Bticino GC8230AC10 User manual

1 / 8
Btdin RCBO 4500A up
to 32A (2P)
Cat N° (s):
GC8230AC10 - GC8230AC16 - GC8230AC20 -
GC8230AC25 - GC8230AC32
Index Pages
1. Descripton............................................. 2
2. Product range ....................................... 2
3. Overall dimensions ............................... 2
4. Fixing –Connection .............................. 3
5. Generl characteristics. ...................... 4-7
6. Compliance - Approvals ........................ 8
7. Curves .................................................. 8
Product information:: IDP000135_EN_01
Updated:
First release :: 23/11/2016

2 / 8
Btdin RCBO 4500A up
to 32A (2P)
Cat N° (s):
GC8230AC10 - GC8230AC16 - GC8230AC20 -
GC8230AC25 - GC8230AC32
1. DESCRIPTION
Residual current operated circuit breaker with integral
overcurrent protection (residual current breaking overload
RCBO).
For control, disconnection and protection of electrical circuits
against overcurrent and insulation faults.
For protection of people against direct and indirect electric
shocks.
Symbol:
Technology:
. Current limiting device.
. Electromagnetic residual current operating by sensitive relay
2. PRODUCT RANGE:
Number of poles:
. Double pole (2P)
Width:
.Double pole –4 modules (4 x 17.8 mm = 71.2 mm).
Rated current at 30°C:
. 10 / 16 / 20 / 25 / 32A
Tripping characteristics and magnetic tripping calibrations:
. Curve C (between 5 and 10 In)
Thermal threshold:
according to IEC/EN 61009-1
. Non operating current (Inf): 1.13 In.
. Operating current (If): 1.45 In.
Types :
. AC (sinusoidal AC fault currents).
Sensitivities and tripping time:
. 30 mA i instantaneous.
2. PRODUCTRANGE (continued):
Rated Voltage / Frequency:
.Duble pole 230 V ~, 50 Hz with standard tolerances.
Operating voltage ~ 50 Hz with standard tolerances :
U
Duble pole
U mini
170 V ~
U maxi
253 V ~
Breaking capacity:
. 4500 A according to IEC /EN 61009-1
Residual breaking capacity IΔm:
. In accordance with standard IEC/EN 61009-1
(Im: short-circuit to ground) Im = 4500A
3. OVERALL DIMENSIONS
N° of poles
“X”
2P
71.2 mm
Product information:: IDP000135_EN_01
Updated:
First release :: 23/11/2016

3 / 8
Btdin RCBO 4500A up
to 32A (2P)
Cat N° (s):
GC8230AC10 - GC8230AC16 - GC8230AC20 -
GC8230AC25 - GC8230AC32
4. PREPARATION - CONNECTION
Fixing:
. On symmetrical IEC/EN 60715 rail or DIN 35 rail.
Power supply:
. From the top through the m.c.b. associated or from the bottom
directly on the differential block.
Operating position :
. Vertical, Horizontal, Flat.
Screw terminals:
. Terminals protected against accidental contact (IP20).
. Cage terminals, with release and captive screw
. Terminal depth: 14 mm.
. Stripping length recommended: 11 mm
. Screw head: Mixed, Slotted and Pozidriv n°2.
. Recommended tightening torque: 3 Nm.
. The screw terminals are separated by built-in shields.
Connectable section:
. In the power terminals in the lower part of the product.
. Copper cable.
Without ferrule
With ferrule
Rigid cable
1 x 25 mm²
-
Flexible cable
1 x 16 mm²
1 x 16 mm²
Recommended tools:
. For the terminals: screwdriver Pozidriv n°2 or flat screwdriver
5,5 mm (6,5 mm maximum).
. For fixing on the DIN rail: flat screwdriver 5 mm (from 4 to5
mm).
4. PREPARATION - CONNECTION (continued):
Manual actuation of the add-on module:
. By the 2-position ergonomic handle of the associated MCB:
I / ON: Closed circuit.
0 / OFF: Opened circuit.
Contacts status display:
. By marking of the associated MCB handle:
“O-Off“ white on a green background = contacts opened.
“I-On” white on a red background = contacts closed
Display of differential fault trip:
. Yellow mechanical signaller into the window on front-side marking
zone.
Lockout:
. By 5 mm padlock with padlock support (cat. N° F80BL)
Labelling:
. Identification of the circuit by insertion of a label in the label holder.
Product information:: IDP000135_EN_01
Updated:
First release :: 23/11/2016

4 / 8
Btdin RCBO 4500A up
to 32A (2P)
Cat N° (s):
GC8230AC10 - GC8230AC16 - GC8230AC20 -
GC8230AC25 - GC8230AC32
5. GENERAL CHARACTERISTICS :
Front side marking :
. By permanent ink pad printing showing and laser marking.
. Cat No: GC8230AC10
. Trade name: ground fault interrupter
. Differential rated current.
. Electrical diagram.
. Bticino mark.
.Symbol that identifies product for switchboard
Code structure :
G
C
8
2
3
0
AC
. Initial code root composed of seven elements:
-Letter “G” shows the device type: Add-on module (BDA).
-Letter “N” breaking capacity 4500A
-Numbers 8 shows device with MCB protection
-Numbers of poles “2” = Two.
-Sensitivity, IΔn (mA):N° 3 = 30mA.
-Numbers 0 indicates a product for switchboard
-Indication of the type “AC” = AC type.
10
. Numerical part composed of one element:
- Rated current of MCB, In (A).
Marking exemple :
5. GENERAL CHARACTERISTICS (continued):
Short-circuit breaking capacity:
. single-phase or three-phase network (50/60 Hz AC)
According to IEC/EN 61009-1
.Icn=Ics 4500A
Test” key operating voltages :
U test
Duble pole
U mini
170 V ~
U maxi
253 V ~
Neutral system :
. IT –TT –TN.
Residual breaking capacity IΔm :
. In accordance with standard IEC/EN 61009-1 (Im: short-circuit to
ground)
Im = 3000A
Insulation rated voltage:
. Ui = 500 V in accordance with standard IEC/EN 61009-1
Pollution degree:
. 2.
Dielectric strength:
. 2500 V
Pulse rated voltage:
. Uimp = 4 kV (wave 1.2 / 50 s).
Product information:: IDP000135_EN_01
Updated:
First release :: 23/11/2016

5 / 8
Btdin RCBO 4500A up to
32A (2P)
Cat N° (s):
GC8230AC10 - GC8230AC16 - GC8230AC20 -
GC8230AC25 - GC8230AC32
5. GENERAL CHARACTERISTICS (continued):
Protection against unwanted tripping:
. Damped recurrent wave –0.5 μs/10kHz : 200A for all types
. Held to the wave 8/20 µs: 250A
Protection class :
. Protection index of terminals against solid and liquid bodies:
IP 20 (in accordance with standards IEC/EN 60529 et NF C 20-010).
. Protection index of the box against solid and liquid bodies:
IP 40 (in accordance with standards , IEC/EN 60529 et NF C 20-010).
.Class II compared to conductive parts.
. Protection index against mechanical shocks:
IK 02 (in accordance with standards EN 50102 et NF C 20-015).
Mechanical endurance: (with MCB associated) :
. 20000 operations without load.
. 10000 operations with load.
. 750 differential tripping operations by the Test key.
. 750 differential tripping operations for fault current.
Specific use:
. Appropriate to be used in humid environment and polluted by
chlorine (pool-type)
Load to close and to open a RCBO by the handle:
. 0,5 Nm per pole to close.
. 0,3 Nm per pole to open.
Power dissipated and impedance average per pole at In :
Double-pole
In
Z (mΩ)
P (W)
10 A
19
1.9
16 A
8.8
2.26
20 A
6.5
2.61
25 A
5.3
3.34
32 A
4.2
4.26
5. GENERAL CHARACTERISTICS (continued):
Enclosure material :
.Nylon.
. Polycarbonate.
. Characteristics of this material: self extinguishing, heat and fire
resistant in accordance with standard IEC/EN 61009-1, glow-wire test
at 960°C for external parts made of insulating material necessary to
retain in position current-carrying parts and parts of protective circuit
(650°C for all other external parts made of insulating material).
Calorific value :
Double-pole
MJ
6.2
Average weight per device :
. Double pole : 0,5 kg
Packed volume:
. Double pole: 0,9 dm3per device.
Ambient operating temperature :
. Min. = -25°C – Max. = +70°C
Ambient storage temperature :
. Min. = -40°C – Max. = +70°C
Derating according to ambient temperature :
. Reference temperature: 30 °C in accordance with standard
IEC/EN 61009-1.
. No derating of the differential block depending on the ambient
temperature between - 25 ° C and +30 ° C.
. Derating between + 30 °C to + 70 °C :
Temperature
30 °C
40 °C
50 °C
60 °C
70 °C
% In
100 %
95 %
90 %
85 %
80 %
Product information:: IDP000135_EN_01
Updated:
First release :: 23/11/2016

6 / 8
Btdin RCBO 4500A up
to 32A (2P)
Cat N° (s):
GC8230AC10 - GC8230AC16 - GC8230AC20 -
GC8230AC25 - GC8230AC32
5. GENERAL CHARACTERISTICS (continued):
Resistance to sinusoidal vibrations:
. in accordance with standard IEC 60068-2-35.
. Axis: x, y, z.
. Frequency range: 5÷100 Hz ; duration 90 min.
. Displacement (5÷13,2 Hz) : 1mm
. Acceleration (13,2÷100 Hz) : 0,7g (g=9,81 m/s2).
Influence of the altitude :
2000 m
3000 m
4000 m
5000 m
Dielectric
strength
3000 V
2500 V
2000 V
1500 V
Max operating
voltage
400 V
400 V
400 V
400 V
Derating at
30°C
none
none
none
none
Derating of circuit-breakers depending on the ambient temperature :
. Rated characteristics of a circuit breaker are modified depending on the ambient temperature which prevails inside the cabinet or the enclosure
where the circuit breaker is located.
. Reference temperature: 30°C according to IEC/EN 60898-1
Ambient temperature / In
In (A)
- 25°C
- 10°C
0°C
10°C
20°C
30°C
40°C
50°C
60°C
70°C
10
12.5
11.5
11.1
10.7
10.3
10.0
9.7
9.3
9.0
8.7
16
20.0
18.7
18.0
17.3
16.6
16.0
15.4
14.7
14.1
13.5
20
25.0
23.2
22.4
21.6
20.8
20.0
19.2
18.4
17.6
16.8
25
31.5
29.5
28.3
27.2
26.0
25.0
24.0
22.7
21.7
20.7
32
41.0
37.8
36.5
34.9
33.3
32.0
30.7
29.1
27.8
26.5
Product information:: IDP000135_EN_01
Updated:
First release :: 23/11/2016

7 / 8
Btdin RCBO 4500A up
to 32A (2P)
Cat N° (s):
GC8230AC10 - GC8230AC16 - GC8230AC20 -
GC8230AC25 - GC8230AC32
5. GENERAL CHARACTERISTICS (continued):
Derating of RCBOs function of the number of devices side by side:
When several RCBOs are juxtaposed and operate simultaneously, the heat dissipation of the poles is limited. This results in an increase in
operating temperature of the circuit breakers which can cause unwanted tripping. It is recommended to apply the following coefficients to the
rated currents.
Number of circuit breakers
side by side
Coefficient
2 - 3
0.9
4 –5
0.8
6 - 9
0.7
10
0.6
These values are given by the recommendation of IEC/EN 60439-1 e NF C 63421 standards.
To avoid to have to use these coefficients, it is necessary to allow a good ventilation and to keep the devices apart with 0.5 module spacing
elements (cat. N° F80/05D).
Product information:: IDP000135_EN_01
Updated:
First release :: 23/11/2016

8 / 8
Btdin RCBO 4500A up
to 32A (2P)
Cat N° (s):
GC8230AC10 - GC8230AC16 - GC8230AC20 -
GC8230AC25 - GC8230AC32
6. COMPLIANCE- APPROVALS :
In accordance with standards:
. IEC/EN 61009-1.
. IEC/EN 60947-2.
. Compliance with Directives 2014/35/UE (LVC), subsequent
modifications and additions.
. Compliance with Directives 2014/30/UE (EMC), subsequent
modifications and additions.
Environment respect –Compliance with CEE directives:
. Compliance with Directive 2011/65/UE called "RoHS" provides
the banishment of hazardous substances, subsequent
modifications and additions.
. Compliance with Directives 91/338/CEE of 18/06/91 and decree
94-647, subsequent modifications and additions.
Plastic materials :
. Halogen-free plastic materials.
. Marking of parts according to ISO 11469 and ISO 1043.
Packaging:
. Design and manufacture of packaging in accordance with
decree 98-638 and Directive 94/62/EC, subsequent modifications
and additions.
Approvals:
.Certificates obtained from the range:
IMQ - LOVAG
.These markings may vary depending on the article
7. CURVES :
Residual current operating characteristic :
. Average tripping time depending on the intensity of the fault current.
8. AUXILIARIES - ACCESSORIES
Wiring accessories:
. Sealable screw cover (cat n° F80CV).
. Insulating shields (cat n° F80S)
Automatic resetting module STOP & GO :
. Automatic resetting module Stop & Go (2 modules –cat n° F80SG)
. Automatic resetting module Stop & Go with self-test (2 modules –cat
n° F80SGB)
Installation software:
. TiQuadri
Product information:: IDP000135_EN_01
Updated:
First release :: 23/11/2016
