Bradley SA70 Series User manual

Installation
P.O. Box 309
Menomonee Falls, WI 53052 USA
800 BRADLEY (800 272 3539)
[phone]
bradleycorp.com
WARNING
Unit is supplied with 1/4" - 20 x 1-1/2" T27 torx head machine screws for installation to wall anchors (not
included). Wall anchors/backing used must provide adequate support for the intended load requirements.
Grab bars are no stronger than the anchors and walls to which they are attached, and therefore, must be
firmly secured in order to support the intended load requirements. To avoid potential injury, the building
owner or maintenance personnel should remove the grab bar from service if the mounting is not adequately
secured to the wall or if there are any observed product defects.
CAUTION
Personal Protective Equipment (PPE) is required during the installation of this product.
IMPORTANT
Read this entire installation manual to ensure proper installation. When finished with the installation, file
this manual with the owner or maintenance department. Compliance and conformity to local codes and
ordinances is the responsibility of the installer.
Separate parts from packaging and make sure all parts are accounted for before discarding any packaging
material. If any parts are missing, do not begin installation until you obtain the missing parts.
Product warranties may be found under "Products" on our website at www.bradleycorp.com.
Security Grab Bars -
Exposed Mounting
SA70 Series
500-378 Rev. A; ECN 18-15-009
© 2018 Bradley
Page 1 of 2 4/2/2018
-001 configuration shown. See Bradley's
website for other configurations.

SA70 Series Installation
2 4/2/2018 Bradley • 500-378 Rev. A; ECN 18-15-009
Installation
Verify all rough-in dimensions prior to installation.
WARNING Wall must be reinforced in the area of the grab bar in order to support the load it is
intended to support.
1. Using the bar as a template, mark the mounting hole location onto the wall.
2. Drill holes and set anchors as appropriate.
3. Mount grab bar and secure mounting screws.
For more information on Bradley's grab bar mounting kits, please visit www.bradleycorp.com
Mounting Flange Dimensions
3-1/4"
(80mm)
2-1/2"
(60mm)
* 1-1/2" wall clearance required
under most building design codes
* 1-1/2"
(38mm)
1/8"
(3mm)
3-1/8"
(79mm)
exposed
