Data Sheet
Cisco TelePresence MCU 4500 Series
Figure 1. Cisco TelePresence MCU 4500 Series
Product Overview
The Cisco TelePresence®MCU 4500 Series is the industry’s leading full high-definition multimedia conferencing
bridge (Figures 1 and 2). It delivers superior video and voice with an easy-to-use, versatile management interface.
Compatible with all major vendors’ endpoints, each model maintains its capacity and performance in every
configuration, delivering the best experience for each participant, every time.
Cisco TelePresence MCU is WebEx enabled, allowing customers to enjoy fully integrated, scalable conference
involving callers from WebEx clients and telepresence endpoints.
Figure 2. Example of endpoints supported by the Cisco TelePresence MCU 4500 Series

© 2013 Cisco and/or its affiliates. All rights reserved. This document is Cisco Public. Page 2 of 7
Features and Benefits
Table 1 summarizes the key features of the Cisco TelePresence MCU 4500 Series, and Table 2 gives information
about the models in the series.
Table 1. Cisco TelePresence MCU 4500 Series Feature Summary
Feature Benefit
Design Features ●Standards-based and compatible with all major vendors’ endpoints
●Up to 40 video plus 40 voice ports
●More than 50 custom layouts
●Comprehensive wideband audio support
●Support for both Session Initiation Protocol (SIP) and H.323 endpoints
●Support for Cisco TelePresence PacketSafe technology, which minimizes effects of network packet loss
●Compact size: Two rack units (2RU) tall and 19-in. rack-mountable
Application Features ●Offers Cisco TelePresence ConferenceMe for multipoint desktop video
●Enables transition from standard definition (SD) to high definition (HD) using Cisco TelePresence ClearVision
technology
●Integrated with Cisco Unified Communications Manager (v8.6 or later) for ad-hoc conferencing
●Integrated with Cisco TelePresence Conductor
●Integrated with Cisco TelePresence Management Suite
●Offers full interoperability with ISDN networks using standalone Cisco TelePresence ISDN Gateways
●Compatible with Microsoft Office Communications Server
●Fully integrated, with built-in gatekeeper and streaming server
●Supports Cisco TelePresence Multiway technology
Performance Features ●High-definition continuous presence on every port
●Cisco TelePresence Universal Port technology, ensures each participant receives the best possible experience
●Constant high capacity
●Bandwidth per site up to 4 Mbps
●Video resolutions up to 1080p 30 fps and 720p 60fps
Table 2. Cisco TelePresence MCU 4501 Models
Model Continuous Presence Video
Participants (Symmetric) With 1080p30 HD+ Capacity Option (Asymmetric) Additional Voice Participants Video Streaming Unicast*/Multicast
CTI-4505-MCU-K9 12 x 720p30
6 x 1080p30 or 720p60 12 x 1080p30 12 24/unlimited
CTI-4510-MCU-K9 20 x 720p30
10 x 1080p30 or 720p60 20 x 1080p30 20 40/unlimited
CTI-4515-MCU-K9 30 x 720p30
15 x 1080p30 or 720p60 30 x 1080p30 30 60/unlimited
CTI-4520-MCU-K9 40 x 720p30
20 x 1080p30 or 720p60 40 x 1080p30 40 80/unlimited
*Maximum number of unicast streams depends on network topology. When using the web conferencing option feature, the
maximum number of unicast streams supported by the Cisco TelePresence MCU 4515 and Cisco TelePresence MCU 4520 is
50.
Product Specifications
Table 3 lists the product specifications; Table 4 gives video and audio specifications; Table 5 gives network,
security, and management specifications; and Table 6 lists the product physical specification for the Cisco
TelePresence MCU 4500 Series.

© 2013 Cisco and/or its affiliates. All rights reserved. This document is Cisco Public. Page 3 of 7
Table 3. Product Specifications
Product Compatibility ●Standards-based and compatible with all major vendors’ endpoints
Universal Transcoding
and Transrating
●HD and SD can be combined within the same conference
●All calls are automatically audio and video transcoded and transrated
●Any bandwidth, any resolution, any video or audio codec can be used on any video call within the same
conference
●All participants have their own personal encodes
Streaming Video ●Built-in streaming server
●Ability to view using Windows Media Player, RealPlayer, or QuickTime
●Streaming of slides (H.239 and Virtual Network Computing [VNC])
●Text chat
●Unicast and multicast
●User Datagram Protocol (UDP), TCP, or HTTP
●Independent choice of bandwidth and codec
Localization and
Customization
●Custom interactive voice response (IVR)/auto attendant audio prompts and graphics
●Uploadable multilanguage support
●Unicode conference and site names
Built-In Gatekeeper ●Resolution of E.164 numbers
●Registration of conferences, endpoints, and gateways
●Ability to register up to 25 devices
Built-In Web Server ●Complete configuration, control, and monitoring of the system and conferences
Multipoint-Control-Unit
(MCU) Features
●Dial in or dial out through web server
●Standalone or with gatekeeper/registrar/proxy
●Configurable audio and video auto attendant
●Advanced continuous presence as standard on all ports
●Automatic selection of best layout
●Individual layout selection using remote control or webpages
●More than 50 custom layouts
●Active speaker selection using remote control or voice activated
●Floor assignment through webpage or management application
●Far-end camera control tunneling using remote control or web pages
●Text identification of sites
●On-screen text messaging to individual or all sites
●Built-in conference scheduling and reservation
●On-demand and ad hoc conferences
●Automatic lecture mode
●Preview of conference and individual camera on webpages
●Web conferencing option—those without endpoints can still interact
●Uploadable bitmaps for voice participants
●Video association for IP and traditional private branch exchanges (PBXs)
●Automatic connection to audio conferences
●Integration with Cisco Unified Communications Manager v8.6 or later ad-hoc conferencing features allows Cisco
video IP phones to initiate impromptu multiparty calls with other Cisco TelePresence endpoints.
●Linked voice and video calls
●Automatic redialing
●Cisco TelePresence Multiway technology, which enables Cisco®video endpoints to initiate ad hoc multiparty calls

© 2013 Cisco and/or its affiliates. All rights reserved. This document is Cisco Public. Page 4 of 7
Content Features ●Presentation mode: You can add slides from your PC using VNC.
●Dual video using H.239 and BFCP content sharing
●Automatic content handover
●Widescreen (16:9) support
●Four content modes: Hybrid, Passthrough, transcode and main video
●Up to 1080p in H.264
●Up to 720p in H.263
●Passthrough content option to maximize capacity
●Content transcoding for interoperability
●Participants with no content support can receive transcoded content in main video
Cisco Telepresence
ConferenceMe
●Video, audio, and content sharing
◦ Multiple layouts
◦ Firewall friendly
●Independent transcode per participant
●Up to 12 simultaneous connections
●Client computer requirements: Refer to the system requirements of your PC and the list of verified webcams
under the support section of the Cisco website.
High-Definition
Performance
●Main video up to 1080p 30 fps and 720p 60 fps H.264 4-Mbps continuous presence
●Comprehensive HD audio codecs
●Content video up to 1080p
Language ●English as standard, but alternative language packs can be loaded onto the system
Table 4. Video and Audio Specifications
Bandwidth ●Up to 4 Mbps with both H.263 and H.264, for each site in all conference modes, including advanced continuous
presence
Video Standards ●H.261, H.263, H.263+, H.263++, and H.264
Video Resolution ●From QCIF up to 1080p (1920 x 1080), including interlaced iCIF and iSIF
●4:3 and 16:9 aspect ratios
Frame Rates ●Up to 60 frames per second
Audio Standards ●G.711, G.722, G.722.1, G.723.1, G.728, G.729, MPEG-4 AAC-LC, MPEG-4 AAC-LD, and Polycom
Siren14/G.722.1 Annex C
Audio Features ●Wideband audio mixing
●Built-in and uploadable auto attendant voice prompts
●Automatic gain control, adjustable gain, power indication, and individual audio mute using webpages
Table 5. Network, Security, and Management Specifications
Protocols ●H.323, SIP, H.235 (Advanced Encryption Standard [AES]), Secure Real-Time Transport Protocol (SRTP),
Transport Layer Security (TLS), H.239 (dual video), VNC, BinaryFloor Control Protocol (BFCP), H.243 (chair
control), FTP, Real-Time Transport Protocol (RTP), (Real-Time Streaming Protocol (RTSP), HTTP, Secure
HTTP (HTTPS), Dynamic Host Configuration Protocol (DHCP), Simple Network Management Protocol (SNMP),
Network Time Protocol (NTP), IPv4, and IPv6
Quality Of Service (QoS) ●Configurable differentiated services code point (DSCP) or type of service (ToS)/IP Precedence
Security Features ●Seven levels of access rights and privileges for users
●Strong password policy
●Personal identification number (PIN)-protected conferences
●Conference locking through remote control or web interface or management application
●Secure non-PC hardware and operating system
●AES encryption, 128-bit key, H.235
●SIP encryption
●TLS certificate verification
●Video firewall option—second Ethernet port
●Audit log
●Static ARP
●Certificate-based login with OCSP certificate checking

© 2013 Cisco and/or its affiliates. All rights reserved. This document is Cisco Public. Page 5 of 7
Interfaces ●RJ-45 Ethernet, 10-/100-/1000-Mbps full / half duplex, manual or autosensing
●RJ-45 serial port
●CompactFlash socket
●Thirty-nine status LEDs
System Management ●XML–RPC management application programming interface (API)
●Management through embedded web server
●RS-232 for local control and diagnostics
●Syslog for diagnostics
●Configurable event logs and full H.323 and SIP decoding
●Configuration backup to network
●Secure upgrades through Ethernet or CompactFlash
●Call detail records (CDRs)
●SNMP
Network Resilience ●Cisco TelePresence Packet Safe technology, which provides intelligent down-speeding, packet pacing, and
packet-loss concealment to help ensure optimum video and audio quality
●Dynamic jitter buffering
●Alternate gatekeepers
●DNS SRV failover for SIP
Table 6. Physical Specifications
Physical Dimensions
(H x W x D)
●Physical dimensions: 3.43 x 17.4 x 19.25 in. (87 x 442 x 489 mm) (2RU)
●19-in. rack-mountable (kit supplied) or standalone
Weight ●33 lb (15 kg)
Power ●100-240 VAC, 50/60 Hz
●2684 BTU/h (787W) maximum heat dissipation
Environmental Data ●Operating temperature 32 to 95°F (0 to 35°C) ambien t
●Relative humidity below 95% (noncondensing)
Approvals and
Compliance
●European safety: EN 60950-1
●USA/Canada safety: UL 60950-1
●CB, CE
●EMC:
◦ EN55022 class A, EN61000-3-2, EN61000-3-3, EN55024: EN61000-4-2, -3, -4, -5, -6, -11, FCC Part 15 class
A, VCCI class A, AS/NZS 3548, CCC: GB4943, GB9254, YD/T993
●NAL Certificate (China)
●RoHS compliant
●Compliance Model Number:
◦ MCU 4505
◦ MCU 4510
◦ MCU 4515
◦ MCU 4520
Warranty Information
Find warranty information on Cisco.com at the Product Warranties page.
Ordering Information
To place an order, visit the Cisco Ordering Home Page and refer to Table 7 or contact your local Cisco
representative. To download software, visit the Cisco Software Center.

© 2013 Cisco and/or its affiliates. All rights reserved. This document is Cisco Public. Page 6 of 7
Table 7. Ordering Information
Product Name Part Number
Cisco TelePresence MCU 4505 CTI-4505-MCU-K9
Comes with: MCU 4505 - 12 Port HD MCU, Web Conferencing software license feature option and cables
Software License Feature Options for Cisco TelePresence MCU 4505
1080p HD+ Capacity Option For MCU 4505 LIC-4505-MHD
Video Firewall Option for enabling second Ethernet port on MCU 4505 LIC-4500-VFO
Conference Director Option for MCU 4505 LIC-4505-CCD
AES and HTTPS Enable Option for MCU 4505 LIC-AESCDN-K9
Cisco TelePresence MCU 4510 CTI-4510-MCU-K9
Comes with: MCU 4510 - 20 Port HD MCU, Web Conferencing software license feature option and cables
Software License Feature Options for Cisco TelePresence MCU 4510
1080p HD+ Capacity Option For MCU 4510 LIC-4510-MHD
Video Firewall Option for enabling second Ethernet port on MCU 4510 LIC-4500-VFO
Conference Director Option for MCU 4510 LIC-4510-CCD
AES and HTTPS Enable Option for MCU 4510 LIC-AESCDN-K9
Cisco TelePresence MCU 4515 CTI-4515-MCU-K9
Comes with: MCU 4515 - 30 Port HD MCU, Web Conferencing software license feature option and cables
Software License Feature Options for Cisco TelePresence MCU 4515
1080p HD+ Capacity Option For MCU 4515 LIC-4515-MHD
Video Firewall Option for enabling second Ethernet port on MCU 4515 LIC-4500-VFO
Conference Director Option for MCU 4515 LIC-4515-CCD
AES and HTTPS Enable Option for MCU 4515 LIC-AESCDN-K9
Cisco TelePresence MCU 4520 CTI-4520-MCU-K9
Comes with: MCU 4520 - 40 Port HD MCU, Web Conferencing software license feature option and cables
Software License Feature Options for Cisco TelePresence MCU 4520
1080p HD+ Capacity Option For MCU 4520 LIC-4520-MHD
VFO-4500 Video Firewall Option for enabling second Ethernet port on MCU 4520 LIC-4500-VFO
Conference Director Option for MCU 4520 LIC-4520-CCD
AES and HTTPS Enable Option for MCU 4520 LIC-AESCDN-K9
Cisco TelePresence MCU 4500 Series license PAK (Product Authorization Key) for post sale upgrades L-MCU4500-UPG-PAK
Start with L-MCU4500-UPG-PAK in order to obtain post sales upgrades for the options above apart from LIC-AESCDN-K9
AES and HTTPS Encryption Option for MCU 4500 Series post sales upgrade L-AESCDN-K9=

© 2013 Cisco and/or its affiliates. All rights reserved. This document is Cisco Public. Page 7 of 7
Cisco Services
Cisco and our partners provide a broad portfolio of intelligent, personalized services and support that can help you
realize the full value of your Cisco TelePresence investment by increasing business agility and network availability.
This portfolio of services accelerates business innovation through a network-based collaboration platform that
enables businesses to collaborate anywhere, anytime. For more information about these services, please visit:
http://www.cisco.com/go/telepresenceservices.
For More Information
For more information about the Cisco TelePresence MCU 4501, please visit http://www.cisco.com/go/telepresence
or contact your local Cisco account representative or authorized Cisco partner. Product specifications are
estimates and subject to change without notice.
Printed in USA C78-627482-08 06/13
