Cleveland HA-MKGL-100-T User manual

Cleveland
™
Project ________________________________
Item __________________________________
Quantity_______________________________
FCSI Section ____________________________
Approval _______________________________
Date __________________________________
1333 East 179 St.,
Cleveland, Ohio,U.S.A. 44110
Tel: [phone]
Fax: [phone]
Web Site:www.ClevelandRange.com
Email: [e-mail]
MIXER KETTLES
Cleveland Standard Features
n60, 80 or 100 gallon working capacity
n Type 304 stainless steel with #4 finish on kettle and supports
nPrecise solid state temperature control
nSolid state low water safety controls in a plug-in module
nL.E.D. indicators for heat cycle and low water warning
n3˝ dia. butterfly valve
nThree (3) horse power horizontal agitator drive
nVariable mixer speed control from 5 to 20 r.p.m. with
agitator start/stop controls
nSpring loaded teflon blades scrape the entireheated
surface area
nInternal mixing fins for most efficient, uniform mixing of
products
nEasily removable agitator without the use of tools
n190 M-BTU high efficiency power burner heating system
for fast heat-up and recoverytimes
n"Glow type" automatic safety ignition system
nPower tilt mechanism with case hardened self-locking
worm and segment gear
nKettle steam jacket permanently filled with treated
distilled water
n50 psi steam jacket rating and safety valve
nFront mounted combination pressure-vacuum gauge
nHeavy duty welded rim bar
nWater fill faucet with swing spout for hot and cold water
nFaucet mounting bracket.
nSpring assisted, hinged stainless steel cover
nStandard for Natural Gas operation
nStandard Electrical for agitator drive is 208V/3Ph/60Hz
nAccepted for use in USDA inspected facilities
nTypical approvals include AGA, CSA, CE, NSF and
ASME
Options & Accessories
p Type 316 stainless steel kettle liner for high acid products (316 )
pDolly for horizontal agitator
pStainless steel bi-fold hinged cover
Shall be CLEVELAND Model HA-MKGL- ____ -T, gas fired, 2/3 steam
jacketed, ____ gallon operating capacity,tilting horizontal agitator
mixer kettle. 190M BTU High Efficiency Power Burner heating sys-
tem with automatic Glow Type Ignition, type 304
stainless steel with #4 finish on kettle and supports, insulated
Heat Exchanger,50 psi jacket rating, 3HP Motor Drive for mixer arm
with variable speed control, variable temperatures control, L.E.D.
indicators for heat cycle and low water warning, 3" dia. Butterfly
Valve.
p3" diameter air operated flush mounted piston draw-off
valve with variable control (FPVA3, for use with a food
pump, replaces 3˝ butterfly valve, requires air compressor)
pAutomatic water meter (GMF or LMF) Wall or stand
mounted)
pFood Strainer (FS)
p Kettle Accessory Kit (KAK) includes:
pClean-up Brush (CB) p36 " Kettle Paddle (KP)
p36 " Kettle Whip (KW) p36 " Kettle Brush (KB)
pDraw-off Brush (DB) p24 oz. Ladle (KL)
pOption for propane gas operation (PG)
pVoltage option for agitator drive other
than standard 208V/3Ph/60Hz
Short Form Specifications
MIXER KETTLES, GAS-FIRED
HORIZONTAL AGITATOR
2/3 STEAM JACKETED, TILTING
MODELS:cHA-MKGL-60-T
cHA-MKGL-80-T
cHA-MKGL-100-T
SECT. XI PAGE 25
0707

RECOMMENDED
FLOOR DRAIN
K O
M
H
J
A
F
5 3/4"
G
28" L
16"
RECOMMENDED FLOOR
SLOPE 1 INCH PER 4 FEET
PIPE DRAIN RECOMMENDED
MINIMUM VALVE SIZE PLUS 1"
T
3" MIN
CLEARANCE
E
(COVER
FULLY
OPEN)
S
B
A
SPRING ASSIST
COVER (FULLY
OPEN AT 90°)
3 HP
ELECTRIC
MOTOR
AI.D.
C
D
6" RECOMMENDED
WALL
WALL
FLOOR DRAIN
A
MODEL
HA-MKGL-60-T
HA-MKGL-80-T
HA-MKGL-100-T
A
29 1/2"
33"
35 1/2"
DIMENSIONS
B
48 1/4"
51 3/4"
54 1/4"
C
61 5/8"
65 3/8"
68 3/8"
D
46 3/4"
52"
55"
E
93"
98"
104"
F
27 3/4"
30 3/4"
32 3/4"
G
42"
45 11/16"
48 3/16"
H
30 5/8"
33 5/8"
35 5/8"
O
8"
9"
10"
K
28"
30"
32"
J
78"
84"
95 5/8"
L
10 3/8"
11 7/16"
11 5/8"
M
53"
57"
66"
S
19 1/4"
20 3/4"
22"
T
25"
26 1/2"
28"
A
NOTES: Cleveland Range equipment is built to comply with applicable standards for manufacturers. Included among those approval agencies are: UL, A.G.A., NSF, ASME/N.BD., CSA, CGA, ETL, and others.
 Installations of back flow preventers, vacuum breakers and other specific code requirements are the responsibility of the owner and installer.
 All vertical dimensions shown are minimum.Feet are adjustable to +1" maximum.
 Manufacturer must be notified if unit will be operating above 2000' altitude.
 Consult factory for manufactured gas.

Cleveland Range reserves right of design improvement or modification, as warranted.
VOLTS: 208/240
PHASE: 3
AMPS: 15
FREQ: 60 HZ
ELECTRICAL
SUPPLY
TYPE: NAT or LP
BTU PER CU. FT.:
1000 (NAT), 2500 (LP)
SUPPLY PRESSURE:
4" to 14" W.C.
BTU RATINGS:
190,000 per hour
60 GAL -
1010 LBS.
458 KG.
80 GAL -
1120 LBS.
508 KG.
100 GAL -
1325 LBS.
601 KG.
APPROX.
SHIPPING
WEIGHTS
GAS SUPPLY
(PIPING 3/4" NPT)
APPROVALS
AIR SUPPLY (PIPING 1/2" NPT)
AGA CGA NSF
H C
CH
5/8"Ø, 
2 HOLES
ON 
4" B.C.D.
SOLID
FOOT DETAIL
5 1/2"
3/8"
1"
(MAX. ADJUSTMENT)
2"
RIGHT: 3", LEFT: 3"
REAR: 3"
(ALLOW 12" SPACE
MINIMUM ON LEFT 
SIDE FOR SERVICE)
CLEARANCE
PRESSURE:
90 - 100 PSI
(only required for optional 3" dia.
piston draw-off valve)

HOT & COLD
WATER
H C
1/2" NPT CONNECTION 
40-60 PSI PRESSURE
RIM BAR
3" DIA. BUTTERFLY VALVE
13"
SECT. XI PAGE 26
0707
