Bradley OmniDeck 3000 Series User manual

P.O. Box 309, Menomonee Falls, WI USA 53052-0309
PHONE 800.BRADLEY (800.272.3539) FAX [phone]
bradleycorp.com
Installation
215-1288 Rev. R; ECM 11-11-008
© 2011 Bradley Corporation
Page 1 of 10 3/30/11
LD3060
OmniDeck™ - 3000 Series
Table of Contents
Pre-Installation information .................2
Supplies Required ........................2
Components...........................3–4
Dimensions .............................5
Rough-Ins ..............................6
OmniDeck Installation .....................7
Supplies, Drain and P-trap..................8
Trap Cover Installation .....................8
Cleaning and Maintenance .................9
Troubleshooting Vernatherm™ TMV .........10

LD-3060 Series Installation
23/30/11 Bradley Corporation • 215-1288 Rev. R; ECM 11-11-008
IMPORTANT!
Read this entire installation manual to ensure proper installation. When finished with the
installation, file this manual with the owner or maintenance department. Compliance and
conformity to local codes and ordinances is the responsibility of the installer.
Separate parts from packaging and make sure all parts are accounted for before
discarding any packaging material. If any parts are missing, do not begin installation until
you obtain the missing parts.
Make sure that all water supply lines have been flushed and then completely turned off
before beginning installation. Debris in supply lines can cause valves to malfunction.
Turn OFF electrical power to the electrical outlets, then unplug all electrical units prior
to installation. Electrical power MUST remain off until installation is completed. After
installation is complete, turn on the water supply first, then turn on the electrical power.
Hardware supplied by installer must be appropriate for wall construction. Wall anchors
used must have a minimum pull-out rating of 1,000 lbs.
Product warranties and service parts information may be found on our web site at
bradleycorp.com.
Installation
THIS
SIDE
UP
Packing List
•
•
•
•
Supplies Required:
• (6)³⁄₈" wall anchors, bolts and 1" min. O.D. washers to mount support brackets to wall (min.pull-out rating of 1,000 lbs.)
• #10wallanchors/bolts/washerstomountanglebracketstosidewall,ifrequired(twoeachperbracket)
• (2)¼"wallanchors(tomountoptionalmixingvalve/bracket)
• ½"NPThot/coldortemperedsupplypiping
• 1½"NPTdrainpiping
• 110voltelectricaloutletforoptional110/24VACplug-intransformer,ifrequired

Installation LD-3060 Series
Bradley Corporation • 215-1288 Rev. R; ECM 11-11-008 3/30/11 3
Components
Mounting Bracket
(140-823R)
Bracket Hardware (two
each required to attach
bracket to OmniDeck)
Screw (160-120)
Washer (142-002AZ)
Angle Bracket
(140-824)
Trap Cover (textured)
Putty (186-1261)
Coal (186-1261B)
Panel Fasteners
(160-132)
Finish Washers
(142-002CA)
OmniDeck Configurations
(contact your Bradley Representative for part number)
Trap Cover V2 (with
soap access opening)
Putty (186-1544)
Coal (186-1544B)
Angle Bracket Hardware
(two each required to attach
bracket to OmniDeck)
Screw (160-120)
Washer (142-002AZ)
LD3060-2 LD3060-2-XDRW LD3060-2-XDR
LD3060-2-XDLW
LD3060-2-XDL
LD3060-2-XDL-XDR
LD3060-2-XDL-XDRW
LD3060-2-XDLW-XDRW
LD3060-2-XDR-XDLW

LD-3060 Series Installation
43/30/11 Bradley Corporation • 215-1288 Rev. R; ECM 11-11-008
Components
Drain Assembly
Waste Receptacle
with Textured Lid
Putty (S50-372)
Coal (S50-372B)
Handle Repair Kit
(S65-244)
Base Leveler Repair Kit
Stainless Steel (S65-245)
Plastic (S65-287)
Sensor-Operated
Soap Dispenser
(6315)
Soap Dispenser
(6324)
Tempered Line (S45-2081)
(269-1735)
(S27-102)
(S45-2082)
(140-934)
(P18-054)
Vernatherm™ Mixing Valve
(S59-4004XS)
(S01-524)
Strainer
(269-1839A)
Twin Tee Ell
(111-079)
P-trap
(S29-094)
Waste Arm
(111-080)

Installation LD-3060 Series
Bradley Corporation • 215-1288 Rev. R; ECM 11-11-008 3/30/11 5
Dimensions (shown with optional selections) LD-3060-2 XDLW/XDRW is shown. Other configurations
are similar. All dimensions shown are for reference only
and are subject to change.
Side View
Front View
3"
(76mm)
3"
(76mm)
54"
(1372mm)
37"
(940mm)
13½"
(343mm)
34"
(864mm)
31"
(787mm)
29"
(737mm)
ADA
8" (203mm) ADA
Optional Trap Cover
with Soap Access
Opening
Top View
11½"
(292mm)
7" (178mm) 7" (178 mm)
4" (102mm)
12"
(305mm)
8" (203mm)
15"
(381mm)
15"
(381mm)
60" (1524mm)
7½'(2286mm)
9"
(229mm)
22"
(559mm)
24"
(610mm)
8" (203mm)
30" (762mm)
30" (762mm)
30" (762mm)
9"
(229mm)

LD-3060 Series Installation
63/30/11 Bradley Corporation • 215-1288 Rev. R; ECM 11-11-008
1Rough-Ins
Side Wall
Mounting
Locations
(If Required)
Back
Wall
Finished Floor
¼"WallAnchors
(Supplied by
Installer)
5¾"
(146mm)
10"
(254mm)
32"
(813mm)
32"
(813mm)
#10WallAnchors(SuppliedbyInstaller)
(Hot/ColdSupplyOnly)
19"
(483mm)
18" (457mm)
25¼"(641mm)
110V GFCI
Electrical
Outlet
9³⁄₈"
(238mm)
18"
(457mm)
29"
(737mm)
17"
(432mm)
½"(13mm)NPTTempered
Supply Stub Out 2" (51mm)
from Wall (If Tempered
Supply Required)
1½"(38mm)NPTHot/Cold
Supply Stub Out 2" (51mm)
fromWall(IfHot/Cold
Supply Required)
³⁄₈" Wall Anchors
Supplied by Installer
(6) Places
Finished Floor
14" (356mm)
3"
(76mm)
25¼"(641mm)
1½"(38mm)NPT
Drain Stub Out 2"
(51mm) from Wall
Centerline
OmniDeck
9"
(229mm)
1³⁄₈"
(35mm)
Side Wall Mounting Locations for Angle Brackets
(standard height mounting)

Installation LD-3060 Series
Bradley Corporation • 215-1288 Rev. R; ECM 11-11-008 3/30/11 7
2OmniDeck Installation
Secure the mounting brackets to the wall with
hardware supplied by the installer.
With help from at least one other person,
position the OmniDeck on the mounting brackets
and secure the deck with the hardware provided.
For alcove wall only, secure the angle
bracket to the alcove wall after installation
of the OmniDeck is complete.
C
Secure the angle brackets to
the bottom of the OmniDeck
with the hardware provided.
B
LD-3060-2 XDLW/XDRW is shown throughout. Other configurations are similar.
Reference mounting height dimension from the top of the OmniDeck to the finished floor is 34" (864mm)
maximum (OmniDeck thickness is 1/2" [13mm]). The support brackets are slotted and may be adjusted
to meet this dimension. If necessary, adjust the OmniDeck height before securing to the brackets.
Scribe a level line for the
mountingbrackets33½"
above the finished floor.
A
Back Wall
Alcove
Wall
Finished Floor Knee
Wall
33½"
(851mm)
ref.

LD-3060 Series Installation
83/30/11 Bradley Corporation • 215-1288 Rev. R; ECM 11-11-008
3Supplies, Drain and P-trap
½"-14 NSPM
Hot
Nut Hot
Rubber Washer
Fiber Washer
Mixing Valve
Cold
Cold
Tempered
Supply
4Trap Cover Installation
10-24x½"
FL Panel
Fasteners
with Finish
Washer
Standard trap cover is shown.
Optional V2 trap cover is similar.

Installation LD-3060 Series
Bradley Corporation • 215-1288 Rev. R; ECM 11-11-008 3/30/11 9
Cleaning and Maintenance for Terreon®
Material Description: Terreon is an NAHB-certified densified solid surface material composed of polyester resin and is
resistant to chemicals, stains, burns and impact. Surface damage can be easily repaired with everyday cleansers or fine grit
abrasives.
Routine Cleaning: Clean daily or as often as conditions require using a standard commercial or household cleaner such as
Formula 409®or Windex®.
Stubborn Stains: Remove tough stains with Ajax®, Comet®, or Soft-Scrub®and a green Scotch-Brite®pad or lightly sand in a
circularmotionwith240gritwet/drysandpaper.ThenishcanberenewedwithamaroonScotch-Britepad.
Special Situations for Terreon Material
Scratches: Remove scratches with a green Scotch-Brite pad. The finish can then be renewed with a maroon Scotch-
Brite pad, followed by a white Scotch-Brite pad or 30-micron sandpaper.
Hard Water Deposits: Remove hard water deposits with a mild solution of vinegar and water. Always rinse the unit
thoroughly after cleaning.
Restoring the surface: Use Hope’s®Solid Surface cleaner and polish to refresh and protect the Terreon Solid Surface
material. Bradley recommends additional care and maintenance for the darker colored Terreon. For complete instructions
on this additional maintenance, visit bradleycorp.com.
Do not use strong acid or alkaline chemicals and cleansers to clean Terreon. If these chemicals come in
contact with the surface, wipe them off immediately and rinse with soapy water. Avoid contact with harsh
chemicals such as paint remover, bleach, acetone, etc. Avoid contact with hot pans and objects.
Repair Kits: Terreon repair kits are available. Contact your Bradley representative or distributor for part numbers and
pricing. Repair kits are made to order and have a shelf life of 30 days.
Terreon®is a unique, cast solid surface material. Aggregate flow and distribution as well as shades of color can vary
from product to product creating natural characteristics.
Cleaning and Maintenance for Stainless Steel
Material Description: Stainless steel is extremely durable, and maintenance is simple and inexpensive. Proper care,
particularly under corrosive conditions, is essential. Always start with the simplest solution and work your way toward the more
complicated.
Routine cleaning: Daily or as often as needed use a solution of warm water and soap, detergent, or ammonia. Apply the
cleaningsolutionperthemanufacturer'sinstructionsandalwaysuseasoftclothorspongetoavoiddamagingthenish.
Stubborn Stains: To remove stains from stainless steel use a stainless steel cleaner and polish such as Ball®stainless steel
cleanerorasoftabrasive.Alwaysfollowthemanufacturer'sinstructionsandapplyinthesamedirectionasthepolishlines.
Never use ordinary steel wool or steel brushes on stainless steel. Always use stainless steel wool or
stainless steel brushes.
Fingerprints and Smears: To remove fingerprints or smears use a high quality stainless steel cleaner and polish in
accordancewiththemanufacturer'sinstructions.Manyoftheseproductsleaveaprotectivecoatingthathelpspreventfuture
smears and fingerprints.
Grease and Oil: To remove grease and oil use a quality commercial detergent or caustic cleaner. Apply in accordance to the
manufacturer'sinstructionsandinthedirectionofthepolishlines.
Precautions: Avoid prolonged contact with chlorides (bleaches, salts), bromides (sanitizing agents), thiocyanates (pesticides,
photography chemicals, and some foods), and iodides on stainless steel equipment, especially if acid conditions exist.
Do not permit salty solutions to evaporate and dry on stainless steel.
The appearance of rust streaks on stainless steel leads to the belief that the stainless steel is rusting. Look for the actual source
of the rust in some iron or steel particles which may be touching, but not actually a part of the stainless steel structure.
Strongly acidic or caustic cleaners may attack the steel causing a reddish film to appear. The use of these cleaners
should be avoided.
Brand Names
Use of brand names is intended only to indicate a type of cleaner. This does not constitute an endorsement, nor does the
omission of any brand name cleaner imply inadequacy. Many products named are regional in distribution, and can be found
in local supermarkets, department and hardware stores, or through your cleaning service. It is emphasized that all products
should be used in strict accordance with package instructions.

LD-3060 Series Installation
10 3/30/11 Bradley Corporation • 215-1288 Rev. R; ECM 11-11-008
Troubleshooting – Vernatherm™Thermostatic Mixing Valve: Part no. S01-524
Before attempting to troubleshoot the valve or disassemble the
components, check for the following conditions:
• Ifstop/checkvalvesareused,makesurethattheyarefullyopen.
• Makesurethatthehotandcoldinletpipesareconnected
properly, and that there are no cross-connections or leaking
stop/checkvalves.
• Makesurewaterheateroutputisatleast20°Fabovetheset
temperature.
Close shut-off valves prior to disassembly and reopen the valves
after inspection and repair is complete.
9
6
5
4
3
2
1
7
8
Strainer
(173-028)
Valve Body
Spring
Thermostat
Piston
Stem
O-Ring
O-Ring
Cap
Nut 3/8-24 Hex Jam
10
Seal Cup
11
Item Qty. Description
5 1 Thermostat
7 1 O-ring
8 1 O-ring
Repair Kit S65-259
Strainer
173-028
Tempered Line Adapter Option: Part no. S39-685
(replaces S01-524 if tempered line is used)
Problem Cause Solution
External
leaks in the
system.
O-rings
have been
damaged.
Replace O-rings. Contact your Bradley representative to order Repair Kit no. S65-259.
Improper water
temperature or
temperature
fluctuation.
Thermostat is
slowly failing
or not working
at all.
Check the thermostat for proper operation:
1. At room temperature (80° F or less) remove the cap and thermostat.
2. Place the thermostat into a container with 115° F water. The push rod should pop out of the thermostat
approximately1/10".Ifpushroddoesnotpopout,replacethethermostat.ContactyourBradley
representative to order Repair Kit no. S65-259.
Valve
temperature
is not properly
set
Adjust the temperature using a blade screwdriver: Turn the adjustment stem counterclockwise to increase
the temperature or clockwise to decrease the temperature.
Limited
water flow.
Dirt and
debris have
built up in
the valve or
strainer.
1. Ensure hot and cold supplies are connected to the mixing valve and that they have sufficient water flow.
2. Remove and clean the strainer. If it needs to be replaced, Contact your Bradley representative to order
Bradley part no. 173-028.
3. Check the piston for smooth movement:
A. Remove the valve’s cap and thermostat.
B. Push down on the piston; if the piston does not move freely, clean it as outlined below:
• Removethethermostat.Liftthepistonoutwithaneedle-nosepliersandremovethespring.
• Anybrassandstainlesssteelcleanermaybeused.Ifasuitablecleanerisinsufficienttoremove
debris, use a 400-grit sandpaper to polish and hone the piston and valve body).
• Snapthespringintothepiston(itwilldetent);reassembleintothevalvebody.Retestthepiston.
C. If, after a thorough cleaning, the piston does not move freely, the piston must be replaced. Contact
your Bradley representative to order Repair Kit no. S65-259.
