Bradley CBSHWR9000KD User manual

IMPORTANT!
Read this entire installation manual to ensure proper installation. When
finished with the installation, file this manual with the owner or maintenance
department. Compliance and conformity to local codes and ordinances is
the responsibility of the installer. Bradley cannot assume any responsibility
for improperly installed units.
Separate parts from packaging and make sure all parts are accounted for
before discarding packaging material. If any parts are missing, do not begin
installation until you obtain the missing parts.
Make sure that all water supply lines have been flushed and then completely
turned off before beginning installation. Debris in supply lines can cause
valves to malfunction.
Product warranties may be found under “Products” on our web site at
bradleycorp.com.
Installation
THIS
SIDE
UP
Packing List
•
•
•
•
P.O. Box 309, Menomonee Falls, WI 53052-0309
Phone: 1-800-BRADLEY Fax: [phone]
bradleycorp.com
Installation
215-1676; EN 10-07-002
© 2010 Bradley Corporation
Page 1 of 4 4-9-10
CBSHWR9000KD
Cabinet Shower
Table of Contents
Supplies Required ...........................2
Rough-In Information .........................2
Installation Instructions .......................3
Cleaning Instructions .........................4

CBSHWR9000KD Installation
24-9-10 Bradley Corporation • 215-1676; EN 10-07-002
Supplies Required:
• 1/2" NPT supply pipe
• Caulk (suitable for plumbing applications) for panel seams.
• Supplies required for optional lead caulk drain joint.
MODEL A B C
9030KD 30" (762) 15" (381) 13-1/4" (337)
9032KD 32" (813) 16" (406) 14-1/4" (362)
9036KD 36" (914) 18" (457) 16-1/4" (413)
Floor Drain Rough-In Dimensions
Configuration and Connection Options
Rough in Dimensions
Detail of Optional Drain
Caulk Assembly
C
L
Finished Floor
Chase Wall-All Models
14˝ Sq. Wall
Opening to connect
1/2˝ NPT Supply
(supplied by others)
to valve assembly.
Installer can vary
supply location
within the opening.
10˝ Sq. Wall
Opening for Vent
10˝ Sq. Wall
Opening for Drain
and Showwerhead
Connection
75-3/4"
(1924)
52-1/4"
(1327)
88"
(2235)
C
L
3-3/8˝
(86)
2˝ (51)
Finished Floor
5˝
(127)
C
L
3-3/8˝
(86)
2˝ (51)
Finished Floor
5˝
(127)
C
L
2-3/4˝
(70)
1-3/4˝
(44)
2˝ (51)
Finished Floor
5˝
(127)
C
L
2-3/4˝
(70)
1-3/4˝
(44)
2˝ (51)
Finished Floor
5˝
(127)
Shower Front
Shower Front
Shower Front
Shower Front
Left Back
Chase
Drain/Showerhead ConnectionOverhead View
Right Back
Chase
Left Side
Chase
Right Side
Chase
1/2" Supply: Nominal Copper Tube
Showerhead Connection Point
2-1/4" (57) No-Hub P-Trap (if specified)
2-1/4" (57) No-Hub Elbow (if specified)
Key
Shower Front
Drain
Location Security
Screw
Removable
Drain Plate
Shower
Pan
Lead Caulk Joint
Finished Floor
2" (51) Nom.
Drain Pipe
4-1/4" +/-1/4"
(108 +/-6)
A
A
B
C
(mm)

Installation CBSHWR9000KD
Bradley Corporation • 215-1676; EN 10-07-002 4-9-10 3
9036KD Left Side
Chase Shown.
9036KD Back Right
Chase Shown.
BBolt the two side panels and chase panel
together. DO NOT TIGHTEN BOLTS.
CBolt panels to shower pan. DO NOT
TIGHTEN BOLTS.
AFor optional caulk drain, position shower pan over
drain. Connect drain to lead caulk drain joint. Use
no-hub coupling for p-trap and elbow style waste.
DBolt top to side panels.
Tighten all bolts after unit is
completely assembled.
Shower Pan
Chase Panel
To p
Side Panel
1Assemble Shower
2Position Shower and Make Plumbing Connections
AInstall the valve assembly to the supply
and attach the push button to the panel
per the valve instructions.
CAttach Access Panel Assembly to the
cabinet with security screws provided.
BConnect 3/8" Showerhead supply
tube from the valve assembly to
the Showerhead connection point
in the base.
Caulk around Valve Panel to seal
against water intrusion. Back View of Chase Panel
3/8" NPT Tube
Connector
3/8" NPT
Showerhead
Connection

CBSHWR9000KD Installation
44-9-10 Bradley Corporation • 215-1676; EN 10-07-002
Cleaning Stainless Steel
Material Description: Stainless steel is extremely durable, and maintenance is simple and inexpensive. Proper care, particularly
under corrosive conditions, is essential. Always start with the simplest solution and work your way toward the more complicated.
Routine Cleaning: Daily or as often as needed use a solution of warm water and soap, detergent, or ammonia. Apply the cleaning
solution per the manufactures instructions and always use a soft cloth or sponge to avoid damaging the finish.
Stubborn Stains: To remove stains from stainless steel use a stainless steel cleaner and polish such as Ball®stainless steel
cleaner or a soft abrasive. Always follow the manufactures instructions and apply in the same direction as the polish lines.
Never use ordinary steel wool or steel brushes on stainless steel. Always use stainless steel wool or stainless
steel brushes.
Special Situations for Stainless Steel Material
Fingerprints and Smears: To remove fingerprints or smears use a high quality stainless steel cleaner and polish in accordance
with the manufactures instructions. Many of these products leave a protective coating the helps prevent future smears and
fingerprints.
Grease and Oil: Grease and Oil : To remove grease and oil use a quality commercial detergent or caustic cleaner. Apply in
accordance to the manufactures instructions and in the direction of the polish lines.
Precautions: Precautions: Avoid prolonged contact with chlorides (bleaches, salts), bromides (sanitizing agents), thiocyanates
(pesticides, photography chemicals, and some foods), and iodides on stainless steel equipment, especially if acid conditions
exist.
Do not permit salty solutions to evaporate and dry on stainless steel.
The appearance of rust streaks on stainless steel leads to the belief that the stainless steel is rusting. Look for the actual source
of the rust in some iron or steel particles which may be touching, but not actually a part of the stainless steel structure.
Strongly acidic or caustic cleaners may attack the steel causing a reddish film to appear.The use of these
cleaners should be avoided.
Brand Names
Use of brand names is intended only to indicate a type of cleaner. This does not constitute an endorsement, nor does the omission
of any brand name cleaner imply inadequacy. Many products named are regional in distribution, and can be found in local
supermarkets, department and hardware stores, or through your cleaning service. It is emphasized that all products should be used
in strict accordance with package instructions.
