Crux F Series User manual

INTERFACING SOLUTIONS
CFD-03F
F-SERIES TAILGATE
HANDLE
W/ CAMERA
FORD
2004 - UP F-Series 150/250/350
PARTS INCLUDED
(1) Black Plastic Handle
(1) 18mm Bullet Camera
(1) 19ft RCA Video Cable
(1) Instruction Sheet
SAFETY PRECAUTIONS
1. Please read through the entire instruction manual before starting any of the installation procedures.
2. Thisproduct is under Crux’s 1 year manufacturer’s warranty. Warranty may be voided in the case where
the device shows proof of being opened or improper extreme force.
TECH SERVICES
All our products are manufactured under strict quality control. Each device is being tested before shipment. If nevertheless do occur problems
if you have technical questions, contact us directly: Crux Interfacing Solutions Tech Support
1 [phone] (Mon - Fri - 9:00 AM - 5:00 PM) Pacic Time
www.cruxinterfacing.comRev. 040815 1
INSTALLATION OVERVIEW
YELLOW RCA /
VIDEO SIGNAL
F-SERIES T AILGA TE
HANDLE
CAMERA
LOCA TION
KEY CYLINDER
LOCA TION
CAMERA
INPUT
BLACK /
GROUND
RED /
TO REVERSE
BLACK BARREL /
CAM POWER
19FT
EXTENSION
SPECIFICATIONS:
CAMERA:
Sensor: CCD
Size:18mm
Viewing Angle (H): 170°
Viewing Angle (V): 90°
TV System: NTSC / PAL
Guide Lines: Yes
Invert Image: No
Resolution: 480 TV Lines
Illumination: 0.4 Lux/ F1.2
PowerSupply: 12v
Waterproof: IP67

INTERFACING SOLUTIONS
CFD-03F
F-SERIES TAILGATE
HANDLE
W/ CAMERA
www.cruxinterfacing.comRev. 040815 2
INSTALLING THE TAILGATE HANDLE
Follow these steps to properly install the Tailgate Handle.
Step 1 Remove Tailgate Cover - Start bylowering the tailgate of the truck. Remove the tailgate cover by using a T-30 torx bit,
remove (8-13 depending on the model) torx boltsthat secure the tailgate cover.
Step 2 Remove Tailgate Handle - After removing the tailgate cover you will have access to the backside of the factory tailgate handle.
Using a10mm socket, remove the (2) nuts holding the tailgate handle in place. Lift up on the latch to release the (2) tailgate handle studs and
remove the tailgate handle.
Step 3 Set Up New Handle - On the lock cylinder, remove the metal clip that holds the locking mechanism in place. Re-Install the locking
mechanism onto the new tailgate handle. Take the included camera and insert into the new tailgate handle..
Tip : Insert the Video
RCA and Power wires
through the camera h .
Step 4 Re-Install New Tailgate Handle - Re-assemble the new tailgate handle into the tailgate in reverse order.
Route the wiring to power the camera towards the bottom of the tailgate and through an access port to reach underneath the truck.
Step 5 Routing The Video and PowerCables - Route the Video and Power cables from the tailgate of the truck towards the radio
location where the rest of the installation of the camera will take place. You will need to connect the RED power wire to REVERSE and the
BLACK wire to ground.
Tip: There should be an opening between
the cabin and the bed of the truck
where you can insert the cables
into the cabin area.
.............................
F-SERIES TAILGATE
HANDLE
