Connects2 Vision CAM-FT6 User manual

Connects2Vision
- Resolution 720 x 480 (Wide Angle View)
- Picture Mode NTSC
- CMOS Chipset: 1/3”
- Lens FOV: 210 Degrees (H) x 140 Degrees (V)
- Viewing Angles: Birds-Eye, Wide Angle, Reversing Left/Right Blind Spot, Driving
- Waterproof Rating: IP67
- Parking Guidelines Yes (Removable/Dynamic)
User Manual
Prior to Installation
Read the manual prior to installation. Technical knowledge is necessary for installation. Please ensure you use
the correct tools to avoid damage to the vehicle or product.
Connects2 can not be held responsible for the installation of this product.
Technical Support
Connects2 want to provide a fast and suitable resolution should you encounter any technical issues. With this in
mind, when contacting Connects2, try to provide as much Information as possible. This will speed up the process
and help us to help you.
Please use our dedicated online technical support centre: support.connects2.com
2-in-1 Reversing Camera/Brake Light Solution
with Wireless Controller
Fiat Ducato (X250) 2006 - 2014, (X290) 2014-UP
PRODUCT FEATURES:
CAM-FT6
V1-10-19

www.connects2.com
2
Connects2Vision
Extension Cable
Power Adapter
Cable
M
Camera replaces OEM brake light
ake Connections to Vehicle/Unit or Screen
Control Unit
Wireless Controller (Mount on dashboard)
Control Unit
Extension Cable
Power Adapter
Cable
Vehicle Connection Overview
Wiring Diagram
INSTALLATION
1
1
2
3
4
5
Red Acc 12V Connect to vehicle 12V Accessory feed
2 Black Ground Connect to ground
3 Purple Reverse Connect to reverse light
5 Green Reverse Trigger OUTPUT
4 Blue CAN + Connect to rear of OBD connector (see diagram on Page 3)
White CAN - Connect to rear of OBD connector (see diagram on Page 3)
Connecting CAN-Bus Wiring
Connect the CAN + (blue) and CAN - (white) wires to
the OBD plug or other position.
IMPORTANT: Other vehicles CAN positions may vary.
FRONT OF OBD CONNECTOR
12345678
10111213141516 9
OBD position can be
found on the pin 1 & 9.
Connect to the wire
side of the plug
Fiat Ducato Peugeot Boxer Citroen Relay

www.connects2.com 3
Connects2VisionUSING THE WIRELESS CONTROLLER
The wireless controller included in the kit can be used to change the viewing mode of the camera, as
well as adjust key parameters for each viewing mode.
The currently selected viewing mode is displayed by the icon in the centre of the HUD menu. This will
Note: The HUD menu will time-out after 3 seconds to allow an uninhibited view of the camera image.
Press the A button on Remote Control to bring the HUD menu back onto the screen.
To bring up the HUD menu, put the vehicle into reverse gear and press A on Remote Control.
default to Driving/Rear-View mode, or to Reversing mode when in reverse gear.
T
through the Reversing, Wide Angle and Birds-Eye viewing Modes.
o change the camera mode, whilst the vehicle is in reverse gear, press B or C on Remote Control to cycle
Start-Up
HUD Display ScreenRemote Control
Viewing Modes
Reversing (Select from HUD Menu) Driving/Rear-View (Default view when not in reverse)
Currently
Selected View
Go to Settings
A
Switch to
Birds-eye
C
Switch to
Wide Angle B
Go to Settings
A
Adjust
Parameter
Adjust
Parameter
C
B
Wide Angle (Select from HUD Menu) Right Blind Spot (Triggered by Indicator - See Page 4)

www.connects2.com
4
Connects2Vision
Adjusting Settings
To adjust settings for all viewing modes, press A on Remote Control to enter the settings menu.
Once in the settings menu, short press A on Remote Control to cycle through the various settings
screens available. Screens include camera angle and position for each mode, and guideline width
for parking lines.
Once in a settings screen, the selected setting is indicated by the icon in the centre of the display.
The parameters can be adjusted with B and C buttons on Remote Control.
To return to the previous screen, Press and hold A on Remote Control.
Activating/Deactivating Blind Spot View (BSV) Mode
When in any of the settings screens, a long press of B on Remote Control will activate or deactivate BSV
(Blind Spot View).
When active, this will trigger the blind spot camera image when an indicator is activated and the vehicle
is moving at a speed of over 40km/h.
When inactive, using the indicators will not trigger the blind spot view and the camera will remain in
Driving/Rear-View mode.
Note: this function will only work if the CAN-Bus wiring is connected.
Birds-Eye (Select from HUD Menu) Left Blind Spot (Triggered by Indicator - See Page 4)
Remote Control
A
Move to next
setting (Short Press)
Return to previous
(Long Press)
Adjust
Parameter
C
Adjust paramater
(Short Press)
Activate/
Deactivate BSV
(Long Press)
BAdjust paramater
(Short Press)
Activate/
Deactivate BSV
(Long Press)
Currently
Selected
Setting
Move to next
setting (Short Press)
Return to previous
(Long Press)
Adjust
Parameter
HUD Display Screen
BC
A
