CAM-LR1-AD
Rear View Camera Input and Video In Motion
Application:
Land Rover Range Rover Vogue (L322) 2010 - 2012,
Range Rover Sport (L320) 2004 - 2013,
Discovery (L319) 2010 - 2011
For Touch Screen Navigation Version 2.0 Head Units

www.connects2.comwww.connects2.com
2
ABOUT THIS PRODUCT...
CAM-LR1-AD
Reverse Camera Add On Interface with Video In Motion. For Land Rover 2010 -
2011 vehicles with touch screen navigation systems. Add on Camera interface
designed to allow the addition of an aftermarket reverse camera to the OEM
screen - compatible with NTSC cameras only.
Prior to Installation
Read the manual prior to installation. Technical knowledge is necessary for installa-
tion. The place of installation must be free of moisture and away from heat sources.
Please ensure you use the correct tools to avoid damage to the vehicle or product.
Connects2 can not be held responsible for the installation of this product.
Technical Support
Connects2 want to provide a fast and suitable resolution should you encounter any
technical issues. With this in mind, when contacting Connects2, try to provide as
much Information as possible. This will speed up the process and help us to help you.
Please use our dedicated online technical support centre: support.connects2.com
Subscribe to our YouTube Channel for installation
guides and tips... www.youtube.com/connects2

www.connects2.comwww.connects2.com
3
PIN-ASSIGNMENTS
Dipswitch Settings
Vehicle/ navigation Dip 1 Dip 2 Dip 3 Dip 4 Dip 5 Dip 6
Video-in-motion permanent ON ON OFF OFF ON ON
Video-in-motion selective* OFF ON OFF OFF ON ON
* With Dip1 set to “OFF”, the included green cable can be used to activate the
video in motion function
Interface Dipswitch Functionality:
Dip 1 – Activation of Video in Motion
Dip 2 – Existing Rear View Camera
Dip 3 – TV icon simulation
Dip 4 – No function
Dip 5 – Termination resistor CAN-Bus
Dip 6 – Termination resistor CAN-Bus
Setting Dip2 to “ON” codes the factory rear-view camera input, located on
the brown Fakra male connector of the factory monitor. When reverse gear is
engaged, the navigation will automatically switch to this input.
Pin Conguration
Range Rover Vogue
Cable Colour Assignment
Yellow/White CAN-HIGH Pin 9
Yellow/Blue CAN-LOW Pin 10
Range Rover Sport/Discovery
Cable Colour Assignment
Yellow/White CAN-HIGH
Yellow CAN-LOW

www.connects2.comwww.connects2.com
4
PIN-ASSIGNMENTS
Interface Pin Conguration
Cable Colour Pin-No. Assignment
Yellow Pin 4 CAN-HIGH – connection to the head-unit
Blue Pin 3 CAN-LOW – connection to the head-unit
Yellow/Black Pin 8 CAN-HIGH – connection to the vehicle
Blue/Black Pin 7 CAN-LOW – connection to the vehicle
Red Pin 1 +12V Permanent
Black Pin 5 Ground
Green Pin 6 Activation of the video-in-motion function
(+12V = TV-free activated)
White Pin 2 Trigger output (+12V DC 500mA)
Monitor Connection Pin Conguration
Pin 2: Video-signal rear-view camera
Pin 5: Video-signal ground rear-view camera

www.connects2.comwww.connects2.com
5
CONNECTION DIAGRAM/INSTALLATION
Installation
NB: Before installation, switch off ignition, disconnect the vehicle battery and
remove the vehicle’s head unit.
The installaton location is on rear of the radio module and behind the factory
navigation monitor. In Range Rover Vogue vehicles, the radio module is a hide-
away box, located behind the glove box. In Range Rover Sport and
Discovery 4 vehicles, the radio module is located behind the factory
navigation monitor.
Supplied
Adapter
Interface
Supplied
Harness

www.connects2.comwww.connects2.com
6
INSTALLATION
Connecting Interface, Harness amd Radio Module
1. Connect the female 8pin Molex connector of the harness to the male 8pin
Molex connector of the interface.
2. Transfer the female system-connector of vehicle harness from the rear of the
radio module into the male system-connector of the supplied harness
3. Plug the female system-connector of the supplied harness into the male
socket on the rear of the radio module.
Connecting to Rear-View Camera
Interface
Harness
Supplied
Adapter
Female 6pin
connector

www.connects2.comwww.connects2.com
7
1. Pin the coloured video-signal (black video-signal ground) into pin 2 (pin 5) of
the female grey-red 6pin connector.
2. Connect the female grey-red 6pin connector to the 6pin male port of the
monitor.
3. Connect the video RCA of the rear-view camera to the female RCA con-
nector of supplied adapter
Note: Only compatible with NTSC cameras.
If the factory Adventure-camera is installed, there is already a female grey-
red 6pin connector on the factory vehicle harness which is connected to the
male 6pin port on the backside of the factory monitor. In this case, pin the two
bare contacts into the female grey-red 6pin connector of the vehicle harness
instead of the supplied one.
Activating Video in Motion
The video-in-motion can be activated and deactivated by Dip 1 or alternative-
ly by the included loose green cable in connection with a switch (not included
in delivery).
Video-in-motion permanent
With Dip1 set to “ON”, the video-in-motion function is permanently activated
Video-in-motion selective
With Dip1 set to “OFF”, the included green cable is used to activate the vid-
eo-in-motion function.
Connect a switch to the green cable and connect the green cable to +12V
ACC.
● +12V = Video in Motion is activated
● 0V = Video in Motion is not activated
Note: The loose white cable is not required and must be isolated.
INSTALLATION

www.connects2.com
8
