Instruction Manual Model 3116-192
Block Downconverter
December 2, 2021 Rev. A
MENU
EXECUTE
MODEL 3116
CROSS TECHNOLOGIES INC.
IN LO FREQ REF.
3 9790.4 EXT
POWER
REMOTE
ALARM
DOWNCONVERTER
19.2-20.2 GHZ
G=+10.0 Ref AUTO-I
Data, drawings, and other material contained herein are proprietary to Cross Technologies, Inc.,
but may be reproduced or duplicated without the prior permission of Cross Technologies, Inc.
for purposes of operating the equipment.
When ordering parts from Cross Technologies, Inc., be sure to include the equipment
model number, equipment serial number, and a description of the part.
CROSS TECHNOLOGIES, INC.
6170 Shiloh Road
Alpharetta, Georgia 30005
[phone]
FAX [phone]
Toll Free 888-900-5588
WEB www.crosstechnologies.com
E-MAIL [email protected]

INSTRUCTION MANUAL
MODEL 3116-192 Block Downconverter
TABLE OF CONTENTS PAGE
Warranty 2
1.0 General 3
1.1 Equipment Description 3
1.2 Technical Characteristics 4
1.3 Monitor & Control Interface 6
2.0 Installation 9
2.1 Mechanical 9
2.2 Rear Inputs and Outputs 10
2.3 Front Panel Indicators 10
2.4 Installation/Operation 11
2.5 Menu Settings 12
3.0 Environmental Use Information 17
WARRANTY - The following warranty applies to all Cross Technologies, Inc. products.
All Cross Technologies, Inc. products are warranted against defective materials and
workmanship for a period of one year after shipment to customer. Cross Technologies,
Inc.’s obligation under this warranty is limited to repairing or, at Cross Technologies, Inc.’s
option, replacing parts, subassemblies, or entire assemblies. Cross Technologies, Inc. shall
not be liable for any special, indirect, or consequential damages. This warranty does not
cover parts or equipment which have been subject to misuse, negligence, or accident by the
customer during use. All shipping costs for warranty repairs will be prepaid by the
customer. There are not other warranties, express or implied, except as stated herein.
CROSS TECHNOLOGIES, INC.
6170 Shiloh Road
Alpharetta, Georgia 30005
[phone]
FAX [phone]
Toll Free 888-900-5588
WEB www.crosstechnologies.com
E-MAIL [email protected]
3116-192 Manual Page 2 12/02/21

MODEL 3116-192 Block Downconverter
1.0 General
1.1 Equipment Description
The 3116-192 Block Downconverter converts 19.2 - 20.2 GHz to 0.95 - 1.95 GHz with low phase noise and flat
frequency response. Frequency translation is via a 18.25 GHz local oscillator. The gain is +35 ± 2 dB
maximum and is adjustable in 0.5 ± 0.5 dB steps. Front panel LEDs provide indication of Remote operation,
PLL Alarm and DC Power. Gain and internal/external/Auto reference frequency selection are controlled by
front panel switches or remote selection (via RS 232C, standard; Ethernet Optional) and are viewable on the
LCD Display. Connectors are Super SMA female for the RF and BNC female for the L-Band and external
reference input and reference output. In AUTO, the 10 MHz reference stays in external if the external level is
+3 dBm, ±3 dB. The 3116 is powered by a 100-240 ± 10% VAC power supply, and housed in a 1 3/4” X 19 “
X 12” rack mount chassis.
MENU
EXECUTE
MODEL 3116
CROSS TECHNOLOGIES INC.
IN LO FREQ REF.
3 9790.4 EXT
POWER
REMOTE
ALARM
DOWNCONVERTER
19.2-20.2 GHZ
G=+10.0 Ref AUTO-I
FRONT PANEL (Shown with optional Etherent)
AC
RF INPUT
GND
J101
J8
10 MHZ REF
OUTPUT
J11
ALARM
1
5
2
3
4
6
7
8
9
J2
EXT 10 MHZ
INPUT
L-BAND
OUTPUT
J1
J14
REAR PANEL (Shown with optional Etherent)
FIGURE 1.1 Front and Rear Panels
0.95 -
1.95
GHz
OUT
19.2
to
20.2
GHz
IN
1.95 GHz LP
CONTROLLER
G=+10.0 Ref AUTO
19.2-20.2 GHz BP
18.25
GHz
EXT
10MHz
var
atten
INT
10MHz
3116-192 Block Diagram
AUTO
FIGURE 1.2 Block Diagram
3116-192 Manual Page 3 12/02/21

1.2 Technical Characteristics
Available Options continued on page 5...
3116-192 Manual Page 4 12/02/21
±1.5 dB, 0.95 - 1.95 GHz out; ± 0.5 dB, 40 MHz BW
Frequency Response
Channel Characteristics
LO Characteristics
± 0.01 ppm maximum over temp internal reference; external reference input
Frequency Accuracy
Non-inverting
Frequency Sense
<-50 dBC for two carriers spaced 4 MHz, at FC +-2MHz each at -10 dBm out
Intermodulation
<-50 dBm, 0.5-0.94 GHz and 1.96- 3.0 GHz, at max. gain
Spurious, Out of Band
SIGNAL RELATED<-55 dBC in band, 0 dBm out; SIGNAL INDEPENDENT,<-60 dBm
Spurious, Inband
3 dBm, ± 3 dB, with Auto-detect
10 MHz Level
18.25 GHz, fixed LO
LO Frequency
> 60 dB, minimum
Image Rejection
+35 dB ±2 dB, max. gain; +5 to +35 dB adjustment range in 0.5 ± 0.5 dB Steps at Fc
Gain, max adgustment
Other
100-240 ±10% VAC, 47-63 Hz, 30 watts maximum
Power
19 inch, Standard Chassis 1.75” high X 12.0” deep
Size
DB9 - NO or NC Contact Closure on Alarm
Alarm / Remote Connector
BNC (female), 75ΩConnector; Works with 50Ωor 75Ω
10 MHz Connectors
Super SMA (female), 50Ω/ BNC (female), 50Ω
RF/L-Band Connector
-110
-95
-80
-75
-70
1M
100k
10k
1k
100
dBC/Hz
Phase Noise @ F (Hz) >
Yellow LED, Indicates External 10 MHz Reference Selected
Power; Alarm; Remote; Mute
Controls, Indicators
direct readout LCD; pushbutton switches or remote
Freq.,Gain, Ext Ref Sel.
RS232C/RS485/422, 9600 baud (Ethernet Optional)
Remote
TABLE 1.1 3116-192 Block Downconverter Specifications*
-55 to -35 dBm
Input Level Range
12 dB maximum gain
Noise Figure, Maximum
-25 dBm
Input 1dB Compression
19.2 to 20.2 GHz
Frequency
+10 dBm at maximum gain
Output 1 dB Compression
-20 to 0 dBm
Output Level Range
Output Characteristics (designated L-Band)
Input Characteristics (RF)
0.95 to 1.95 GHz
Frequency
50Ω/ 14 dB
Impedance / Return Loss
50Ω/ 14 dB
Impedance / Return Loss

Available Options
Extended Temperature Option
- 0˚C to 50˚C
W31
Connector Options
50ΩSuper SMA (RF), 50ΩSMA (L-Band)
- 26S
50ΩSuper SMA (RF), 50ΩN-Type (L-Band)
- 26N
50ΩSuper SMA (RF), 75ΩBNC (L-Band)
- 267
*+10 to +40 degrees C; Specifications subject to change without notice. © 2021 Cross Technologies, Inc.
3116-192 Manual Page 5 12/02/21
Ethernet w/direct TCP/IP Interface
W28
Remote M&C Ethernet Options
W8 + W18 + W28
W828
Ethernet w/SNMP (and MIB) Interface
W18
Ethernet w/web browser Interface
W8

1.3 Monitor and Control Interface
A) Remote Serial Interface
Protocol: RS-232C, 9600 baud rate, no parity, 8 data bits, 1 start bit, and 1 stop bit.
(RS-232C, RS-422, or RS-485)
Female DB-9
PC Com Port
Male DB-9
2
1
3
4
5
6
7
8
9
2
1
3
4
5
6
7
8
9
M&C Cable Diagram - Cross Technologies Frequency Converters and
Frequency Sources
Connector: Rear panel, DB-9 male
J11 Pinouts (RS-232C/422/485)
J11 Pinouts (RS-232C/422/485)
Pin Function
1 Rx-
2 Rx+ (RS-232C)
3 Tx+ (RS-232C)
4Tx-
5GND
6 Alarm Relay: Common
7 Alarm Relay: Normally Open
8 Not Used
9 Alarm Relay: Normally Closed
3116-192 Manual Page 6 12/02/21

B) Status Requests - Table 1.1 lists the status requests for the 3116-192 and briefly describes them.
* PLEASE NOTE: The two character {aa}(00-31) prefix, in the table below,
should be used ONLY when RS-485 is selected.
TABLE 1.1 3116-192 Downconverter Status Requests
TABLE 1.1 3116-192 Downconverter Status Requests
TABLE 1.1 3116-192 Downconverter Status Requests
Command Syntax *Description
Get Gain {aaSG} returns {aaSGxxx} where:
• xxx = Converter gain in 0.5 ±0.5 dB steps.
Get Internal 10 MHz Reference Offset {aaSO} Returns {aaSOxxxxx} where:
• xxxxxx = Internal 10 MHz reference frequency offset.
Get 10 MHz Reference Mode {aaSE} Returns {aaSEx} where:
• x = 0 if the converter's 10 MHz reference mode is set to Internal
• x = 1 if the converter's 10 MHz reference mode is set to External
• x = 2 if the converter's 10 MHz reference mode is set to Auto
Get Mute {aaSM} Returns {aaSMx} where:
• x = 0 if the converter's RF output is NOT muted (RF output is ON)
• x = 1 if the converter's RF output is muted (RF output is OFF)
Get 10 MHz Reference Status {aaSB} Returns {aaSBx} where:
• x = 0 if the currently selected 10 MHz reference is Internal
• x = 1 if the currently selected 10 MHz reference is External
Get Summary Alarm Status {aaSA} Returns {aaSAx}where:
• x = 0 when there is no summary alarm condition
• x = 1 if there is a summary alarm condition
Get IP Address {Si} Returns {Sixxx.xxx.xxx.xxx} where:
Ethernet Option Only • xxx.xxx.xxx.xxx = IP address
Get Subnet Mask {Ss} Returns {Ssxxx.xxx.xxx.xxx} where:
Ethernet Option Only • xxx.xxx.xxx.xxx = subnet mask
!Get Product/Model info!! {Sv} Returns {Sv3116-192y..yverZZZZ} where:
• 3116-xx is the product model number
• y..y = list of options, if any
• '"ver" = separates model & options from firmware version
• ZZZZ = firmware version (e.g., 1.00)
3116-192 Manual Page 7 12/02/21

C) Commands
Table 1.2 lists the commands for the 3116 and briefly describes them.
After a command is sent the 3116 sends a return “>” indicating the command has been received and executed.
General Command Format - The general command format is {CND...}, where:
{ = start byte
C = 1 character, either C (command) or S (status)
N = 1 character command or status request
D = 1 character or more of data (depends on command)
} = stop byte
*PLEASE NOTE: The two character {aa}(00-31) prefix, in the table below,
should be used ONLY when RS-485 is selected.
TABLE 1.2 3116-192 Downconverter Commands
TABLE 1.2 3116-192 Downconverter Commands
TABLE 1.2 3116-192 Downconverter Commands
Command Syntax *Description
Set Gain {aaCGxxx} where:
• xxx = Converter gain in 0.5 ±0.5 dB steps.
Range: 050 to 350 where 050 = 5.0 dB and 350 = 35.0 db
Example: {CG155} sets the converter's gain to +15.5dB
Set Internal 10 MHz Reference Offset {aaCOxxxxx} where:
• xxxxxx = Internal 10 MHz reference frequency offset.
Range: -2000 to +2000
Set 10 MHz Reference Mode {aaCEx} where:
• x = 0 to set the reference mode to Internal
• x = 1 to set the reference mode to External
• x = 2 to set the reference mode to Auto
Set Mute {aaCMx} where:
• x = 0 to NOT mute the RF output (RF output is ON)
• x = 1 to mute the RF output (RF output is OFF)
3116-192 Manual Page 8 12/02/21

2.0 Installation
2.1 Mechanical - The 3116-192 consists of one RF PCB housed in a 1 RU (1 3/4 inch high) by 12 inch deep
chassis. A switching, ± 12, +24, +5 VDC power supply provides power for the assemblies.
The 3116-192 can be secured to a rack using the 4 holes on the front panel.
Figure 2.0 shows how the 3116-192 is assembled.
1
PS IN
PIN 1, +12 VDC
PIN 2, +5 VDC
PIN 3, +5 VDC
PIN 4, GROUND
PIN 5, GROUND
PIN 6, -12 VDC
PIN 7, +24 VDC
PIN 8, +24 VDC
POWER
SUPPLY
J10
J101 - Panel Mount
Super SMA Connector
FIGURE 2.0 3116-192 Mechanical Assembly
3116-192 Manual Page 9 12/02/21

2.2 Rear Panel Input/Output Signals
Figure 2.1 shows the input and output connectors on the rear panel.
J101- INPUT
19.2 - 20.2 GHz
-55 to -35 dBm
Super SMA Female
Connector.
See Table 2.2
AC1 - POWER IN
AC input for switching power supply.
100-240 ±10% VAC, 47-63 Hz.
J1 - RF OUTPUT
0.95 - 1.95 GHz,
-20 to 0 dBm
BNC Female Connector
See Table 2.2
J11 - ALARM
DB9 female connector.
See Table 2.1.
J8 - 10 MHz EXT REF OUTPUT
+3 ±3 dBm with Auto-detect
BNC Female Connector.
AC
GND
J2 - 10 MHz EXT REF INPUT
+3 ±3 dBm with Auto-detect
BNC Female Connector..
RF INPUT
J101
J8
10 MHZ REF
OUTPUT
J11
ALARM
1
5
2
3
4
6
7
8
9
J2
EXT 10 MHZ
INPUT
RF
OUTPUT
J1
J14
J14 - Ethernet Connector
RJ45 Ethernet connector.
INT
FIGURE 2.1 3116-192 Rear Panel I/Oʼs
TABLE 2.1 J11 Pinouts*
TABLE 2.1 J11 Pinouts*
Pin Function
1 Rx-
2 Rx+ (RS-232C)
3 Tx+ (RS-232C)
4Tx-
5GND
6 Alarm Relay: Common
7 Alarm Relay: Normally Open
8 Not Used
9 Alarm Relay: Normally Closed
50ΩSuperSMA (RF), 50ΩSMA (L-BAND)
26S -
50ΩSuperSMA (RF), 50ΩN-type (L-BAND)
26N -
Contact Cross for other options
Table 2.2 Available Connector Options
50ΩSuperSMA (RF), 75ΩBNC (L-BAND)
267 -
*Remote Serial Interface
Interface: DB-9 Male Protocol: RS-232C (RS-232C/422/485, selectable),
9600 baud rate, no parity, 8 data bits, 1 start bit, 1 stop bit.
2.3 Front Panel Indicators
The following are the front panel indicators.
MENU
EXECUTE
19.2 - 20.2 GHZ
G = +10.0 Ref AUTO-I
POWER
ALARM
S3 - MENU/EXECUTE BUTTON
Press this to get into Program mode
and to execute any changes.
DS6 - ALARM LED
Red LED indicates an
alarm condition.
S2 - VERT. TOGGLE
Vertical toggle switch that controls
values in the Menu items when in
program mode. Does not function in
the normal display mode.
S1 - HORIZ. TOGGLE
Horizontal toggle switch that
controls which values are being
adjusted. Does not function in the
normal display mode.
REMOTE
DS2 - POWER LED
Green LED indicates
presence of DC power
from power supply.
DS3 - REMOTE LED
Yellow LED indicates
remote operation.
LCD DISPLAY
Display shows current
mode and output level
in dBm or gain in dB.
FIGURE 2.2 3116-192 Front Panel Controls and Indicators
3116-192 Manual Page 10 12/02/21

2.4 Installation / Operation
2.4.1 Installing and Operating the 3116-192
1. Connect a -55 dBm to -35 dBm signal to RF IN, J101 (Figure 2.1).
2. Connect the RF OUT, J1, to the external equipment.
3. Connect 100-240 ±10% VAC, 47 - 63 Hz to AC connector on the back panel.
4. Set the gain +35 dB maximum, adjustable in 0.5 ±0.5 dB steps
5. Make sure the output stays within -20 to 0 dBm with the gain.
selected and the input level provided. (See Section 2.5 Menu Settings).
6. Be sure DS2 (green, DC Power) is on and DS6 (red, Alarm) is off (Figure 2.2).
7. AC Fuse - The fuse is a 5 mm X 20 mm, 2 amp slow blow (Type T) and is inserted in the far slot
in the drawer below the AC input as shown in Figure 2.3. There is a spare fuse in the near slot.
If a fuse continues to open, the power supply is most likely defective.
AC Fuse - 2 amp slow blow (Type T),
5 mm X 20 mm
FUSE DRAWER
SPARE FUSE
~
INPUT
100-240± 10%VAC
47-63 Hz
2A MAX
FUSE
TYPE T 2A GDC
250 VOLT
FOR 100 - 240 V~
~
FIGURE 2.3 Fuse Location and Spare Fuse
3116-192 Manual Page 11 12/02/21

2.5 Menu Settings
2.5.1 Functions
This section describes operation of the front panel controls. There are three operator switches, the LCD display
and alarm indicator LEDs. All functions for the equipment are controlled by these components.
The functions are (See Figure 2.4):
Power Up
Normal Display
Menu 1 Set Gain
Menu 2 Set Mute
Menu 3 Set Reference Mode
Menu 4 Set Reference Offset
Menu 5 Set Remote
Menu 6 Set Remote Interface
Menu 4 Set RS-485 Address
Save Menu When “R” is selected from any above menu or at the end.
Alarm indications appear on the LEDs (see Figure 2.2).
All program changes must start with the operation of the Menu/Execute switch and must also end with the
operation of the Menu/Execute switch verified by the “Save Settings?” Menu. If this sequence is not followed,
none of the changes will take effect. If programming is initiated and no operator action takes place for
approximately 30 seconds (before the final press of the Menu/Execute switch) the display will revert to its
previous status and you will need to start over.
3116-192 Manual Page 12 12/02/21

2.5.2. Power On Settings
NOTE: THE LAST OPERATING PARAMETERS OF A UNIT ARE RETAINED EVEN WHEN
POWER IS REMOVED. WHEN POWER IS RESTORED, THE UNIT WILL RETURN TO IT'S
PREVIOUS SETTINGS.
When power is first applied, the LCD display goes through three steps.
1. The LCD goes black to show all segments are functioning.
2. The Model and Software version will be displayed.
3116-192
Rev. 1.00
3. The present frequency and gain of the downconverter is shown.
19.2 - 20.2 GHz
G = +10.0 REF=AUTO-1
The unit is now operational and ready for any changes the operator may desire.
2.5.3 Control Switches
1. Menu/Execute - Any change to the programming of the unit must be initiated by pressing the
Menu/Execute switch and completed by pressing the Menu/Execute switch.
2. Horizontal Switch - This switch is mounted so its movement is horizontal and moves the
display cursor left or right.
3. Vertical Switch - This switch is mounted so its movement is vertical and has two functions:
a. During gain changes, the vertical movement will raise or lower the number
in the direction of the arrows.
b. For other functions such Remote on/off, the vertical switch will alternately turn the function
on or off regardless of the direction operated.
3116-192 Manual Page 13 12/02/21

2.5.4 Gain Changes
When you get to this menu note that gain changes will be made as you make them but if you do not wish to
save the changes you have made, scroll to “R” and push the menu/Execute switch and select “NO” in the
“SAVE SETTINGS?” window or do not press the Menu/Execute switch; simply do nothing for
approximately 30 seconds, and the system will return to the normal operating mode.
NOTE: THE GAIN WILL CHANGE AS YOU ADJUST THE NUMBERS. HOWEVER, THE
VALUE WILL NOT BE STORED UNTIL YOU INDICATE YES IN THE SAVE SETTINGS
WINDOW. DO NOT SET A GAIN THAT WOULD EXCEED 0 dBm OR HAVE LESS
THAN -20 dBm OUTPUT LEVEL.
Press the Up/Down switch to change the gain in 0.5, 1, or 10 dB steps and then push the
Menu/Execute switch to get to the Save Settings Menu:
GAIN = +17.5
R
When the display indicates the value desired you can push the Menu/Execute switch to the next item
OR you can scroll to “R”, push the Menu/Execute switch to get to:
SAVE SETTINGS?
YN
Selecting Ywill save the new settings. Selecting Nwill revert to the previous settings.
Figure 2.4 (page 15) gives the menu items and how to make changes.
3116-192 Manual Page 14 12/02/21

2.5.5 Alarm Indications
An alarm condition will occur if any local oscillator phase lock loop (PLL) comes out of lock.
The Remote LED will light when you select the Remote mode.
2.5.6 10 MHz Reference Mode Operation
Internal Mode: The unit uses its own built-in 10 MHz OCXO. The Internal Reference is present on the
Reference Output Connector, J8. REF = INT appears on the front panel display.
External Mode: The unit uses a 10 MHz Reference that is connected to the External Reference Input, J2.
REF = EXT appears on the front panel display. The External 10 MHz Reference level
must be +3dBm, ±3dB. If the External 10 MHz signal does not meet the unit’s
specified parameters then the unit will not function properly. The External Reference
is present on the Reference Output connector, J8.
Auto Mode: The unit defaults to the External 10 MHz Reference as long as the level meets the +3dBm,
±3dB specification. REF = AUTO - E appears on the front panel display where the -E
indicates that the unit is using the External 10 MHz Reference. The External Reference is
present on the Reference Output connector, J8.
If the external 10 MHz Reference signal level is less than -1dBm, the unit switches to
Internal 10 MHz Reference. REF = AUTO -I appears on the front panel display
where -I indicates that the unit is using the Internal 10 MHz Reference. The Internal
10 MHz Reference is present on the reference output connector, J8.
3116-192 Manual Page 15 12/02/21

NORMAL DISPLAY
PUSHING MENU/EXECUTE SEQUENCE
3116-192
1.0
19.2 - 20.2 GHZ
G = +10.0 REF AUTO-1
SCROLL <>
SCROLL PUSH BUTTON
PUSH BUTTON
Power Up 1:
Power Up 2:
Normal Display
Menu 1 Set Gain
Menu 2 Set Mute
Menu 3 Set Reference Mode
Menu 4 Set Reference Offset
Menu 5 Set Remote
Menu 6 Set Remote Interface
Menu 7 Set RS485 Address
Save? When go to end
SCROLL <>
SCROLL PUSH BUTTON
R
R
SCROLL <>
SCROLL PUSH BUTTON
R
SCROLL <>
SCROLL
PUSH BUTTON
MUTE = ON
REF MODE = AUTO
INTERNAL FREQ ADUST
OFFSET = -1225
INTERFACE = RS232
RS485 ADDRESS = 0
R
R
SAVE SETTINGS? Y N
SCROLL <>
SCROLL PUSH BUTTON
SCROLL <>
SCROLL
PUSH BUTTON
REMOTE = ON
R
SCROLL <>
SCROLL PUSH BUTTON
= = = IP Addr = = =
192.168.123.002
ON POWER UP (1)
ON POWER UP (2)
SCROLL <>
SCROLL PUSH BUTTON
R
MUTE = ON
SCROLL <>
SCROLL PUSH BUTTON
R
GAIN = 15.5
FIGURE 2.4 Menu Display and Sequences
3116-192 Manual Page 16 12/02/21

3.0 Environmental Use Information
A.Rack-Mounting - To mount this equipment in a rack, please refer to the installation instructions
located in the user manual furnished by the manufacturer of your equipment rack.
B. Mechanical Loading - Mounting of equipment in a rack should be such that a hazardous condition
does not exist due to uneven weight distribution.
C.Elevated Operating Ambient Temperature - If installed in a closed or multi-unit rack assembly,
the operating ambient temperature of the rack may be greater than room ambient temperature.
Therefore, consideration should be given to Tmra (Maximum Recommended Ambient Temperature).
D. Reduced Air Flow - Installation of the equipment in a rack should be such that the amount of air flow
required for safe operation of the equipment is not compromised. Additional space between units
may be required.
E. Circuit Overloading - Consideration should be given to the connection of the equipment to the supply
circuit and the effect that overloading of circuits could have on over current protection and supply wiring.
Appropriate consideration of equipment name plate rating should be used when addressing this concern.
F. Reliable Earthing - Reliable earthing of rack-mounted equipment should be maintained.
Particular attention should be given to supply connections other than direct connection to the
Branch (use of power strips).
G. Top Cover - There are no serviceable parts inside the product so, the Top Cover should not be removed.
If the Top Cover is removed the ground strap and associated screw MUST BE REINSTALLED
prior to Top Cover screw replacement. FAILURE TO DO this may cause INGRESS and/or EGRESS
emission problems.
3116-192 Manual Page 17 12/02/21

CROSS TECHNOLOGIES, INC.
6170 Shiloh Road
Alpharetta, Georgia 30005
[phone]
FAX [phone]
Toll Free 888-900-5588
WEB www.crosstechnologies.com
E-MAIL [email protected]
Printed in USA
3116-192 Manual Page 18 12/02/21
