Cisco MX300 G2 Instruction Manual

Installing Cisco TelePresence MX300 G2 - Wheel Base
78-100145-01 | OCTOBER 2013 | © 2013 Cisco Systems, Inc. All rights reserved.
This installation guide covers MX300 G2 with a wheel base.
Dimensions
Height: 1606mm / 63.3 in.
Width: 1278mm / 50.4in.
Depth: 755mm / 29.8in.
Weight total: 47 kg / 104 lb
Weight monitor: 35kg / 78lb
Manpower
Two people working together are required to mount the
monitor to the base module.
Room setup
Explore the Meeting Room – London scenario on the Cisco Project
Workplace, http://www.cisco.com/go/projectworkplace, to find
inspiration and guidelines when preparing your office or meeting
room for video conferencing.
Documentation
The user documentation for this product, including compliance
and safety information, is available on the Cisco web site,
http://www.cisco.com/go/mx-docs

Installing Cisco TelePresence MX300 G2 - Wheel Base
78-100145-01 | OCTOBER 2013 | © 2013 Cisco Systems, Inc. All rights reserved.
• Wheel base
• Column
• Screws for mounting the base
• Screwdriver
C
D
A
B
E
Back cover
Monitor
Accessories:
• Microphones
• Cables
• Screws for mounting
the monitor
• Gloves
Touch controller

Installing Cisco TelePresence MX300 G2 - Wheel Base
78-100145-01 | OCTOBER 2013 | © 2013 Cisco Systems, Inc. All rights reserved.
Optional
It is possible to replace the wheels with rubber pads.
The rubber pads are kept underneath the wheel base,
and must be moved to their correct position.
M5x8 (Allen key, 3 mm)
1Mounting the wheel base
A
You may place the column on the empty
wheel base box as illustrated. Then it is
easier to enter the screws from below.
4 ×
1
2
3
4 × M6x20

Installing Cisco TelePresence MX300 G2 - Wheel Base
78-100145-01 | OCTOBER 2013 | © 2013 Cisco Systems, Inc. All rights reserved.
2Mounting the monitor
The monitor may be tilting slightly
forward. If you gently pull it to a vertical
position, the screws enter more easily.
Front
B C
Use gloves when
handling the monitor.
Remove the cable
channel lid for now.
You need it in step 4.
4 × M6x16

Installing Cisco TelePresence MX300 G2 - Wheel Base
78-100145-01 | OCTOBER 2013 | © 2013 Cisco Systems, Inc. All rights reserved.
3Connecting the cables
Thread the cables up
through the hole in the base.
C D
For maintenance only
Reset to factory settings
Audio line output
Always use the provided power cable.
The wall socket outlet must be easily
accessible after installation.
Power switch
Audio line input
LAN **
Video input
(e.g. PC *)
Video output
(e.g. 2nd display *)
Power (100-240 VAC,
50/60 Hz)
Microphones
Touch
controller **
USB, for future use
HDMI
DVI-I
*Optional
** Use the cable that is labeled
with for the Touch controller;
use the cable that is labeled
with for the LAN

Installing Cisco TelePresence MX300 G2 - Wheel Base
78-100145-01 | OCTOBER 2013 | © 2013 Cisco Systems, Inc. All rights reserved.
• Connect to power and LAN/Ethernet.
• Switch on the system. The power switch is placed
next to the power connector at the rear side of the
system.
Wait while the unit starts up. Normally this takes a few minutes.
It may include automatic software upgrade and restart of the
Touch controller.
• If prompted, follow the instructions on the Touch controller to
set the language etc.
• If your system is not set up to be automatically provisioned, you
must configure the system before you can make your first call.
This is described in the Getting Started Guide, which is available
on the Cisco web site.
Never move the camera manually when power is switched on;
always use the camera control function on the Touch controller
to change the camera position.
5Starting up the system
Snap on the cable
channel lid for strain relief.
Lead the cables out at the
front or back as appropriate.
4Snapping on the cable channel lid

Installing Cisco TelePresence MX300 G2 - Wheel Base
78-100145-01 | OCTOBER 2013 | © 2013 Cisco Systems, Inc. All rights reserved.
On our web site you will find an overview of the
worldwide Cisco contacts.
Go to: http://www.cisco.com/web/siteassets/contacts
Corporate Headquarters
Cisco Systems, Inc.
170 West Tasman Dr.
San Jose, CA 95134 USA
EMC Class A declaration
WARNING: This is a class A product. In a domestic environment
this product may cause radio interference in which case the
user may be required to take adequate measures.
声
明
此为
A级产品，在生活环境中，该产品可能会造成无线电干扰。在这种
情况下，可能需要用户对其干扰采取切实可行的措施。
WARNING: This is a class A product. In a domestic environment
this product may cause radio interference in which case the user
may be required to take adequate measures.
6Mounting the back cover
E
Wind up the cables on the hook on
the back cover when rolling the unit.
Lift this handle to
lock/unlock the back
cover. Use both
hands if required.
