ASSEMBLY GUIDE
Field Console Table
v1.0

Components
A x 10
(Bolt)
B x 1
(Allen key)
Hardware
What you need
Left Leg x 1
Right Leg x 1
Body x 1
Before you get started, check you have all of the pieces below. If anything’s
missing, please visit www.brosa.com.au/pages/product-return-and-parts-request
and we’ll sort it out right away.
2
3
1
aa x 2
(Mounting Plate)
bb x 1
(Nylon Strap)
cc x 2
(Screw)

Step 1
Step 1.1
Step 1.2
Step 1.3
1.1 To open the storage turn the clip hinges up and
release the clamp.
1.2 Lift the cover up. It is possible to take the inner
box out.
1.3 To close the storage put the cover down, attach
the clamps to the cover and turn down the clip
hinges.

Step 2 Align the legs (2, 3) to the underside of the table
body (1) so that the holes are overlaping. Secure
them with bolts (A) using an allen key (B).
A x 10
B x 1
3
1
A
B
2

Step 1.1
Step 1.2
Step 1.3
Step 3 1.1 To put back the inner box turn the clip hinges up
and release the clamp. Open the storage.
1.2 Lift the cover up and put back the inner box.
1.3 To close the storage put the cover down, attach
the clamps to the cover and turn down the clip
hinges.

Step 4 Fix a mounting plate (aa) to the back of the storage
using at head screws (cc).
By using appropriate fastener based upon wall com-
position, x another mounting plate (aa) to the wall.
Connect two plates with the nylon srap (bb).
Tighten the strap so that the table is xed in the
place.
aa x 2
cc x 2
bb x 1
cc
cc
aa
WALL
aa bb
aa

Step 5 Enjoy your new table!
