Cisco TelePresence System EX90
installation guide

EX90 is delivered with:
• EX90 unit
• Touch screen with cable
• Handset base with cable
• Handset
• AC adapter and power cable
• DVI-D to DVI-I cable
(recommended for optimal PC
image quality)
• VGA to DVI-I cable
• Stereo audio cable 3.5mm
• Ethernet cable
• Screwdriver
• Cleaning cloth
User documentation
User guides and compliance and safety information for this product
are available at the Cisco web site: http://www.cisco.com/go/ex-docs
1Unpacking the touch screen and cables
Lift the rectangular box out of
the package.
In the box you will find the
cables, and another box with
the touch screen and handset.
Unpack the touch screen with
the handset and handset base.
Handset
Handset
base
Touch
screen
Cables

2Unpacking the EX90 unit
Lay the package flat on the floor.
Pull the EX90, surrounded by foam
protection, out of the package.
EX90
Carefully loosen the foam protection.
Lift the EX90 and place it on a firm surface.
Weight: 14 kg / 31 lb

BFasten the two units together. The screws are pre–mounted in the handset base.
Use the screwdriver and fasten the screws at the
handset base from the underneath.
AHold the touch screen and the handset base in an upright position.
Move the two units together. Make sure the
connector on the handset base slides into the
corresponding hole on the touch screen.
CConnect the handset to the handset base, and connect the handset cable.
3Optional: Mounting the handset
Tool: Screwdriver
EMC Class A declaration
This is a class A product. In a
domestic environment this product
may cause radio interference in
which case the user may be required
to take adequate measures.
声明
此为A级产品，在生活环境中，该产品可能会造成无线电干扰。在这种
情况下，可能需要用户对其干扰采取切实可行的措施。
WARNING: This is a class A product. In a domestic environment
this product may cause radio interference in which case the user
may be required to take adequate measures.
Touch
screen
Handset
base

4System overview and basic setup
Kensington lock
Scale 1:1
Scale 1:1
Remove the cover to get
access to the connectors
at the rear side.
Local area
network (LAN)
Touch screen Power supply
(use the supplied
AC adapter)
Optional LAN
connection for PC
For future
use
Optional
HDMI output
Optional
HDMI input
Optional PC
video input
Optional PC
audio input
Micro-
phone
Headset 2 x USB
Connect the touch screen,
LAN and power as illustrated.
To connect a PC, see more
details in step 5.
You may connect an
external microphone
and a headset to your
system (not provided).

5Connecting a PC
6Starting the system
Audio and video input from PC
Connect the audio and video cables from the PC.
We recomemend using the DVI-D to DVI-I video
cable for optimal PC image quality.
The cables are in the rectangular box, see
illustration in step 1.
Optional LAN connection for PC
If you have a single LAN wall outlet only, you may
connect your PC to the second RJ45 socket of
the EX90 (labelled with a PC symbol). Your PC and
the EX90 will then share the LAN connection.
Optional
LAN connection
for PC, RJ45
Scale 1:1
Video from PC,
DVI-I cable
Audio from PC,
Stereo cable
3.5mm mini jack
Power button
• Tap the power button once to switch on/
off the monitor.
• Press gently and hold the power button
to shut down the system.
Camera
• Turn to open/close the
privacy cover.
• Tilt downwards to use as
document camera.
Camera LED
Power LED
Please read the user documentation,
which is available on the Cisco web
site, for further information about
how to set up and use your system.
