Biosan ES-20/80C User manual

2 Edition 1.04
If you have any feedback on our products or services, we would like to hear from you.
Please send all feedback to:
Manufacturer:
SIA Biosan
Ratsupites iela 7 k-2, Riga, LV-1067, Latvia
Phone: [phone]
Fax: [phone]
www.biosan.lv
Marketing:[e-mail]
Service: [e-mail]

Edition 1.04 3
Contents
1. About this edition of user instructions.......................................................................3
2. Safety precautions ...................................................................................................4
3. General information..................................................................................................5
4. Getting started..........................................................................................................6
5. Stacking ...................................................................................................................8
6. Operation ...............................................................................................................10
7. Specifications.........................................................................................................13
8. Ordering information ..............................................................................................15
9. Care and maintenance...........................................................................................16
10. Storage and transportation.....................................................................................17
11. Warranty.................................................................................................................18
12. EU Declaration of conformity..................................................................................19
1. About this edition of user instructions
1.1 The current edition of the user instructions applies to the following models:
Model and name
Version
ES-20/80C, orbital shaker-incubator
V.1AD
1.2 Edition 1.04 –September of 2022.

4 Edition 1.04
2. Safety precautions
2.1 Symbols used in the user instructions:
Caution!
Make sure you have fully read and understood the present instructions
before using the equipment. Please pay special attention to sections
marked by this symbol.
Caution!
Hot surface! Incubator surface and inner camera may become hot dur-
ing use. Always use protective cotton gloves to install or remove sam-
ples when the temperature is set higher than 60°C.
2.2 Symbols and icons used on the unit and packaging:
CE marking, manufacturer affirms conformity with European health, safety,
and environmental protection standards, see 12.1
WEEE directive marking, see 12.1
2.3 General safety
•The protection provided can be ineffective if theoperation of the unit does not comply
with the manufacturer's requirements.
•Save the unit from shocks and falling.
•After transportation, storage or in the case of condensation formation, and before
connecting it to the electric circuit, keep the unit under room temperature for 2-3 hrs
to dry out the unit. Without drying out, the operation of the unit may not comply with
all safety requirements.
•Store and transport the unit as described in section 10. Storage and transportation.
•Before using any cleaning or decontamination methods except those recommended
by the manufacturer, check with the manufacturer that the proposed method will not
damage the equipment.
•Do not make modifications in design of the unit.
2.4 Electrical safety
•Connect only to the mains with voltage corresponding to that on the serial number
label.
•Do not plug the unit into an ungrounded powersocket, and donot use an ungrounded
extension lead.
•Ensure that the power plug is easily accessible during use.
•Disconnect the unit from the mains before moving.
•If liquid penetrates into the unit, disconnect it from the mains and have it checked by
a repair and maintenance technician.
•Do not operate the unit in premises where condensation can form. Operating condi-
tions of the unit are defined in section 7. Specifications.

Edition 1.04 5
2.5 During operation
•Make sure that all sample vessels are tightly sealed. Humidity caused by evaporation
from unsealed vessels inside the incubator will damage the unit.
•Do not operate the unit in environments with aggressive or explosive chemical mix-
tures. Please contact manufacturer for possible operation of the unit in specific at-
mospheres.
•Do not incubate flammable, explosive or chemically active substances. If such sub-
stance is spilled inside the incubator, it must be cleaned with a moist cloth and a mild
soap solution.
•Do not operate the unit if it is faulty or has been installed incorrectly.
•Do not use outside laboratory rooms.
•Do not place aload exceeding the maximum load value mentioned insection 7. Spec-
ifications.
2.6 Biological safety
•The user is responsible to carry out appropriate decontamination if hazardous mate-
rial spills on or penetrates into the equipment.
3. General information
ES-20/80C shaker-incubator for biotechnological and pharmaceutical laboratories is
a professional category equipment. The typical applications include –microbial and cell cul-
ture cultivation, protein expression, solubility studies, generalmixing, as well as other various
applications in the fields of biology and chemistry. The unit is equipped with a newly devel-
oped triple eccentric mechanism for platform motion that provides supreme balancing char-
acteristics, superior reliability and quiet operation. The achieved stability of the unit during
vigorous mixing allows for stacking installation of up to 3 units which enables to save space.
The new display and easy to use user interface provide a clear and intuitive control
of parameters and allow data logging, storage and display over time. Additional features like
out of balance sensor and automatic thermostat failure detection make this shaker-incubator
an advanced and safe product. Bluetooth connectivity to PC allows for data management,
data logging, parameter control and profiling in a dedicated software.
A combination of an electric heating element and a built-in heat-resistant brushless
fan provides precise temperature distribution inside the chamber up to +80 °C. Cooling of
the chamber is provided by additional Peltier modules allowing to cool until 12.5 °C below
the ambient temperature. Additionally, an excellent sample temperature uniformity of
±0.2 °C at 37 °C is achieved. The inner chamber is made of stainless steel. State-of-the-art
motor, thermal insulation materials and parameter PID-control decrease the energy con-
sumption and make the shaker-incubator highly energy efficient despite its relatively large
size.

6 Edition 1.04
4. Getting started
4.1 Unpacking. Remove packing materials carefully and retain them for future shipment
or storage of the unit. Examine the unit carefully for any damage incurred during
transit. The warranty does notcover in-transit damage. Warrantycovers only the units
transported in the original package.
Caution!
Due to the high weight of the ES-20/80C model, its unpacking and in-
stalling must be carried out by two persons.
4.2 Complete set. Package contents:
4.2.1 Standard set:
- ES-20/80C, Orbital shaker-incubator ...............................................................1 pce.
- Power cable ....................................................................................................1 pce.
- Spare fuse (inside fuse holder) .......................................................................1 pce.
- Four screws and a hex driver.............................................................................1 set
- USB drive with software and software manual.................................................1 pce.
- User instructions, declaration of conformity ....................................................1 copy
4.2.2 Optional accessories –available on request:
- HSP-30/100 platform........................................................................................1 pce.
- HSP-16/250 platform........................................................................................1 pce.
- HSP-9/500 platform..........................................................................................1 pce.
- HSP-6/1000 platform........................................................................................1 pce.
- PP-400 platform...............................................................................................1 pce.
- UP-168 universal platform................................................................................1 pce.
- HSC-50, HSC-100, HSC-250, HSC-500, HSC-1000 clamps for UP-168.........1 pce.
- SPML double-sided adhesive strips....................................................1 set of 3 pce.
- TR-21/50 test tube rack for UP-168 .................................................................1 pce.
- TR-44/15 test tube rack for UP-168 .................................................................1 pce.
- Stacking kit for two units.....................................................................................1 set
- Stacking kit for three units..................................................................................1 set
- USB Bluetooth adapter for PC .........................................................................1 pce.
HSP-30/100 HSP-16/250 HSP-9/500
HSP-6/1000 PP-400 UP-168

Edition 1.04 7
SPML TR-21/50 TR-44/15
Figure 1. Select optional accessories
4.3 Setup.
Note.
Ensure that the unit is placed on level horizontal surface, which is able to
support its weight.
Note.
To stack two or three units, see the section Stacking.
- Place the unit upon even horizontal firm and stable non-flammable surface 30 cm
away from any flammable materials, and clear 20 cm around the device on all sides
for ventilation.
- Level the unit on the surface by adjusting the threaded legs. Rotate the legs until
the unit is stable, then secure the thread with a jam nut. The unit should stand on all
4 legs, vibrations should be absent.
- Remove the protective film from the display.
- Connect the power cable to the socket on the rear side of the unit and position it
with easy access to the power switch and plug.
Caution!
After transportation, storage or in the case of condensation formation,
and before connecting it to the electric circuit, keep the unit under room
temperature for 2-3 hrs to dry out the unit. Without drying out, the opera-
tion of the unit may not comply with all safety requirements.
4.4 Platform installation.
4.4.1 Remove the silicon mat and unscrew four screws from the previous platform using a
hex driver if a platform was present. Install and secure the new platform to the moving
part of the base with four screws and replace the silicone mat.
4.4.2 UP-168 platform. The platform can be outfitted with flask clamps, test tube racks or
adhesive strips. Arrange the components symmetrically in relation to the centre of the
platform. Clamps and racks include screws to secure them on the platform. Maximum
number of components is listed in section 7. Specifications.
4.4.3 SPML strips for UP-168.
- Remove any obstructing clamps or racks (UP-168).
- Degrease, clear and dry the platform as described in 9.3.1.
- Remove protective plastic sheet from one side of the mat/strip and place it on the
platform. Place up to three SPML strips symmetrically, in parallel to the longer
edge.
- Remove the remaining protective sheet. Keep both sheets!
Note.
Consult the manual enclosed with the SPML for recommendations on
sample vessel choice, and for maintenance beyond stated in 9.3.3

8 Edition 1.04
5. Stacking
Note.
The following section applies to the optional stacking kit, to use with 2 or
3 incubator units.
5.1 Stacking kit contains:
Component
Kit for 2 units
Kit for 3 units
Catalogue number
BS-0101670-OK
BS-0101670-PK
Side legs
–
2
Holder plate
4
8
Hex screw (4 mm)
16
40
Washer
16
40
Lock washer
16
40
Hex driver
1
1
5.2 Acquiring a kit. To purchase the kit, contact Biosan or your local Biosan representa-
tive, with information from the section Ordering information.
5.3 Getting started.
5.3.1 Unpack the kit. Unpower the units and disconnect the power cables.
5.3.2 Prepare the working space. Ensure that the floor and the desk support at least 150
kgF/m2(for 2 units) or 200 kgF/m2(for 3 units). Laminated or rubberized flooring is not
recommended since it may reduce overall stability.
5.3.3 Position the units so that the access to the mains plugs, the sockets and the power
switches is unobstructed.
5.4 Stacking two units (figure 2).
5.4.1 Set one unit atop the other.
5.4.2 Connect the units with four plates. A plate requires four screws, each with a washer
and a lock washer on it (fig. 3). Fix the screws tightly.
5.5 Stacking three units.
5.5.1 Base unit (figure 4):
5.5.2 Attach the left and the right legs to the base unit. A leg requires four screws, each
with a washer and a lock washer on it (fig. 3). Fix the screws tightly.
5.5.3 Regulate the rubber parts of the legs so that the base unit is stable and level.
5.5.4 Middle unit (figure 5):
5.5.5 Set the middle unit atop of the base unit.
5.5.6 Connect the units with four plates. A plate requires four screws, each with a washer
and a lock washer on it (fig. 3). Fix the screws tightly.
5.5.7 Top unit (figure 6):
5.5.8 Set the top unit atop of the middle unit.
5.5.9 Connect the units with four plates. A plate requires four screws, each with a washer
and a lock washer on it (fig. 3). Fix the screws tightly.
5.6 Connect the power cables to the units and to grounded mains sockets.
5.7 Maintenance. Check the screw fixation and unit stack stability once a month.

Edition 1.04 9
Figure 2. Stacking two units Figure 3. Washers on the screw
Figure 4. Stacking three
units, base level
Figure 5. Stacking three
units, middle level
Figure 6. Stacking three
units, top level

10 Edition 1.04
6. Operation
Caution!
After transportation, storage orin the case of condensation formation, and
before connecting it to the electric circuit, keep the unit under room tem-
perature for 2-3 hrs to dry out the unit. Without drying out, the operation
of the unit may not comply with all safety requirements.
6.1 Connect the unit to a grounded power socket. Set the
Power switch on the rear panel to position I(on).
6.2 The display turns on. From top to bottom, display shows:
- Current date and time;
- Actual and set temperatures;
- Actual RPM, set RPM and timer;
- Status bar;
- Context buttons, corresponding to unmarked keys be-
low the display.
6.2.1 Below the display:
- Four unmarked keys, corresponding to context buttons
on the display;
- The Select, ▲, ▼ and Run Stop keys.
6.3 Setting the parameters. Press the Select key to select
the parameter to change. Use the ▲ and ▼ keys to ad-
just the parameter. Pressing the key for longer than 2 s
increases changing speed. Press the Select key again
to select the next parameter. Changes are saved auto-
matically.
6.3.1 Setting temperature. Temperature starts changing ac-
cording to set value. Increment is 0.1ºC. Values can be
changed anytime.
6.3.2 Setting speed (RPM). Increment is 10 RPM. Speed can be adjusted anytime.
6.3.3 Setting time. Time is set separately for hours and minutes, with increment of 1 mi-
nute.
6.4 Program execution.
6.4.1 When the actual temperature in the incubator reaches set values, open the door and
place samples on the platform.
Caution!
Place the samples symmetrically in relation to the centre of the platform
to avoid imbalance errors.
Caution!
Do not fill the vessels inside the incubator. Please make sure that all
vessels are tightly sealed. Humidity caused by evaporation from un-
sealed vessels inside the incubator will damage the unit!
6.4.2 Press the Run Stop key. The platform will start rotating and the timer indicator will
start counting the time interval.
Note.
If the speed is set to zero, pressing the Run Stop key will start the timer,
but the platform will not move.
Figure 7. Control panel

Edition 1.04 11
6.5 After finishing the program (after the set time elapses), the platform motion stops,
and the status bar shows STOP accompanied by the repetitive sound signal. Press
any key to stop the signal.
Caution!
The chamber heating can only be stopped manually by reducing the tem-
perature.
6.6 If the time is not set (set time is 00:00), the Run Stop key will start continuous oper-
ation of the unit until the Run Stop key is pressed again.
6.7 The platform motion can be stopped at any time by pressing the Run Stop key. In
this case, the program realisation and the platform motion will stop, and the timer will
switch into the STOP mode saving previously set time. Press the Run Stop key to
restart the operation with the same time and speed. Additionally, if the door is opened
the platform will stop, after closing the door, platform will reinitiate motion automati-
cally.
6.8 Power interruption. In case of mains/power failure the unit is equipped with auto-
matic restart function which will reinitiate the platform motion with previously set pa-
rameters.
6.9 Incubator menu. The Menu button opens incubator’s menu. Use ▲ and ▼ buttons
to navigate and Enter button to select. While browsing in the menu, select the top-
most Quit option in order to return from sub-menu to menu.
6.9.1 Incubator ID. Option GetID shows the serial number, name of the incubator and its
Bluetooth module MAC address, as well as remote PC Bluetooth module MAC ad-
dress.
6.9.2 Date & Time. To set the date and time in this submenu, press Enter button to select
the parameter, then ▲ and ▼ buttons to change the value and Enter button to con-
firm.
6.9.3 Service. This submenu has following options: Current Errors and Settings.
6.9.3.1Current Errors. This option allows user to view and reset the list of active errors.
6.9.3.2Settings. This option has two sub-options available –Alarm Setting and Start
mode.
•Alarm Setting. User can set the alarm settings based on values of temperature and
RPM. All alarms are working on the following principle, temperature taken as an ex-
ample:
If Tact < Tthr.low or Tact > Tthr.high for tdelay minutes, then an alarm will be triggered.
Where Tact is the actual temperature inside the incubator, Tthr.low is the lower threshold
limit value, Tthr.high is the higher threshold limit value and tdelay is the time delay in
minutes. Time delay is used in order to avoid false triggering of the alarms.
RPM alarm is operated using the same principle.
•Start Mode. User can change the acceleration mode of the unit. In Start Mode Slow
the unit picks up speed gently to reduce the possibility of spilling. In Start Mode Fast
the unit rapidly gains speed and set RPM rate.

12 Edition 1.04
6.9.4 Active Alarms. This option allows user to view and reset the list of active alarms.
6.9.5 Data Logger. Data logger features following options: View Plot T(t), View Plot
RPM(t), View Plot T(t)+RPM(t), Clear log, Logger on/off.
6.9.5.1All View Plot options use the same interface. Use Left and Right buttons to move the
plot along the x axis. Use Up and Down buttons to move the plot along the y axis.
Use <-xx-> button to choose the x axis navigational scale. Available scales are 15
minutes, 1 hour, 1 day, 1 week and 1 month.
6.9.5.2Clear Log button clears the logger’s data.
6.9.5.3Logger On/Off button toggles the automatic logging of the data.
6.9.5.4Available memory indicator. When the data logger uses up all available memory, it
begins overwriting data from beginning. 100% of memory is used up in approximately
1 month.
6.10 At the end of operation, set the Power switch in position O (off). Disconnect the power
cable from electric circuit.
Note.
Frequently check condensation accumulation in the condensation tray
(see 9.1.5 and figure 8), discard if necessary.

Edition 1.04 13
7. Specifications
The unit is designed for operation in cold rooms and closed laboratory rooms at am-
bient temperature from +4°C to +40°C, altitude up to 2000 m, in a non-condensing atmos-
phere, maximum relative humidity 80% for temperatures up to 31°C decreasing linearly to
50% relative humidity at 40°C, transient overvoltages up to the II category and pollution de-
gree 2.
Biosan is committed to a continuous programme of improvement and reserves the
right to alter design and specifications of the equipment without additional notice.
7.1 Temperature specifications
Setting range ................................................................... +4°C ... +80°C (increment 0.1°C)
Control range ......................................................................12.5°C below ambient ... +80°C
Uniformity
1
..................................................................................................................±0.2°C
Control accuracy ........................................................................................................±0.1°C
Heat up time to +80°C inside the chamber ................................................................70 min
7.2 Dimension specifications
Weight, accurate within ±10% ......................................................................................50 kg
Dimensions, WxDxH ................................................................................ 620x620x510 mm
Dimensions of the inner chamber, WxDxH...............................................460x400x325 mm
Note.
Inner chamber height is measured from the shaking platform. Ensure that
the vessels in use can be installed and removed from the current platform.
Stacking.............................................................................................................up to 3 units
Note.
Stacking possible only with the stacking kit installed. Base side-mounted
leg parts are required for third level stacking.
7.3 Electrical specifications
Operating voltage..............................................................................................220–240 V~
Operating frequency............................................................................................... 50/60 Hz
Operating current .........................................................................................................3.7 A
Maximum power consumption.................................................................................... 810 W
1
Data for liquid temperature, at 37°C and 240 RPM

14 Edition 1.04
7.4 General specifications
Speed control range........................................................50–400 RPM (increment 10 RPM)
Digital time setting.............................................1 min - 96 hrs (increment 1 min) / non-stop
Maximum load...........................................................................................................10.6 kg
Orbit ...........................................................................................................................20 mm
Display ...................................................................................................................TFT LCD
Data transfer...........................................................................................................Bluetooth
7.5 Maximum number of holders that can be fitted onto UP-168 platform:
Holder
FC-50
FC-100, FC-250
FC-500
FC-1000
SPML
TR-21/50, TR-44/15
Quantity
36
16
8
4
3
2
7.6 Recommended maximum speed for UP-168 platform with fully loaded TR-21/50 or
TR-44/15, depending on the set angle:
Set angle
Speed, in RPM
200
250
350
400
0°
OK
15°
OK
30°
OK
45°
OK
Not recommended
60°
OK
Not recommended
75°
OK
Not recommended

Edition 1.04 15
8. Ordering information
8.1 Models and versions available:
Model
Version
Description
Catalogue number
ES-20/80C
V.1AD
220–240 V, 50/60 Hz, no platforms
BS-010173-A01
8.2 To inquire about or order the optional accessories, contact Biosan or your local Bio-
san representative.
8.3 Optional accessories for ES-20/80C:
Model
Description
Catalogue
number
HSP-30/100
Platform with clamps for 30 flasks of 100 ml
BS-010167-KK
HSP-16/250
Platform with clamps for 16 flasks of 250 ml
BS-010167-MK
HSP-9/500
Platform with clamps for 9 flasks of 500 ml
BS-010167-NK
HSP-6/1000
Platform with clamps for 6 flasks of 1000 ml
BS-010167-LK
PP-400
Flat platform with non-slip silicone mat
BS-010135-FK
UP-168
Universal platform for different flasks
BS-010135-JK
HSC-50
Clamp for 50 ml flask for UP-168 platform (ø 50 mm)
BS-010167-DK
HSC-100
Clamp for 100 ml flask for UP-168 platform (ø 65 mm)
BS-010167-EK
HSC-250
Clamp for 250 ml flask for UP-168 platform (ø 85 mm)
BS-010167-FK
HSC-500
Clamp for 500 ml flask for UP-168 platform (ø 105 mm)
BS-010167-JK
HSC-1000
Clamp for 1000 ml flask for UP-168 platform (ø 130 mm)
BS-010167-IK
SPML
Set of 3 double-sided adhesive strips for UP-168,
dimensions 390x80x3 mm
BS-010135-MK
TR-21/50
Variable angle test tube rack for 21 tubes of 50 ml for UP-168
BS-010135-KK
TR-44/15
Variable angle test tube rack for 44 tubes of 15 ml for UP-168
BS-010135-LK
Bluetooth®adapter
BS-010167-CK
Stacking kit for two units
BS-010167-OK
Stacking kit for three units
BS-010167-PK

16 Edition 1.04
9. Care and maintenance
9.1 Service and maintenance.
9.1.1 If the unit is disabled (e.g., not incubating, no reaction on key and switch presses) or
requires maintenance, disconnect the unit from the mains and contact Biosan or your
local Biosan representative.
9.1.2 All maintenance and repair operations (except listed below) must be performed only
by qualified and specially trained personnel.
9.1.3 Operating integrity check. If the unit follows the procedure described in section Op-
eration, then no additional checks are required.
9.1.4 If a stacking kit is used, check the screw fixation and unit stack stability once a month.
See section 5. Stacking for additional information.
9.1.5 Frequently check condensation accumulation in the condensation tray (fig. 8), discard
if necessary.
Figure 8. Condensation tray
9.2 Cleaning and disinfection.
9.2.1 Use mild soap and water with a soft cloth or sponge for cleaning the exterior. Rinse
remaining washing solution with distilled water. Wipe dry the excess water with clean,
soft cloth or sponge.
9.2.2 Standard ethanol (75%) or other cleaning agents recommended for cleaning of labor-
atory equipment can be used for cleaning and decontamination of the steel surfaces.
9.2.3 For decontamination, it is recommended to use a special DNA/RNA removing solu-
tion (e.g., Biosan PDS-250, DNA-Exitus Plus™, RNase-Exitus Plus™).
9.2.4 SPML adhesive material maintenance. Clean the adhesive surfaces with water or
mild soap solution, rinse and air dry before reattaching. Adhesive properties work
only when the surface is clean, dry and dust-free. Do not subject to UV radiation, do
not place in high humidity (i.e., do not autoclave). Read the enclosed manual for ad-
ditional info.

Edition 1.04 17
9.3 Fuse replacement. Disconnect the power cable from the mains. Disconnect the
power cable from the socket on the rear of the unit. Open the fuse holder, located
near the socket (figure 9). Check and replace with a correct fuse, if necessary, see
table below:
Model & version
Fuse1
ES-20/80C V.1AD (230 V)
M 4 A
Figure 9. Fuse holder
9.4 Disposal. Disposal of the appliance requires special precautions andmust be carried
out at an appropriate disposal site, separate from normal household waste. To pre-
vent pollution of the environment, all waste resulting from the disposal of the product
must be collected and disposed of in the country of use, in accordance with the ap-
plicable requirements for the handling of electronic waste.
10. Storage and transportation
10.1 Store and transport the unit in a horizontal position (see package label) at ambient
temperatures between -20°C and +60°C and maximum relative humidity of 80%.
10.2 After transportation, storage or in the case of condensation formation, and before
connecting it to the electric circuit, keep the unit under room temperature for 2-3 hrs
to dry out the unit. Without drying out, the operation of the unit may not comply with
all safety requirements.
10.3 For extended storage, check condensation accumulation, see 9.1.5. No further ac-
tions are necessary.
1
Fuse type M - time lag Medium

18 Edition 1.04
11. Warranty
11.1 The Manufacturer guarantees the compliance of the unit with the requirements of
Specifications, provided the Customer follows the operation, storage and transporta-
tion instructions.
11.2 The warranted service life of the unit from the date of its delivery to the Customer is
24 months, excluding optional accessories mentioned in the section Ordering infor-
mation. For extended warranty, see 11.5.
11.3 Warranty covers only the units transported in the original package.
11.4 If any manufacturing defects are discovered by the Customer, an unsatisfactory
equipment report shall be compiled, certified and sent to the local distributor address.
To obtain the claim form, visit Technical support page on our website at link below.
11.5 Extended warranty. For ES-20/80C, the Smart class model, extended warranty is a
paid service. Contact your local Biosan representative or our service department
through the Technical support section on our website at the link below.
11.6 Description of the classes of our products is available in the Product class descrip-
tion section on our website at the link below.
Technical support
Product class description
biosan.lv/en/support
biosan.lv/classes-en
11.7 The following information will be required in the event that warranty or post-warranty
service comes necessary. Complete the table below and retain for your records.
Model
Serial number
Date of sale
ES-20/80C,
Orbital shaker-incubator
11.8 Production date. Production date is placed in the serial number, on the label of the
unit. Serial number consists of14 digits styled XXXXXXYYMMZZZZ, where XXXXXX
is model code, YY and MM –year and month of production, ZZZZ –unit number.
11.9 The Bluetooth®logo and name are registered trademarks of Bluetooth SIG, Inc. and
any use by Biosan is under licence.

Edition 1.04 19
12. EU Declaration of conformity
12.1 Orbital shaker-incubator ES-20/80C is in conformity with the following relevant Union
legislations:
LVD 2014/35/EU
LVS EN 61010-1:2011 Safety requirements for electrical equipment for
measurement, control, and laboratory use. General requirements.
LVS EN 61010-2-010:2015Particular requirements for laboratory equip-
ment for heating of materials.
LVS EN 61010-2-051:2015 Particular requirements for laboratory equip-
ment for mixing and stirring.
EMC 2014/30/EU
LVS EN 61326-1:2013 Electrical equipment for measurement, control and
laboratory use. EMC requirements. General requirements.
RoHS3 2015/863/EU
Directive on the restriction of the use of certain hazardous substances in
electrical and electronic equipment.
WEEE 2012/19/EU
Directive on waste electrical and electronic equipment.
12.2 Declaration of Conformity is available for download on the page for the relevantmodel
on our website by links below, in the Downloads section:
ES-20/80C

Biosan SIA
Ratsupites 7 k-2, Riga, LV-1067, Latvia
Phone: [phone] Fax: [phone]
Edition 1.04 –September of 2022
