and skin irritations can distort the result.
• the forehead must be free from perspiration and cosmetics.
• before taking a reading, please remain indoors at room temperature for 5 minutes avoiding
exercise or taking a bath for 30 min prior reading.
• in case of doubt, please measure several times and take the highest measurement value.

16
Hold the thermometer 2 – 3 cm (0.78 – 1.18 in) from the indicated point.
Press the Start-measurement button and move the thermometer from
side to side over the forehead area (Fig. 8). During measurement you will
hear short beeps (only if the acoustic signal is activated), which signal
that the thermometer has found a new highest measurement. End of
measurement is signaled by a long beep.
Release the Start-measurement button. You can now read the
measurement value.
Note:
Only one single measurement is taken at a single spot in the middle of the forehead.
The display also shows the symbols or depending on the measurement:
Symbol indicates that the body temperature is equal to or higher than 38°C,
whereas symbol indicates a measured value below 38°C (100.4°F).
If the acoustic signal is switched on, three beeps will sound once the measurement is
complete if the temperature is equal to or higher than 38°C (100.4°F).
The device is ready to take another measurement when two short beeps sound and the
forehead symbol stops flashing.
The measurement is automatically saved with the date/time and classification / .
Note:
Holding the thermometer in one place too long may cause a higher ambient temperature
reading which could make the body temperature reading lower than usual.
7.1 Displaying Saved Measurements
The device only stores measurements in forehead temperature mode . The device
automatically stores the values from the last 60 measurements.
When 60 storage places are exceeded the oldest value is deleted.
Fig. 8

17
The memory can be called up as follows:
• With the thermometer switched on, press and hold the MODE/MEM button for 5 seconds.
The most recent measurement is displayed.
• With each subsequent pressing of the MODE/MEM button, first the storage space number
is displayed followed by the measurement upon release.
• In the upper line, the time and date are displayed alternately.
8. Measuring Object Temperature/Room Temperature
Object temperature mode
If you want to measure an object temperature with this thermometer, switch
to object temperature mode.
• With the thermometer switched on, briefly press the MODE/MEM button.
The device switches to the object temperature mode .
• Hold the thermometer 2 – 3 cm ( 0.78 – 1.18 in) from the measuring
point. Briefly press the Start-measurement button and read the
temperature in the display (Fig. 9).
Measurements taken in object temperature mode are not stored.
Fig. 9
Room temperature mode
If you want to use the thermometer to measure the room temperature you
need to switch to room temperature mode.
• With the thermometer switched on, briefly press the MODE/MEM
button twice.
The device switches to the room temperature mode .
• The room temperature is immediately displayed (Fig. 10).
Measurements taken in room temperature mode are not stored.
Fig. 10

18
9. Troubleshooting Guide
Error
message Problem Solution
Measurement during self-
test, device not yet ready for
measurement.
Wait until the forehead symbol stops
flashing.
Room temperature below <10°C or
over 40°C (<50°F, >104°F). Room temperature must be between 10°C and 40°C (50°F and 104°F).
(1) Forehead temperature mode:
The temperature recorded is
higher than 42.2°C (108°F).
(2) Object temperature mode: The
temperature recorded is higher
than 80°C (176°F).
Operate the thermometer only between the
specified temperature ranges. In the event
of a repeated error message, contact your
retailer or Customer Services.
(1) Forehead temperature mode:
The temperature recorded is
lower than 34°C (93.2°F).
(2) Object temperature mode: The
temperature recorded is lower
than -22°C (-7.6°F).
Operate the thermometer only between the
specified temperature ranges. In the event
of a repeated error message, contact your
retailer or Customer Services.
The batteries are empty. Replace the batteries.
10. Changing batteries
The device requires two AAA (LR03) batteries.
• Open the battery compartment.
Use a pointed object to press down on the battery
compartment lock and at the same time slide the
battery compartment downwards.

19
• Take the used batteries out of the battery compartment.
• Insert new batteries.
Make sure that the batteries are inserted observing the correct polarity.
• Close the battery compartment.
11. Care, Maintenance and Disposal
NOTICE:
• Do not subject the device to mechanical impacts.
• When not in use, store the thermometer in the provided storage case.
• Do not expose the device to liquids. The device is not waterproof. Avoid all direct
contact with water or other liquids.
• Do not expose the device to direct sunlight.
• Clean the measuring sensor before each use.
• Do not touch the measuring sensor with fingers.
• The measuring sensor is the most sensitive part of the thermometer. Take great
care of the measuring sensor when cleaning the device.
• Do not use any harsh cleaning products.
• Always observe all safety notes for user and device.
Safety notes wPage 3 – 6.
Clean the measuring sensor after each use. Use a clean cloth or cotton bud that can be
moistened with disinfectant or 70% alcohol.
To clean the entire device, please use a soft cloth slightly moistened with a mild soapy
solution. Under no circumstances may liquid enter the device.
Do not use the device again until it is completely dry.
Disposal
Observe the local regulations for material disposal. Dispose of the device in accordance to
local regulations. If you have any questions, please contact the local authorities responsible
for waste disposal.

20
12. Technical Specifications
If the device is used other than in accordance with the specifications, perfect functioning
cannot be guaranteed!
We reserve the right to make technical changes to improve and develop the product.
Type FT90
Model NT6
Measurement method Non-contact infrared measurement
Basic functions Forehead temperature measurement
Object temperature measurement
Room temperature measurement
Measurement units Celsius (°C ) and Fahrenheit (°F)
Operating conditions 10°C to 40°C (50°F to 104°F)
with a relative humidity of ≤95%
Storage and Transport Conditions -20°C to 50°C (-4°F to 122°F)
with a relative humidity of ≤85 %
Measurement distance 20 - 30 mm (-0.78 to 1.18 in) from the measuring point
Measurement range and accuracy
of forehead temperature
measurement
Forehead temperature measurement
34°C to 42.2°C (93.2°F to 108°F)
Measurement accuracy 36°C to 39°C: ±0.2°C
(96.8°F to 102°F: ±0.4°F)
In the remaining measurement range ±0.3°C (±0.5°F)
Clinical repeat precision 0.23°C (0.41°F)
Measurement range and accuracy
Object temperature measurement Object temperature measurement -22°C to 80°C (-7.6°F to 176°F)
Measurement accuracy ±4% or ±2°C (±4°F)
Memory function
Body temperature measurement Automatically stores the last 60measurements.
Acoustic signal With device activation, during measurement, when
measurement is complete (can be set).
