Cognex In-Sight D900 Series User manual

In-Sight®D900 Series
Vision System
Reference Guide
2020 April 29
Revision: 1.2.0.1

Legal Notices
The software described in this document is furnished under license, and may be used or copied only in accordance with
the terms of such license and with the inclusion of the copyright notice shown on this page. Neither the software, this
document, nor any copies thereof may be provided to, or otherwise made available to, anyone other than the licensee.
Title to, and ownership of, this software remains with Cognex Corporation or its licensor. Cognex Corporation assumes
no responsibility for the use or reliability of its software on equipment that is not supplied by Cognex Corporation.
Cognex Corporation makes no warranties, either express or implied, regarding the described software, its
merchantability, non-infringement or its fitness for any particular purpose.
The information in this document is subject to change without notice and should not be construed as a commitment by
Cognex Corporation. Cognex Corporation is not responsible for any errors that may be present in either this document or
the associated software.
Companies, names, and data used in examples herein are fictitious unless otherwise noted. No part of this document
may be reproduced or transmitted in any form or by any means, electronic or mechanical, for any purpose, nor
transferred to any other media or language without the written permission of Cognex Corporation.
Copyright © 2020. Cognex Corporation. All Rights Reserved.
Portions of the hardware and software provided by Cognex may be covered by one or more U.S. and foreign patents, as
well as pending U.S. and foreign patents listed on the Cognex web site at: cognex.com/patents.
The following are registered trademarks of Cognex Corporation:
Cognex, 2DMAX, Advantage, AlignPlus, Assemblyplus, CheckitwithChecker, Checker, CognexVisionforIndustry,
CognexVSOC, CVL, DataMan, DisplayInspect, DVT, EasyBuilder, Hotbars, IDMax, In-Sight, LaserKiller, MVS-8000,
OmniView, PatFind, PatFlex, PatInspect, PatMax, PatQuick, SensorView, SmartView, SmartAdvisor, SmartLearn,
UltraLight, VisionSolutions, VisionPro, VisionView
The following are trademarks of Cognex Corporation:
The Cognex logo, 1DMax, 3D-Locate, 3DMax, BGAII, CheckPoint, CognexVSoC, CVC-1000, FFD, iLearn, In-Sight
(design insignia with cross-hairs), In-Sight2000, InspectEdge, Inspection Designer, MVS, NotchMax, OCRMax,
PatMaxRedLine, ProofRead, SmartSync, ProfilePlus, SmartDisplay, SmartSystem, SMD4, VisiFlex, Xpand
Portions copyright © Microsoft Corporation. All rights reserved.
Portions copyright © MadCap Software, Inc. All rights reserved.
Other product and company trademarks identified herein are the trademarks of their respective owners.
2
Legal Notices

Regulations and Conformity
Note: For the most current CE declaration and regulatory conformity information, see the Cognex support site:
cognex.com/support.
Safety and Regulatory
Manufacturer Cognex Corporation
One Vision Drive
Natick, MA 01760 USA
In-Sight D902: Regulatory Model 50118
In-Sight D905: Regulatory Model R00099
This is a class A product. In a domestic environment this product may cause radio interference in
which case the user may be required to take immediate measures. This equipment complies with the
essential requirements of the EU Directive 2014/30/EU. Declarations are available from your local
representative.
EU RoHS Compliant to the most recent applicable directive.
FCC FCC Part 15, Class A
This equipment has been tested and found to comply with the limits for a Class A digital device,
pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection
against harmful interference when the equipment is operated in a commercial environment. This
equipment generates, uses, and can radiate radio frequency energy and, if not installed and used in
accordance with the instruction manual, may cause harmful interference to radio communications.
Operation of this equipment in a residential area is likely to cause harmful interference in which case
the user will be required to correct the interference at his own expense.
Korea In-Sight D902: Regulatory Model 50118: R-R-CGX-50118
In-Sight D905: Regulatory Model R00099: R-R-CGX-R00099
This device is certified for office use only and if used at home, there can be frequency interference
problems.
TÜV In-Sight D902: Regulatory Model 50118
In-Sight D905: Regulatory Model R00099
NRTL: TÜV SÜD AM SCC/NRTL OSHA Scheme for UL/CAN 61010-1.
CB report available upon request. TÜV SÜD AM, IEC/EN 61010-1.
3
Regulations and Conformity

China RoHS
Hazardous Substances 有害物质
Part Name
部件名称
Lead (Pb)
铅
Mercury (Hg)
汞
Cadmium
(Cd)
镉
Hexavalent
Chromium
(Cr (VI))
六价铬
Polybrominated
biphenyls (PBB)
多溴联苯
Polybrominated
diphenyl ethers (PBDE)
多溴二苯醚
Regulatory
Model
50118
R00099
X O O O O O
This table is prepared in accordance with the provisions of SJ/T 11364.
这个标签是根据SJ / T 11364 的规定准备的。
O: Indicates that said hazardous substance contained in all of the homogeneous materials for this part is below the limit
requirement of GB / T26572 - 2011.
表示本部件所有均质材料中含有的有害物质低于GB / T26572 - 2011 的限量要求。
X: Indicates that said hazardous substance contained in at least one of the homogeneous materials used for this part is
above the limit requirement of GB / T26572 - 2011.
表示用于本部件的至少一种均质材料中所含的危害物质超过GB / T26572 - 2011 的限制要求。
For European Community Users
Cognex complies with Directive 2012/19/EU OF THE EUROPEAN PARLIAMENT AND OF THE COUNCIL of 4 July 2012
on waste electrical and electronic equipment (WEEE).
This product has required the extraction and use of natural resources for its production. It may contain hazardous
substances that could impact health and the environment, if not properly disposed.
In order to avoid the dissemination of those substances in our environment and to diminish the pressure on the natural
resources, we encourage you to use the appropriate take-back systems for product disposal. Those systems will reuse or
recycle most of the materials of the product you are disposing in a sound way.
The crossed out wheeled bin symbol informs you that the product should not be disposed of along with municipal
waste and invites you to use the appropriate separate take-back systems for product disposal.
If you need more information on the collection, reuse, and recycling systems, please contact your local or regional waste
administration.
You may also contact your supplier for more information on the environmental performance of this product.
4
Regulations and Conformity

Precautions
To reduce the risk of injury or equipment damage when you install the Cognex product, observe the following
precautions:
lThe vision system requires a UL or NRTL listed power supply with a 24VDC output that meets the following rating
requirements:
lAt least 5A continuous current.
lOutput rated SELV or National Electrical Code (NEC) Class 2.
Any other voltage creates a risk of fire or shock and can damage the components. Applicable national and local
wiring standards and rules must be followed.
lThis product is intended for industrial use in automated manufacturing or similar applications.
lThe safety of any system incorporating this product is the responsibility of the assembler of the system.
lDo not install Cognex products where they are exposed to environmental hazards such as excessive heat, dust,
moisture, humidity, impact, vibration, corrosive substances, flammable substances, or static electricity.
lRoute cables and wires away from high-current wiring or high-voltage power sources to reduce the risk of
damage or malfunction from the following causes: over-voltage, line noise, electrostatic discharge (ESD), power
surges, or other irregularities in the power supply.
lDo not expose the image sensor to laser light. Image sensors can be damaged by direct, or reflected, laser light.
If your application requires laser light that might strike the image sensor, use a lens filter at the corresponding
laser wavelength. For suggestions, contact your local integrator or application engineer.
lThis product does not contain user-serviceable parts. Do not make electrical or mechanical modifications to
product components. Unauthorized modifications can void your warranty.
lChanges or modifications not expressly approved by the party responsible for regulatory compliance could void
the user’s authority to operate the equipment.
lInclude service loops with cable connections.
lEnsure that the cable bend radius begins at least six inches from the connector. Cable shielding can be
degraded or cables can be damaged or wear out faster if a service loop or bend radius is tighter than 10X the
cable diameter.
lThis device should be used in accordance with the instructions in this manual.
lAll specifications are for reference purposes only and can change without notice.
5
Precautions

Table of Contents
Legal Notices 2
Regulations and Conformity 3
China RoHS 4
For European Community Users 4
Precautions 5
Table of Contents 6
Symbols 8
Introduction 9
Support 9
Standard Components 9
Accessories 10
In-Sight Lenses, Lights and Covers 10
External Lights 16
Cables 18
Mounting Brackets 19
Power Supplies 19
Connectors and Indicators 20
Installation 21
Install the Lens, Lighting and Cover 21
Install the C-Mount Lens and Cover (COV-7000-CMNT or COV-7000-CMNT-EX) 21
Install the C-Mount Lens and Cover (COV-7000-CMNT-LG) 23
Install the C-Mount Lens and In-Sight Illumination 24
Install the Autofocus Module and In-Sight Illumination 29
Install the S-Mount/M12 Manual Focus Lens 35
Working Distance and Field of View (S-Mount/M12 Lenses) 37
Mount the Vision System 38
Install the Mounting Bracket (BKT-INS-01) 39
Connect the External Light Cable (Optional) 40
Connect the Ethernet Cable 41
Connect the Breakout Cable 42
Replace the SD Card (Optional) 43
Replace the LED Ring Light (Optional) 44
Replace the M12 Autofocus Lens (Optional) 49
Specifications 58
D902 Vision System Specifications 58
D905 Vision System Specifications 61
Acquisition Trigger Input 64
General-Purpose Inputs 65
High-Speed Outputs 66
High-Speed Output Wiring 67
External Light Connector 68
Ethernet Cable 69
Breakout Cable 70
Dimensions 71
6
Table of Contents

D902 Vision System 71
D905 Vision System 72
D900 Series Vision System with Cover (COV-7000-CMNT) 73
D900 Series Vision System with Cover (COV-7000-CMNT-EX) 74
D900 Series Vision System with Cover (COV-7000-CMNT-LG) 75
D900 Series Vision System with Cover (COV-7000-CMNT-LG) and Extender (COV-7000-CMNT-LGX) 76
D900 Series Vision System with Illumination (ISLM-7000-xxx) 77
Mounting Bracket (BKT-INS-01) 78
C-Mount Lens Clearance Dimensions 79
Cleaning/Maintenance 80
Clean the Housing 80
Clean the Image Sensor Window 80
Clean the Cover 80
Appendix 81
Mechanical Vignetting 81
Remove the Illumination Accessory PCB 82
7
Table of Contents

Symbols
The following symbols indicate safety precautions and supplemental information:
WARNING:This symbol indicates a hazard that could cause death, serious personal injury or electrical shock.
CAUTION:This symbol indicates a hazard that could result in property damage.
Note: This symbol indicates additional information about a subject.
Tip: This symbol indicates suggestions and shortcuts that might not otherwise be apparent.
8
Symbols

Introduction
The In-Sight®vision system is a compact, network-ready, stand-alone machine vision system used for automated
inspection, measurement, identification and robot guidance applications on the factory floor. All models can be easily
configured remotely over a network using an intuitive user interface.
Support
Many information resources are available to help you use the vision system:
lThe In-Sight®ViDi Help file.
lThe In-Sight®Vision Suite Help file.
Standard Components
Note:
lCables are sold separately.
lIf a standard component is missing or damaged, immediately contact your Cognex Authorized Service
Provider (ASP) or Cognex Technical Support.
Component Description
Vision System Provides image acquisition, vision processing, job storage, Ethernet connectivity and discrete I/O.
The vision system has an 8GB SD card pre-installed.
9
Introduction

Accessories
You can purchase the following components separately. For a list of options and accessories, contact your local Cognex
sales representative.
In-Sight Lenses, Lights and Covers
The following In-Sight lenses, lights and covers are supported with the vision system.
C-Mount Standard and Extended Covers
Note:
lWhen using a C-Mount lens, the following restrictions apply:
lMaximum thread length is 5.25mm.
lThe C-Mount lens threads and body cannot protrude more than 6.5mm in length into the vision
system when screwed in unless the diameter of the back lens is smaller than 14.75mm. If the C-
Mount lens threads and body protrude more than 6.5mm, you can add a spacer between the lens
and vision system. However, the spacer decreases the working distance.
lRefer to C-Mount Lens Clearance Dimensions on page79 for more information.
CAUTION:If installing a C-Mount cover, the illumination accessory (ISLM-7000-xxx) PCB should not be installed to
the vision system. Refer to Remove the Illumination Accessory PCB on page82 for steps to safely remove the PCB
and avoid damage to the vision system.
Accessory Part Number Accessory Image
Standard plastic C-Mount cover and lens cover adapter.
Note: If using the COV-7000-CMNT cover, the maximum lens
length is 41mm, the maximum lens body diameter is 36.5mm
and the maximum diameter including locking screws is 47mm.
COV-7000-CMNT
Standard extended plastic C-Mount cover and lens cover adapter.
Note: If using the COV-7000-CMNT-EX cover, the maximum
lens length is 62mm, the maximum lens body diameter is
36.5mm and the maximum diameter including locking screws
is 46.5mm.
COV-7000-CMNT-EX
Wide plastic C-Mount cover and lens cover adapter.
Note: If using the COV-7000-CMNT-LG cover, the maximum
lens length is 77mm, the maximum lens body diameter is
55mm and the maximum diameter including locking screws is
55mm.
COV-7000-CMNT-LG
Wide plastic 30mm C-Mount extender, compatible with the
COV-7000-CMNT-LG cover. COV-7000-CMNT-LGX
10
Introduction

Accessory Part Number Accessory Image
Metal C-Mount lens cover adapter. Compatible with the following
In-Sight 5000 series metal C-Mount lens covers:
lLNS-CVR-EXT01
lLNS-CVR-R-00
lLNS-CVR-UV-00
lLNS-CVR50-AL-2
Note: If using the ADPT-MTL-M55 lens cover adapter, the
maximum lens diameter including locking screws is 58.5mm.
ADPT-MTL-M55
11
Introduction

C-Mount Illumination Accessories
Note:
lThe vision system supports connecting an integrated illumination accessory to the vision system's faceplate
and connecting an external light to the vision system's LIGHT connector, but does not support using both
lighting devices simultaneously.
lWhen using a C-Mount lens, the following restrictions apply:
lMaximum thread length is 5.25mm.
lThe C-Mount lens threads and body cannot protrude more than 6.5mm in length into the vision
system when screwed in unless the diameter of the back lens is smaller than 14.75mm. If the C-
Mount lens threads and body protrude more than 6.5mm, you can add a spacer between the lens
and vision system. However, the spacer decreases the working distance.
CAUTION:The following C-Mount lenses are supported with vision systems with 2.3 mega-pixel resolution and
below, when using the illumination accessory (ISLM-7000-xxx). If using a different C-Mount lens with the
illumination accessory, it must be 29.5mm in diameter or smaller. Maximum lens length is 38.5mm without a
bandpass filter and 36mm with a bandpass filter. Larger lenses will irreparably damage the vision system.
Accessory Part Number Accessory Image
9mm F1.4 aperture lens LFC-9F1B
12.5mm F1.4 aperture lens LFC-12.5F
16mm F1.4 aperture lens LFC-16F1
25mm F1.4 aperture lens LFC-25F1
35mm F1.6 aperture lens LFC-35F1
50mm F1.4 aperture lens LFC-50F1
Illumination accessory with white LED ring light, cover and hex wrench ISLM-7000-WHI
Illumination accessory with cover and hex wrench. Does not include an
LED ring light.
ISLM-7000-00
Diffuse cover COV-7000-DF
Clear cover COV-7000-CLR
Polarized cover
Note: When installing the cover, pull the red tab to remove the
protective film.
COV-7000-PL-FULL
12
Introduction

Accessory Part Number Accessory Image
Red LEDring light ISL-7000-RD
IR LED ring light ISL-7000-IR
Blue LED ring light ISL-7000-BL
White LED ring light ISL-7000-WHI
Red bandpass filter used with the ISL-7000-RD LEDring light ISF-7000-RDBP605
IR bandpass filter used with the ISL-7000-IR LED ring light ISF-7000-IRBP815
Blue bandpass filter used with the ISL-7000-BL LED ring light ISF-7000-BLBP435
13
Introduction

S-Mount/M12 Autofocus Accessories
Note:
lThe vision system supports connecting an integrated illumination accessory to the vision system's faceplate
and connecting an external light to the vision system's LIGHT connector, but does not support using both
lighting devices simultaneously.
lFor the In-Sight D905, the vision system image circle is larger than the S-Mount/M12 lenses used in the
autofocus module (ISAF-7000-8mm)and the S-Mount/M12 adapter kit (ISLN-7000-SMNT), resulting in
mechanical vignetting in the image when using any S-Mount/M12 lens. Therefore, S-Mount/M12 lenses are
not recommended. For more information, see Mechanical Vignetting on page81.
Accessory Part Number Accessory Image
Autofocus module with 8mm S-Mount/M12 lens ISAF-7000-8mm
Lens removal tool with replacement lens nuts ISAF-7000-TOOL
6mm M12 lens LM12-06-01
8mm M12 lens LM12-08-01-F2.2
12mm M12 lens LM12-12-01-F2.3
16mm M12 lens LM12-16-01
25mm M12 lens LM12-25-01
Illumination accessory with white LED ring light, cover and hex wrench ISLM-7000-WHI
Illumination accessory with cover and hex wrench. Does not include an
LED ring light.
ISLM-7000-00
Diffuse cover COV-7000-DF
Clear cover COV-7000-CLR
Polarized cover
Note: When installing the cover, pull the red tab to remove the
protective film.
COV-7000-PL-FULL
14
Introduction

Accessory Part Number Accessory Image
Red LEDring light ISL-7000-RD
IR LED ring light ISL-7000-IR
Blue LED ring light ISL-7000-BL
White LED ring light ISL-7000-WHI
Red bandpass filter used with the ISL-7000-RD LEDring light ISF-7000-RDBP605
IR bandpass filter used with the ISL-7000-IR LED ring light ISF-7000-IRBP815
Blue bandpass filter used with the ISL-7000-BL LED ring light ISF-7000-BLBP435
S-Mount/M12 Manual Focus Accessories
Note:
lThe following S-Mount/M12 lenses are supported. If a different lens is used, the following restrictions apply:
lAt infinity focus, the back focal length must be greater than 5.5mm.
lClose up, the back focal length of the lens cannot be greater than 13mm.
lThe DataMan clear cover accessory (DM300-CLCOV) is supported with In-Sight S-Mount/M12 manual focus
lenses and provides an IP65 rating.
lFor the In-Sight D905, the vision system image circle is larger than the S-Mount/M12 lenses used in the
autofocus module (ISAF-7000-8mm)and the S-Mount/M12 adapter kit (ISLN-7000-SMNT), resulting in
mechanical vignetting in the image when using any S-Mount/M12 lens. Therefore, S-Mount/M12 lenses are
not recommended. For more information, see Mechanical Vignetting on page81.
Accessory Part Number Accessory Image
6mm M12 lens LM12-06-01
8mm M12 lens LM12-08-01-F2.2
12mm M12 lens LM12-12-01-F2.3
16mm M12 lens LM12-16-01
25mm M12 lens LM12-25-01
S-Mount/M12 adapter kit:
lS-Mount/M12 adapter
l13mm lens locking cone (P/N 1000000178)
l14mm lens locking cone (P/N 372-1270R)
lInstallation tool
Note: The S-Mount/M12 adapter kit (ISLN-7000-SMNT) is
required when installing In-Sight S-Mount/M12 manual focus
lenses.
ISLN-7000-SMNT
Clear cover DM300-CLCOV
15
Introduction

External Lights
External lights can be connected to the vision system's LIGHTconnector using the External Light cable.
Note:
lThe vision system supports connecting an integrated illumination accessory to the vision system's faceplate
and connecting an external light to the vision system's LIGHT connector, but does not support using both
lighting devices simultaneously.
lIf daisy-chaining multiple Cognex IVSL-YLW2X-xxx or IVSL-YLW300-xxx external lights:
lThe lights must be powered externally by a separate power supply.
lA Cognex control cable (CCB-FOV25-MAL-012) can be used to connect the vision system’s LIGHT
connector to the external light and a Cognex power cable (IVSL-5PM12-5) can be used to connect
the light to the separate power supply. Only the power and ground wires from the Cognex power
cable (IVSL-5PM12-5) should be connected to the remote power supply.
lIf using a Cognex IVSL-LX520-xxx external light:
lThe lights must be powered externally by a separate power supply.
lA Cognex control cable (CCB-FOV25-MAL-012) can be used to connect the vision system’s LIGHT
connector to the external light and a Cognex power cable (IVSL-5PM12-5) can be used to connect
the light to the separate power supply. Only the power and ground wires from the Cognex power
cable (IVSL-5PM12-5) should be connected to the remote power supply.
lThe following cables must not be used with IVSL-LX520-xxx external lights: IVSL-5PM12-J300,
IVSL-5PM12-J500 and IVS-5PM12-J1000, IVSL-5PM12-J2000.
lThe vision system supports Cognex IVSL-YL300-xx external lights with the following External Light cables:
IVSL-M12-NSB-300, IVSL-M12-NSB-1000 and IVSL-M12-NSB-2000.
Accessory Part Number Supported External Light Cables Accessory Image
Brick light, narrow blue IVSL-ODDM-S75-470 IVSL-5PM12-J300
IVSL-5PM12-J500
IVSL-5PM12-J1000
IVSL-5PM12-J2000
Brick light, narrow red IVSL-ODDM-S75-625 IVSL-5PM12-J300
IVSL-5PM12-J500
IVSL-5PM12-J1000
IVSL-5PM12-J2000
16
Introduction

Accessory Part Number Supported External Light Cables Accessory Image
Bar light, wide red IVSL-YLW2X-625 IVSL-5PM12-J300
IVSL-5PM12-J500
IVSL-5PM12-J1000
IVSL-5PM12-J2000
Bar light, narrow red, linear
polarizer
IVSL-YLW2X-625P IVSL-5PM12-J300
IVSL-5PM12-J500
IVSL-5PM12-J1000
IVSL-5PM12-J2000
Bar light, narrow infrared IVSL-YLW2X-850 IVSL-5PM12-J300
IVSL-5PM12-J500
IVSL-5PM12-J1000
IVSL-5PM12-J2000
Bar light, narrow blue IVSL-YLW300-470 IVSL-5PM12-J300
IVSL-5PM12-J500
IVSL-5PM12-J1000
IVSL-5PM12-J2000
Bar light, wide blue IVSL-YLW300-470 W IVSL-5PM12-J300
IVSL-5PM12-J500
IVSL-5PM12-J1000
IVSL-5PM12-J2000
Bar light, narrow red IVSL-YLW300-625 IVSL-5PM12-J300
IVSL-5PM12-J500
IVSL-5PM12-J1000
IVSL-5PM12-J2000
Bar light, wide red IVSL-YLW300-625 W IVSL-5PM12-J300
IVSL-5PM12-J500
IVSL-5PM12-J1000
IVSL-5PM12-J2000
Bar light, narrow white IVSL-YLW300-WHI IVSL-5PM12-J300
IVSL-5PM12-J500
IVSL-5PM12-J1000
IVSL-5PM12-J2000
Bar light, wide white IVSL-YLW300-WHI W IVSL-5PM12-J300
IVSL-5PM12-J500
IVSL-5PM12-J1000
IVSL-5PM12-J2000
Bar light, blue IVSL-LX520-470 CCB-FOV25-MAL-012 for intensity and
strobe control.
IVSL-5PM12-5 for power.
Bar light, red IVSL-LX520-625 CCB-FOV25-MAL-012 for intensity and
strobe control.
IVSL-5PM12-5 for power.
17
Introduction

Cables
Note:
lIf using an integrated or external illumination accessory, the 10 meter and 15 meter Breakout cables are not
supported.
lWhen using the 15 meter Breakout cable, full 24VDC voltage must be maintained at the input leads of the
Breakout cable when the vision system is operating.
Accessory Part Number Accessory Image
External Light Cable, Yellow
Note: This cable supports intensity control.
IVSL-5PM12-J300
IVSL-5PM12-J500
IVSL-5PM12-J1000
IVSL-5PM12-J2000
External Light Cable, Black
Note:
lThis cable supports intensity control.
lThis cable is used with standard
SVL lights.
IVSL-M12-NSB-300
IVSL-M12-NSB-1000
IVSL-M12-NSB-2000
External Light Cable, Grey
Note: This cable does not support intensity
control.
CCB-M12LTF-xx (xx specifies length: 0.5m,
1m, 2m, 5m)
Ethernet Cable, X-coded M12-8 to RJ-45 CCB-84901-2001-xx (straight, xx specifies
length: 2m, 5m, 10m, 15m, 30m)
Ethernet Cable, X-coded M12-8 to RJ-45 CCB-84901-2002-xx (right-angled, xx specifies
length: 2m, 5m, 10m)
Ethernet Cable, Robotic X-Coded M12-8 to RJ-
45
CCB-84901-2RBT-xx (straight, xx specifies
length: 2m, 5m, 10m)
Breakout Cable, M12-12 to Flying Lead CCB-PWRIO- xx (straight, xx specifies length:
5m, 10m, 15m)
Breakout Cable, M12-12 to Flying Lead CCB-PWRIO-xxR (right-angled, xx specifies
length: 5m, 10m, 15m)
18
Introduction

Mounting Brackets
Accessory PartNumber Accessory
Mounting bracket with M3, M4 and 1/4 - 20 mounting holes. Mounting screws are not
included. The mounting bracket is supported with In-Sight 5000 series, In-Sight 7000
Gen2 series, In-Sight 9000 series and In-Sight D900 series vision systems.
BKT-INS-01
Power Supplies
Accessory Part Number Accessory Image
DIN rail power supply that converts AC mains power to 24VDC. ACC-Quint-PS
19
Introduction

Connectors and Indicators
Connector Function
PWR
Connector
Connects the Breakout cable, which provides connections to an external power supply, the acquisition
trigger input, general-purpose inputs and high-speed outputs. For more information, refer to Breakout
Cable on page70.
LIGHT
Connector
Connects the vision system to an external lighting device. For more information, refer to External Light
Connector on page68.
ENET
Connector
Connects the Ethernet cable, which provides 10/100/1000 Ethernet connectivity. For more information,
refer to Ethernet Cable on page69.
Indicator Function
Focus Metric LEDs Not supported.
TRIG Button Not supported.
Power LED The green LED illuminates to indicate that the vision system is powered on.
SD Card Status LED lOff: The SDcard is not inserted.
lGreen: The SD card is present, and it is safe to remove the SD card after
removing power from the vision system.
lYellow: The SD card is present, but it is not safe to remove it.
Pass/Fail LED and
Indicator Ring
Green or red when active. User configurable.
Network LED The yellow LED flashes to indicate network activity.
Error LED Red when active. User configurable.
TUNE Button Not supported.
20
Introduction
