Clarke CGS5D Instruction Manual

OPERATION & MAINTENANCE
INSTRUCTIONS
LS0519
ORIGINAL INSTRUCTIONS
GUN SAFE WITH DIGITAL LOCK
MODEL NO: CGS5D, CGS8D
PART NO: 7724029, 7724032

2
Parts & Service: 020 8988 7400 / E-mail: [e-mail] or [e-mail]
INTRODUCTION
Thank you for purchasing this CLARKE Gun Safe with Digital Lock.
Before attempting to use this product, please read this manual thoroughly and
follow the instructions carefully. In doing so you will ensure the safety of yourself
and that of others around you and you can look forward to your purchase
giving you long and satisfactory service.
GUARANTEE
This product is guaranteed against faulty manufacture for a period of 12
months from the date of purchase. Please keep your receipt which will be
required as proof of purchase.
This guarantee is invalid if the product is found to have been abused or
tampered with in any way, or not used for the purpose for which it was
intended.
Faulty goods should be returned to their place of purchase, no product can
be returned to us without prior permission.
This guarantee does not effect your statutory rights.
CARTON CONTENTS
The following items should be supplied in the carton. If any parts are missing or
damaged, please see your Clarke dealer.
1 x Gun Safe
2 x Gun Safe Override Keys
2 x Ammunition Safe Keys
2 x Expansion Bolts
4 x AA Batteries

3
Parts & Service: 020 8988 7400 / E-mail: [e-mail] or [e-mail]
PART IDENTIFICATION

4
Parts & Service: 020 8988 7400 / E-mail: [e-mail] or [e-mail]
INSTALLATION
Remove everything from the box and dispose of any packaging materials in
an environmentally friendly way.
FIXING THE GUN SAFE IN POSITION
1. Your gun safe must be securely fixed to the structure of the building.
• Ideally it must be in a room or space that does not have direct
access to the outside of the building.
• It must not be in a garage, shed or other outbuilding.
• When considering the larger or heavier gun safes, you should
consider the load bearing strength of your floors.
• Wherever possible, it should be fixed to either a wall that is built from
bricks or concrete blocks or to the floor. If this is not possible then to a
strong joist using suitable fixings.
• The gun safe must be out of sight. If it is in a corner, it is more difficult
for a thief to attack it.
• You should avoid fixing the gun safe near any heat source.
2. The gun safe must be secured using suitable fixings.
• There are two fixing holes on the rear and four on the bottom.
3. Fit the gun safe flush to the wall.
• If needed remove the skirting boards behind/to the side of the gun
safe as they may leave a large enough gaps for a crowbar to be
used to prise the gun safe away.
NOTE: IF YOU HAVE ANY QUERIES CONTACT YOUR LOCAL FIREARMS
LICENCING TEAM.
KEYS
1. Remember it is YOUR responsibility to ensure that unauthorised persons can
not gain access to your guns.
• Do not let anyone (including family members) know the
combination or where the override keys are kept. You may lose your
shotgun/firearm certificate if you do.
2. Keep the keys to the gun safe in a place where they can’t be found easily.
• “hiding” keys in a drawer is pretty obvious to a thief, so think carefully
about the hiding place. Consider purchasing a small combination
safe where only you know the combination.

5
Parts & Service: 020 8988 7400 / E-mail: [e-mail] or [e-mail]
BEFORE USE
OPENING THE SAFE FOR THE FIRST TIME
1. Remove the override key cover
from the front panel.
2. Insert the override key, turn it
clockwise as far as possible and
hold it in position.
3. At the same time, turn the keypad
lock anticlockwise as far as
possible and hold it in this position.
4. Release the override key
5. Push the main handle down and
pull the door towards you to open
the safe.
IMPORTANT: Never keep the override
keys inside the safe itself.
6. Remove the key and replace the
override key cover onto the front
panel.
INSTALLING THE BATTERIES
The safe requires 4 x size “AA” (1.5V) batteries.
1. Open the safe.
2. Remove the battery cover plate
on the back of the door and
install the batteries.
• Ensure the batteries are fitted
with the correct polarity.
3. Use of alkaline batteries is
recommended.

6
Parts & Service: 020 8988 7400 / E-mail: [e-mail] or [e-mail]
PROGRAMMING THE CODE
NOTE: You have approximately 5 seconds to carry out each step before the
lock resets and you need to start again.
1. With the safe door open and the
batteries installed: Press the code
reset button (A) on the rear of the
door once.
• You will hear a beep.
• The yellow light will be
displayed on the keypad.
2. Enter the code you want to use
(3-8 digits) as a combination.
3. Press “A” or “B” to confirm your
code.
• The safe “beeps” once and the
yellow light will go off,
• Your personal code is now set.
4. Test the safe using the new
combination immediately.

7
Parts & Service: 020 8988 7400 / E-mail: [e-mail] or [e-mail]
USING YOUR SAFE
TO OPEN THE SAFE
1. Enter your personal code followed
by the letter “A” or “B”.
• you will hear a beep and the
green light on the front of the
safe will light up.
2. Turn the keypad lock
anticlockwise as far as possible
and hold it in this position.
3. Push the handle down and pull
the door towards you.
• If you, or an intruder uses the
incorrect group of numbers, it
will not open, if the incorrect
combination is used 3 times,
you must wait for 18 seconds
before trying again.
• If the incorrect combination is
selected a further 3 times, you
must wait approximately 4.5 minutes before trying again.

8
Parts & Service: 020 8988 7400 / E-mail: [e-mail] or [e-mail]
INSERT THE GUNS
1. Remove all ammunition from the
guns and secure the ammunition
in the ammunition safe.
2. Place the guns into the gun safe
making sure they are resting
securely against the foam inserts.
THE AMMUNITION SAFE
Inside the gun safe is a small
ammunition safe.
Use the key supplied to access this
compartment.
CLOSING THE GUN SAFE
1. Close the door and lift the handle up.
2. Turn the keypad lock clockwise as far as possible to lock the safe.
BATTERY REPLACEMENT WARNING
If the batteries are low, the red light on the keypad will illuminate. Replace the
batteries immediately.
MANUAL OVERRIDE
See “Opening the safe for the first time” on page 5.

9
Parts & Service: 020 8988 7400 / E-mail: [e-mail] or [e-mail]
MAINTENANCE AND SERVICING
There are no user serviceable parts in this gun safe. Any repairs must be carried
out by Clarke service (see bottom of the page for contact number)
CLEANING
Wipe the surfaces with a damp cloth. Do not use harsh cleaners as they may
damage the finish of your gun safe.

10
Parts & Service: 020 8988 7400 / E-mail: [e-mail] or [e-mail]
REPLACEMENT OVERRIDE KEY
A small label is located on the door of each safe with a key number.
This number must be registered with Clarke international in the event you may
require a replacement key.
Please complete the registration form supplied and send it to the address
stated with the form.
If you fail to register the safe we will not be able to provide you with a
replacement key.
We recommend that in addition to sending the completed form you remove
the label from the safe and fix it to the space below. Please retain this
document for future reference.
Fix or record the key number here
Key Number....................................................................................

11
Parts & Service: 020 8988 7400 / E-mail: [e-mail] or [e-mail]
SPECIFICATIONS
Model Number CGS5D CGS8D
Part Number 7724029 7724032
External Dimensions (W x D x H) (mm) 350 x 340 x 1450 490 x 360 x 1450
Fixing Hole diameter (mm) 10 10
Capacity 5 Guns 8 Guns
Maximum Gun Length (mm) 1260 1260
Ammunition Box Dimensions (mm) 340 x 145 x 185 480 x 155 x 190
Wall thickness (mm) 4 4
Weight (Empty) (kg) 53 61.5
