RVCAD-81T
Front and Rear View Integration Interface
for AUDI TT with 4G Systems
PRODUCT FEATURES:
- Acvates Reverse camera input in Audi TT with 4G systems.
- Rear-view camera input with PDC seng.
- Front camera input with med acvaon/deacvaon seng.
- On-screen display and setup.
PARTS INCLUDED:
RCVAD-81T Module RVCAD-81T Harness LVDS Cable Programming Keypad
rev.0725191 of 6
Power/CAN POWER Harness
REARFRONT
①ACC (Yellow)
②FRONT/REAR_POWER (Red)
③CAN -HIGH (Orange)
④CAN -LOW (Green)
⑤MMI (Blue)
⑥GND (Black)
① ② ③ ④ ⑤ ⑥
CONNECTOR PIN ASSIGNMENT:

Crux Interfacing Solutions • 21541 Nordhoff St., Unit C, Chatsworth, CA 91311
phone: [phone] • fax: [phone] • www.cruxinterfacing.com
RVCAD-81T
Front and Rear View Integration Interface
for AUDI TT with 4G Systems
2 of 6 rev.072519
R
INTERFACING SOLUTIONS
Sightline
REAR-VIEW INTEGRATION
DIP SWITCH SETTINGS:
DIP# FUNCTION SETTING
1 NO FUNCTION SET TO OFF
2NO FUNCTION SET TO OFF
3NO FUNCTION SET TO OFF
4 NO FUNCTION SET TO OFF
5
AUDI TT with 12” screen
ON
6 ON
7 ON
8OFF
NOTE on DIP Switches:
DOWN is ON
WIRING DIAGRAM:
ACC (Yellow)
Rear Camera Power (Red)
Ground (Black)
To OE Monitor
Connect to GRAY Connector
(DO NOT connect to Blue or
Green Connector)
RVCAD-81T
To Rear Camera
To Front Camera

Crux Interfacing Solutions • 21541 Nordhoff St., Unit C, Chatsworth, CA 91311
phone: [phone] • fax: [phone] • www.cruxinterfacing.com
rev.072519
RVCAD-81T
Front and Rear View Integration Interface
for AUDI TT with 4G Systems
R
INTERFACING SOLUTIONS
Sightline
REAR-VIEW INTEGRATION
1. Unplug the Quadlock connector from the headunit. 2. Remove the GRAY connector insert from the Quadlock.
3. Plug the factory GRAY connector insert to the
RVCAD-81T harness
4. Plug the GRAY connector insert on the RVCAD-81T
harness to the Quadlock connector.
INSTALLATION INSTRUCTIONS:
3 of 6
ON SCREEN DISPLAY (OSD) SETTINGS:
Plug in the OSD Control Keypad to the module to adjust the sengs. Unplug and store when nished.
MENU OSD On/O
Return to previous menu
SEL Select Item
UP Move cursor Up
Increase selected value
DOWN Move cursor Down
Decrease selected value
MENU SEL UP DOWN

R
INTERFACING SOLUTIONS
Sightline
REAR-VIEW INTEGRATION
Crux Interfacing Solutions • 21541 Nordhoff St., Unit C, Chatsworth, CA 91311
phone: [phone] • fax: [phone] • www.cruxinterfacing.com
rev.072519
RVCAD-81T
Front and Rear View Integration Interface
for AUDI TT with 4G Systems
4 of 6
First Menu Second Menu Third Menu Descripon
Opon
RearCam-Type OEM OEM Camera
EXTDevice Aermarket Camera
RearCam-Power
ON Camera power connously ON
AUTO Camera power ON in reverse gear
OFF Camera Power OFF
RearCam-Det
PDC Detected by P >> buon (CAN)
GEAR Detected by Reverse Gear (CAN)
WIRE Not Used
FrontCam-Type OEM OEM Camera
ExtDevice Aermarket Camera
FrontCam-Power
ON Camera power connously ON
AUTO Camera power ON aer reverse gear
OFF Camera power OFF
FrontCam-Det CAN Detected by CAN
WIRE Not Used
RearCam-RcvOpt
ON Show front camera aer reverse process
Set me to show front camera (1 - 30 seconds)
OFF Do not show front camera
Steering Mode Not Used (set to OFF)
Reset Execute Reset to factory defaults
Front and Rear Camera Sengs:
First Menu Second Menu Descripon
Screen
Horizontal Horizontal screen movement
Vercal Verical screen movement
Scale X Up Reduce / Increase screen width
Scale X Down
Scale Y Up Reduce / Increase screen height
Scale Y Down
Reset Reset to factory defaults
Screen Posion Sengs:

R
INTERFACING SOLUTIONS
Sightline
REAR-VIEW INTEGRATION
Crux Interfacing Solutions • 21541 Nordhoff St., Unit C, Chatsworth, CA 91311
phone: [phone] • fax: [phone] • www.cruxinterfacing.com
rev.072519
RVCAD-81T
Front and Rear View Integration Interface
for AUDI TT with 4G Systems
First Menu Second Menu Third Menu Descripon
Parking
OPS Display ON Display OPS (Opcal Parking Sensors)
OFF OPS not displayed
Line Display ON Display parking guide lines
OFF Parking guide lines not displayed
Warnings Lang Set warning text language
Horizontal Move parking line horizontally
Vercal Move parking line vercally
Transparency Parking line transparency
Reset Reset to factory defaults
Park Assist System (PAS) Sengs:
Parking Line ON Parking Line OFF
5 of 6
PDC ON PDC OFF

Crux Interfacing Solutions • 21541 Nordhoff St., Unit C, Chatsworth, CA 91311
phone: [phone] • fax: [phone] • www.cruxinterfacing.com
6 of 6 rev.072519
RVCAD-81T
Front and Rear View Integration Interface
for AUDI TT with 4G Systems
Grid Type - Split Grid Type - Full
Press UP Buon
Press DOWN Buon
Press
MENU
Buon
Press
SEL
Buon
Use the OSD Control Keypad to make the
Vercal and Horizontal adjustments to
the parking guide lines. Set the screen
to show the reverse camera in order to
properly adjust the parking guide lines.
Image to the right shows which buons
to use on the keypad.
VEHICLE APPLICATIONS:
R
INTERFACING SOLUTIONS
Sightline
REAR-VIEW INTEGRATION
Audi
2016 - 2020 TT with 12” screen
