Intrusion Alarm Systems | D220A Series LED Keypads
D220A Series LED Keypads
www.boschsecurity.com
uStep Outside excursion feature provides easy to use
bypass and restoral of entry points
uExit Only function allows users to exit when the
system is On with No Delay without turning the
system Off
uIndividual color-coded lights show system status at
a glance
The D220A Series Keypad displays are strategically
placed and easy to read. Most users can operate the
keypad with confidence after only a few minutes of
instruction, eliminating the need for extensive training
sessions.
Functions
Individual Color-coded Lights
The keypads have the following lights to indicate
system status:
• Red light indicating the system is On
• Yellow light indicating the system is On with No Delay
• Red lights indicate each of the eight sensor loops
• Green light indicating the system is "All On"
• Green light indicating the system is "Part On"
• Green light indicating overall system operation is okay
Coded Sounder
The sounder uses coded tones to provide alarm,
trouble, watch, entry and exit delay, error, and other
annunciation. Some tones can be enabled, disabled,
and otherwise altered by programming.
Three Programmable Emergency Keys
Along with the 11 action keys, there are three
programmable keys that can be programmed for
specific functions, such as Emergency, Fire, or Panic.
Single key operation controls many of the basic
functions. All of the keys illuminate during entry delay
and when a key is pressed. Custom labeling is
provided for all the keys except the "CLEAR" key.
Certifications and approvals
NFPA 72 Household
Region Certification
USA UL AMCX: Central Station Alarm Units
(UL1610, UL1635), AOTX: Local Alarm
Units (UL464, UL609), APAW: Police
Station Alarm Units (UL365, UL464),
APOU: Proprietary Alarm Units
(UL1076), NBSX: Household Burglar
Alarm System Units (UL1023), UTOU:
Control Units and Accessories - House-
hold System Type (UL985)
CSFM 7167-1615: 124 July 2008
Installation/configuration notes
The D220A and D220AW Keypads are compatible with
D2212B and D2212BE Control Panels.

Refer to the control panel’s installation manual for
information on the maximum number of keypads that
can be used with the specific system. Regardless of
the system or the number of keypads being wired in
parallel, the maximum wire length for all keypads
combined is 152 m (500 ft) of 0.8 mm (22 AWG) wire.
Technical specifications
Enclosure
Dimensions: 12 cm x 21 cm x 2 cm
(4.56 in. x 8.15 in. x 0.816 in.)
Power Requirements
Voltage (Input): 12 VDC supplied by the panel
Current Draw: 30 mA standby (no backlighting);
125 mA maximum
Trademarks
Plexiglas® is a registered trademark of Arkema.
Ordering information
D220A LED Keypad
Off-white case.
Order number D220A
D220AW LED Keypad
White case.
Order number D220AW
Accessories
D54B Brass Flush‑mount Kit
Back box and polished brass faceplate.
Order number D54B
D54C Stainless Steel Flush‑mount Kit
Back box and stainless steel faceplate.
Order number D54C
D55 Keypad Desk Stand
Portable desk stand in smoke colored Plexiglas.
Order number D55
D56 Surface Mount Conduit Box
White surface mount box.
Order number D56
D56R Red Surface Mount Conduit Box
Red surface mount box.
Order number D56R
