Cisco 9971 IP Phone User Guide
(Version 2.0)
\

Remote Extension S (Video) –Cisco 9971 IP Phone User Guide
Version 2.0 © WTT HK Limited 2017
2
Table of Content
1Phone Set Features and Functions......................................................................3
1.1 Operation for IP Phone 9971 ...........................................................................3
1.2 Location of Control...........................................................................................4
2Quick Installation Procedures..............................................................................7
3Preference Setup.................................................................................................10
3.1 Adjust Brightness...........................................................................................10
3.2 Adjust Ringtone .............................................................................................10
3.2.1 Change Volume.....................................................................................10
3.2.2 Change Ringtone...................................................................................10
3.3 Adjust Wallpaper............................................................................................11
4Basic Features.....................................................................................................12
4.1 Placing a Call.................................................................................................12
4.2 Answering a Call............................................................................................12
4.3 Ending a Call .................................................................................................12
4.4 Muting a Call..................................................................................................13
5Call Management Features .................................................................................13
5.1 Putting a Call on Hold....................................................................................13
5.2 Using Call Waiting .........................................................................................13
5.3 Transferring a Call to another Party ...............................................................14
5.4 Redialing the Last Number Dialed..................................................................14
5.5 Forwarding Calls to another Phone................................................................14
5.5.1 Setting up Call Forwarding from your IP Phone .....................................14
5.5.2 Setting up Call Forwarding from your mobile..........................................15
5.5.3 Setting up Call Forwarding via Internet ..................................................15
5.6 Placing a Conference Call..............................................................................15
5.7 Call Pickup.....................................................................................................16
5.7.1 Call Pickup within your Group................................................................16
5.7.2 Directed Call Pickup (Specific Group Member)......................................16
VoiceMail Service........................................................................................................18
5.8 Activating VoiceMail.......................................................................................18
5.8.1 Activating VoiceMail on your IP Phone....................................................18
5.8.2 Remote Activation of VoiceMail ..............................................................18
5.9 Accessing VoiceMail......................................................................................18
5.10 Remote Access to VoiceMail .........................................................................19
5.11 Retrieval of VoiceMail via Outlook 2000.........................................................19
5.12 Visual VoiceMail ............................................................................................20
6Using Phone Log.................................................................................................21
6.1 Viewing and Dialing from the Phone Log .......................................................21
6.2 Deleting Call Record from Phone Log............................................................21
7Password Management.......................................................................................22
7.1 Change The Cloud Voice S Password...........................................................22
7.2 Change The IP Phone PIN.............................................................................23

Remote Extension S (Video) –Cisco 9971 IP Phone User Guide
Version 2.0 © WTT HK Limited 2017
3
WTT Cloud Voice S service is an advanced, state-of-the art unified communications
service which consists of full-featured IP telephony and performs all the functions of a
traditional telephone with the added advantages of Mobility Apps, Sim-Ring, Extension
Mobility, Remote Extension, Presence Communicator and Cloud Communicator
(softphone). It helps to enhance the operational efficiency of your business and assures
that your colleagues can always stay in touch with your business partners anytime,
anywhere.
The Remote Extension service allows remote offices and users across the territories to
connect IP phones to the Cloud Voice S platform and communicate seamlessly and
securely with one another by simply dialing their extension number.
The Remote Extension service enabled by Cisco Unified IP Phone 9971 is an advanced
professional media endpoint that delivers an enhanced user experience with an easy-to-
use and eco-friendly ergonomic design. Highlights of the IP Phone 9971 include a
higher-resolution, fully backlit (VGA) color and touch-screen display, a USB port for
peripherals, Gigabit Ethernet network and pc switch ports, and High-definition (HD) voice
support, enabling a more productive user experience for multimedia application
engagement.
1 Phone Set Features and Functions
1.1 Operation for IP Phone 9971
Item
Description
1
DC adaptor port (DC48V).
2
AC-to-DC power supply.
3
AC power wall plug.
4
Network port (10/100/1000 SW) with IEEE 802.3af
and 802.3at power enabled.
5
Computer port (10/100/1000 PC) connection
6
Headset connection (optional).
7
Analog headset connection
8
USB port
9
Anti-theft security lock connector
10
Camera pin holes (for Cisco Unified Video
Camera)
11
Secure Digital I/O (SDIO) slot (not used for this
release)
Notes: IP Phone 9971 cannot function properly when there is a failure in power supply.

Remote Extension S (Video) –Cisco 9971 IP Phone User Guide
Version 2.0 © WTT HK Limited 2017
4
1.2 Location of Control
Item
Description
1
Phone screen
Shows information about your phone, including directory number, call
information (for example caller ID, icons for an active call or call on hold)
and available softkeys.
Phone screen items, such as menu options and softkeys, are touch-
sensitive.
2
Session buttons
Each corresponds with an active call or a call function. Pressing the
button takes the default action:
•Active calls—Pressing the button takes the default action for an active
call. For example, pressing the session button for a ringing call
answers the call and pressing the button on a held call resumes the
call. Session information, such as caller ID and call duration, appears
on the phone screen next to the session button.
•Call functions—When a session button is not being used for an active
call, it can be used to initiate functions on the phone, as indicated by
the adjacent phone screen icons. For example, pressing the session
button can display missed calls, take the phone off hook, or dial your
voice-messaging system (with a Voicemail icon). Color LEDs reflect
the call state. LEDs can flash (blink on and off rapidly), pulse
(alternately dim and brighten), or appear solid (glow without
interruption).
•Flashing amber —Ringing call. Pressing this button answers
the call.
•Solid green —May be a connected call or an outgoing call that
is not yet connected. If the call is connected, pressing this button

Remote Extension S (Video) –Cisco 9971 IP Phone User Guide
Version 2.0 © WTT HK Limited 2017
5
displays the call details or the participants of a conference call. If the
call is not yet connected, pressing this button ends the call.
•Pulsing green —Held call. Pressing this button resumes the
held call.
•Solid red —Shared line in-use remotely. Pressing this button
allows you to barge in on the call (if Barge is enabled).
•Pulsing red —Shared line call put on hold remotely. Pressing
this button resumes the held call. (The positions of the session
buttons and feature buttons can be reversed on phones that use a
locale with a right-to-left reading orientation, such as Hebrew and
Arabic.)
3
Back button
Returns to the previous screen or menu.
4
Release button
Ends a connected call or session.
5
Navigation pad and
Select button
The four-way Navigation pad allows you to scroll through menus,
highlight items, and move within a text input field. The Select button
(center of the Navigation pad) allows you to select a highlighted item.
The Select button is lit (white) when the phone is in power-save mode.
6
Conference button
Creates a conference call.
7
Hold button
Places a connected call on hold.
8
Transfer button
Transfers a call.
9
Keypad
Allows you to dial phone numbers, enter letters, and choose menu items
(by entering the item number).
10
Speakerphone
button
Selects the speakerphone as the default audio path and initiates a new
call, picks up an incoming call, or ends a call. During a call, the button is
lit green. The speakerphone audio path does not change until a new
default audio path is selected (for example, by picking up the handset). If
external speakers are connected, the Speakerphone button selects
them as the default audio path.
11
Mute button
Toggles the microphone on or off during a call. When the microphone is
muted, the button is lit red.
12
Headset button
Selects the headset as the default audio path and initiates a new call,
picks up an incoming call, or ends a call. During a call, the button is lit
green. A headset icon in the phone screen header line indicates the
headset is the default audio path. This audio path does not change until
a new default audio path is selected (for example, by picking up the
handset).
13
Volume button
Controls the handset, headset, and speakerphone volume (off hook) and
the ringer volume (on hook). Silences the ringer on the phone if an
incoming call is ringing.
14
Messages button
Dials to retrieve your Voicemail messages.

Remote Extension S (Video) –Cisco 9971 IP Phone User Guide
Version 2.0 © WTT HK Limited 2017
6
15
Applications button
Opens/closes the Applications menu. Depending on how your system
administrator sets up the phone, use it to access applications such as
call history, preferences, and phone information.
16
Contacts button
Opens/closes the Contacts menu. Depending on how your system
administrator sets up the phone, use it to access personal directory,
corporate directory, or call history.
17
Phone display
Can be positioned to your preferred viewing angle.
18
Programmable
feature buttons
(also called feature
buttons)
Each corresponds with a phone line, speed dial, and calling feature.
Pressing a button for a phone line displays the active calls for that line. If
you have multiple lines, you may have an All Calls button that displays a
consolidated list of all calls from all lines (oldest at the top). Then it is
recommended that you keep your phone in the All Calls view. Color
LEDs indicate the line state:
•Amber —Ringing call on this line
•Green —Active or held call on this line
•Red —Shared line in-use remotely
(The positions of the session buttons and feature buttons can be
reversed on phones that use a locale with a right-to-left reading
orientation, such as Hebrew and Arabic.)
19
Handset with light
strip
The handset light strip lights up to indicate a ringing call (flashing red) or
a new voice message (steady red).

Remote Extension S (Video) –Cisco 9971 IP Phone User Guide
Version 2.0 © WTT HK Limited 2017
7
2 Quick Installation Procedures
Remote Extension offers an IP Phone for you to setting up in non-coverage
remote offices or homes. You can enjoy the voice service same as the office
such as the extension dialing. Follow below steps to connect the IP Phone to
a DHCP (Dynamic Host Configuration Protocol) broadband.
A. Footstand Installation
1. Insert the curved connectors into the lower slots.
2. Lift the footstand until the connectors snap into the upper slots.

Remote Extension S (Video) –Cisco 9971 IP Phone User Guide
Version 2.0 © WTT HK Limited 2017
8
B. Physical Network Connection Setup
1. Connect the IP Phone to Power Adaptor with the power supply.
2. Connect the LAN Cable to the Network port of the IP Phone and the
Internet router.
3. Connect the Handset to the IP Phone.
4. Remove the protective plastic from the camera lens and body.
5. Remove the small plastic cover located on the topside of the phone
display.
6. With your phone idle, slide the camera’s USB connector into the phone’s
USB port (back of phone display).
7. After the phone confirms installation.
Note: IP Phone 9971 cannot be functioned when there is a failure in power supply

Remote Extension S (Video) –Cisco 9971 IP Phone User Guide
Version 2.0 © WTT HK Limited 2017
9
C. VPN Setup
1. Press the Application button
2. Select the VPN application
3. Turn on the VPN
4. Enter your User ID (cv + your Cloud Voice S Number, e.g. your Cloud Voice S
Number is 31234567, your User ID is cv31234567)
5. Enter your Password (your Cloud Voice S Number)
6. Press Sign In soft key

Remote Extension S (Video) –Cisco 9971 IP Phone User Guide
Version 2.0 © WTT HK Limited 2017
10
3 Preference Setup
3.1 Adjust Brightness
As the display of IP Phone may be affected by the lighting of office
environment, you can adjust the brightness in order to have best performance
on the display accordingly.
1. Press the Applications button .
2. Select Preferences. (Use the Navigation bar and button to scroll and
select.)
3. Select Brightness.
To increase brightness, press the Right arrow on the Navigation bar
To decrease brightness, press the Left arrow on Navigation bar
4. Press the Save soft key to confirm the brightness level, or just press the
Cancel soft key to exit without changing the setting.
3.2 Adjust Ringtone
You can change the volume or ringing tone to suit your business environment
by means of following procedures.
3.2.1 Change Volume
1. Press the Volume button to adjust the loudness of the
ringtone.
3.2.2 Change Ringtone
1. Press the Applications button .
2. Select Preferences. (Use the Navigation bar and button to scroll and
select.)
3. Select Ringtone and different types of ringing tone are displayed.

Remote Extension S (Video) –Cisco 9971 IP Phone User Guide
Version 2.0 © WTT HK Limited 2017
11
4. Press the Play soft key to play a sample.
5. Press the Set soft key to select the ringtone.
6. Press the Apply soft key to confirm your selection, or press the Cancel
soft key to go back to the Ringtone screen.
3.3 Adjust Wallpaper
There are some standard IP phone wallpaper background templates
prepared by WTT . You can easily change it accordingly.
1. Press the Applications button .
2. Select Preferences. (Use the Navigation pad and Select button to scroll
and select.)
3. Select Wallpaper and it will display different wallpaper in your IP phone.
Select the wallpaper you preferred.
4. Press the Preview soft key to preview the wallpaper.
5. Press the Set soft key to apply the wallpaper to your IP phone.

Remote Extension S (Video) –Cisco 9971 IP Phone User Guide
Version 2.0 © WTT HK Limited 2017
12
4 Basic Features
4.1 Placing a Call
There are 4 options for placing a new call:
1. When using the handset, lift the handset and dial the number.
2. To make a new call on the current line, press the NewCall soft key and
dial the number.
3. To dial with the phone on hook, from the main screen, perform either of
these actions:
Dial the number and lift handset or press the Dial soft key. The phone
will not produce the dial tone until after you lift the handset or press the
Dial soft key.
Press the NewCall soft key and dial the number.
4. To dial the last dialed number, press the Redial soft key.
4.2 Answering a Call
There are 3 options for answering a call:
1. Lift the handset.
2. Press the Answer soft key
3. Press the Speakerphone button
4.3 Ending a Call
There are 3 options for ending a call:
1. Hang up the handset.
2. Press the EndCall soft key
3. Press the Speakerphone button , when using hand-free
conversation mode

Remote Extension S (Video) –Cisco 9971 IP Phone User Guide
Version 2.0 © WTT HK Limited 2017
13
4.4 Muting a Call
1. Press the Mute button.
2. To disengage mute, press the Mute again.
Note: If you are using mute along with the speakerphone, lifting the handset will
disengage the mute function.
5 Call Management Features
5.1 Putting a Call on Hold
During the call conversation, you can put the other call party temporarily on-
hold.
1. To put a call on hold,
Press the Hold button .
The Hold icon will be displayed and the Line button will be pulsed to
green colour.
2. To resume the highlighted call, you can press the Resume soft key.
5.2 Using Call Waiting
If you are enabled with call waiting for your phone and you are on a call, you
will hear a call waiting tone and the caller ID information will be shown on the
phone’s LCD screen if a new call comes in when you are on the phone.
1. To answer the new call, press the Answer soft key. When you do so, the
original call will be put on hold.
2. To return to the original call, press the Resume soft key.
3. If the second call is still active, the call will be put on hold when you return
to the original call.
4. You can continue to use the Hold button to switch between the calls.

Remote Extension S (Video) –Cisco 9971 IP Phone User Guide
Version 2.0 © WTT HK Limited 2017
14
5.3 Transferring a Call to another Party
During the call conversation (not ‘On-hold’ mode), if you wish to transfer your
call conversation to another party, you can:
1. Press the Transfer button .
2. Enter 8-digits local number * / 4-digits extension number of the recipient
3. Press the Transfer button again or the Transfer soft key.
* If you wish to transfer the call to external partner, please remember to add ”9”
before the 8-digits telephone number
5.4 Redialing the Last Number Dialed
To redial the most recently dialed number, press the Redial soft key. If you
have not lifeted up the handset, it will be in speakerphone mode and
automatically activate speaker.
5.5 Forwarding Calls to another Phone
5.5.1 Setting up Call Forwarding from your IP Phone
1. Press the Forward All soft key. You will hear two beeps.
2. Enter the destination number to which you want to forward all of your calls,
exactly as you were placing a call to that number.
3. To cancel all call forwarding, press the Forward Off soft key.
Note: If you wish to forward the call to external partner, please remember to add ”9”
before the 8-digits telephone number
Tips: To forward all incoming calls to your voicemail, just simply press Forward All
and Message button.

Remote Extension S (Video) –Cisco 9971 IP Phone User Guide
Version 2.0 © WTT HK Limited 2017
15
5.5.2 Setting up Call Forwarding from your mobile
1. Dial 2112 1113 to access Remote Call Forwarding hotline.
2. Follow the voice prompts and select the language by pressing ‘1’ for
Cantonese/ ‘2’ for English.
3. Enter your Cloud Voice S number and Cloud Voice S password
accordingly.
4. Enter the destination of number to which you want to forward all of your
calls (e.g. your mobile).
5. Similarly, to cancel all call forwarding, please dial 2112 1113 to deactivate
the call forwarding setting accordingly.
Note: Starter Cloud Voice S Password is your Cloud Voice S number. For security
reason, please change your password in a regular basis.
5.5.3 Setting up Call Forwarding via Internet
1. Browse to website https://adp.wtt-cloudvoice.com/pc/en/index.jsp
2. Click ‘Cloud Voice S User Portal’ button.
3. Enter your Cloud Voice S number and Cloud Voice S Password to login
Cloud Voice S User Portal.
4. Click ‘Call Management’ to activate the Call Forwarding.
5. Enter the destination of number to which you want to forward all of your
calls (e.g. your mobile).
6. Similarly, to cancel all call forwarding, please login to ‘Cloud Voice S User
Portal’ again to deactivate the call forwarding accordingly.
Note: Starter Cloud Voice S Password is your Cloud Voice S number. For security
reason, please change your password in a regular basis.
5.6 Placing a Conference Call
During the phone conversation, you can invite more business partners to join
the conversation by means of N-way Conference Call.

Remote Extension S (Video) –Cisco 9971 IP Phone User Guide
Version 2.0 © WTT HK Limited 2017
16
1. During an active call conversation, press the Conference button
2. Enter 8-digits local number / 4-digits extension number of the other
invited party.
3. Press the Call soft key and wait for the invited party to answer.
4. Press the Conference button again or the Conference soft key.
5. The conference call with 3 parties will be begun.
6. Repeat these steps to add more parties, if desired.
Note: If you wish to make a conference with external partner, please remember to
add ”9” before the 8-digits telephone number
Tips: To view and remove conference participants, you can press Details button and
press Remove to remove a conference participant.
5.7 Call Pickup
5.7.1 Call Pickup within your Group
When one of your pickup group member’s phone rings, you can use your own
phone to pick up and answer the call directly.
1. Press the PickUp button to transfer a ringing call within your pickup group
to your phone.
2. When your phone rings, press the Answer soft key to pickup and connect
to the call.
5.7.2 Directed Call Pickup (Specific Group Member)
1. Press Group Pickup.
2. Enter the extension number of the phone line with the call that you want
to pick up.
(For example, if the call is ringing on line extension number ‘1234’, please
enter ‘1234’.)
3. When your phone rings, press the Answer soft key to pickup and connect
to the call.

Remote Extension S (Video) –Cisco 9971 IP Phone User Guide
Version 2.0 © WTT HK Limited 2017
17

Remote Extension S (Video) –Cisco 9971 IP Phone User Guide
Version 2.0 © WTT HK Limited 2017
18
VoiceMail Service
5.8 Activating VoiceMail
5.8.1 Activating VoiceMail on your IP Phone
1. Press the Message button on your IP Phone
2. Enter your VoiceMail PIN followed by “#”
3. Follow the voice instructions to change the VoiceMail PIN to activate the
VoiceMail service.
5.8.2 Remote Activation of VoiceMail
1. Dial the access number 2112-2345. [Please dial (852) 2112-2345 when
you are accessing VoiceMail service from overseas.]
2. A welcome greeting message will be announced and please select the
language by pressing ‘1’ for Cantonese / ‘2’ for English.
3. Enter your User ID (your Cloud Voice S Number) followed by “#”
4. Enter your VoiceMail PIN followed by “#”
5. Follow the voice instructions to change the VoiceMail PIN to activate the
VoiceMail service
Note: Starter VoiceMail PIN is your Cloud Voice S Number. For security reason,
please change your VoiceMail PIN regularly.
5.9 Accessing VoiceMail
1. The red light on your Handset will light up when you have a voicemail
message.
2. To access the voice messaging system, press the Message button
and follow the voice instructions.

Remote Extension S (Video) –Cisco 9971 IP Phone User Guide
Version 2.0 © WTT HK Limited 2017
19
5.10 Remote Access to VoiceMail
1. Dial the access number 2112-2345. [Please dial (852) 2112-2345 when
you are accessing VoiceMail service from overseas.]
2. A welcome greeting message will be announced and please select the
language by pressing ‘1’ for Cantonese / ‘2’ for English.
3. Enter your User ID (your Cloud Voice S Number) followed by “#”
4. Enter your VoiceMail PIN followed by “#”
5. Follow the voice prompts for voice mail service.
Note: The User ID will be your Cloud Voice S Number. For security reason, please
change your VoiceMail PIN regularly
5.11 Retrieval of VoiceMail via Outlook 2000
1. Open your Microsoft Outlook
2. Click Tools
3. Select Accounts
4. Click New
5. Select Microsoft Exchange, POP3, IMAP, or HTTP and click Next
6. Enter Account Information * and click Next
7. Select Internet E-mail and click Next
8. Enter Server Information ** and click Next
9. Click Finish
* When entering the Account Information, please input the following
Your Name: Name wish to be displayed in email
E-mail Address: [email protected]-cloudvoice.com; ‘3xxxxxxx’ is your
Cloud Voice S Number
Username: Your Cloud Voice S Number (e.g. 3xxxxxxx)
Password: Your Cloud Voice S Password
** When entering Server Information, please input the following
Account Type: IMAP
Incoming mail server: imap.wtt-cloudvoice.com;
Outgoing mail server: smtp.wtt-cloudvoice.com

Remote Extension S (Video) –Cisco 9971 IP Phone User Guide
Version 2.0 © WTT HK Limited 2017
20
5.12 Visual VoiceMail
By using Visual VoiceMail service, your voicemail messages will be displayed
in your IP phone so that you can prioritize which messages to listen first.
1. Press the Message button and select Visual Voicemail.
2. Enter your VoiceMail PIN for your voicemail account.
(Toggle on Remember Me to keep you sign-in status)
3. Press the Sign In soft key.
4. The VoiceMail will be displayed accordingly.
