BROSA Baker Bar Table User manual

ASSEMBLY GUIDE
Baker Bar Table
v1.0
Components
A x 2
(Long Dowel)
(Ø10 x 40)
B x 2
(Steel Dowel)
(M8 x 10 x 48.5)
C x 2
(Grub Screw)
(M10 x 10)
D x 16
(M6 Short Bolt)
(M6 x 35)
E x 1
(M5 Allen Key)
(M5 x 30 x 107)
F x 1
(M4 Allen Key)
(M4 x 30 x 107)
H x 4
(Long Bolt)
(M8 x 115)
Hardware
What you need
Leg x 2
Leg Base x 2
Middle Rail x 1
Mounting
Plate x 2
Table top x 1
Before you get started, check you have all of the pieces below. If anything’s
missing, please visit www.brosa.com.au/pages/product-return-and-parts-request
and we’ll sort it out right away.
L x 8
(Short Dowel)
(Ø8 x 30)
G x 4
(M8 Short Bolt)
(M8 x 35)
2
3
4
1
5
Step 1 Insert two short dowels (L) into the diagonal holes at
the top of the leg (3), and two short dowels (L) into
the diagonal holes at the bottom of the leg (3)
Repeat this for the second leg.
L x 8
Step 2 Align a leg (3) with the leg base (4) and the mounting
plate (2). Attach the parts together. Secure the base
in place with long bolts (H) and tighten it with the
M4 Allen key (F). Secure the mounting plate (2) in
place with M8 short bolts (G) and tighten it with the
M4 Allen key (F).
F x 1
H x 4
3× 2
2
L
L
L
L
3
G
G
F
× 2
× 2
× 2
× 2
F
H
H
4
1.4
G x 4
Step 3 3.1 Screw a steel dowel (B) into the side hole on the
leg base. Ensure that the holes are facing the bottom
as shown in the diagram. Repeat this for the other
leg.
3.1 Insert long dowels (A) into the holes on each end
of the middle rail (5).
B x 2
Step 3.1
Step 3.2
5
A
B
A x 2
Step 4 Align one of the formed leg structures with the
underside of the table top (1) so that the holes
overlap. Secure them with M6 short bolts (D) using a
M4 Allen key (F).
F x 1
1
D
F
D x 8
Step 5 5.1 Attach the middle rail (5) to the leg that was xed
in the previous step. Make sure the holes on the rail
are facing the bottom as shown in below diagram.
Attach the second leg to the rail and make sure that
the holes on the mounting plate are aligned with the
holes on the table top.
5.2 Secure the leg with M6 short bolts (D) using the
M4 Allen key (F).
D
F
1
5
F x 1
D x 8
Step 5.1
Step 5.2
Step 6 Secure the middle rail with grub screws (C) using the
M5 Allen key (E).
C x 2
E x 1
E
C
Step 7 Enjoy your new bar table!
