Connects2 CT23SK05 User manual

Compatible with these Double-DIN devices:
Double-DIN Navigation
Installation Manual
Double DIN Kit
colour: piano black
part-no.: CT23SK05
• Skoda Octavia 2013->
110
4
6
8
2
9
3
9
8
7
5
10
Double DIN Set contents
• (1) Facia Plate
• (2) Mounting bracket right
• (3) Mounting bracket left
• (4) Housing right
• (5) Housing left
• (6) Cover right
• (7) Cover left
• (8) Self tapping screw with collar
• (9) Flat headed screw
• (10) Magnet D=5 t=3

3. Unplug all connectors of
OEM head unit
Remove OEM head unit
~29
pre-assembly Unit and Brackets
Unit front surface
(1 : 2)
Installation Manual Double DIN Kit
All installation work must be performed by a qualied professional installer only.
The manufacturer / dealer is not liable for any kind of incidential or indirect damages.
1. Insert radio release keys
into appropriate openings
of OEM head unit
(see arrows)
2. Pull out OEM head unit
carefully in order to
unplug connectors
4. Octavia dashboard
with head unit removed
6. Connect all required circuit
points.
Place Double-DIN head unit
on dashboard
5. Mount brackets
to Double-DIN head unit
as shown in the drawing
7. Place facia plate
