Cleveland KGL-40-T User manual

Cleveland
™
Project ________________________________
Item __________________________________
Quantity_______________________________
FCSI Section ____________________________
Approval _______________________________
Date __________________________________
1333 East 179 St.,
Cleveland, Ohio,U.S.A. 44110
Tel: [phone]
Fax: [phone]
Web Site:www.ClevelandRange.com
Email: [e-mail]
GAS KETTLES
MODELS:cKGL-40-T cKGL-80-T
cKGL-60-T
Cleveland Standard Features
nHigh efficiency Power Burner Heating System (62% to
65% efficiency)
nFast Heat-up and Recovery Time, 140M BTU’s on 40 gallon
models, 190M BTU’s on 60 gallon and larger
nInsulated Heat Exchanger
nAutomatic Ignition System
nSteam Jacket permanently filled with treated, distilled water.
Venting and/or refilling not required.
nSolid State Controls, for Temperature and Low Water Safety,
in a plug-in Control Module
nControl Panel includes:
nPrecise, consistent temperature control: less than
n± 1°Cvariance (ideal for simmering).
nL.E.D. Indicators for Heat Cycle and Low Water Warning.
nPower
“on/off” Switch
nFront mounted combination Pressure/Vacuum Gauge
nType 304 Stainless Steel with #4 finish on kettle and supports
nTilt Mechanism of roller bearings and case hardened
self-locking worm and segment gear
nSupport Legs with level adjustable feet, flanged for floor bolting
n50 psi Steam Jacket Rating and Safety Valve
nStandard voltage is 115 volts, 60 Hz, single-phase,
supplied with cord and plug
nStandard for natural gas operation
nTypical approvals include AGA, CSA, CE, NSF and ASME
Options & Accessories
pType 316 Stainless Steel Kettle Liner for high acid food
products (316)
pPan Carrier (PCK)
pFlow Diverter (FD)
pFood Strainer (FS)
pKettle Markings (KM)
pCooking Baskets and Tri-Basket Supports (BS and TBS)
pDrain Strainers (DS-)
pFaucet Mounting Bracket (FBKT)
p2˝ or 3" diameter Tangent Draw-Off Valve with Drain Strainer
(TD2 or TD3*), *TD3 for 60 and 80 gallon only and will raise
height of kettle by 5-5/8" (143mm)
p3" diameter Butterfly Valve (BV3)
Shall be CLEVELAND, Gas-Fired Tilting Kettle, Model KGL- _____ T;
_____ gallons, 2⁄3 Steam Jacketed, Power Burner Heating System,
Insulated Heat Exchanger, 50 psi Steam Jacket Rating. Infinite
Variable Temperature Control, L.E.D. indicators for Heat Cycle and
Low Water Warning, Automatic Ignition System.
pSpring-assisted, hinged, rotatable, domed Stainless
Steel Cover (CHS-)
pHot and Cold Water Faucet with Swing Spout (DPK)
pKettle Accessory Kit (KAK) includes:
pClean-up Brush(CB) p36”Kettle Paddle (KP)
p36”Kettle Whip(KW) p36”Kettle Brush (KB)
pDraw-offBrush (DB) p24 oz. Ladle (KL)
pAutomatic Water Meter (GMF or LMF)
pMeasuring Strip (MS)
pOption for Propane Gas operation
pCorrectional Package
pHeat Deflector Shield (HS001)
Short Form Specifications
Shown with optional Spring Assisted
Cover and 2" Tangent Draw-Off Valve
LEG TYPE, GAS-FIRED KETTLES
TILTING, 2⁄3 STEAM JACKETED
“SPLASH PROOF SERIES”
40, 60, or 80 GALLONS (150, 225, or 300 LITERS)
SECT. IX PAGE 7
0707

J
K
C
H
NO
M
L
Q
P
3" 
(77 mm)
REF
S I.D.
C
B
A
G
HANDWHEEL REPLACED
BY SWITCH FOR
POWER TILT OPTION
H
F
E
D
2 1/4" 
(57 mm)
REF
2 1/2"
(64 mm)
2 1/2"
(64 mm)
4 1/8"
(105 mm)
3" (77 mm) 
MIN.
CLEARANCE
UNIT SHOWN WITH OPTIONAL 2" TANGENT DRAW-OFF VALVE,
SPRING ASSIST COVER AND HOT & COLD WATER FAUCET.
9/16"
14
mm
120º
TYP
1" (25
mm)
MAX. ADJUSTMENT
1 5/8" (42 mm) Ø
FLANGED FOOT DETAIL
7/16" (11 mm) Ø
3 HOLES ON
31/8" (80
mm) Ø 
B.C.D.
47/8"
124
Ø mm
RECOMMENDED
FLOOR SLOPE

1" (26 mm) per 4' (1220 mm)
PIPE DRAIN RECOMMENDED
min. valve size plus 1" (26 mm)
4" (102 mm)
RECOMMENDED
VALVE OPENING
NOTE : TD3, 3" tangent draw off will
raise height of kettle by 5-5/8" (143mm).
Available on 60 & 80 gallon models only.
NOTES:
Cleveland Range reserves right of design improvement or modification, as warranted.
Many regional, state and local codes exist and it is the responsibility of the owner and installer to comply with the codes.
Installation of backflow preventers, vacuum breakers and other specific coder requirements is the responsibility of the owner and installer.
Cleveland Range equipment is built to comply with applicable standards for manufacturers. Included among those approval agencies are U.L., A.G.A., NSF, ASME/N.Bd., CSA, CGA, ETL and others.
1⁄2˝dia. Soft
Copper
Tubing (each)
When
ordered with
optional
faucet.
WATERELECTRIC
120V-1 Phase, 60 Hz, 10
amps
GAS CLEARANCE
H
RIGHT =0˝
LEFT = 0˝
REAR = 3˝
Allow 6˝ space minimum
from rear and sides when
located near combustible
walls. 12" recommended on
right side for service
NATURAL PROPANE
Piping: 3⁄4˝ N.P.T. Piping: 3⁄4˝ N.P.T.
Supply pressure: Supply pressure:
4.00˝ W.C. minimum 4.00˝ W.C. minimum
14.00˝ W.C. maximum 14.00˝ W.C. maximum
Manufacturer must be notified if unit will be operated above 2,000 ft. altitude.
C
B.T.U. RATING
40 gal. 140,000
60 gal.
80 gal. 190,000
100 gal.
H
C
SECT.IX PAGE 8
1003
Litho in U.S.A.
CAPACITIES: (in 8 oz. servings,
other sizes may be calculated)
40 Gallon / 150 liters . . . 640 servings
60 Gallon / 225 liters . . . 960 servings
80 Gallon / 300 liters . . . 1280 servings
DIMENSIONS
GALS./
LITERS A B C D E F G H J K L M N O P Q S I.D.
40 IN 45 3/4 42 1/2 38 35 9 42 1/4 71 40 1/2 15 1/2 23 1/4 19 35 3/4 4 3/8 24 33 63 26
150 mm 1163 108 966 889 229 1074 1804 1029 394 591 483 909 112 610 839 1601 661
60 IN 49 3/8 46 41 1/2 37 11 3/4 47 1/4 75 43 3/4 15 1/4 24 1/2 22 39 3/8 6 28 37 68 29 1/2
225 mm 1255 1169 1055 940 299 1201 1905 1112 388 623 559 1001 153 712 940 1728 750
80 IN 53 49 44 1/2 39 14 3/4 51 78 44 3/4 14 25 25 43 7 30 40 72 33
300 mm 1347 1245 1131 991 375 1296 1982 1137 356 635 635 1093 178 762 1016 1829 839
