S19-120T
Drench Shower - Horizontal Supply
Table of Contents
Pre-Installation Information .............................................................2
Supplies Required...........................................................................3
Assemble components....................................................................3
Connect water supply......................................................................3
Assembly of Components ...............................................................4
Parts List .........................................................................................4

2
S19-120T Installation
7/18/2017 Bradley • 215-148CP Rev. N; ECN 17-05-039
WARNING
The installation and location of all Safety drench showers, eye and eye/face washes must comply
with the requirements of ANSI Z358.1.
Emergency equipment must be supplied with tepid water (60-100°F/ 15.6-37.8°C). Any prolonged
exposure to near freezing water affects the body’s ability to maintain body temperature, increasing
the risk of hypothermia.
Flush the water supply lines before beginning installation and after installation is complete. Test
the unit for leaks and adequate water flow. Main water supply to the eyewash should be “ON” at all
times. Provisions shall be made to prevent unauthorized shutoff.
The ANSI Z358.1 standard requires an uninterrupted supply of flushing fluid. Bradley plumbed
emergency fixtures require a minimum of 30 PSI (0.21 MPa) flowing pressure. Flushing fluid
should be tepid per ANSI Z358.1.
Weekly activation must be conducted on all plumbed emergency equipment to ensure a
suitable flushing fluid supply is present and any sediment build-up in the supply line is cleared.
Emergency Equipment should be inspected monthly to address any maintenance issues ensuring
the equipment is in good operating condition and that there are no signs of wear.
Workers who may come in contact with potentially hazardous materials should be trained
regarding the placement and proper operation of emergency equipment per ANSI Z358.1.
NOTICE
Before installing this product ensure that there are adequate clearances around the product and
activation of the product does not interfere with other products or obstructions
IMPORTANT
Read this installation manual completely to ensure proper installation, then file it with the owner or
maintenance department. Compliance and conformity to drain requirements and other local codes
and ordinances is the responsibility of the installer.
Separate parts from packaging and make sure all parts are accounted for before discarding any
packaging material. If any parts are missing, do not begin installation until you obtain the missing
parts.
For questions regarding the operation or installation of this product, visit www.bradleycorp.com or
call 1-800-BRADLEY.
Product warranties and service parts information may also be found under ”Products” on our web
site at www.bradleycorp.com.

3
Installation S19-120T
Bradley • 215-148CP Rev. N; ECN 17-05-039 7/18/2017
Supplies Required
• Pipe sealant and teflon tape
• Piping to 1" NPT water supply inlet
• Adequate supply pipe supports
• Minimum 4" (102 mm) drain to
accommodate 30 gallons (115 liters) per
minute discharge for shower waste
• Sign-mounting hardware
Assemble components
1. Assemble components as shown on page 4.
2. Apply pipe sealant or tape (by installer) to
all male-threaded pipe joints.
3. Bottom edge of showerhead should be
7'-0" (2134 mm) from the floor.
Connect water supply
NOTICE! Do not rely on Bradley’s Drench
Shower to support supply piping.
1. Connect water supply piping to 1" NPT
inlet on unit (piping supplied by installer).
Provide adequate supports (supplied
by installer) for supply pipe using pipe
hangers or other means.
2. Mount the safety sign to the wall using
sign-mounting hardware supplied by
installer.
5-1/4"
(133mm)
9"
(229mm)
Ø 10-3/4"
(273mm)
15-7/8"
(403mm)
7'-0"
(2134mm)
Suggested
Height to
Floor
24"
(610mm)
3-5/8"
(92mm)

4
S19-120T Installation
7/18/2017 Bradley • 215-148CP Rev. N; ECN 17-05-039
Assembly of Components
P.O. Box 309, Menomonee Falls,WI 53051
R
TESTTHIS UNIT EACH WEEK
Test-operate valve(s)each week and sign below.
Report any malfunctions immediately.
Ventil(e) wöchentlich imTestbetrieb prüfen, bestätigt
durch Unterschrift. Jegliche Störung sofort melden.
Date
Datum
Date
Signed
Unterschrift
Signe
Date
Date
Date Signed
Signed
Signed
DIESES GERÄT 1STWÖCHENTLICH ZU PRÜFEN.
ESSAI HEBDOMADAIRE
Test le fonctionnementdes valves chaque semaine et
signe en bas. S'il y à quelque chose qui ne va pas fait
un rapport immédiatement.
P.O. BOX 309, MENOMONEE FALLS,WI 53052-0309 USA
TEL: 1-800-BRADLEY FA X: (262-251-5817)
http://www.bradleycorp.com
114-050
7
8
2
3
4
5
1.2 1.3
1.4
1.11
1.1
1
6
6.11
6.1
6.12
6.2
Parts List
1" NPT
Supply Inlet
NOTE: Use
teflon tape
only.
Item Part No. Qty. Description
1 S30-059 1 Stay-Open Ball Valve
Assembly
1.1 S27-278 1 1" Ball Valve with Jam Nut
1.11 110-214 1 Jam Nut only
1.2 153-489 1 Adapter
1.3 124-048 1 Washer, Friction
1.4 128-201 1 Handle
2 128-156A 1 Pull Rod, 24"
3 151-001 2 Curtain Hook
4 113-594 1 Pipe 1" NPT x 12"
Item Part No. Qty. Description
5 169-1073 1 90° Elbow NPT
6 S24-189 1 Plastic Showerhead and
Stainless Steel Shroud
Assembly
6.1 S24-193 1 Shroud Assembly
6.11 187-053 1 Showerhead Shell
6.12 154-147 1 Ring
6.2 S24-188 1 Plastic Showerhead Assembly
7 114-050 1 Safety Sign
8 204-421 1 Emergency Inspection Tag
